GE Appliances WASR3110 User manual

GE Appliances
Washers
Profile
Laveuses
Profile
Lavadoras
Profile
English section begins on page 2
La section française commence à la page 16
La sección en español empieza en la página 30
Part No. 175D1807P243 Pub. No. 49-9972 3–98 CG
GE Answer Center ®800.626.2000
WASR3110
WMSR3110
WPSL3120
WPSR3100
WPSR3120
WPSR4130
WSSR3120
Owner’s Manual
Manuel d’utilisation
Manual del propietario

Congratulations!
You Are Now Part of the GE Family.
Welcome to the GE family. We’re proud of our quality products and we are
committed to providing dependable service. You’ll see it in this easy-to-use Owner’s
Manual and you’ll hear it in the friendly voices of our customer service department.
Best of all, you’ll experience these values each time you use your washer. That’s
important, because your new washer will be part of your family for many years. And
we hope you will be part of ours for a long time to come.
We thank you for buying GE. We appreciate your purchase, and hope you will
continue to rely on us whenever you need quality appliances for your home.
AService Partnership.
Safety Information . . . . . . . .3
Operating Instructions
Control Panels . . . . . . . . . . . . . . . .4, 5
Features . . . . . . . . . . . . . . . . . . . . .7, 8
Loading and Using the Washer . .9, 10
Troubleshooting Tips
Before You Call For Service . . . . 11–13
Customer Service
U.S. Warranty . . . . . . . . . . . . . . . . .14
Canada Warranty . . . . . . . . . . . . . . .15
Service Telephone
Numbers . . . . . . . . . . . . . .Back Cover
FOR YOUR RECORDS
Write the model and serial numbers here:
#
#
You can find them in the upper right corner on the back of
your washer.
Inside you will find many helpful hints on how to use and maintain
your washer properly. Just a little preventive care on your part can
save you a great deal of time and money over the life of your washer.
You’ll find many answers to common problems in the Before You
Call For Service section. If you review our chart of Troubleshooting Tips
first, you may not need to call for service at all.
READ THIS MANUAL
IF YOU NEED SERVICE
If you do need service, you can relax knowing help is only a phone
call away. A list of toll-free customer service numbers is included in
the back section. Or, in the U.S., you can always call the GE Answer
Center®,at 800.626.2000, 24 hours a day, 7 days a week. In Canada,
call 1-800-361-3400.
IMPORTANT!
Staple sales slip or cancelled check here.
Proof of the original purchase date is needed to obtain service
under the warranty.
2
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips

■Install or store where it will not be exposed to
temperatures below freezing or exposed to the weather. ■Properly ground washer to conform with all governing codes and ordinances. Follow details in Installation
Instructions.
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire
or explosion, electric shock, or to prevent property damage, personal injury, or loss of life.
WATER HEATER SAFETY
Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks
or more. Hydrogen gas can be explosive under these circumstances.
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning on
all hot water faucets and allowing them to run for several minutes. Do this before using any electrical appliance
which is connected to the hot water system. This simple procedure will allow any built-up hydrogen gas to escape.
Since the gas is flammable, do not smoke or use an open flame or appliance during this process.
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions before it is used. If
you did not receive an Installation Instructions sheet, you can receive one by calling, toll-free, in the United States the
GE Answer Center
®,
800.626.2000. In Canada, call, 1-800-361-3400.
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
■Keep the area underneath and around your
appliances free of combustible materials such as
lint, paper, rags, chemicals, etc.
■Close supervision is necessary if this appliance is used
by or near children. Do not allow children to play on,
with, or inside this or any other appliance.
YOUR LAUNDRY AREA
■Never reach into washer while it is moving. Wait
until the machine has completely stopped before
opening the lid.
■Do not mix chlorine bleach with ammonia or acids
such as vinegar and/or rust remover. Mixing
different chemicals can produce a toxic gas which
may cause death.
■Do not wash or dry articles that have been cleaned in,
washed in, soaked in, or spotted with combustible or
explosive substances (such as wax, oil, paint, gasoline,
degreasers, dry-cleaning solvents, kerosene, etc.) which
may ignite or explode. Do not add these substances to
the wash water. Do not use or place these substances
around your washer or dryer during operation.
■ The laundry process can reduce the flame retardancy
of fabrics. To avoid such a result, carefully follow the
garment manufacturer’s wash and care instructions.
■To minimize the possibility of electric shock, unplug
this appliance from the power supply or disconnect
the washer at the household distribution panel by
removing the fuse or switching off the circuit breaker
before attempting any maintenance or cleaning.
NOTE: Turning the Cycle Selector knob to an off
position does NOT disconnect the appliance from
the power supply.
■Never attempt to operate this appliance if it is damaged,
malfunctioning, partially disassembled, or has missing
or broken parts, including a damaged cord or plug.
WHEN USING THE WASHER
■Turn off water faucets to relieve pressure on hoses
and valves and to minimize leakage if a break or
rupture should occur. Check the condition of the
fill hoses; they may need replacement after 5 years.
■Before discarding a washer, or removing it from
service, remove the washer lid to prevent children
from hiding inside.
■Do not attempt to repair or replace any part of this
appliance unless specifically recommended in this
Owner’s Manual, or in published user-repair
instructions that you understand and have the skills
to carry out.
■Do not tamper with controls.
WHEN NOT IN USE
Read and follow this Safety Information carefully.
SAVE THESE INSTRUCTIONS
3
Use this
appliance
only for its
intended
purpose as
described in
this Owner’s
Manual.

HEAVY 12
MEDIUM 10
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
EXTRA HEAVY 15 SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF SET
WARM
COLD
HOT
COLD
COLD
COLD
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
MEDIUM LARGE
LOAD SIZE TEMPERATURE EXTRA RINSE
SMALL SUPER
WASH/SPIN
SPEED
SensorWash
SPOT SOAK
SensorWash
Model WMSR3110
HEAVY 12
MEDIUM 10
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
15 MIN
AUTO SOAK
EXTRA HEAVY 15 SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF SET
WARM
COLD HOT
COLD
COLD
COLD
WARM
WARM
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
MEDIUM LARGE
LOAD SIZE TEMPERATURE EXTRA RINSE
SMALL SUPER
WASH/SPIN
SPEED
SensorWash
SensorWash
Models WPSL3120 and WPSR3120
HEAVY 12
MEDIUM 9
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
EXTRA HEAVY 15 SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF SET
WARM
COLD HOT
COLD
COLD
COLD
WARM
WARM
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
MEDIUM LARGE
LOAD SIZE TEMPERATURE EXTRA RINSE
SMALL SUPER
WASH/SPIN
SPEED
SensorWash
SensorWash
Find your washer control panel.
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
You can locate your model number behind the top edge of the control panel.
4
Model WASR3110
1 2 3 4
1 2 3 4
1 2 3 4

HEAVY 12
MEDIUM 10
LIGHT SOIL 5
PERMANENT PRESS
KNITS
30 MIN
AUTO SOAK
15 MIN
AUTO SOAK
EXTRA HEAVY 15
COTTONS
DELICATES
EASY CARE
OFF SET
COLD
COLD HOT
COLD
WARM
COLD
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
MEDIUM
LOAD SIZE TEMPERATURE EXTRA RINSE
SMALL SUPER
LARGE
WASH/SPIN
SPEED
Model WPSR3100
HEAVY 12
MEDIUM 9
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
PREWASH
15 MIN
AUTO SOAK
EXTRA HEAVY 15
SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF
SPOT SOAK
SET
WARM
COLD HOT
COLD
COLD
COLD WARM
WARM
GENTLE
SLOW NORMAL
SLOW
GENTLE
FAST NORMAL FAST
EXTRA
LARGE EXTRA
SMALL
TEMPERATURE EXTRA RINSE
LARGE MEDIUM
SUPER RESET
WASH/SPIN
SPEED
LOAD SIZE
VARIABLE
SensorWash
SensorWash
Model WPSR4130
HEAVY 12
MEDIUM 9
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
15 MIN
AUTO SOAK
EXTRA HEAVY 15
SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF SET
WARM
COLD HOT
COLD
COLD
COLD WARM
WARM
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
EXTRA
LARGE EXTRA
SMALL
LOAD SIZE TEMPERATURE EXTRA RINSE
LARGE MEDIUM
SUPER RESET
WASH/SPIN
SPEED
VARIABLE
SensorWash
SensorWash
Model WSSR3120
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
1 2 3 4
1 2 3 4
1 2 3 4
5

Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
About the control settings.
Color Logic
Select the correct TEMPERATURE setting. Match the particular color below the words with the
same color on the WASH/SPIN SPEED setting. Next, match the color again with the same color
on the Cycle Dial.
Example: Washing a load of medium soiled whites, such as towels and sheets.
Choose the LOAD SIZE.
Choose the TEMPERATURE setting -—for this load it would be the HOT COLD (which is a
particular color) .
Choose the WASH/SPIN SPEED setting that matches that color—for this load it would be the
NORMAL FAST.
Turn the Cycle Dial to the area that has the same color as the TEMPERATURE and
WASH/SPIN SPEED settings you have chosen—for this load it would be the COTTONS area.
Then turn the Cycle Dial to the MEDIUM soil setting.
4
3
2
1
6
Load Size
The water level should just cover the clothes. Adjust the load size accordingly. Loosely load clothes
no higher than the top row of holes in the washer tub.
Wash/Spin Speed
The agitator moves clothes around for a cleaner wash; the basket spins later in the cycle to release
water from the load. The Wash/Spin Speed dial sets the speed of both the agitator and the basket.
With Normal wash speed, the agitator moves faster. Use for cottons, denims and play clothes. With
Gentle wash speed, the agitator moves slower. Use for delicate and knit items.
The Fast spin speed is for durable items. The Slow spin speed is for delicate items like sweaters and
lingerie. Clothes will be less dry than when using Fast spin speed.
Temperature
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care
label or instructions when laundering. Follow the water temperature guide on the washer lid.
Wash Cycle
The wash cycle controls the length of the washing process. The chart below will help you match the
wash cycle setting with your clothing.
COTTONS For heavy to lightly soiled cottons, household linens, work and play clothes.
EASY CARE For easy care and wrinkle-resistant items.
KNITS Specially designed for normally soiled knits.
DELICATES For lingerie and delicate fabrics with light to normal soil.
HANDWASH For lingerie and special-care fabrics with light soils. Provides periods of agitation and soak during wash
and rinse.
EXTRA HEAVY For heavily soiled and heavy-duty fabrics. This cycle provides a longer agitation.
PREWASH For heavily soiled clothes or for clothes with a care label that recommends prewashing before wearing.
AUTO SOAK For heavily soiled clothes. Begins with a brief agitation, soaks for a specified period of time, then moves
through the rest of the cycle automatically.
4
3
2
1

Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
About washer features. NOTE: Not all features are available on all washer models.
Extra Rinse
When you use extra detergent or bleach
to clean heavily soiled clothes, you may
want to use the Extra Rinse option. This
option provides a second deep cold rinse
in the COTTONS cycle. Turn the Extra Rinse
knob to SET.
The washer will pause for a few minutes before
the Extra Rinse option begins.
OFF SET
SensorWash (on some models)
The SensorWash senses the incoming water temperature and adjusts the fill water to obtain a
more precise temperature range for all three wash temperatures. You may select cold, warm
or hot. For example, in a Cold Wash selection, some warm water may be added to reach a
temperature needed to better dissolve detergents. Often, detergents are not completely
dissolved in very cold water, especially in cooler climates.
NOTE: The SensorWash will not adjust the fill on WARM WASH unless the washer lid is
closed. Be sure to start the washer after the lid is closed.
Spot Soak (on some models)
When you open the washer lid and press the SPOT SOAK button, you will see a short stream
of cold water.
Open the washer lid.
Press the SPOT SOAK button. (You will see a short stream of water.)
Dampen your soiled garment with the SPOT SOAK option and rub your favorite
pretreatment product into soiled area.
NOTE: The SPOT SOAK option will not work if
■ the washer lid is down
■ the washer tub is filling
■ the water has already reached the
level you selected.
3
2
1
SPOT SOAK
Liquid Bleach Dispenser (on some models)
The dispenser dilutes liquid chlorine bleach before it reaches into your wash load.
Check clothing care labels for special instructions.
Measure liquid bleach carefully, following instructions on the bottle.
■ Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash basket.
■ Do not pour powdered bleach into bleach dispenser.
Before starting the washer, pour measured amount of bleach directly into bleach
dispenser. Avoid splashing or over-filling dispenser. If you prefer to use powdered
bleach, add it into the wash basket with your detergent.
■ Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover. Mixing can
produce a toxic gas which may cause death.
3
2
1
7
SensorWash

8
About washer features. NOTE: Not all features are available on all washer models.
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
The Agitator Cap or Fabric Softener Dispenser (depending on model)
The agitator cap fits into the top of the
agitator. If it accidentally comes off, simply
put it back on.
The fabric softener dispenser automatically
releases liquid fabric softener at the proper
time during the cycle.
Do not stop the washer during the first
spin. This will cause the dispenser to
empty too soon.
To use, follow these steps:
Make sure dispenser is securely attached
to agitator.
Use only liquid fabric softener. Pour
into dispenser, using amount
recommended on package.
Never pour fabric softener directly on
clothes. It may stain them.
Add water to dispenser until it reaches
the maximum fill line.
3
2
1
Do not pour anything into the agitator if
the agitator cap or dispenser is removed.
Cleaning the Fabric Softener Dispenser (on some models)
Remove the dispenser from the top of the agitator.
Separate the dispenser cup from the cover by grasping the top and pushing down on
the inside of the cup with your fingers. Dispenser cup will pop free from the cover.
To clean the dispenser, soak both the dispenser cup and the dispenser cover in the
following solution:
■ 1 US gallon (3.8 liters) warm water
■ 1/4 cup (60 ml) heavy duty liquid detergent
■ 1 cup (240 ml) bleach
If necessary, loosen build-up with a clean, soft cloth after soaking. Do not use a stiff
brush; you may roughen the surface of the dispenser.
Rinse and reassemble dispenser. Place dispenser back on the agitator.
5
4
3
2
1
Separate for cleaning.

9
Loading and using the washer. Always follow fabric manufacturer’s care label when laundering.
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
Sorting Wash Loads
Proper Use of Detergent
Add detergent and start the washer before adding
clothes so that the detergent can work effectively.
Follow the detergent package directions. Using too
little detergent is a common cause of laundry
problems.
Use more detergent if you have hard water, large
loads, greasy or oily soils or lower water
temperature.
Loading the Washer
Load dry items loosely, no higher than the top
row of holes in the washer tub. When loading wet
items make sure you set the load/water level high
enough to allow the items to move freely. Water
level should just cover the clothes. To add items
after washer has started, push in Cycle Dial and
submerge additional items next to the agitator.
Close the lid and pull Cycle Dial out to restart.
■ Do not wrap large items like sheets around the
agitator.
■ Do not wash fabrics containing flammable
materials (waxes, cleaning fluids, etc.).
■ Agitation will not start with the lid up.
Colors
Whites
Lights
Darks
Soil
Heavy
Normal
Light
Fabric
Delicates
Easy Care
Sturdy Cottons
Lint
Lint Producers
Lint Collectors

Loading and using the washer. Always follow fabric manufacturer’s care label when laundering.
10
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
Care and Cleaning of the Washer
Wash Basket: Leave the lid open after washing to
allow moisture to evaporate. If you want to clean the
basket use a clean soft cloth dampened with liquid
detergent, then rinse. (Do not use harsh or gritty
cleaners.)
Fill Hoses: Hoses connecting washer to faucet should
be replaced every 5 years.
Lint Filter: The lint filter is located under the agitator.
It is self-cleaning and requires no maintenance.
Exterior: Immediately wipe off any spills. Wipe with
damp cloth. Try not to hit surface with sharp objects.
Moving and Storage: Ask the service technician to
remove water from drain pump and hoses. Do not
store the washer where it will be exposed to the
weather. Call the GE Answer Center®, 800.626.2000
for information on how to keep the tub stationary
when moving the washer.
Long Vacations: Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will be
below freezing.
Fabric Care Labels
Machine
wash
cycle
Normal Permanent Press/
wrinkle resistant Gentle/
delicate Hand wash Do not wash Do not wring
Water
temperature
Hot
(50°C/120°F) Warm (40°C/105°F) Cold/cool (30°C/85°F)
Tumble
dry
Dry Normal Permanent Press/
wrinkle resistant Gentle/
delicate Do not tumble dry Do not dry
(used with
do not wash)
Heat
setting
High Medium Low No heat/air
Special
instructions
Line dry/
hang to dry Drip dry Dry flat In the shade
Bleach
symbols
Any bleach
(when needed) Only non-chlorine bleach
(when needed) Do not bleach
Below are fabric care label “symbols” that affect the clothing you will be laundering.
WASH LABELS
DRY LABELS
BLEACH LABELS

Before you call for service…
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
11
Problem Possible Causes What To Do
Washer won’t operate Washer is unplugged •Make sure cord is plugged securely into a working outlet.
Water supply is turned off •Turn both hot and cold faucets fully on.
Controls are not set •Check controls and make sure Cycle knob is pulled out
properly to ON position.
Lid is open •Close lid and pull Cycle knob out to ON position.
Circuit breaker/fuse is •Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have separate outlet.
Water temperature Control is not set properly •Check water temperature control and adjust.
Water supply is turned off •Turn both hot and cold faucets fully on and make sure
or improperly connected hoses are connected to correct faucets.
Water valve screens are •Turn off the water source and remove the water
stopped up connection hoses from the upper back of the washer.
Use a brush or toothpick to clean the screens in the
machine. Reconnect the hoses and turn the water
back on.
House water heater is •Make sure house water heater is delivering water
not set properly at 120°F.–140°F.(48°C.–60°C.).
Water won’t drain Drain hose is kinked or •Straighten drain hose and make sure washer is not
improperly connected sitting on it.
•Top of drain outlet should be less than 8 ft. above floor.
Water leaks Fill hoses or drain hose is •Make sure hose connections are tight at faucets and
improperly connected make sure end of drain hose is correctly inserted in
and secured to drain facility.
Household drain may •Check household plumbing. You may need
be clogged to call a plumber.
Constant water pressure •Tighten hoses at the faucets and turn the water off
to the fill hoses at the after each use.
water source •Check condition of the fill hoses; they may need
replacement after 5 years.
SensorWash (on The washer is in a cold rinse cycle •This is normal. The SensorWash feature is designed not
some models) wash to activate during a cold rinse cycle so that the coldest
temperature is incorrect water available is used.
(Review SensorWash All the water in the water heater •Wait until the water in the water heater is heated to the
in the About washer has been used correct temperature.
features section)
Troubleshooting Tips
Save time and money! Review the charts on the following
pages first and you may not need to call for service.
is incorrect

Before you call for service…
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
Problem Possible Causes What To Do
Lint or residue on Incorrect sorting •Separate lint producers from lint collectors.
clothes
Washing too long •Wash small loads for a shorter time than larger loads.
Detergent not dissolving •Add detergent as wash basket fills with water, before you
load clothes.
•Try a liquid detergent.
•Use warmer water temperature.
Overloading •Load clothes no higher than the top row of holes in the
washer tub.
•Make sure load size selector matches clothes load size.
Incorrect use of fabric •Check fabric softener package for instructions and follow
softener directions for using dispenser.
Colored spots Incorrect use of fabric •Check fabric softener package for instructions and follow
softener directions for using dispenser.
•Pretreat stain and rewash.
Dye transfer •Sort whites or lightly colored items from dark colors.
Wrinkling Improper sorting •Avoid mixing heavy items (like work clothes) with light items
(like blouses).
•Try a fabric softener.
Overloading or •Load your washer so clothes have enough room to move
incorrect water level freely.
Incorrect wash and •Match Cycle selection to the type of fabric you are washing
dry cycles (especially for easy care loads).
Repeated washing in •Wash in warm or cold water with plenty of detergent.
water that is too hot
Too many suds Type of detergent •Switch to a lower sudsing detergent brand and follow
instructions on package.
Very soft water •Try less detergent.
Snags, holes, tears, rips Pins, snaps, hooks, sharp •Fasten snaps, hooks, buttons, and zippers.
or excessive wear buttons, belt buckles, •Remove loose items like pins, objects in pockets and sharp
zippers, and sharp objects buttons.
left in pockets •Turn knits (which snag easily) inside out.
Undiluted chlorine bleach •Check bleach package instructions for proper amount.
•Never add undiluted bleach to wash or allow clothes to come
in contact with undiluted bleach.
Chemicals like hair bleach •Rinse items that may have chemicals on them before
or dye, permanent wave washing.
solution
12

13
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Instructions
Problem Possible Causes What To Do
Pilling Result of normal wear on •While this is not caused by the washer, you can slow the
poly-cotton blends and pilling process by washing garments inside out.
fuzzy fabrics
Grayed or yellowed Not enough detergent •Use more detergent (especially with larger loads).
Hard water •Use a water conditioner like Calgon brand or install
a water softener.
Water is not hot enough •Make sure water heater is delivering water at
120°F.–140°F. (48°C.–60°C.).
Washer is overloaded •Select load size to match clothes load.
Detergent is not •Add detergent as wash basket fills with water before you
dissolving load clothes.
Dye transfer •Sort clothes by color. If fabric label states wash separately,
unstable dyes may be indicated.
Washer is noisy Washer is uneven •Make sure washer is level and firm to the floor.
Washer load is •Push the Cycle knob in to stop the washer, open the lid
unbalanced and redistribute the load evenly. Close the lid and restart.
Washer pauses in cycle The washer normally pauses
between washing steps
Clothes too wet Incorrect cycle selected •Make sure the cycle selected matches the load you are
washing.
clothes

14
Operating Instructions Safety InstructionsCustomer Service Troubleshooting Tips
GE Washer Warranty (For customers in the United States.)
All warranty service provided by our Factory Service Centers or an authorized Customer Care
®
technician. For service, call 1-800-GE-CARES.
One Year Any part of the washer which fails due to a defect in materials or workmanship. During this full
From the date of the one-year warranty, GE will also provide, free of charge, all labor and in-home service to replace the
original purchase defective part.
Two Years Any part of the washer which fails due to a defect in materials or workmanship. During this two-year
From the date of the limited warranty, you will be responsible for any labor or in-home service costs.
original purchase
Five Years The suspension rod and spring assembly, if any of these parts should fail due to a defect in materials
From the date of the or workmanship. GE will also replace the washer lid or cover, if they should rust under operating
original purchase conditions. During this five-year limited warranty, you will be responsible for any labor or in-home
service costs.
Ten Years The transmission and washer tub, if any of these parts should fail due to a defect in materials or
From the date of the workmanship. During this ten-year limited warranty, you will be responsible for any labor or
original purchase in-home service costs.
Lifetime The washer basket, if it should fail due to a defect in materials or workmanship. During this lifetime
From the date of the limited warranty, you will be responsible for any labor or in-home service costs.
original purchase
For The Period Of: We Will Replace, At No Charge To You:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. In Alaska, the
warranty excludes the cost of shipping or service calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state. To know what your legal rights are, consult your local or state consumer affairs office or
your state’s Attorney General.
■Service trips to your home to teach you how to use
the product.
■Improper installation.
■Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by accident, fire, floods or
acts of God.
■Incidental or consequential damage to personal property
caused by possible defects with this appliance.
What Is Not Covered:
Warrantor: General Electric Company. Louisville, KY 40225

GE Washer Warranty (For customers in Canada)
15
All warranty service provided by our Factory Service Centers or an authorized technician.
For service, call 1-800-361-3400.
What Is Not Covered:
One Year Any part of the washer which fails due to a defect in materials or workmanship. During this full
From the date of the one-year warranty, GE will also provide, free of charge, all labor and in-home service to replace
original purchase the defective part.
Two Years Any part of the washer which fails due to a defect in materials or workmanship. During this two-year
From the date of the limited warranty, you will be responsible for any labor or in-home service costs.
original purchase
Five Years The suspension rod, spring assembly and motor, if any of these parts should fail due to a defect in
From the date of the materials or workmanship. GE will also replace the washer lid, cover and cabinet, if they should
original purchase rust under normal operating conditions. During this five-year limited warranty, you will be
responsible for any labor or in-home service costs.
Ten Years The transmission and washer tub, if any of these parts should fail due to a defect in materials or
From the date of the workmanship. During this ten-year limited warranty, you will be responsible for any labor or
original purchase in-home service costs.
Lifetime The washer basket, if it should fail due to a defect in materials or workmanship. During this lifetime
From the date of the limited warranty, you will be responsible for any labor or in-home service costs.
original purchase
For The Period Of: We Will Replace, At No Charge To You:
Customer Service
Troubleshooting Tips
Operating InstructionsSafety Instructions
■Service trips to your home to teach you how to use the
product.
Read your Owner’s Manual. If you then have any questions
about operating the product, please contact your dealer
or our Consumer Relations office at:
Manager, Consumer Relations
Camco Inc.
1 Factory Lane, Suite 310
Moncton, N.B.
E1C 9M3
■Improper installation.
If you have an installation problem, contact your
dealer or installer. You are responsible for providing
adequate electrical, exhausting and other connecting
facilities.
■ Replacement of house fuses or resetting of circuit
breakers.
■Failure of the product if it is misused, or used for
other than the intended purpose or used
commercially.
■ Damage to product caused by accident, fire, floods or
acts of God.
WARRANTOR IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES.
Warrantor: CAMCO INC.

Félicitations!
Désormais vous faites partie de la famille GE.
Bienvenue dans la famille GE. Nous sommes fiers de la qualité de nos produits
et de la fiabilité de notre service après-vente. Vous le constaterez dans le présent
manuel, facile à utiliser, et dans la voix amicale de notre personnel du service à la
clientèle.
Mais, surtout, vous le constaterez chaque fois que vous ferez votre lessive. C’est
important, car votre nouvelle laveuse fera partie de votre famille pendant des
années. Et nous espérons que vous ferez partie de la nôtre pendant longtemps
aussi.
Nous vous remercions de votre achat GE, et espérons qu’à l’avenir vous penserez à
nous chaque fois que vous aurez besoin d’un électroménager de qualité.
Un partenariat de service.
Mesures de sécurité . . . . . .17
Directives de
fonctionnement
Tableaux de commande . . .18, 20
L es caractéristiques . . . . . .21, 22
Chargement et utilisation
de la laveuse . . . . . . . . . . .23, 24
Conseils de dépannage
Avant d’appeler
un réparateur . . . . . . . . . . .25–27
Service à la clientèle
Garantie . . . . . . . . . . . . . . . . . .28
Numéros de
service . . . . . . . . . . . . . . . . . . .29
À CONSERVER SOIGNEUSEMENT
Transcrivez les numéros de modèle et de série ici.
N
o
N
o
Vous les trouverez derrière le tableau de commande.
Vous y trouverez de nombreux conseils pour l’utilisation et
l’entretien de votre laveuse. Ces quelques mesures préventives vous
permettront d’économiser du temps et de l’argent, et, ainsi, de
prolonger la vie de votre laveuse.
Vous trouverez des solutions aux problèmes courants que vous
pourriez rencontrer dans la section Avant d’appeler un réparateur .
Et, en consultant d’abord nos Conseils de dépannage , vous pourrez
peut-être éviter de faire appel à un réparateur.
LISEZ VOTRE MANUEL
SI VOUS AVEZ BESOIN DE SERVICE
Si vous avez besoin de service, vous savez que vous n’avez qu’à
nous téléphoner. Vous trouverez à la fin du présent manuel les
numéros sans frais du service à la clientèle. Aux États-Unis, vous pouvez
appeler 24 heures par jour, 7 jours par semaine au GE Answer Center®,
800.626.2000. Au Canada, appelez le 1- 800-361-3400.
IMPORTANT!
Agrafez ici votre facture ou une copie de votre chèque.
Pour bénéficier de réparations sous garantie, il faut fournir une
preuve de la date d’achat d’origine.
16
Fonctionnement Mesures de sécuritéService à la clientèle Conseils de dépannage

■Installez ou entreposez la laveuse à l’abri des
températures inférieures au point de congélation et
des intempéries.
■Mettez la laveuse à la terre conformément à tous les
codes et règlements en vigueur. Consultez les
Directives d’installation.
MESURES DE SÉCURITÉ IMPORTANTES.
LISEZ D’ABORD TOUTES LES DIRECTIVES.
MISE EN GARDE! Pour votre sécurité, suivez les directives fournies dans le présent manuel afin de
minimiser les risques d’incendie, d’explosion et de chocs électriques et prévenir
des dégâts matériels et des blessures graves or mortelles.
SÉCURITÉ DU CHAUFFE-EAU
Dans certaines circonstances, de l’hydrogène peut se former
dans le chauffe-eau s’il n’a pas été utilisé pendant deux
semaines ou plus. L’hydrogène peut être explosif dans ces
conditions.
Si l’eau chaude n’a pas été utilisée depuis deux semaines
ou plus, réduisez les risques de dommages ou de blessures
en ouvrant tous les robinets d’eau chaude et en laissant
couler l’eau pendant plusieurs minutes avant d’utiliser
un appareil électrique raccordé au système d’eau
chaude. L’hydrogène sera ainsi libéré dans
l’atmosphère. Comme c’est un gaz inflammable, ne
fumez pas ou n’utilisez pas une flamme nue ou un
appareil ménager au cours de ce processus.
UNE INSTALLATION ADÉQUATE
Avant d’utiliser votre laveuse, assurez-vous qu’elle a été adéquatement installée, conformément aux Directives d’installation.
Si vous n’avez pas reçu de Directives d’installation, vous pouvez les obtenir en appelant sans frais aux États-Unis au GE
Answer Center
®
, 800.626.2000. Au Canada, appelez sans frais un 1-800-361-3400.
Service à la clientèleConseils de dépannageFonctionnementMesures de sécurité
■Évitez toute accumulation de matériaux combustibles
(charpie, papiers, chiffons, produits chimiques, etc.) à
proximité de vos électroménagers.
■Il faut exercer une étroite surveillance lorsque
l’appareil fonctionne en présence d’enfants. Ne les
laissez pas jouer sur, avec ou à l’intérieur de cet
appareil ni aucun autre électroménager.
AUTOUR DE VOTRE LAVEUSE
■Ne mettez jamais la main dans la laveuse pendant
qu’elle fonctionne. Attendez que l’appareil se soit
complètement arrêté avant d’ouvrir le couvercle.
■ Ne mélangez pas de javellisant avec de l’ammoniaque
ou des acides (vinaigres ou décapant pour la rouille).
Ce mélange peut produire un gaz toxique et mortel.
■Ne lavez pas et ne séchez pas des articles qui ont été
lavés ou trempés dans des produits combustibles ou
explosifs (cire, huile, peinture, essence, dégraissants,
solvants de nettoyage à sec, kérosène, etc.). Ne versez
pas ces substances dans l’eau de lavage. N’utilisez pas
ces substances à proximité de votre laveuse ou
sécheuse pendant qu’elle fonctionne.
■La lessive peut atténuer les propriétés ignifugeantes
des tissus. Pour éviter cette situation, suivez les
directives données par le fabricant du vêtement.
■Pour réduire les risques de chocs électriques,
débranchez toujours l’appareil ou débranchez la
laveuse au panneau de distribution en enlevant le
fusible ou en déclenchant le disjoncteur avant de la
réparer ou de la nettoyer. REMARQUE : Le fait de régler
le sélecteur de programme sur une position d’arrêt ne
coupe PAS l’alimentation électrique de l’appareil.
■N’essayez jamais de faire fonctionner l’appareil s’il est
endommagé, défectueux, partiellement démonté, si
des pièces sont manquantes ou défectueuses ou si le
cordon d’alimentation ou la fiche est endommagé.
LORSQUE VOUS UTILISEZ LA LAVEUSE
■Fermez les robinets afin de réduire la pression et les
fuites si jamais un boyau ou l’électrovanne se brise ou
se rompt. Vérifiez l’état des boyaux de remplissage; il
faudra peut-être les remplacer au bout de 5 ans.
■ Avant de jeter ou d’entreposer une laveuse, enlevez le
couvercle de l’appareil afin d’empêcher les enfants de
se cacher à l’intérieur.
■Ne réparez et ne remplacez aucune pièce de cet
appareil, à moins que cela soit spécifiquement
recommandé dans le présent manuel ou dans des
directives de réparation que vous comprenez et que
vous êtes en mesure de suivre.
■Ne trafiquez pas les commandes de l’appareil.
LORSQUE LA LAVEUSE N’EST PAS UTILISÉE
Veuillez lire et suivre attentivement ces mesures de sécurité.
CONSERVEZ CES DIRECTIVES
17
N’utilisez
cet
appareil
que pour
l’usage
auquel il
est destiné,
comme
expliqué
dans le
présent
manuel.

Fonctionnement Mesures de sécuritéService à la clientèle Conseils de dépannage
18
Les commandes de votre laveuse.
Vous pouvez repérer le numéro de votre modèle à l’arrière du tableau de commande.
HEAVY 12
MEDIUM 10
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
EXTRA HEAVY 15 SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF SET
WARM
COLD
HOT
COLD
COLD
COLD
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
MEDIUM LARGE
LOAD SIZE TEMPERATURE EXTRA RINSE
SMALL SUPER
WASH/SPIN
SPEED
SensorWash
SPOT SOAK
SensorWash
Modèle WMSR3110
HEAVY 12
MEDIUM 10
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
15 MIN
AUTO SOAK
EXTRA HEAVY 15 SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF SET
WARM
COLD HOT
COLD
COLD
COLD
WARM
WARM
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
MEDIUM LARGE
LOAD SIZE TEMPERATURE EXTRA RINSE
SMALL SUPER
WASH/SPIN
SPEED
SensorWash
SensorWash
Modèles WPSL3120 et WPSR3120
HEAVY 12
MEDIUM 9
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
EXTRA HEAVY 15 SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF SET
WARM
COLD HOT
COLD
COLD
COLD
WARM
WARM
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
MEDIUM LARGE
LOAD SIZE TEMPERATURE EXTRA RINSE
SMALL SUPER
WASH/SPIN
SPEED
SensorWash
SensorWash
Modèle WASR3110
1 2 3 4
1 2 3 4
1 2 3 4

19
Service à la clientèleConseils de dépannageFonctionnementMesures de sécurité
HEAVY 12
MEDIUM 10
LIGHT SOIL 5
PERMANENT PRESS
KNITS
30 MIN
AUTO SOAK
15 MIN
AUTO SOAK
EXTRA HEAVY 15
COTTONS
DELICATES
EASY CARE
OFF SET
COLD
COLD HOT
COLD
WARM
COLD
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
MEDIUM
LOAD SIZE TEMPERATURE EXTRA RINSE
SMALL SUPER
LARGE
WASH/SPIN
SPEED
Modèle WPSR3100
HEAVY 12
MEDIUM 9
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
PREWASH
15 MIN
AUTO SOAK
EXTRA HEAVY 15
SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF
SPOT SOAK
SET
WARM
COLD HOT
COLD
COLD
COLD WARM
WARM
GENTLE
SLOW NORMAL
SLOW
GENTLE
FAST NORMAL FAST
EXTRA
LARGE EXTRA
SMALL
TEMPERATURE EXTRA RINSE
LARGE MEDIUM
SUPER RESET
WASH/SPIN
SPEED
LOAD SIZE
VARIABLE
SensorWash
SensorWash
Modèle WPSR4130
HEAVY 12
MEDIUM 9
LIGHT SOIL 6
PERMANENT PRESS
WRINKLE FREE COTTON
KNITS
30 MIN
AUTO SOAK
15 MIN
AUTO SOAK
EXTRA HEAVY 15
SOAK/WASH
COTTONS
HANDWASH
EASY CARE
OFF SET
WARM
COLD HOT
COLD
COLD
COLD WARM
WARM
GENTLE
SLOW NORMAL
FAST
GENTLE
FAST
EXTRA
LARGE EXTRA
SMALL
LOAD SIZE TEMPERATURE EXTRA RINSE
LARGE MEDIUM
SUPER RESET
WASH/SPIN
SPEED
VARIABLE
SensorWash
SensorWash
Modèle WSSR3120
1 2 3 4
1 2 3 4
1 2 3 4

Fonctionnement Mesures de sécuritéService à la clientèle Conseils de dépannage
Réglage des commandes.
20
Load Size (taille de brassée)
Le niveau d’eau doit être suffisant pour couvrir le linge. Réglez donc la taille de votre brassée en conséquence.
Assurez-vous que les vêtements ont suffisamment de place pour bouger librement et ne dépassent pas la rangée
supérieure de trous de la cuve.
Wash/Spin Speed (vitesse de lavage/essorage)
L’agitateur bouge les vêtements pour un lavage plus propre; le panier tourne en fin de programme pour que la
laveuse puisse enlever l’eau de lavage. Le cadran Wash/Spin Speed (vitesse de lavage/essorage) programme la
vitesse de l’agitateur et du panier.
Au réglage Normal, l’agitateur oscille plus rapidement pour le lavage des cotons, toiles et vêtements de jeu. Au
réglage Gentle (lent), l’agitateur oscille plus lentement pour le lavage des articles délicats et des tricots.
La vitesse d’essorage Fast (rapide) convient aux articles durables. La vitesse d’essorage Slow (lent) convient aux
articles délicats tels que les tricots et la lingerie. Les vêtements seront moins séchés que lorsque vous utilisez la
vitesse d’essorage Fast (rapide).
Temperature (température)
Sélectionnez une température d’eau pour les programmes de lavage et de séchage. Lors de la lessive, observez
toujours les directives données sur l’étiquette d’entretien du vêtement. Suivez le guide de température d’eau qui
figure sous le couvercle de la laveuse.
Programme de lavage
Le programme de lavage détermine la durée du lavage. Le tableau ci-dessous vous aidera à choisir le programme de
lavage qui convient à votre brassée.
COTTONS (cotons) Pour les cotons, le linge de maison et les vêtements de travail ou de jeu légèrement ou très sales.
EASY CARE (entretien facile) Pour les articles à entretien facile et ceux qui résistent aux faux-plis.
KNITS (tricots) Spécialement conçu pour les tricots normalement sales.
DELICATES (tissus délicats) Pour la lingerie fine et les tissus délicats légèrement ou normalement sales.
HANDWASH (lavage à la main) Pour la lingerie fine et les tissus à entretien spécial légèrement sales. Ce programme fournit des périodes
d’agitation et de trempage pendant le lavage et le rinçage.
EXTRA HEAVY (tissus très lourds) Pour les vêtements très sales et les toiles. Ce programme fournit une période d’agitation plus longue.
PREWASH (prélavage) Pour les vêtements très sales et ceux dont l’étiquette recommande un prélavage avant qu’ils soient portés.
AUTO SOAK (auto-trempage) Pour les tissus très sales et résistants. Ce programme fournit une agitation plus longue.
4
3
2
1
La logique des couleurs
Sélectionnez le programme de TEMPERATURE (température) correct. Faites correspondre la couleur particulière en
dessous des mots avec la même couleur dans le programme WASH/SPIN SPEED (vitesse de lavage/essorage) . Ensuite,
faites encore correspondre la couleur avec la même couleur sur le cadran.
Par exemple : Laver une brassée de blancs moyennement sales, comme des serviettes de bain et des draps.
Choisissez le programme de LOAD SIZE (taille de la brassée)
Choisissez le programme de TEMPERATURE -—pour cette brassée cela devrait être HOT COLD (eau chaude/froide)
(qui est d’une couleur particulière) .
Choisissez le programme de WASH/SPIN SPEED qui correspond à cette couleur —pour cette brassée cela devrait être
NORMAL FAST (normal rapide) .
Tournez le cadran de programme à l’endroit qui a la même couleur que TEMPERATURE et WASH/SPIN SPEED que
vous avez choisi—pour cette brassée cela devrait être COTTONS (cotons) . Ensuite, tournez le cadran sur le programme
de saleté MEDIUM (moyenne) .
4
3
2
1
