GE JVM6172RFSS Operating manual

For answers to your Monogram®or GE®appliance
questions, visit our website at geappliances.com
or call GE Answer Center®service, 800.626.2000. 340175
Specification Revised 7/13
Listed by
Underwriters
Laboratories
JVM6172SF/RF
GE® 1.7 cu. ft. Over-the-Range Microwave Oven
Note: Requires 120V grounded outlet. Electrical receptacle
must be located in cabinet above Spacemaker microwave oven.
No additional wiring, venting or cabinet rebuilding necessary
in many cases. Complete detailed, easy-to-follow installation
instructions and convenient full-size templates are packed with
the Spacemaker microwave oven.
Important Information: When installing the Spacemaker
microwave oven over a range, allow minimum of 2" from bottom
of Spacemaker microwave oven to top of range backguard to
allow for removal of light covers.
Ventilation Options: The Spacemaker microwave ovens
are designed for adaptation to the following three types of
ventilation:
• Outside exhaust (vertical – as shown)
• Outside exhaust (horizontal)
• Recirculating (non-vented ductless – see Filter Kit drawing)
Installation Information: This information is not intended to
be used for installing unit described. Before installing, consult
installation instructions packed with product/kit for current
dimensional data.
Dimensions and Installation Information (in inches)
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required Exhaust outlet
connects to
3-1/4" X 10" duct
16-1/2"
(rear)
105°
Door open
(without obstruction)
15"
22-7/8 "
15-7/8"
29-7/8"
Minimum distance from
door hinge side to
adjacent wall should
equal 1/2 inch.
13"
MAX.
12"
MIN.

For answers to your Monogram®or GE®appliance
questions, visit our website at geappliances.com
or call GE Answer Center®service, 800.626.2000. 340175
Specification Revised 7/13
Listed by
Underwriters
Laboratories
JVM6172SF/RF
GE® 1.7 cu. ft. Over-the-Range Microwave Oven
Hood Exhaust Duct: Outside ventilation requires a HOOD EXHAUST DUCT. Read the
following carefully.
Exhaust Connection: The hood exhaust has been designed to mate with a standard
3-1/4" x 10" rectangular duct. If a round duct is required, a rectangular-to-round transition
adaptor must be used. Do not use less than a 6" diameter duct
Rear Exhaust: If a rear or horizontal exhaust is to be used, care should be taken to
align exhaust with space between studs, or wall should be prepared at the time it is
constructed by leaving enough space between the wall studs to accommodate exhaust.
Maximum Duct Length: For satisfactory air movement, the total duct length of
3-1/4" x 10" rectangular or 6" diameter round duct should not exceed 120 equivalent feet.
Elbows, Transitions, Wall and Roof Caps, etc., present additional resistance to airflow
and are equivalent to a section of straight duct which is longer than their actual physical
size. When calculating the total duct length, add the equivalent length of all transitions
and adaptors plus the lengths of all straight duct sections. The chart below shows the
approximate feet of equivalent length of some typical ducts.
Duct Equivalent Feet
A. Rectangular-To-round
Transition Adaptor 5 ft.
B. Wall Cap 40 ft.
C. 90° Elbow 10 ft.
D. 45° Elbow 5 ft.
E. 90° Elbow 25 ft.
F. 45° Elbow 5 ft.
G. Roof Cap 24 ft.
Optional Accessories (Available at additional cost)
Filler Panel Kit JX48
When replacing a 36" range hood,
this kit fills in the additional width to
provide a custom built-in
appearance. For installation
between cabinets only; not
for end-of-cabinet installation.
Each kit contains two 3"-wide
filler panels.
Filter Kit JX81J–
Recirculating Charcoal
Filter Kit To be used
when the Spacemaker
microwave oven
cannot be vented to
the outside.
Dimensions and Installation Information (in inches)

340175
Specification Revised 7/13
Listed by
Underwriters
Laboratories
JVM6172SF/RF
GE® 1.7 cu. ft. Over-the-Range Microwave Oven
JVM6172SF
6:30 PM
Features and Benefits
• 1.7 cu. ft. capacity - 1000 watts (IEC-705 test procedure)
• Convenience cooking controls - Operating made quick and easy
• Auto and time defrost - Defrosting times and power levels are
programmed automatically or manually for optimal results
• Recessed turntable with on/off - Controls turntable operation
• Two-speed, 300-CFM venting system - Removes smoke, steam and odors
• Removable oven rack - Allows you to cook large quantities of your family’s
favorites
• Model JVM6172SFSS - Stainless steel
• Model JVM6172RFSS - Stainless steel/black
