GE Spacemaker JVM1740DP User manual

Spacemaker Microwave Oven
Owner’s Manual
Model: JVM1730
JNM1731
JVM1740
2
30
Helpful Information
Microwave Terms 30
Care and Cleaning 31
36
If Something Goes Wrong
Before You Call For Service 36
GE Service Numbers 38
Warranty Back Cover
GE Appliances
10
Important Safety Instructions
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy 2
Special Notes About Microwaving 5
Operating Instructions
Features of Your Microwave 10
The Controls on Your Microwave 11
Time Features 14
Convenience Features 20
Other Features 24
Oven Shelf 29
49-40613
DE68-03700A
06-09 JR
Write the model and serial numbers here:
Model# ______________________________
Serial# ______________________________
Find these numbers on a label inside the oven.

2
IMPORTANT SAFETY INSTRUCTIONS
READ ALL SAFETY
INFORMATION BEFORE USING
FOR YOUR
SAFETY
PRECAUTIONS
TO AVOID
POSSIBLE
EXPOSURE
TO EXCESSIVE
MICROWAVE
ENERGY
For your safety, the information in this manual
must be followed to minimize the risk of fire
or explosion or to prevent property damage,
personal injury or loss of life.
Do Not Attempt
to operate this oven
with the door open
since open-door
operation can result
in harmful exposure
to microwave energy.
It is important not to
defeat or tamper with
the safety interlocks.
Do Not Place any object
between the oven front
face and the door or
allow soil or cleaner
residue to accumulate
on sealing surfaces.
Do Not Operate the oven
if it is damaged. It is
particularly important
that the oven door
close properly and
that there is no
damage to the:
1 door (bent),
2 hinges and latches
(broken or loosened),
3 door seals and sealing
surfaces.
The Oven Should Not
be adjusted or repaired
by anyone except
properly qualified
service personnel.
WARNING!
To reduce the risk of burns, electric shock, fire, injury to persons, or exposure to excessive
microwave energy:
SAVE THESE INSTRUCTIONS

3
When using electrical appliances, basic safety precautions should be followed, including
the following:
WARNING
•Read and follow the
specific “Precautions to
Avoid Possible Exposure
to Excessive Microwave
Energy” on page 2.
•This appliance must be
grounded. Connect only
to properly grounded
outlet. See Grounding
Instructions section on
page 9.
•Do not mount this
appliance over a sink.
•Install or locate this
appliance only in
accordance with the
provided Installation
Instructions.
•This over-the-range oven
was designed for use over
ranges no wider than 36.″
It may be installed over
both gas and electric
cooking equipment.
•Do not operate this
appliance if it has a
damaged power cord or
plug, if it is not working
properly or if it has been
damaged or dropped.
If the power cord is
damaged, it must be
replaced by General
Electric Service or an
authorized service agent
using a power cord
available from General
Electric.
•Use this appliance only
for its intended use as
described in this manual.
Do not use corrosive
chemicals or vapors in
this appliance. This
microwave oven is
specifically designed to
heat, dry or cook food,
and is not intended
for laboratory or
industrial use.
This microwave oven is
UL listed for installation
over electric and gas
ranges.
This microwave oven is
not approved or tested
for marine use.
SAFETY
PRECAUTIONS
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS

SAVE THESE INSTRUCTIONS
•Do not cover or block any
openings on the appliance.
•Do not store this appliance
outdoors. Do not use this
product near water—for
example, in a wet
basement, near a
swimming pool, near a
sink or in similar locations.
•Keep power cord away
from heated surfaces.
•Do not immerse power
cord or plug in water.
•To reduce the risk of fire
in the oven cavity:
— Do not overcook food.
Carefully attend
appliance when paper,
plastic or other com-
bustible materials are
placed inside the oven
while cooking.
— Remove wire twist-ties
and metal handles
from paper or plastic
containers before placing
them in the oven.
— Do not use the oven
for storage purposes.
Do not leave paper
products, cooking
utensils or food in the
oven when not in use.
— If materials inside oven
ignite, keep the oven
door closed, turn the
oven off and disconnect
the power cord, or shut
off power at the fuse or
circuit breaker panel.
If the door is opened, the
fire may spread.
— Do not use the
Sensor Features twice in
succession on the same
food portion. If food is
under cooked after the
first countdown, use
Time Cook for additional
cooking time.
•See door surface cleaning
instructions in the Care
and Cleaning section(s)
of this manual.
•This appliance must only
be serviced by qualified
service personnel. Contact
nearest authorized service
facility for examination,
repair or adjustment.
•As with any appliance,
close supervision is
necessary when used
by children.
• Do not store anything
directly on top of the
microwave oven surface
when the microwave oven
is in operation.
4
IMPORTANT SAFETY INSTRUCTIONS
READ ALL SAFETY
INFORMATION BEFORE USING

SAVE THESE INSTRUCTIONS
5
SPECIAL NOTES ABOUT MICROWAVING
Arcing is the microwave
term for sparks in the oven.
Arcing is caused by:
•The metal shelf (if
included) not installed
correctly so it touches the
•Metal or foil touching the
side of the oven.
•Foil not molded to food
(upturned edges act like
antennas).
•Metal, such as twist-ties,
poultry pins or gold-
rimmed dishes, in the
microwave.
•Recycled paper towels
containing small metal
pieces being used in
the microwave.
Only use microwave
shelf when reheating
on more than one level.
DO NOT store the oven
shelf in the microwave.
See operating instructions
for oven shelf.
If you see arcing, press
the CLEAR/OFF pad and
correct the problem.
ARCING
•Do not pop popcorn in
your microwave oven
unless in a special
microwave popcorn
accessory or unless you use
popcorn labeled for use in
microwave ovens.
•Some products such as
whole eggs and sealed
containers—for example,
closed jars—are able to
explode and should
not be heated in this
microwave oven. Such
use of the microwave oven
could result in injury.
•Do not boil eggs in a
microwave oven. Pressure
will build up inside egg
yolk and will cause it to
burst, possibly resulting
in injury.
•Operating the microwave
with no food inside for
more than a minute or two
may cause damage to the
oven and could start a
fire. It increases the heat
around the magnetron
and can shorten the life
of the oven.
•Foods with unbroken
outer “skin” such as
potatoes, hot dogs,
sausages, tomatoes, apples,
chicken livers and other
giblets, and egg yolks
should be pierced to allow
steam to escape during
cooking.
FOODS
IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS
SAFETY
FACT
SUPERHEATED WATER
Liquids, such as water,
coffee or tea, are able to
be overheated beyond
the boiling point without
appearing to be boiling.
Visible bubbling or boiling
when the container
is removed from the
microwave oven is not
always present. THIS
COULD RESULT IN VERY
HOT LIQUIDS SUDDENLY
BOILING OVER WHEN THE
CONTAINER IS DISTURBED
OR A SPOON OR OTHER
UTENSIL IS INSERTED
INTO THE LIQUID.
To reduce the risk of injury
to persons:
— Do not overheat the
liquid.
— Stir the liquid both
before and halfway
through heating it.
— Do not use straight-
sided containers with
narrow necks.
— After heating, allow the
container to stand in
the microwave oven
for a short time before
removing the container.
— Use extreme care when
inserting a spoon or
other utensil into the
container.
•Avoid heating baby food
in glass jars, even with
the lid off. Make sure all
infant food is thoroughly
cooked. Stir food to
distribute the heat evenly.
Be careful to prevent
scalding when warming
formula or breast milk.
The container may feel
cooler than the milk
really is. Always test the
milk before feeding
the baby.
•Don’t defrost frozen
beverages in narrow-
necked bottles (especially
carbonated beverages).
Even if the container is
opened, pressure can
build up. This can cause
the container to burst,
possibly resulting in
injury.
•Hot foods and steam
can cause burns. Be
careful when opening
any containers of hot
food, including popcorn
bags, cooking pouches
and boxes. To prevent
possible injury, direct
steam away from hands
and face.
•Do not overcook
potatoes. They could
dehydrate and catch
fire, causing damage
to your oven.
•Cook meat and poultry
thoroughly—meat to
at least an INTERNAL
temperature of 160°F
and poultry to at least an
INTERNAL temperature
of 180°F. Cooking to
these temperatures
usually protects against
foodborne illness.
IMPORTANT SAFETY INSTRUCTIONS
SPECIAL NOTES ABOUT MICROWAVING
6

SAVE THESE INSTRUCTIONS
7
Make sure all cookware
used in your microwave
oven is suitable for
microwaving. Most glass
casseroles, cooking dishes,
measuring cups, custard
cups, pottery or china
dinnerware which does not
have metallic trim or glaze
with a metallic sheen can
be used. Some cookware
is labeled “suitable for
microwaving.”
•If you are not sure if a
dish is microwave-safe,
use this test: Place in the
oven both the dish you
are testing and a glass
measuring cup filled with
1 cup of water—set the
measuring cup either in
or next to the dish.
Microwave 30–45 seconds
at high. If the dish heats,
it should not be used
for microwaving.
If the dish remains cool
and only the water in the
cup heats, then the dish
is microwave-safe.
•If you use a meat
thermometer while
cooking, make sure it is
safe for use in microwave
ovens.
•Do not use recycled
paper products. Recycled
paper towels, napkins
and waxed paper may
contain metal flecks
which could cause arcing
or ignite. Paper products
containing nylon or
nylon filaments should
be avoided, as they may
also ignite.
•Some styrofoam trays
(like those that meat is
packaged on) have a thin
strip of metal embedded
in the bottom. When
microwaved, the metal
can burn the floor of the
oven or ignite a paper
towel.
•Do not use the microwave
to dry newspapers.
•Not all plastic wrap
is suitable for use in
microwave ovens.
Check the package
for proper use.
•Paper towels, waxed
paper and plastic wrap
can be used to cover
dishes in order to retain
moisture and prevent
spattering. Be sure to
vent plastic wrap so
steam can escape.
•Cookware may become
hot because of heat
transferred from the
heated food. Pot holders
may be needed to handle
the cookware.
•“Boilable” cooking
pouches and tightly
closed plastic bags should
be slit, pierced or vented
as directed by package.
If they are not, plastic
could burst during or
immediately after
cooking, possibly resulting
in injury. Also, plastic
storage containers should
be at least partially
uncovered because they
form a tight seal. When
cooking with containers
tightly covered with
plastic wrap, remove
covering carefully and
direct steam away from
hands and face.
MICROWAVE-
SAFE
COOKWARE
How to test for a
microwave-safe dish.
IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS
•Use foil only as directed in
this manual. When using
foil in the microwave
oven, keep the foil at least
1″away from the sides of
the oven.
•Plastic cookware—Plastic
cookware designed for
microwave cooking is
very useful, but should
be used carefully. Even
microwave-safe plastic
may not be as tolerant of
overcooking conditions
as are glass or ceramic
materials and may soften
or char if subjected
to short periods of
overcooking. In longer
exposures to over-
cooking, the food and
cookware could ignite.
Follow these guidelines:
1 Use microwave-safe
plastics only and use
them in strict compliance
with the cookware
manufacturer’s
recommendations.
2 Do not microwave empty
containers.
3 Do not permit children
to use plastic cookware
without complete
supervision.
The fan will operate
automatically under
certain conditions (see
Automatic Fan feature).
Take care to prevent the
starting and spreading of
accidental cooking fires
while the vent fan is in use.
•Clean the underside of
the microwave often.
Do not allow grease
to build up on the
microwave or the
fan filters.
•In the event of a grease
fire on the surface units
below the microwave
oven, smother a flaming
pan on the surface unit
by covering the pan
completely with a lid, a
cookie sheet or a flat tray.
•Use care when cleaning
the vent fan filters.
Corrosive cleaning
agents, such as lye-based
oven cleaners, may
damage the filters.
•When preparing
flaming foods under
the microwave, turn
the fan on.
•Never leave surface units
beneath your microwave
oven unattended at high
heat settings. Boilovers
cause smoking and greasy
spillovers that may ignite
and spread if the
microwave vent fan is
operating. To minimize
automatic fan operation,
use adequate sized
cookware and use high
heat on surface units
only when necessary.
THE VENT
FAN
IMPORTANT SAFETY INSTRUCTIONS
SPECIAL NOTES ABOUT MICROWAVING
8
NOTICE –
PACEMAKERS
Most pacemakers are
shielded from interference
from electronic products,
including microwaves.
However, patients with
pacemakers may wish
to consult their physicians
if they have concerns.

SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS/OPTIONAL KITS
WARNING
Improper use of the
grounding plug can result
in a risk of electric shock.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the
risk of electric shock by
providing an escape wire
for the electric current.
This appliance is equipped
with a power cord having
a grounding wire with a
grounding plug. The plug
must be plugged into an
outlet that is properly
installed and grounded.
Consult a qualified
electrician or service
technician if the grounding
instructions are not
completely understood,
or if doubt exists as to
whether the appliance
is properly grounded.
If the outlet is a standard
2-prong wall outlet, it is
your personal responsibility
and obligation to have it
replaced with a properly
grounded 3-prong wall
outlet.
Do not under any
circumstances cut or
remove the third (ground)
prong from the power
cord.
Do not use an adapter
plug with this appliance.
Do not use an extension
cord with this appliance.
If the power cord is too
short, have a qualified
electrician or service
technician install an outlet
near the appliance.
For best operation, plug
this appliance into its own
electrical outlet to prevent
flickering of lights, blowing
of fuse or tripping of
circuit breaker.
GROUNDING
INSTRUCTIONS
Filler Panel Kits
JX48WH—White
JX48BL—Black
When replacing a 36″
range hood, filler panel
kits fill in the additional
width to provide a custom
built-in appearance.
For installation between
cabinets only; not for
end-of-cabinet installation.
Each kit contains two
3″-wide filler panels.
JX81J— Recirculating
Charcoal Filter Kit
Filter kits are used when
the microwave oven cannot
be vented to the outside.
Available at extra cost from
your GE supplier, or see
GE Service Numbers.
Optional Kits
Ensure proper ground
exists before use.
JX81J
JX48
9
IMPORTANT SAFETY INSTRUCTIONS

10
3
67
9
8
7
1
2
5
Operating Instructions
Features of Your Microwave
(Throughout this manual, features and appearance
may vary from your model.)
1 Door Handle. Pull to
open the door. The
door must be securely
latched for the
microwave to operate.
2 Door Latches.
3 Window with Metal
Shield.
Screen allows
cooking to be viewed
while keeping
microwaves confined
in the oven.
4 Shelf (if included) .
Lets you microwave
several foods at once.
Food microwaves best
when placed directly
on the oven floor or
turntable.
5 Touch Control Panel
You must set the
clock before using
the microwave.
6 Cooktop Lights.
7 Grease Filters.
8 Removable Turntable.
Turntable and support
must be in place when
using the oven. The
turntable may be
removed for cleaning.
9 Convenience Guide.
NOTE:
Rating plate, oven
vent(s) and oven light are
located on the inside walls
of the microwave oven.
Features
4
