GE Spacemaker JVM1665DN Manual

Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
JVM1665DN
GE Spacemaker®Grilling Over-the-Range Microwave Oven
Listed by
Underwriters
Laboratories
340125
Specification Created 7/08
Note: Requires 120V grounded outlet. Electrical receptacle must be
located in cabinet above Spacemaker microwave oven. No additional
wiring, venting or cabinet rebuilding necessary in many cases. Complete
detailed, easy-to-follow installation instructions and convenient full-size
templates are packed with the Spacemaker microwave oven.
Important Information: When installing the Spacemaker microwave
oven over a range, allow minimum of 2” from bottom of Spacemaker
microwave oven to top of range backguard to allow for removal
of light covers.
Ventilation Options: The Spacemaker microwave ovens and
Spacemaker convection/microwave ovens are designed for
adaptation to the following three types of ventilation:
• Outside exhaust (Vertical – as shown)
• Outside exhaust (horizontal)
• Recirculating (non-vented ductless – see Filter Kit drawing)
Installation Information: This information is not intended to be used for
installing unit described. Before installing, consult installation instructions
packed with product/kit for current dimensional data.
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required Exhaust outlet
connects to
3-1/4" X 10" duct
16-13/32
(rear)
105°
Door open
15-3/8
24-1/2
16
29-7/8
Minimum distance from
door hinge side to adjacent
wall should equal 1/2-inch.
(without
obstruction)
13"
MAX.
12"
MIN.
Dimensions (in inches)
Over-the-Range Microwave Oven

Listed by
Underwriters
Laboratories
JVM1665DN
GE Spacemaker®Grilling Over-the-Range Microwave Oven
340125
Specification Created 7/08
Hood Exhaust Duct: Outside ventilation requires a HOOD EXHAUST DUCT. Read the
following carefully.
Exhaust Connection: The hood exhaust has been designed to mate with a standard
3-1/4" x 1" rectangular duct. If a round duct is required, a rectangular-to-round
transition adaptor must be used. Do not use less than a 6" diameter duct.
Rear Exhaust: If a rear or horizontal exhaust is to be used, care should be taken to
align exhaust with space between studs, or wall should be prepared at the time it
is constructed by leaving enough space between the wall studs to accommodate
exhaust.
Maximum Duct Length: For satisfactory air movement, the total duct length of 3-1/4"
x 10" rectangular or 6" diameter round duct should not exceed 140 equivalent feet.
ELBOWS, TRANSITIONS, WALL AND ROOF CAPS: etc., present additional resistance to
airflow and are equivalent to a section of straight duct which is longer than their
actual physical size. When calculating the total duct length, add the equivalent length
of all transitions and adaptors plus the lengths of all straight duct sections. The chart
below shows the approximate feet of equivalent length of some typical ducts.
Duct Equivalent Feet
A. Rectangular-To-round
Transition Adaptor 5 ft.
B. Wall Cap 40 ft.
C. 90° Elbow 10 ft.
D. 45° Elbow 5 ft.
E. 90° Elbow 25 ft.
F. 45° Elbow 5 ft.
G. Roof Cap 24 ft.
Optional accesories
(Available at additional cost)
Filler Panel Kits
JX52BL–Black
JX52WH–White
When replacing a 36"
range hood, this kit fills in
the additional width to
provide a custom built-in
appearance. For installation
between cabinets only;
not for end-of-cabinet
installation. Each kit contains
two 3"-wide filler panels.
Filter Kits
JX81D–Recirculating
Charcoal Filter Kit
To be used when
the Spacemaker
microwave oven
cannot be vented
to the outside.

JVM1665DN
GE Spacemaker®Grilling Over-the-Range Microwave Oven
Specification Created 7/08 340125
Features and Benefits
• 1.6 cu ft Oven Capacity / 1000 Watts
• 1,200 Watt Grilling Power
• Sensor Cooking Controls
• Pre-Programmed Grill Menus
• Easy-Set Control Dial
• Two-Line Scrolling Display
• Brick-Oven Red Interior
• Model JVM1665DNBB – Black
• Model JVM1665DNWW – White
• Model JVM1665SNSS – Stainless steel
JVM1665DN
Light
Clear
Auto
Grill Manual Grill Combo Grill
Popcorn PotatoBeverage Auto
Cook
Time
Cook Soften Melt Power Level
Defrost
Add 30
Seconds
Turn
Table Help Options
Vent Light Timer Clock
Off
Start
Pause
