JVM1740DPWW/CC/BB
GE Spacemaker® Over-the-Range Microwave Oven
Dimensions and Installation Information (in inches)
Note: Requires 120V grounded outlet. Electrical receptacle
must be located in cabinet above Spacemaker microwave oven.
No additional wiring, venting or cabinet rebuilding necessary
in many cases. Complete detailed, easy-to-follow installation
instructions and convenient full-size templates are packed with
the Spacemaker microwave oven.
Important Information: When installing the Spacemaker
microwave oven over a range, allow minimum of 2" from bottom
of Spacemaker microwave oven to top of range backguard to
allow for removal of light covers.
Ventilation Options: The Spacemaker microwave ovens
are designed for adaptation to the following three types of
ventilation:
• Outside exhaust (vertical – as shown)
• Outside exhaust (horizontal)
• Recirculating (non-vented ductless – see Filter Kit drawing)
Installation Information: This information is not intended to
be used for installing unit described. Before installing, consult
installation instructions packed with product/kit for current
dimensional data.
Dimensions and Installation Information (in inches)
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required Exhaust outlet
connects to
3-1/4" X 10" duct
16-7/16
(rear)
105°
Door open
15-1/4
24-1/2
16-1/2
29-7/8
Minimum distance from
door hinge side to adjacent
wall should equal 1/2-inch.
(without
obstruction)
13"
MAX.
12"
MIN.
Dimensions (in inches)
Over-the-Range Microwave Oven

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
340147
Specification Created 4/09
Listed by
Underwriters
Laboratories
JVM1740DPWW/CC/BB
GE Spacemaker® Over-the-Range Microwave Oven
Dimensions and Installation Information (in inches)
Hood Exhaust Duct: Outside ventilation requires a HOOD EXHAUST DUCT. Read the
following carefully.
Exhaust Connection: The hood exhaust has been designed to mate with a standard
3-1/4" x 10" rectangular duct. If a round duct is required, a rectangular-to-round transition
adaptor must be used. Do not use less than a 6" diameter duct
Rear Exhaust: If a rear or horizontal exhaust is to be used, care should be taken to
align exhaust with space between studs, or wall should be prepared at the time it is
constructed by leaving enough space between the wall studs to accommodate exhaust.
Maximum Duct Length: For satisfactory air movement, the total duct length of
3-1/4" x 10" rectangular or 6" diameter round duct should not exceed 120 equivalent feet.
Elbows, Transitions, Wall and Roof Caps, etc., present additional resistance to airflow
and are equivalent to a section of straight duct which is longer than their actual physical
size. When calculating the total duct length, add the equivalent length of all transitions
and adaptors plus the lengths of all straight duct sections. The chart below shows the
approximate feet of equivalent length of some typical ducts.
Duct Equivalent Feet
A. Rectangular-To-round 5 ft.
Transition Adaptor
B. Wall Cap 40 ft.
C. 90° Elbow 10 ft.
D. 45° Elbow 5 ft.
E. 90° Elbow 25 ft.
F. 45° Elbow 5 ft.
G. Roof Cap 24 ft.
Optional Accessories (Available at additional cost)
Filler Panel Kits
JX48BL–Black
JX48WH–White
When replacing a 36" or
42" range hood, this kit fills
in the additional width to
provide a custom built-in
appearance. For installation
between cabinets only; not
for end-of-cabinet installation.
Each kit contains two 3"-wide
filler panels.
Filter KitsJX81D–
Recirculating Charcoal
Filter KitTo be used
when the Spacemaker
microwave oven
cannot be vented to
the outside.

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
340147
Specification Created 4/09
Listed by
Underwriters
Laboratories
JVM1740DPWW/CC/BB
GE Spacemaker® Over-the-Range Microwave Oven
JVM1740DMWW
JVM1740DMCC
JVM1740DMBB
C ONVENIENCE C OOKING
Popcorn Beverage
Time
Cook
T imer
AM/PM
Potato
Power
Level
Surface
Light
Vent
Fan
Add
30 Sec.
Vegetable
ExpressCook
1
4
2
5
3
6
7 8
0
9
Start
Pause
Reminder
Turn
Table
Defrost
Clear
Off
Delay
Start
Clock
Help
AutoNite
Light
Beeper
Volume
Reheat
Cook
Features and Benefits
• 1.7 Cu. Ft. Capacity - 1000 Watts (IEC-705 test procedure)
• Convenience cooking controls - One-touch cooking controls make
operation fast and easy
• Auto and Time defrost - Simply enter the weight of the food, and the oven
automatically sets the optimal defrosting time and power level or set your
desired time for defrosting
• Recessed turntable with On/Off - Ideal for even cooking results or for
accommodating oversized dishes that may not be able to fully rotate
• Two-Speed, 300-CFM Venting System - One touch quickly removes smoke,
steam and odors from the cooktop area
• Removable Oven Rack - Full-width cooking rack allows for multi-level
cooking simultaneously, allowing you to cook large quantities of your
family's favorites
• Full-View Cooktop Lighting - Brilliant, natural-looking lighting fully
illuminates the cooking surface
• Model JVM1740DPBB – Black
• Model JVM1740DPCC – Bisque
• Model JVM1740DPWW - White
