GE KOR-220S User manual

Microwave Oven
KOR-220S
Owner’s Manual
Safety Information . . . . . . . . .2–6
Operating Instructions
Auto Features . . . . . . . . . . . . . .12
Microwave Terms . . . . . . . . . . . .18
Other Features . . . . . . . . . . .16–18
Oven Features . . . . . . . . . . . . .7, 8
Power Levels . . . . . . . . . . . . . . . .9
Sensor Features . . . . . . . . . .13–15
Time Features . . . . . . . . . . . .9–12
Care and Cleaning . . . . . . . . .19
Troubleshooting Tips . . . . . . .20
Things That Are Normal . . . . . .20
Consumer Support
Consumer Support . . .Back Cover
Product Registration . . . . . .21, 22
Warranty . . . . . . . . . . . . . . . . . .23
164D3370P238 49-40298-1 09-02 JR
www.GEAppliances.com
Write the model and serial
numbers here:
Model # __________________
Serial # __________________
You can find them on a label
inside the oven.

Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
IMPORTANT SAFETY INSTRUCTIONS.
READ ALL INSTRUCTIONS BEFORE USING.
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or
to prevent property damage, personal injury, or loss of life.
IMPORTANT SAFETY INSTRUCTIONS.
This microwave oven is not approved or tested for marine use.
Use this appliance only for its intended purpose as described in this Owner’s Manual.
■Read and follow the specific precautions in the
Precautions to Avoid Possible Exposure to Excessive
Microwave Energy section above.
■This appliance must be grounded. Connect only
to a properly grounded outlet. See the Grounding
Instructions section on page 4.
■Install or locate this appliance only in accordance with
the provided installation instructions.
■Be certain to place the front surface of the door three
inches or more back from the countertop edge to avoid
accidental tipping of the appliance in normal usage.
■Do not mount this appliance over a sink.
■Do not mount the microwave oven over or near any
portion of a heating or cooking appliance.
■Do not store anything directly on top of the microwave
oven surface when the microwave oven is in operation.
■Do not operate this appliance if it has a damaged power
cord or plug, if it is not working properly, or if it has
been damaged or dropped. If the power cord is
damaged, it must be replaced by General Electric Service
or an authorized service agent using a power cord
available from General Electric.
■Do not cover or block any openings on the appliance.
■Use this appliance only for its intended use as described
in this manual. Do not use corrosive chemicals or vapors
in this appliance. This microwave oven is specifically
designed to heat, dry or cook food, and is not intended
for laboratory or industrial use.
■Do not store this appliance outdoors. Do not use this
product near water—for example, in a wet basement,
near a swimming pool or near a sink.
■Keep power cord away from heated surfaces.
■Do not immerse power cord or plug in water.
■Do not let power cord hang over edge of table
or counter.
■To reduce the risk of fire in the oven cavity:
– Do not overcook food. Carefully attend appliance
if paper, plastic or other combustible materials are
placed inside the oven while cooking.
– Remove wire twist-ties and metal handles from paper or
plastic containers before placing them in the oven.
– Do not use the oven for storage purposes. Do not leave
paper products, cooking utensils or food in the oven
when not in use.
– If materials inside the oven should ignite, keep the oven
door closed, turn the oven off and disconnect the power
cord, or shut off power at the fuse or circuit breaker
panel. If the door is opened, the fire may spread.
■See door surface cleaning instructions in the
Care and cleaning of the microwave oven section
of this manual.
■This appliance should be serviced only by qualified
service personnel. Contact nearest authorized service
facility for examination, repair or adjustment.
■As with any appliance, close supervision is necessary
when used by children.
SAVE THESE INSTRUCTIONS
(a) Do Not Attempt to operate this oven with the door
open since open-door operation can result in harmful
exposure to microwave energy. It is important not to
defeat or tamper with the safety interlocks.
( b) Do Not Place any object between the oven front face
and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) Do Not Operate the oven if it is damaged. It is
particularly important that the oven door close
properly and that there is no damage to the:
(1) door (bent),
(2) hinges and latches (broken or loosened),
(3) door seals and sealing surfaces.
(d) The Oven Should Not be adjusted or repaired by
anyone except properly qualified service personnel.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
2
WARNING!

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
www.GEAppliances.com
ARCING
If you see arcing, press the CLEAR/OFF pad and correct the problem.
Arcing is the microwave term for sparks in the oven.
Arcing is caused by:
■Metal or foil touching the side of the oven.
■Foil not molded to food (upturned edges act like
antennas).
■Metal, such as twist-ties, poultry pins or gold-
rimmed dishes, in the microwave.
■Recycled paper towels containing small metal
pieces being used in the microwave.
FOODS
■Do not pop popcorn in your microwave oven
unless in a special microwave popcorn accessory
or unless you use popcorn labeled for use in
microwave ovens.
■Some products such as whole eggs and sealed
containers—for example, closed jars—will
explode and should not be heated in this
microwave oven. Such use of the microwave oven
could result in injury.
■Do not boil eggs in a microwave oven. Pressure
will build up inside egg yolk and will cause it to
burst, possibly resulting in injury.
■Operating the microwave with no food inside for
more than a minute or two may cause damage to
the oven and could start a fire. It increases the
heat around the magnetron and can shorten the
life of the oven.
■Foods with unbroken outer “skin” such as
potatoes, hot dogs, sausages, tomatoes, apples,
chicken livers and other giblets, and egg yolks
should be pierced to allow steam to escape during
cooking.
■SUPERHEATED WATER
Microwaved water and other liquids do not always
bubble when they reach the boiling point. They can
actually get superheated and not bubble at all.
Superheated liquid will bubble up out of the cup when
it is moved or when something like a spoon or tea bag
is put into it.
To prevent this from happening and causing injury, do
not heat any liquid for more than 2 minutes per cup.
After heating, let the cup stand in the microwave for
30 seconds before moving it or putting anything into it.
■Avoid heating baby food in glass jars, even with
the lid off. Make sure all infant food is thoroughly
cooked. Stir food to distribute the heat evenly.
Be careful to prevent scalding when warming
formula. The container may feel cooler than the
formula really is. Always test the formula before
feeding the baby.
■Don’t defrost frozen beverages in narrow-necked
bottles (especially carbonated beverages). Even if
the container is opened, pressure can build up.
This can cause the container to burst, possibly
resulting in injury.
■Spontaneous boiling—Under certain special
circumstances, liquids may start to boil during or
shortly after removal from the microwave oven.
To prevent burns from splashing liquid, we
recommend the following: before removing the
container from the oven, allow the container to
stand in the oven for 30 to 40 seconds after the
oven has shut off. Do not boil liquids in narrow-
necked containers such as soft drink bottles, wine
flasks, and especially narrow-necked coffee cups.
Even if the container is opened, excessive steam
can build up and cause it to burst or overflow.
■Hot foods and steam can cause burns. Be careful
when opening any containers of hot food,
including popcorn bags, cooking pouches and
boxes. To prevent possible injury, direct steam
away from hands and face.
■Do not overcook potatoes. They could dehydrate
and catch fire, causing damage to your oven.
■Cook meat and poultry thoroughly—meat to at
least an INTERNAL temperature of 160°F and
poultry to at least an INTERNAL temperature of
180°F. Cooking to these temperatures usually
protects against foodborne illness.
WARNING!
3

4
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
MICROWAVE-SAFE COOKWARE
Make sure all cookware used in your microwave
oven is suitable for microwaving. Most glass
casseroles, cooking dishes, measuring cups, custard
cups, pottery or china dinnerware which does not
have metallic trim or glaze with a metallic sheen can
be used. Some cookware is labeled “suitable for
microwaving.”
■If you are not sure if a dish is microwave-safe,
use this test: Place in the oven both the dish
you are testing and a glass measuring cup filled
with 1 cup of water—set the measuring cup either
in or next to the dish. Microwave 30–45 seconds
at high. If the dish heats, it should not be used
for microwaving.
If the dish remains cool and only the water in
the cup heats, then the dish is microwave-safe.
■If you use a meat thermometer while cooking,
make sure it is safe for use in microwave ovens.
■Do not use recycled paper products. Recycled
paper towels, napkins and waxed paper can
contain metal flecks which may cause arcing
or ignite. Paper products containing nylon or
nylon filaments should be avoided, as they may
also ignite.
■Some styrofoam trays (like those that meat is
packaged on) have a thin strip of metal
embedded in the bottom. When microwaved,
the metal can burn the floor of the oven or ignite
a paper towel.
■Do not use the microwave to dry newspapers.
■
Not all plastic wrap is suitable for use in
microwave ovens. Check the package for
proper use.
■Paper towels, waxed paper and plastic wrap
can be used to cover dishes in order to retain
moisture and prevent spattering. Be sure to
vent plastic wrap so steam can escape.
■Cookware may become hot because of heat
transferred from the heated food. Pot holders
may be needed to handle the cookware.
■“Boilable” cooking pouches and tightly closed
plastic bags should be slit, pierced or vented as
directed by package. If they are not, plastic could
burst during or immediately after cooking,
possibly resulting in injury. Also, plastic storage
containers should be at least partially uncovered
because they form a tight seal. When cooking
with containers tightly covered with plastic wrap,
remove covering carefully and direct steam away
from hands and face.
■Use foil only as directed in this guide. TV dinners
may be microwaved in foil trays less than 3/4″
high; remove the top foil cover and return the
tray to the box. When using foil in the microwave
oven, keep the foil at least 1 inch away from the
sides of the oven.
■Plastic cookware—Plastic cookware designed for
microwave cooking is very useful, but should be
used carefully. Even microwave-safe plastic may
not be as tolerant of overcooking conditions as
are glass or ceramic materials, and may soften or
char if subjected to short periods of overcooking.
In longer exposures to overcooking, the food
and cookware could ignite.
Follow these guidelines:
Use microwave-safe plastics only and use
them in strict compliance with the cookware
manufacturer’s recommendations.
Do not microwave empty containers.
Do not permit children to use plastic
cookware without complete supervision.
3
2
1
WARNING!

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
www.GEAppliances.com
ADAPTER PLUGS
Usage situations where appliance’s power cord will be disconnected infrequently.
Because of potential safety hazards under certain conditions,
we strongly recommend against the use of an adapter plug. However, if
you still elect to use an adapter, where local codes permit, a TEMPORARY
CONNECTION may be made to a properly grounded two-prong wall
receptacle by the use of a UL listed adapter which is available at most
local hardware stores.
The larger slot in the adapter must be aligned with the larger slot in
the wall receptacle to provide proper polarity in the connection of the
power cord.
CAUTION: Attaching the adapter ground terminal to the wall receptacle cover screw does not ground
the appliance unless the cover screw is metal, and not insulated, and the wall receptacle is grounded
through the house wiring.
You should have the circuit checked by a qualified electrician to make sure the receptacle is properly
grounded.
When disconnecting the power cord from the adapter, always hold the adapter with one hand. If this
is not done, the adapter ground terminal is very likely to break with repeated use. Should this happen,
DO NOT USE the appliance until a proper ground has again been established.
Usage situations where appliance’s power cord will be disconnected frequently.
Do not use an adapter plug in these situations because frequent disconnection of the power cord places
undue strain on the adapter and leads to eventual failure of the adapter ground terminal. You should have
the two-prong wall receptacle replaced with a three-prong (grounding) receptacle by a qualified electrician
before using the appliance.
Ensure proper ground
and firm connection
before use.
TEMPORARY
METHOD
Align large
prongs/slots
(Adapter plugs not
permitted in Canada)
5
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of
an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire
for the electric current.
This appliance is equipped with a power cord
having a grounding wire with a grounding plug.
The plug must be plugged into an outlet that is
properly installed and grounded.
Consult a qualified electrician or service technician
if the grounding instructions are not completely
understood, or if doubt exists as to whether the
appliance is properly grounded.
If the outlet is a standard 2-prong wall outlet,
it is your personal responsibility and obligation
to have it replaced with a properly grounded
3-prong wall outlet.
Do not under any circumstances cut or remove
the third (ground) prong from the power cord.
We do not recommend using an extension cord
with this appliance. If the power cord is too short,
have a qualified electrician or service technician
install an outlet near the appliance. (See
EXTENSION CORDS section.)
For best operation, plug this appliance into its
own electrical outlet to prevent flickering of lights,
blowing of fuse or tripping of circuit breaker.
WARNING—Improper use of the grounding plug can result in a risk of electric shock.

6
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
EXTENSION CORDS
A short power supply cord is provided to reduce the risks resulting from becoming entangled in or tripping
over a longer cord.
Extension cords may be used if you are careful in using them.
If an extension cord is used—
The marked electrical rating of the extension cord should be at least as great as the electrical rating of
the appliance;
The extension cord must be a grounding-type 3-wire cord and it must be plugged into a 3-slot outlet;
The extension cord should be arranged so that it will not drape over the countertop or tabletop
where it can be pulled on by children or tripped over unintentionally.
If you use an extension cord, the interior light may flicker and the blower sound may vary when the
microwave oven is on. Cooking times may be longer, too.
3
2
1
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS

7
About the features of your microwave oven. www.GEAppliances.com
Consumer SupportTroubleshooting Tips
Operating InstructionsSafety Instructions
Throughout this manual, features and appearance may vary from your model.
1200 Watts
Features of the Oven
Door Latches.
Window with Metal Shield. Screen allows
cooking to be viewed while keeping
microwaves confined in the oven.
Convenience Guide.
Touch Control Panel Display.
Door Latch Release. Press latch release to
open door.
Removable Turntable. Turntable and support
must be in place when using the oven. The
turntable may be removed for cleaning.
Removable Turntable Support. The turntable
support must be in place when using
the oven.
NOTE: Rating plate, oven vent(s) and oven light are located
on the inside walls of the microwave oven.
Optional Accessories
Available at extra cost from your GE supplier.
Choose the appropriate Installation Kit below
to convert this oven to a built-in wall oven.
For 27″installations:
Model Kit
JE2160BF JX2127BF
JE2160CF JX2127CF
JE2160SF JX2127SF
JE2160WF JX2127WF
For 30″installations:
Model Kit
JE2160BF JX2130BF
JE2160CF JX2130CF
JE2160SF JX2130SF
JE2160WF JX2130WF

You can microwave by time, with the sensor features or with the auto feature.
8
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
About the features of your microwave oven.
Cooking Controls
Time Features
Press Enter
TIME COOK Amount of cooking time
Press once or twice
TIME DEFROST Amount of defrosting time
EXPRESS COOK Starts immediately!
POWER LEVEL Power level 1–10
ADD 30 SEC Starts immediately!
Sensor Features and Auto Features
Press Enter Options
POPCORN Starts immediately! more/less time
VEGETABLE Starts immediately! more/less time
Press once (fresh vegetables)
Press twice (frozen vegetables)
Press three times (canned vegetables)
REHEAT Starts immediately! more/less time
BEVERAGE Starts immediately!
POTATO Starts immediately! more/less time
CHICKEN/FISH Starts immediately! more/less time
Press once (chicken pieces)
Press twice (fish)
Press Enter
AUTO DEFROST Food weight
Check the Convenience Guide before you begin.

Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
About changing the power level. www.GEAppliances.com
The power level may be entered or
changed immediately after entering the
time for Time Cook or Express Cook.
Press TIME COOK.
Enter cooking time.
Press POWER LEVEL.
Select desired power level 1–10.
Press START.
Variable power levels add flexibility to
microwave cooking. The power levels on
the microwave oven can be compared to
the surface units on a range. Each power
level gives you microwave energy a certain
percent of the time. Power level 7 is
microwave energy 70% of the time. Power
level 3 is energy 30% of the time. Most
cooking will be done on High (power level
10) which gives you 100% power. A high
setting (10) will cook faster but food may
need more frequent stirring, rotating or
turning over. A lower setting will cook more
evenly and need less stirring or rotating of
the food. Some foods may have better flavor,
texture or appearance if one of the lower
settings is used. Use a lower power level
when cooking foods that have a tendency
to boil over, such as scalloped potatoes.
Rest periods (when the microwave energy
cycles off) give time for the food to
“equalize” or transfer heat to the inside
of the food. An example of this is shown
with power level 3—the defrost cycle. If
microwave energy did not cycle off, the
outside of the food would cook before
the inside was defrosted.
Here are some examples of uses for various
power levels:
High 10: Fish, bacon, vegetables, boiling
liquids.
Med-High 7: Gentle cooking of meat and
poultry; baking casseroles and reheating.
Medium 5: Slow cooking and tenderizing
for stews and less tender cuts of meat.
Low 2 or 3: Defrosting; simmering; delicate
sauces.
Warm 1: Keeping food warm; softening
butter.
5
4
3
2
1
About the time features.
Time Cook
Allows you to microwave for any time up
to 99 minutes and 99 seconds.
Power level 10 (High) is automatically set,
but you may change it for more flexibility.
Time Cook II
Press TIME COOK.
Enter cooking time.
Change the power level if you don’t
want full power. (Press POWER LEVEL.
Select a desired power level 1–10.)
Press START.
You may open the door during Time Cook
to check the food. Close the door and press
START to resume cooking.
Time Cook II
Lets you change power levels automatically
during cooking. Here’s how to do it:
Press TIME COOK.
Enter the first cook time.
Change the power level if you don’t
want full power. (Press POWER LEVEL.
Select a desired power level 1–10.)
Press TIME COOK again.
Enter the second cook time.
Change the power level if you don’t
want full power. (Press POWER LEVEL.
Select a desired power level 1–10.)
Press START.
At the end of Time Cook I, Time Cook II
counts down.
7
6
5
4
3
2
1
4
3
2
1
9

Vegetable Amount Time Comments
Asparagus
(fresh spears) 1 lb. 5 to 8 min., In 1
1
⁄ 2 -qt. casserole, place 1/4 cup water.
Med-High (7)
(frozen spears) 10-oz. package 4 to 7 min. In 1-qt. casserole.
Beans
(fresh green) 1 lb. cut in half 10 to 14 min. In 1
1
⁄ 2 -qt. casserole, place 1/2 cup water.
(frozen green) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 2 tablespoons water.
(frozen lima) 10-oz. package 4 to 8 min. In 1-qt. casserole, place 1/4 cup water.
Beets
(fresh, whole) 1 bunch 16 to 21 min. In 2-qt. casserole, place 1/2 cup water.
Broccoli
(fresh cut) 1 bunch (1
1
⁄ 4 to 1
1
⁄ 2 lbs.) 5 to 9 min. In 2-qt. casserole, place 1/2 cup water.
(fresh spears) 1 bunch (1
1
⁄ 4 to 1
1
⁄ 2 lbs.) 7 to 10 min. In 2-qt. casserole, place 1/4 cup water.
(
frozen,
chopped) 10-oz. package 4 to 7 min. In 1-qt. casserole.
(frozen spears) 10-oz. package 4 to 7 min. In 1-qt. casserole, place 3 tablespoons water.
Cabbage
(fresh) 1 medium head (about 2 lbs.) 6 to 9 min. In 1
1
⁄ 2 - or 2-qt. casserole, place 1/4 cup water.
(wedges) 5 to 9 min. In 2- or 3-qt. casserole, place 1/4 cup water.
Carrots
(fresh, sliced) 1 lb. 4 to 8 min. In 1
1
⁄ 2 -qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 3 to 7 min. In 1-qt. casserole, place 2 tablespoons water.
Cauliflower
(flowerets) 1 medium head 7 to 10 min. In 2-qt. casserole, place 1/2 cup water.
(fresh, whole) 1 medium head 7 to 14 min. In 2-qt. casserole, place 1/2 cup water.
(frozen) 10-oz. package 3 to 7 min. In 1-qt. casserole, place 2 tablespoons water.
Corn
(frozen kernel) 10-oz. package 2 to 6 min. In 1-qt. casserole, place 2 tablespoons water.
Corn on the cob
(fresh) 1 to 5 ears 11
/4to 4 min. In 2-qt. glass baking dish, place corn. If corn is in
per ear husk, use no water; if corn has been husked, add
1/4 cup water. Rearrange after half of time.
(frozen) 1 ear 3 to 6 min. Place in 2-qt. oblong glass baking dish.
2 to 6 ears 2 to 3 min. Cover with vented plastic wrap. Rearrange after
per ear half of time.
Mixed vegetables
(frozen) 10-oz. package 2 to 6 min. In 1-qt. casserole, place 3 tablespoons water.
Peas
(fresh, shelled) 2 lbs. unshelled 7 to 9 min. In 1-qt. casserole, place 1/4 cup water.
(frozen) 10-oz. package 2 to 6 min. In 1-qt. casserole, place 2 tablespoons water.
Potatoes
(fresh, cubed, white) 4 potatoes (6 to 8 oz. each) 9 to 11 min. Peel and cut into 1-inch cubes. Place in 2-qt.
casserole with 1/2 cup water. Stir after half of
time.
(fresh, whole, sweet 1 (6 to 8 oz.) 2 to 4 min. Pierce with cooking fork. Place in the oven, 1″
or white) apart, in circular arrangement. Let stand 5 minutes.
Spinach
(fresh) 10 to 16 oz. 3 to 6 min. In 2-qt. casserole, place washed spinach.
(frozen, chopped and leaf) 10-oz. package 3 to 6 min. In 1-qt. casserole, place 3 tablespoons water.
Squash
(fresh, summer, and yellow) 1 lb. sliced 3 to 5 min. In 11⁄2-qt. casserole, place 1/4 cup water.
(winter, acorn or butternut) 1 to 2 squash (about 1 lb. each) 5 to 9 min. Cut in half and remove fibrous membranes. In
2-qt. glass baking dish, place squash cut-side-down.
Turn cut-side-up after 4 minutes.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
About the time features.
10
Cooking Guide for Time Cook
NOTE: Use High power level (10) unless otherwise noted.
