Dimensions and Installation Information (in inches)
Factory set for Natural gas. A set of LP orifices is included with
each range for LP conversion.
Gas Self-Clean Range Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing, consult installation
instructions packed with product for current dimensional data.
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
geappliances.com or call GE Answer Center®
service, 800.626.2000.
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
JGBS23SET
GE® 30" Free-Standing Gas Range with Steam Clean
Specification Revised 7/11 330402
All 30" GE gas and electric range backguards
are 30-7/8" wide.*
*Except these models: JGBS07, JGBS04, JGBP90,
all GE Profile free-standing electric and gas
ranges
Fits most countertop backsplash applications.
Consult Use & Care Manual for detailed
installation instructions.
30-7/8"
24
30" FS Gas Ranges-CL
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
46-1/8
26-1/4*
46-3/8
36-1/4±1/4
Installation Information (Dimensions in inches)
Recommended common
area for gas outlet and
electrical outlet
*Dimension from wall
to front of closed
door handle is 29".
30

Features and Benefits
• 4.8 cu. ft. capacity - More room for cooking more dishes at once
• Steam clean cycle - The power of steam loosens baked-on foods and assists
in oven cleaning
• High output burner - This 12,500 BTU burner element provides the high heat
ideal for frying or sautéing and fast heat-up
• Precise simmer burner - Delivers a low setting of 140 degrees, ideal for
delicate foods and sauces
• Big hearth window - Elegant shaped window makes it easy to monitor the
progress of food
• Model JGBS23SETSS - Stainless steel (stainless steel door and black cooktop)
Specification Revised 7/11 330402
JGBS23SET
GE® 30" Free-Standing Gas Range with Steam Clean
