GE Profile Spacemaker PNM1871SMSS User instructions

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Listed by
Underwriters
Laboratories
240267
Specification Created 7/07
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required Exhaust outlet
connects to
3-1/4" X 10" duct
16-29/32
(rear)
105°
Door open
15-29/32
24-1/2
16-9/16
29-7/8
Dimensions (in inches)
Over-the-Range Microwave Oven
Minimum distance from
door hinge side to adjacent
wall should equal 1/2-inch.
(without
obstruction)
13"
MAX.
12"
MIN.
Note: Requires 120V grounded outlet. Electrical receptacle must be
located in cabinet above Spacemaker microwave oven. No additional
wiring, venting or cabinet rebuilding necessary in many cases. Complete
detailed, easy-to-follow installation instructions and convenient full-size
templates are packed with the Spacemaker microwave oven.
Important Information: When installing the Spacemaker microwave
oven over a range, allow minimum of 2” from bottom of Spacemaker
microwave oven to top of range backguard to allow for removal
of light covers.
Installation Information: This information is not intended to be used for
installing unit described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
PNM1871SM
GE Profile™Spacemaker®1.8 Cu. Ft. XL1800 Over-the-Range Microwave Oven with
Recirculating Venting
Dimensions and Installation Information (in inches)

Specification Created 7/07 240267
Features and Benefits
• 1.8 Cu. Ft. Capacity - 1100 Watts (IEC-705 test procedure)
• Circuwave™1100 Cooking System - Patented system provides more
power for faster more even cooking results
• Sensor Cooking Control - Provides a built-in sensor in the upper
microwave that automatically calculates and adjusts cooking times
and power levels for favorite foods
• 1-lb. Quick Defrost - Evenly defrosts a pound meat, poultry or fish in
a fraction of the usual time, without precooking or turning the food
• Full-Width Active Hidden Vent - Out of sight when not in use, the
oven vent hides behind the sleek top panel for a sophisticated,
easy-to-clean look
• 14-1/4" Recessed Turntable - Large enough to handle 5-qt.
casserole dishes and can easily be removed for cleaning
• Four-Speed, 300-CFM Venting System with Boost - with
recirculating exhaust fan - Quickly moves smoke and steam from
the cooktop
• Two Removable Oven Racks - Make room for up to six plates or
three 9" x 13" casserole dishes
• Model PNM1871SMSS – Stainless steel
PVM1870SM
PNM1871SM
