GE GSS22JET Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Dimensions and Installation Information (in inches)
†Water hook-up fits in back air clearance when calculating
installation depth.
If installed against a wall, allow clearance of 14-3/16" on freezer
side to remove bin.
Clearance required to remove fresh food full-size pan without
disassembling is 18-15/16".
Allow additional space for any necessary leveling adjustments.
"94 SxS Refer
A
Front View
Top View
G
D
C
F
BE
H
GSS22JET
GE®22.0 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Overall
Dimensions
Height to top of hinge (in.) A67-1/2
Height to top of case (in.) B66-1/2
Case depth without door (in.) C†28
Case depth less door handle (in.) D†31-1/4
Case depth with door handle (in.) E†33-9/16
Depth with fresh food door open 90° (in.) F†49-3/8
Width (in.) G33-1/2
Width with door open 90° inc. door handle (in.) H35-15/16
Air
Clearances
Each side (in.) 1/8
Top (in.) 1
Back (in.) 1
Listed by
Underwriters
Laboratories
Specification Revised 5/09 310209

GSS22/25JET
Features and Benefits
• ExternalTemperatureControlswithChildLock-Combinestheeaseof0-9temperature
settings, with the sophistication of electronic controls
• AdjustableTemperatureDeliDrawer-Keepmeatsandcheesesdelicious
• AdjustableGallonDoorBins-Makeroomformilkandothergallon-sizecontainers
• AdjustableSpillproofGlassShelves-Helpstocontainspillsforeaseofcleaning
•  F r o s t G u a r d ™Technology - Protects frozen items from freezer burn by monitoring freezer
door openings and defrosting only when needed
• AutoEnergySaver-Sensesfreezerandfreshdooropeningsandadjustsrefrigeration
operation cycles accordingly
• DeluxeQuietDesign-Significantlyreducesoperatingnoise
• NeverClean™Condenser - Condenser coils are encased, so they don’t require cleaning
in normal operating environments
• ModelGSS22JETWW-Whiteonwhite
• ModelGSS22JETCC-Bisqueonbisque
• ModelGSS22JETBB-Blackonblack
GSS22JET
GE®22.0 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Specification Revised 5/09 310209
*
