GE JVM7195SKSS Manual

JVM7195SK/EK/BL/FL
GE®1.9 cu. ft. Over-the-Range Sensor Microwave Oven
Specification Revised 2/20
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
For answers to your Monogram, GE Café™Series, GE Profile™Series or
GE Appliances product questions, visit our website at geappliances.com
or call GE Answer Center®Service, 800.626.2000.
98°
Door open
(without obstruction)
23-9/16"
29-7/8"
16-5/16"
(rear)
15-9/16"
15-11/16"
13"
MAX.
12"
MIN.*
66" MIN.
Mounting
height from
floor
Minimum distance from
door hinge side to
adjacent wall should
equal 1/2"
30" MIN.
width
required Exhaust outlet
connects to
3-1/4"x10" duct
*Maximum depth
with JX15
Bump Out Kit is 16"
Bump Out Kit
sold separately.
NOTE: Requires 120V grounded outlet. Electrical receptacle
must be located in cabinet above microwave oven. No
additional wiring, venting or cabinet rebuilding necessary
in many cases. Complete detailed, easy-to-follow installation
instructions and convenient full-size templates are packed
with the microwave oven.
IMPORTANT INFORMATION: When installing the
microwave oven over a range, allow minimum of 2" from
bottom of microwave oven to top of range backguard to
allow for removal of light covers.
VENTILATION OPTIONS: The microwave ovens
are designed for adaptation to the following three
types of ventilation:
-Outside exhaust (vertical – as shown)
-Outside exhaust (horizontal)
-Recirculating (non-vented ductless – see Filter Kit drawing)
INSTALLATION INFORMATION: This information is
not intended to be used for installing unit described. Before
installing, consult installation instructions packed with
product/kit for current dimensional data.

JVM7195SK/EK/BL/FL
GE®1.9 cu. ft. Over-the-Range Sensor Microwave Oven
Specification Revised 2/20
Filler Panel Kit
JX36BBB/BWW/BSS/BES/BTS/BDS
When replacing a 36" range hood,
this kit fills in the additional width to
provide a custom built-in
appearance. For installation
between cabinets only; not
for end-of-cabinet installation.
Each kit contains two 3"-wide
filler panels.
Filter Kit
WB06X10807
Recirculating
Charcoal Filter Kit
To be used when
the microwave oven
cannot be vented to
the outside.
HOOD EXHAUST DUCT: Outside ventilation requires a HOOD
EXHAUST DUCT. Read the following carefully.
EXHAUST CONNECTION: The hood exhaust has been designed to mate
with a standard 3-1/4" x 10" rectangular duct. If a round duct is required, a
rectangular-to-round transition adaptor must be used. Do not use less than a
6" diameter duct
REAR EXHAUST: If a rear or horizontal exhaust is to be used, care should be
taken to align exhaust with space between studs, or wall should be prepared
at the time it is constructed by leaving enough space between the wall studs to
accommodate exhaust.
MAXIMUM DUCT LENGTH: For satisfactory air movement, the total duct
length of 3-1/4" x 10" rectangular or 6" diameter round duct should not exceed
140 equivalent feet.
ELBOWS, TRANSITIONS, WALL AND ROOF CAPS, etc., present
additional resistance to airflow and are equivalent to a section of straight
duct which is longer than their actual physical size. When calculating the total
duct length, add the equivalent length of all transitions and adaptors plus the
lengths of all straight duct sections. The chart below shows the approximate
feet of equivalent length of some typical ducts.
DUCT EQUIVALENT FEET
A. Rectangular-To-round
Transition Adaptor 5 ft.
B. Wall Cap 40 ft.
C. 90° Elbow 10 ft.
D. 45° Elbow 5 ft.
E. 90° Elbow 25 ft.
F. 45° Elbow 5 ft.
G. Roof Cap 24 ft.
OPTIONAL ACCESSORIES (AVAILABLE AT ADDITIONAL COST)
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)

JVM7195SK/EK/BL/FL
GE®1.9 cu. ft. Over-the-Range Sensor Microwave Oven
Specification Revised 2/20
Defrost
Weight/Time
Popcorn Beverage Potato
Melt Reheat
Steam
Clean
Turntable
Cook
Time
Timer
Power
Level
Display Set
Clock
Reset
Filter
Settings
Mute
Vent Fan
Surface
Light
Sensor Microwave
Microwave Features
Express Cook
Start
Pause
Cancel Add
30 Sec
12345
6 7 8 9 0
Hold 3 Sec
Hold 3 Sec
Lock Control
Hold 3 Sec
6:30 PM
JVM7195SK_EK
FEATURES AND BENEFITS
1.9 cu. ft. capacity – 1000 Watts (IEC-705 test procedure)
Easy clean interior – Makes cleaning spills and splatters a snap
Melt feature – Worry-free melting of butter, caramel, chocolate
and cheese
Easy clean with steam clean – Messes inside the microwave are
easy to wipe away after steam loosens food grime
Weight and time defrost – Simply enter the weight of the food,
and the oven automatically sets the optimal defrosting time and
power level or set your desired time for defrosting
Upfront charcoal filter with indicator light – Light indicates
when odor-removing charcoal filter needs to be replaced
Four-speed with boost, 400-CFM venting fan system – Quickly
removes smoke, steam and odors from the cooktop to keep
kitchen air fresh and clean
Turntable with on/off – Controls turntable operation
Sensor cooking controls – Automatically adjusts time and power
for delicious cooking results
Model JVM7195SKSS – Stainless steel
Model JVM7195EKES – Slate
Model JVM7195BLTS – Black Stainless
Model JVM7195FLDS – Black slate
