GE Spacemaker JVM2050BH User instructions

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
340118
Specification Revised 8/07
Listed by
Underwriters
Laboratories
JVM2050BH/CH/SJ/WH
GE Spacemaker® 2.0 Cu. Ft. Over-the-Range Microwave Oven
Note: Requires 120V grounded outlet. Electrical receptacle
must be located in cabinet above Spacemaker microwave oven.
No additional wiring, venting or cabinet rebuilding necessary
in many cases. Complete detailed, easy-to-follow installation
instructions and convenient full-size templates are packed with
the Spacemaker microwave oven.
Important Information: When installing the Spacemaker
microwave oven over a range, allow minimum of 2" from bottom
of Spacemaker microwave oven to top of range backguard to
allow for removal of light covers.
Installation Information: This information is not intended to
be used for installing unit described. Before installing, consult
installation instructions packed with product/kit for current
dimensional data.
2070 Dimensions (in inches)
66" MIN.
Mounting
height
from
floor
30"
MIN.
width
required Exhaust outlet
connects to
3-1/4" X 10" duct
16-11/32
(rear)
105°
Door open
15-7/16
12"
MIN.
24-1/2
16-11/32
29-7/8
Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
340118
Specification Revised 8/07
Listed by
Underwriters
Laboratories
JVM2050BH/CH/SJ/WH
GE Spacemaker® 2.0 Cu. Ft. Over-the-Range Microwave Oven
Hood Exhaust Duct: Outside ventilation requires a HOOD EXHAUST DUCT. Read the
following carefully.
Exhaust Connection: The hood exhaust has been designed to mate with a standard
3-1/4" x 10" rectangular duct. If a round duct is required, a rectangular-to-round transition
adaptor must be used. Do not use less than a 6" diameter duct
Rear Exhaust: If a rear or horizontal exhaust is to be used, care should be taken to
align exhaust with space between studs, or wall should be prepared at the time it is
constructed by leaving enough space between the wall studs to accommodate exhaust.
Maximum Duct Length: For satisfactory air movement, the total duct length of
3-1/4" x 10" rectangular or 6" diameter round duct should not exceed 120 equivalent feet.
Elbows, Transitions, Wall and Roof Caps, etc., present additional resistance to airflow
and are equivalent to a section of straight duct which is longer than their actual physical
size. When calculating the total duct length, add the equivalent length of all transitions
and adaptors plus the lengths of all straight duct sections. The chart below shows the
approximate feet of equivalent length of some typical ducts.
Duct Equivalent Feet
A. Rectangular-To-round 5 ft.
Transition Adaptor
B. Wall Cap 40 ft.
C. 90° Elbow 10 ft.
D. 45° Elbow 5 ft.
E. 90° Elbow 25 ft.
F. 45° Elbow 5 ft.
G. Roof Cap 24 ft.
Optional Accessories (Available at additional cost)
Filler Panel Kits
JX40CT–Bisque
JX41–Black
JX40WH–White
When replacing a 36" or
42" range hood, this kit fills
in the additional width to
provide a custom built-in
appearance. For installation
between cabinets only; not
for end-of-cabinet installation.
Each kit contains two 3"-wide
filler panels. Two kits are needed
for a 42" opening.
Filter KitsJX81H–
Recirculating Charcoal
Filter Kit
To be used when
the Spacemaker
microwave oven
cannot be vented
to the outside.
Dimensions and Installation Information (in inches)
Decorative Panel Kits
19
30
3/8" 
depth
JX22SS-Stainless Steel
Decorative Panel Kit
When replacing a Hi/Low range with
a microwave/convection oven or
Spacemaker over a range model, this
panel kit fills in the area between the
microwave and range left by the
Hi/Low model.

340118
Specification Revised 8/07
Listed by
Underwriters
Laboratories
JVM2050BH/CH/SJ/WH
GE Spacemaker® 2.0 Cu. Ft. Over-the-Range Microwave Oven
Spacemaker 2.0
EXPRESS COOK
3
EXPRESS COOK
2
EXPRESS COOK
1
EXPRESS COOK
6
EXPRESS COOK
5
EXPRESS COOK
4
9
87
0
CLEAR
OFF
START
PAUSE
POWER
LEVEL
ADD
30 SEC.
TIME
COOK
AUTO /TIME
DEFROST
1lb. QUICK
DEFROST
TIMER TURNTABLE REMINDER
VENT FAN SURFACE
LIGHT
CLOCK
AM / PM
OPTIONS
HELP
DELAY
START
VENT FAN
BOOST
BEVERAGE POTATO
POPCORN
VEGETABLE REHEAT
ONE TOUCH SENSOR
JVM2050WH/BH/CH
Features and Benefits
• Dual Distribution Cooking System - Exclusive new system
features 1100 watts of cooking power, a rotating turntable,
along with a top and side sitrrer for exceptionally even
heating and defrosting of food
• Industry's Largest Usable Capacity - Two oven racks and
turntable on/off function make room for up to six plates or
three 9" x 13" casseroles
• Quick Defrost - Evenly defrosts a pound of meat, poultry or
fish in a fraction of the usual time, without precooking
• Sensor Controls - Automatically adjust time and power for
perfect cooking results
• 14-1/4" Recessed Turntable - Large enough to handle 5-qt
casserole dishes
• Three-Speed, 300-CFM Vortex Venting System - Quickly
moves smoke and steam from the cooktop
• Two-line Bilingual Scrolling Display - Provides helpful cooking
tips and oven-use instructions in easy-to-read English
or Spanish
• Model JVM2050WH – White on white
• Model JVM2050BH – Black on black
• Model JVM2050CH – Bisque on bisque
• Model JVM2050SJ – Stainless steel
*IEC-705 Test Procedure
