Owner’s Manual
Washers
Safety Instructions . . . . . . . . . .2, 3
Operating Instructions
Care and Cleaning
of the Washer . . . . . . . . . . . . . . . . . . . . . . 7
Control Panel . . . . . . . . . . . . . . . . . . . . . . .4
Control Settings . . . . . . . . . . . . . . . . .4–5
Features . . . . . . . . . . . . . . . . . . . . . . . . . .6, 7
Loading and Using
the Washer . . . . . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting Tips . . . . . .8–10
Consumer Support
Consumer Support . . . . . . . . . . . . . . . .12
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . .11
Write the model and serial
number here:
Model #
Serial #
You can find them
under the lid of
the washer.
G141
2
nInstall or store where it will not be exposed to
temperatures below freezing or exposed to the
weather, which could cause permanent damage
and invalidate the warranty.
nProperly ground washer to conform with all
governing codes and ordinances. Follow details
in Installation Instructions.
nThis washer does not include water supply hoses.
GE strongly recommends the use of factory
specified parts. A list of factory hoses available for
purchase are listed below. These hoses are
manufactured and tested to meet GE
specifications.
GE strongly recommends the use of new water
supply hoses. Hoses degrade over time and need
to be replaced every 5 years to reduce the risk of
hose failures and water damage.
Parts and Accessories
To order, please call 1.800.661.1616 or contact your
local GE parts supplier.
Part Number Accessory
WH41X10207 4 ft Rubber Water Supply Hose
WX14X10005 4 ft Braided Water Supply Hose
IM ORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING! 36=3967%*)8=8,)-2*361%8-32-28,-71%29%01978&)*3003;)(831-2-1->)8,)6-7/
3**-6)36)<4037-32)0)'86-'7,3'/368346):)284634)68=(%1%+)4)6732%0-2.96=
3603773*0-*)
" $
!2()6')68%-2'32(-8-327,=(63+)2+%71%=&)463(9')(-2%;%8)6,)%8)68,%8,%7238&))2
97)(*368;3;))/736136)=(63+)2+%7'%2&))<4037-:)92()68,)7)'-6'9178%2')7
If the hot water has not been used for two weeks or more, prevent the possibility of damage or injury by turning
on all hot water faucets and allowing them to run for several minutes. Do this before using any electrical
appliance which is connected to the hot water system. This simple procedure will allow any
built-up hydrogen gas to escape. Since the gas is flammable, do not smoke or use an open flame or
appliance during this process.
,-7;%7,)61978&)4634)60=-278%00)(%2(03'%8)(-2%''36(%2');-8,8,)278%00%8-32
27869'8-327&)*36)-8-797)(*=39(-(2386)')-:)%2278%00%8-3227869'8-3277,))8=39'%2
6)')-:)32)&=:-7-8-2+GEAppliances.ca 36&='%00-2+1.800.561.3344
$!!$
neep the area underneath and around your
appliances free of combustible materials such as
lint, paper, rags, chemicals, etc.
nClose supervision is necessary if this appliance is
used by or near children. Do not allow children to
play on, with or inside this or any other appliance.
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
3
!7)8,-7
%440-%2')
320=*36-87
-28)2()(
496437)%7
()7'6-&)(-2
8,-7;2)6A7
%29%0
GEAppliances.ca
"! "
nNever reach into the washer while it is moving.
Wait until the machine has completely stopped
before opening the lid.
nDo not mix chlorine bleach with ammonia
or acids such as vinegar and/or rust remover.
Mixing different chemicals can produce a toxic gas
which may cause death.
nDo not wash or dry articles that have been
cleaned in, washed in, soaked in or spotted with
combustible or explosive substances (such as
wax, oil, paint, gasoline, degreasers, dry-cleaning
solvents, kerosene, etc.). These substances give off
vapors that may ignite or explode. Do not add
these substances to the wash water. Do not use or
place these substances around your washer or
dryer during operation.
nThe laundry process can reduce the flame
retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s
wash and care instructions.
nTo minimize the possibility of electric shock,
unplug this appliance from the power supply
or disconnect the washer at the building’s
distribution panel by removing the fuse or
switching off the circuit breaker before attempting
any maintenance or cleaning.
NOTE: 962-2+8,)='0))0)'83623&83%23**
437-8-323646)77-2+!(3)7 NOT (-7'322)'8
8,)%440-%2')*6318,)43;)679440=
nNever attempt to operate this appliance if it is
damaged, malfunctioning, partially disassembled,
or has missing or broken parts, including a
damaged cord or plug.
" !
nTurn off water faucets to relieve pressure on hoses
and valves and to minimize leakage if a break or
rupture should occur. Check the condition of the fill
hoses; GE recommends changing the hoses every 5
years.
nBefore discarding a washer, or removing it
from service, remove the washer lid to prevent
children from hiding inside.
nDo not attempt to repair or replace any part
of this appliance unless specifically recommended
in this Owner’s Manual, or in published user-repair
instructions that you understand and have
the skills to carry out.
nDo not tamper with the controls.
" $
!$
SAVE THESE INSTRUCTIONS
4
Quick Start Guide
About the control panel—for models with START button.
Signal
nSelect for an end of cycle signal.
Temperature
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care label or instructions when
laundering.
erfecTemp senses the incoming water temperature and adjusts the fill water to obtain a more precise temperature range for all wash
temperatures. For example, in a COLD wash selection, some warm water may be added to reach a temperature needed to better
dissolve detergents. Often, detergents are not completely dissolved in very cold water, especially in cooler climates.
During winter months, when the water entering your home is colder, or for locations with very cold water year round, use the
erfecTemp plus COLD to help dissolve powdered detergents and to improve the cleaning of your clothes.
The TA COLD feature turns the erfecTemp feature on your washer off and uses your household tap water temperature for a COLD
wash. This can provide energy savings by reducing the amount of hot water used in your wash. Cold waster will be added to hot water
to optimize performance.
Options
2nd Rinse Option 32731)13()07
When you use extra detergent or bleach to clean heavily soiled clothes, you may want to use the 2nd Rinse option.
It provides an enhanced second cold rinse.
Extended Spin Option 32731)13()07
Use this option to extract more water from your clothes. Clothes will be drier when this option is selected and will dry more quickly in
your dryer.
Fabric Softener
Set this option when adding fabric softener to the washer.
NOTE: 323897)*%&6-'73*8)2)6(-74)27-2+&%007;-8,8,-7;%7,)6 ,)=(3238;36/'366)'80=-2,-+,)**-'-)2'=;%7,)67
3286307
• Add fabric softener (on models
with a fabric softener dispenser);
see page 6 for details
• Add detergent. GE recommends
the use of High Efficiency
detergents in all Energy
Star-rated washers
• Select wash options,
including Fabric
Softener option
• Select wash cycle
• Push S AR
Step 2 Step 3 Step 4
• Loosely add items around infusor.
Overloading may negatively impact
wash performance. Adjust the load
size accordingly.
• Close lid
NO E: Washer will not start to fill
with lid open.
A
B
C
A B C
D
E F
SIGNAL EMPERA URE OP IONS
S AR
S OP/PAUSE
5
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
GEAppliances.ca
Status Indicator Lights
The Cycle Indicator Lights show what stage the washer is in. When the Selector knob is set to a new cycle, the Indicator
Lights will flash momentarily, showing what stages the cycle will go through. On models without an AUTO SOAK option,
the SOA light will not light up.
Wash Cycle—Cycle Selector Knob
The wash cycle controls the length and intensity of the washing process. The knob can be turned in either direction.
Turning the Cycle Selector knob after starting a cycle will stop the washer and reset the cycle to the new selection. Press
STAR to begin the new cycle selection.
The chart below will help you match the wash cycle setting with your clothing.
CO ONS (Regular Wash/Fast Spin) For heavy to lightly soiled cottons, household linens, work and play clothes.
This
cycle provides the best overall cleaning and should be used for most everyday items. Provides a high speed spin.
PREWASH For removing surface dirt from heavily soiled clothes. Make sure to follow with a
regular wash cycle.
CASUALS (Gentle Wash/Slow Spin) For wrinkle-free and permanent press items and knits. Provides a low speed spin.
EASY CARE (Gentle Wash/Fast Spin) For wrinkle-free and permanent press items and knits. Provides a high speed spin.
DELICA ES (Extra Gentle Wash/Slow Spin)
For lingerie and special-care fabrics with light soil. Provides a low speed spin.
DRAIN & SPIN OR SPIN ONLY (Fast Spin) For draining the tub and spinning water out of the clothes. Provides a high
speed spin.
QUICK RINSE (Fast Spin) Rinses and spins non-soiled items where a rinse only is desired. Provides a high speed spin.
START
Press START to begin the cycle. Pressing START again will AUSE the cycle and the Cycle indicator light will blink.
To continue the cycle, press START again or close the lid. If machine is paused more than 24 hours, the cycle will be
cancelled. To stop the cycle, hold the button for 3 seconds. If water remains in the machine, select the DRAIN & S IN
OR S IN ONLY cycle to drain tub and spin water out of the washer tub.
Raising the lid will stop agitation or spin action but does not pause the cycle.
D
E
F
This model has AUTOMATIC LOAD SENSING. This selection provides the correct amount of water suited to the size and
type of load placed in the unit.
- The washer will not fill with water during automatic load sensing if the lid is open. When the lid is closed the machine
is able to begin filling with water in order to sense the load size.
Note: ,-7-7%,-+,)**-'-)2'=;%7,-2+1%,-2);-8,2*9736
;%7,%'8-32 ,-77=78)16)59-6)70)77;%8)6;,-0)
463:-(-2+)**)'8-:)'0)%2-2+%'8-32$391%=238-')8,%88,);%8)60):)0-703;)68,%232=39646):-397;%7,)6 ,-7-7
2361%0*36%22*9736
)59-44)(;%7,)6
Liquid Bleach Funnel
The water fill dilutes liquid chlorine bleach as the washer fills for the wash cycle.
Check clothing care labels for special instructions.
Measure liquid bleach carefully, following instructions on the bottle.
n ):)6439692(-098)(0-59-(',036-2)&0)%',(-6)'80=3283'038,)736-2838,);%7,&%7/)8
n 3238439643;()6)(&0)%',-283&0)%',*922)0
Before starting the washer, pour measured amount of bleach directly into bleach funnel.
Avoid splashing or over-filling dispenser. If you prefer to use powdered bleach, add it into
the wash basket with your detergent.
n 32381-<',036-2)&0)%',;-8,%1132-%36%'-(779',%7:-2)+%6%2(3669786)13:)6
-<-2+'%2463(9')%83<-'+%7;,-',1%='%97)()%8,
3
2
1
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
6
About washer features.
Cleaning the Fabric Softener Dispenser 32731)13()07
The Fabric Softener Dispenser is self cleaning. This dispenser does not require regular cleaning
like standard fabric softener dispensers. Wipe down exterior surfaces of the dispenser
as needed. If cleaning of the internal dispenser components is needed, follow these steps
after the wash cycle is complete:
The Fabric Softener Dispenser 32731)13()07
Lift the tab on the fabric softener
dispenser top.
Measure out fabric softener into
the cap and pour the softener into
the dispenser top. The fabric softener
will drain into the receiving cup inside
the dispenser. Use only “Ultra” or
concentrated fabric softeners.
Push down on the tab to close
the dispenser top. Make sure the tab
is pushed down fully and snaps shut.
Select FABRIC SOFTENER from SETTINGS
on the control panel.
NOTE: Overfilling the dispenser will cause
fabric softener to drain out of the holes in the
side of the infusor when filling. Do not overfill.
4
3
2
1
OPTIONS
FABRIC SOFTENER
With
2nd RINSE
OFF
EXT.
SPIN
2nd
RINSE
The fabric softener dispenser %9831%8-'%00=6)0)%7)70-59-(*%&6-'73*8)2)6%88,)4634)68-1)
(96-2+8,)'='0)
Do not stop the washer or raise the lid during the first spin. This will cause the dispenser to
empty
too soon.
Never pour fabric softener directly on clothes. This may cause stains on your clothing.
397)*3003;8,)7)78)47
Lift the dispenser top tab and turn the top
counterclockwise using the 2 turning tabs
shown. Lift the dispenser out of the
Infusor™.
Clean out any buildup from inside the
Infusor™ with a soft cloth or toothbrush.
Ensure the three rectangular holes
in the bottom which allow the fabric
softener to drain are not blocked.
Gently pull the cap away from
the dispenser cup to separate.
Wipe surfaces with a soft cloth or soak
the parts in a solution of 1 gallon warm
water, 1/4 cup liquid detergent and 1 cup
bleach. Ensure the small hole in the top
surface of the cap and associated tube
are not obstructed.
Reassemble the dispenser cup and cap
by snapping them together.
Place the dispenser assembly into
the Infusor™. Turn the top clockwise
using the 2 turning tabs shown. Push
down on the tab to close the dispenser
top. Make sure the tab is pushed down
fully and snaps shut.
2
6
5
4
3
1
1
2
3
4
Tab
Turning Tabs
Turning Tabs
1
3
5
6
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
7
GEAppliances.ca
Loading and using the washer.
0;%=7*3003;*%&6-'1%29*%'896)6A7'%6)0%&)0;,)20%92()6-2+
368-2+"%7,3%(7
Sort by color (whites, lights, colors), soil level,
fabric type (sturdy cottons, easy care, delicates)
and whether the fabric produces lint (terry cloth,
chenille) or collects lint (velveteen, corduroy).
634)6!7)3*)8)6+)28
Add detergent and fabric softener before adding
items so that the detergent can work effectively.
Using too little or too much detergent is a common
cause of laundry problems.
Use less detergent if you have soft water, a smaller
load or a lightly soiled load.
For spots, apply pre-treatment to items as
recommended on the product label. Application
should be made in the basket to prevent overspray
which may cause the coloring on the lid or graphics
to fade.
GE recommends the use of High Efficiency
detergents in all Energy Star rated washers.
HE detergents are formulated to work with low water
wash and rinse systems. HE detergents reduce
the oversudsing problems commonly associated
with regular detergents.
When using high efficiency or concentrated
detergents, consult the product label to determine
amount required for optimum performance.
Excessive detergent will negatively impact wash
performance.
3%(-2+8,)"%7,)6
Load dry items loosely in the washer basket. For best
results, load items evenly and loosely around the
outside of the basket. To add items after washer has
started, lift the lid and submerge additional items
around the outside of the basket.
n323840%')0%6+)-8)1779',%77,))87&0%2/)87
%2(83;)07%'63778,)2*9736?3%(8,)1%6392(
8,)3987-()3*8,)&%7/)8
n3238;%7,*%&6-'7'328%-2-2+*0%11%&0)
1%8)6-%07;%<)7'0)%2-2+*09-(7)8'
n"%7,)6;-00238%+-8%8)3674-2;-8,8,)0-(94
,3;):)68,)8-1)6;-00'328-29)83692
Care and cleaning of the washer.
Wash Basket: Leave the lid open after washing to allow
moisture to evaporate. If you want to clean
the basket, use a clean, soft cloth dampened with liquid
detergent; then rinse. (Do not use harsh or
gritty cleaners.)
Fill Hoses: GE recommends changing the hoses
every 5 years.
Exterior: Immediately wipe off any spills. Wipe
with damp cloth. Try not to hit surface with
sharp objects.
Interior: The occasional use of a cycle that contains
bleach will keep the inside of the washer clean.
Glass Lid: Use a clean, soft cloth dampened with vinegar
and water solution.
Note: Do not use any cleaners that contain ammonia.
Moving and Storage: Ask the service technician
to remove water from drain pump and hoses.
See the Installation Instructions packed with product for
information on how to reinstall the shipping
rod to keep the tub stationary when moving
the washer. For more information, visit GEAppliances.ca
or call 1.800.561.3344. Do not store the washer where it
will be exposed to the weather.
Long Vacations: Be sure water supply is shut off
at faucets. Drain all water from hoses if weather will
be below freezing.
WATER ossible Causes What To Do
Water level seems low his is normal • Water may not cover the top level of the clothes.
This is normal for this high-efficiency washer.
Water fills and drains Drain stand pipe is too low • The drain stand pipe must be above 30".
at the same time
Too many suds oo much detergent • Measure your detergent carefully. Use less soap if you have
soft water, a smaller load or a lightly soiled load.
ype of detergent • Switch to HE detergent.
Soft water • Try less detergent.
Water leaks Using too much detergent • Use less detergent. Use less soap if you have soft water,
in washer a smaller load or a lightly soiled load.
ype of detergent • Switch to HE detergent.
Fill hoses or drain hose is • Make sure hose connections are tight at faucets and
improperly connected rubber washers are installed. Make sure end of drain hose
is correctly inserted in and secured to drain facility.
Household drain may • Check household plumbing. You may need to call
be clogged a plumber.
Drain hose is loose • Make sure drain hose is fully seated in back of washer and
that the two retaining screws are fully seated.
Drain hose rubs on wall • Make sure drain hose does not make contact with the wall.
May cause excessive wear on the hose.
Constant water pressure • Tighten hoses at the faucets and turn the water off after
to the fill hoses at the each use.
water source •Check condition of the fill hoses; they should be replaced
every 5 years.
Water temperature Cooler water temperatures • New laundry detergents have been formulated to work
seems incorrect provide improved energy with cooler water temperatures without affecting wash
efficiency performance.
Water supply is turned off • Turn both hot and cold faucets fully on and make sure
or improperly connected hoses are connected to correct faucets.
Water valve screens are • Turn off the water source and remove the water connection
stopped up hoses from the upper back of the washer. Use a brush or
toothpick to clean the screens in the machine. Reconnect
the hoses and turn the water back on.
Cool/Cold Water when • This is normal. PerfecTemp senses water temperature and
selecting Hot optimizes for best results. Cold water is added periodocally
when hot is selected.
House water heater is • Make sure house water heater is delivering water at
not set properly 120°F–140°F (48°C–60°C).
Water pumped out before Lid lifted or cycle was put in • Reset cycle.
cycle is complete pause for over 24 hours
Water won’t drain Drain hose is kinked or • Straighten drain hose and make sure washer is not
improperly connected sitting on it.
•Top of drain outlet should be less than 6 ft (1.8 m)
above floor.
Washer pauses during he REWASH Cycle or • This is normal. The washer alternates between agitate and
wash cycle AUTO SOAK Option was soak during these cycles to get your clothes cleaner with
chosen less wear.
Washer pauses during his is normal • The washer may pause during the spin cycle to remove
spin cycle soapy water more efficiently.
Washer does not fill his is normal • The lid must be closed for washer to fill or operate.
when lid is open
639&0)7,338-2+ -47
%:)8-1)%2(132)=):-);8,)',%687328,)*3003;-2+4%+)7
36:-7-8GEAppliances.ca. $391%=2382))(83'%00*367)6:-')
Before you call for service…
8
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
O ERATION ossible Causes What To Do
Washer won’t operate Washer is unplugged • Make sure cord is plugged securely into a working outlet.
Water supply is turned off • Turn both hot and cold faucets fully on.
Controls are not set properly • Check controls.
Lid is open—safety feature • Close lid and reset cycle, to the beginning if necessary.
prevents agitation and
spinning when lid is up
Circuit breaker/fuse is • Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have a separate outlet.
Electronics need to be reset • Unplug washer, wait 2 minutes, plug back in and press START.
START was not pressed • Press START.
Lid magnet missing • Call for service.
Time not shown Unit filling • This is normal. Estimated time remaining is updated during
on display fill time.
Movement inside machine Shifting mechanism is • When the machine is manually turned off, the shifter will
when shut off disengaging the motor disengage the motor before completely shutting down.
If lid is raised before the motor is disengaged, it will resume
when lid is closed.
Basket seems loose Basket moves or rotates freely • Washer basket does not have a traditional brake. Basket will
move freely. This is normal.
ERFORMANCE ossible Causes What To Do
Clothes too wet Incorrect cycle selected. • Make sure the cycle selected matches the load you are
washing. Some fabrics will feel wetter when rinsed with cold water.
Wash load out of balance •
Redistribute load in washer and run through Drain & Spin cycle.
Colored spots Incorrect use of fabric • Check fabric softener package for instructions and follow
softener directions for using dispenser.
•Make sure you have selected the Fabric Softener option.
•Pretreat stain and rewash.
Dye transfer • Sort whites or lightly colored items from dark colors.
Grayed or yellowed Detergent amount • Be sure to follow detergent manufacturer’s directions.
clothes Hard water • Use a water conditioner like Calgon brand or install
a water softener.
Water is not hot enough • Make sure water heater is delivering water at
120°F–140°F (48°C–60°C).
Washer is overloaded • Loosely load clothes no higher than the top row of holes in the
washer basket. For best results, load items around the outside
of the basket.
Detergent is not • Add detergent to the wash basket before you load clothes.
dissolving
Dye transfer • Sort clothes by color. If fabric label states ;%7, 7)4%6%8)0=
unstable dyes may be indicated.
Lint or residue on Clothes are air or line dried • If you do not dry your clothes with a clothes dryer, your
clothes clothes may retain more lint.
Incorrect sorting • Separate lint producers from lint collectors.
Washing too long • Wash small loads for a shorter time than larger loads.
Detergent not dissolving • Add detergent to wash basket before you load clothes.
•Try a liquid detergent.
•Use warmer water temperature.
Overloading • Loosely load clothes in the washer basket. For best results, load
items around the outside of the basket.
Incorrect use of fabric • Check fabric softener package for instructions
softener and follow directions for using dispenser.
•Make sure you have selected the Fabric Softener option.
GEAppliances.ca
9
Operating Instructions Safety InstructionsConsumer Support Troubleshooting Tips
Before you call for service…
ERFORMANCE (cont.) ossible Causes What To Do
illing Result of normal wear on • While this is not caused by the washer, you can slow the
poly-cotton blends and pilling process by washing garments inside out.
fuzzy fabrics
Snags, holes, tears, rips Pins, snaps, hooks, sharp • Fasten snaps, hooks, buttons and zippers.
or excessive wear buttons, belt buckles, •Remove loose items like pins, objects in pockets and
zippers and sharp objects sharp buttons.
left in pockets •Turn knits (which snag easily) inside out.
Undiluted chlorine bleach • Check bleach package instructions for proper amount.
•Never add undiluted bleach to wash or allow clothes to
come in contact with undiluted bleach.
Chemicals like hair bleach or • Rinse items that may have chemicals on them before
dye, permanent wave solution washing.
Wrinkling Improper sorting • Avoid mixing heavy items (like work clothes) with light items
(like blouses).
•Try a fabric softener.
Overloading or incorrect • Loosely load clothes in the washer basket.
water level
Incorrect wash and • Match Cycle selection to the type of fabric you are washing
dry cycles (especially for easy care loads).
Repeated washing in • Wash in warm or cold water.
water that is too hot
SOUNDS ossible Causes What To Do
“Metallic clicking” Shifter mechanism is • The drive system will engage at the start of agitate and
engaging or disengaging disengage when agitate is complete. This occurs multiple
times during the wash.
Back and forth “swoosh” Electric motor reversing • This machine has a drive system that doesn’t use gears.
or light “clicking” sound direction This sound is the motor rotating back and forth to clean
during agitate your laundry.
Quick short agitation Clothing redistribution • At the end of agitate, the motor makes short agitation strokes
sounds at end of agitate to redistribute the load.
“Click” when water Relay switch • The relay makes a click sound when activated. The water
stops filling level activates the relay and stops filling.
“Clicking” behind Control Automatic emperature • This valve mixes in cold and hot water. The “clicking” is the
anel during fill Control Valve valve turning on and off.
Water volume changes Automatic emperature • This valve mixes in cold and hot water. The sound changes
during fill Control Valve when the valves are turned on and off.
Motor “whining up” or Motor ramping up/down • The motor will speed up incrementally during the spin cycle.
“coasting down” in spin during spin cycle When spin is complete, it will coast until it stops.
“Humming” Water drain pump • The drain pump will make a humming sound when pumping
out water after agitation stops and continue until spin is
complete.
“Gurgling” Water drain pump • When the pump starts drawing in air, It starts to gurgle.
The washer should then begin spinning and the sound will
continue until it is done spinning.
Water “swishing” his is normal
•This washer uses a Infusor™ wash action. Water swishing while
the unit is agitating is normal, especially with smaller loads.
Washer is noisy Washer is uneven • To level the front of the washer, adjust the front leveling legs
by rotating the individual leg in the proper direction for up
or down. To level the back of the washer, lift the back
of the machine 4" (11 cm) and set down.
Shipping rod is still assembled • To remove the shipping rod from the washer, pull the yellow
in the unit tag and attached rod from the bottom right hand side
of the washer.
10
639&0)7,338-2+ -47
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions
11
8%40)=3966)')-48,)6)
633*3*8,)36-+-2%0496',%7)
(%8)-72))()(833&8%-27)6:-')
92()68,);%66%28=
GE Washer Warranty.
For The eriod Of: We Will Replace:
One Year Any factory specified part of the washer which fails due to a defect in materials or workmanship.
6318,)(%8)3*8,) During this limited one-year warranty, GE will also provide, free of charge, all labor and related
36-+-2%0496',%7) service costs to replace the defective part.
What Is Not Covered:
,-7;%66%28=-7)<8)2()(838,)36-+-2%0496',%7)6%2(%2=79''))(-2+3;2)6*36463(9'87496',%7)(-2%2%(%*36,31)97)
;-8,-2%2%(%2,31);%66%28=7)6:-');-00&)463:-()(-2%6)%7;,)6)-8-7%:%-0%&0)%2(()1%2(6)%732%&0)&=%&)83
463:-()
31)78%8)736463:-2')7(3238%003;8,))<'097-32360-1-8%8-323*-2'-()28%036'327)59)28-%0(%1%+)7738,)%&3:))<'097-32
1%=238%400=83=39 ,-7;%66%28=+-:)7=3974)'-*-'0)+%06-+,87%2(=391%=%073,%:)38,)66-+,87;,-',:%6=*631463:-2')83
463:-2') 3/23;;,%8=3960)+%06-+,87%6)-2=396463:-2')'327908=39603'%036463:-2'-%0'32791)6%**%-673**-')
Warrantor: Mabe Canada Inc.,
Burlington, Ontario
nService trips to your home to teach you how to use
the product.
nImproper installation, delivery or maintenance.
nFailure of the product if it is abused, misused, or
used for other than the intended purpose or used
commercially.
nReplacement of house fuses or resetting of circuit
breakers.
nDamage caused after delivery.
nDamage to the product caused by accident, fire, floods
or acts of God.
nIncidental or consequential damage caused by possible
defects with this appliance.
nProduct not accessible to provide required service.
#!" @$396730)%2()<'097-:)6)1)(=-7463(9'86)4%-6%7463:-()(-28,-7-1-8)("%66%28=
2=-140-)(;%66%28-)7-2'09(-2+8,)-140-)(;%66%28-)73*1)6',%28%&-0-8=36*-82)77*36%4%68-'90%6496437)%6)0-1-8)(83
32)=)%6368,)7,368)784)6-3(%003;)(&=0%;
00;%66%28=7)6:-')463:-()(&=396%98,36->)(7)6:-')')28)67
367)6:-')'%001.800.561.3344.
0)%7),%:)7)6-%0291&)6%2(13()0291&)6%:%-0%&0);,)2
'%00-2+*367)6:-')
6-28)(-28,)!2-8)(8%8)7
12
Consumer Support.
440-%2')7")&7-8) wwwgeappliances.ca
Have a question or need assistance with your appliance? Visit our Website, www.geappliances.ca, 24 hours a
day, and any day of the year!
',)(90))6:-') 1.800.561.3344
Expert GE repair service is close to you.
To arrange service for your GE appliance, all you have to do is call.
)%0-*))7-+289(-3 GEAppliances.ca
Upon request, GE can provide a brochure on designing a kitchen for persons with limitedmobility.
Contact : Manager, Consumer Relations, Mabe Canada Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3.
%687%2('')7736-)7 GEAppliances.ca
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted).
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
$39;-00*-2(8,)2)%6)78%&))6:-'))28)6-28,)=)003;4%+)73*=3964,32)&33/6'%0097%8
328%'8!7
If you are not satisfied with the service you have received
First of all, communicate with the people who repaired your appliance.
hen, if you are still not satisfied, send all information including telephone number to:
Director,l Consumer Relations, Mabe Canada Inc.
Suite 310, 1 Factory Lane
Moncton, N.B. E1C 9M3
)+-78)6$396440-%2') www.geappliances.ca
Register your new appliance on-line—at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise.
You may also mail in the pre-printed registration card included in the packing material.
ELECTROMENAGER GE.CA
Manuel d’utilisation
Laveuse
49-90416-1 09/02/10 GE
Consignes de sécurité
Consignes d’utilisation
7=;/=3/7/=7/==8B+1/
./5+5+?/></
#+77/+>./-866+7./5
$I15+1/./<-866+7./<T
87-=387<
2+;1/6/7=/='=353<+=387
./5++?/></
Conseils de dépannage T
Assistance à la clientèle
<<3<=+7-/F5+-53/7=J5/
+;+7=3/
Inscrivez ici les numéros de
modèle et de série :
Numéro de modèle
Numéro de érie
/<7>6I;8<<87=
37<-;3=<<8><5/-8>?/;-5/
./5+5+?/></
G141
n7<=+55/C8>/7=;/98</C?8=;/+99+;/35.+7<>7
/7.;83=8N357/</;+9+</A98<I+>1/58>+>A
37=/69I;3/<:>398>;;+3/7=-+></;./<.866+1/<
9/;6+7/7=</=+77>5/;5+1+;+7=3/
n/==/C-8;;/-=/6/7=5+5+?/></F5+=/;;/
-8708;6I6/7=F=8><5/<-8./</=;J15/6/7=</7
?31>/>;%>3?/C=8><5/<.I=+35<.877I<.+7<5/<
7<=;>-=387<.V7<=+55+=387
n/==/C-8;;/-=/6/7=5+5+?/></F5+=/;;/
-8708;6I6/7=F=8><5/<-8./</=;J15/6/7=</7
?31>/>;%>3?/C=8><5/<.I=+35<.877I<.+7<5/<
7<=;>-=387<.V7<=+55+=387
?8><;/-866+7./08;=/6/7=.V>=353</;./<
=>B+>A.V+536/7=+=387/7/+>7/>0/<=>B+>A</
.I1;+./7=+?/-5/=/69</=.83?/7=K=;/;/695+-I<
=8><5/<+7<98>;;I.>3;/5/;3<:>/./;>9=>;/./<
=>B+>A/=8>./.I1G=<./</+>A
Pièces et accessoires
99/5/C5/8>-87=+-=/C?8=;/
6+;-2+7../93J-/<58-+5
!>6I;8./93J-/ --/<<83;/
)* &>B+>/7-+8>=-28>-./93
6J=;/<98>;5V+536/7=+=387/7/+>
)** &>B+>=;/<<I./936J=;/<
98>;5V+536/7=+=387/7/+>
IMPORTANTE CON IGNE DE ÉCURITÉ
VEUILLEZ LIRE TOUTE LE CON IGNE AVANT UTILI ATION.
AVERTI EMENT! Pour votre sécurité, les informations contenues dans ce manuel
doivent être suivies afin de minimiser les risques d'incendie ou
d’explosion, de chocs électriques et d'éviter les dommages , les
blessures corporelles voire la mort.
SÉCURITÉ DU CHAUFFE-EAU
Dans certaines conditions, de l’hydrogène gazeux peut être produit dans un chauffe-eau lorsque
ce dernier n’a pas été utilisé pendant deux semaines ou plus. Dans ces conditions, l’hydrogène
gazeux peut provoquer une explosion.
%3?8><7V+?/C9+<>=353<I5V/+>-2+>././9>3<95><././>A</6+37/<I?3=/C=8>=.866+1/8>,5/<<>;//7
8>?;+7==8><5/<;8,37/=<.V/+>-2+>.//=/75/<5+3<<+7=-8>5/;9/7.+7=:>/5:>/<637>=/<00/-=>/C-/1/<=/
+?+7=.V>=353</;=8>=+99+;/35I5/-=;86I7+1/;,;+7-2I+><B<=J6/.V/+>-2+>.//==/9;8-I.>;/<3695/
9/;6/=F=8>=/+-->6>5+=387.V2B.;81J7/1+C/>A./<I-2+99/;866/-/1+C/<=3705+66+,5/7/0>6/C
9+<7V>=353</C9+<./05+66/?3?/8>.V+99+;/35I5/-=;86I7+1/;9/7.+7=-/==/9;8-I.>;/
INSTALLATION CORRECTE
Cette laveuse doit être correctement installée et positionnée conformément aux Instructions
d’Installation avant toute utilisation. Si vous n’avez pas reçu de fiche contenant les consignes
d’installation, vous pouvez vous en procurer une sur le site ELECTROMENAGER GE.CA ou en
appelant le 1.800.561.3344.
VOTRE AIRE DE LESSIVE
n+;./C5+C87/+>=8>;/=/7./<<8><./5+5+?/></
9;89;//=/A/69=/./=8>=6+=I;3+>-86,><=3,5/
=/5:>/./<-2+;93/<.>9+93/;./<-230087<8>./<
9;8.>3=<-2363:>/<
n'7/<>;?/355+7-/+--;>//<=7I-/<<+3;/58;<./
5V>=353<+=387./-/=+99+;/35/79;I</7-/.V/70+7=<
!/5/>;9/;6/==/C9+<./48>/;<>;5/./<<><+?/-
8>.+7<-/==/5+?/></8>+?/-=8>=+>=;/+99+;/35
I5/-=;86I7+1/;
Consignes d’utilisation Consignes de sécuritéAssistance à la clientèle Conseils de dépannage
Assistance à la clientèleConseils de dépannageConsignes d’utilisationConsignes de sécurité
N’utilisez cet
appareil
qu’aux fins
prévues
décrites
dans le
manuel
d’utilisation
electromenagersge.ca
LORS UE VOUS UTILISEZ VOTRE LAVEUSE
n!V/<<+B/C4+6+3<.V8>?;3;?8=;/5+?/></58;<:>/
-/55/-3/<=/76+;-2/==/7./C:>/5+6+-237/<83=
-8695J=/6/7=+;;K=I/+?+7=.V8>?;3;5/-8>?/;-5/
n!/6I5+71/C4+6+3<./4+?/553<+7=+?/-./
5V+66873+:>/8>./<+-3./<=/5<:>/.>?37+31;/
/=8>./5V+7=3;8>355//6I5+71/./<.300I;/7=<
9;8.>3=<-2363:>/<9/>=9;8.>3;/./<1+C=8A3:>/<
98>?+7=/7=;+L7/;5+68;=
n!/5+?/C9+</=7/<I-2/C9+<./<+;=3-5/<+B+7=
I=I7/==8BI<5+?I<=;/69I<8>=+-2I<9+;./<
<>,<=+7-/<-86,><=3,5/<8>/A958<3?/<=/55/<:>/
5+-3;/5V2>35/5+9/37=>;/5/<</7-/5/<<>,<=+7-/<
.I1;+3<<+7=/<5/<<85?+7=<./7/==8B+1/F</-5/
9I=;85//=-/<<>,<=+7-/<9/>?/7=.I1+1/;./<
?+9/>;<:>39/>?/7=<V/705+66/;8>/A958</;
!V+48>=/C9+<-/<<>,<=+7-/<F5V/+>./5+?+1/
!V>=353</C9+</=7/95+-/C9+<-/<<>,<=+7-/<
+>=8>;./?8=;/5+?/></8>./?8=;/<I-2/></
9/7.+7=5/>;087-=3877/6/7=
n/9;8-/<<><./5+?+1/9/>=;I.>3;/5+;I<3<=+7-/
+>A05+66/<./<=3<<><#8>;I?3=/;./=/5<
;I<>5=+=<<>3?/C<8317/></6/7=5/<37<=;>-=387<./
5+?+1//=.V/7=;/=3/7.877I/<9+;5/0+,;3-+7=./
?K=/6/7=<
n#8>;;I.>3;/5/;3<:>/./-28-I5/-=;3:>/
.I,;+7-2/C5V+99+;/35./5+536/7=+=387I5/-=;3:>/
8>.I,;+7-2/C5+5+?/></+>73?/+>.>9+77/+>
./.3<=;3,>=387/7;/=3;+7=5/0><3,5/8>.I-5/7-2+7=
5/.3<487-=/>;+?+7=./7=;/9;/7.;/=8>=/+-=3?3=I
.V/7=;/=3/78>./7/==8B+1/
REMARQUE: L’appareil n’est pas déconnecté de
l’alimentation électrique lorsque vous faites tourner
le bouton de sélection de programme sur la position
Arrêt ou lorsque vous appuyez sur Pause.
n!V/<<+B/C4+6+3<./0+3;/087-=3877/;-/=+99+;/35
<V35/<=/7.866+1I<V357/087-=3877/9+<
-8;;/-=/6/7=<V35/<=9+;=3/55/6/7=.I687=I8><3
-/;=+37/<./<93J-/<<87=6+7:>+7=/<8>-+<<I/<
B-869;3<<35/-8;.87.V+536/7=+=387/<=
/7.866+1I
LORS UE VOUS N’UTILISEZ PAS VOTRE LAVEUSE
n/;6/C5/<;8,37/=<.V/+>98>;;I.>3;/5+9;/<<387
.+7<5/<=>B+>A/=5/<;8,37/=</=98>;.3637>/;5/
;3<:>/./0>3=//7-+<./-+<<>;/8>./;>9=>;/
(I;303/C5VI=+=./<=>B+>A.V+536/7=+=387?8><
;/-866+7././5/<-2+71/;=8><5/<+7<
n?+7=./6/==;/?8=;/5+?/></+>;/,>=8>./5+
6/==;/28;<</;?3-/;/=3;/C5/-8>?/;-5/98>;I?3=/;
:>/5/</70+7=<7/</-+-2/7=F5V37=I;3/>;
n!V/<<+B/C9+<./;I9+;/;8>./;/695+-/;>7/
93J-/./5V+99+;/35F6837<.>7/;/-866+7.+=387
9;I-3</F-/=/00/=.+7<-/6+7>/58>.+7<./<
37<=;>-=387<./;I9+;+=3879+;5V>=353<+=/>;9>,53I/<
:>/?8><-869;/7/C/=98>;5/<:>/55/<?8><
98<<I./C5/<-869I=/7-/<;/:>3</<
n!/68.303/C4+6+3<5/<-866+7./<
LISEZ ET SUIVEZ SOIGNEUSEMENT CES CONSIGNES DE
SÉCURITÉ.
CON ERVEZ CE IN TRUCTION
Guide de démarrage rapide
A propos du tableau de commande—Pour les modèles avec bouton de mise en marche
ignal
n%I5/-=3877/C>7<317+5./037./-B-5/
Température
283<3<</C5+=/69I;+=>;/./5V/+>98>;5/<9;81;+66/<./5+?+1//=./;37H+1/",</;?/C=8>48>;<5/<;/-866+7.+=387<37.3:>I/<<>;
5/<I=3:>/==/<.V/7=;/=3/7.>0+,;3-+7=8></<37<=;>-=387<98>;5/5+?+1/
PerfecTemp .I=/-=/5+=/69I;+=>;/./5V/+>.V+536/7=+=387/=+4><=/5V/+>./;/6953<<+1/98>;8,=/73;>7/1+66/./=/69I;+=>;/
95><9;I-3</98>;=8>=/<5/<=/69I;+=>;/<./5+?+1/#+;/A/695/98>;>75+?+1/;83../5V/+>=3J./9/>=K=;/+48>=I/98>;8,=/73;5+
=/69I;+=>;/89=36+5/./.3<<85>=387.>.I=/;1/7=%8>?/7=5/<.I=/;1/7=<7/</.3<<85?/7=9+<-8695J=/6/7=.+7<>7//+>=;J<0;83./
<>;=8>=.+7<5/<9+B<F-536+=95><0;83.
#/7.+7=5/<683<.V23?/;58;<:>/5V/+>.V+536/7=+=387/<=95><0;83./8>+>A/7.;83=<8N5V/+>/<==;J<0;83./.>;+7==8>=/5V+77I/>=353</C
PerfecTemp 95><;83.98>;+3./;F5+.3<<85>=387./<.I=/;1/7=</798>.;//=+37<3+6I538;/;5/5+?+1/./?8<?K=/6/7=<+087-=387
+>0;83./.>;8,37/=.I<+-=3?/5+087-=387PerfecTemp /=/00/-=>/>75+?+1/Froid F5+=/69I;+=>;/./5V/+>0;83./.>;8,37/=/-3
9/;6/=.VI-87863</;./5VI7/;13/9+;5+;I.>-=387./5+:>+7=3=I.V/+>-2+>./>=353<I/98>;5/5+?+1//5V/+>0;83./</;++48>=I/F5V/+>
-2+>./98>;89=363</;5V/003-+-3=I.>5+?+1/
Options
2ème rinçage (sur certains modèles)
8;<:>/?8><>=353</C.>.I=/;1/7=8>.>4+?/553<+7=<>995I6/7=+3;/98>;7/==8B/;./<?K=/6/7=<=;J<<+5/<?8><98>?/C-283<3;5V89=387
J6/;37H+1//==/89=3879;898</>7./>A3J6/;37H+1/F0;83.
Essorage prolongé (sur certains modèles)
'=353</C-/==/89=38798>;/A=;+3;/>7/95><1;+7./:>+7=3=I.V/+>./?8<?K=/6/7=</<?K=/6/7=<</;87=95><</-<58;<:>/-/==/89=387
/<=+-=3?I//=<J-2/;87=95><;+93./6/7=.+7<?8=;/<I-2/></
Assouplissant
-=3?/C-/==/89=38758;<:>/?8><+48>=/C./5V+<<8>953<<+7=.+7<?8=;/5+?/></
REMARQUE : N’utilisez pas de boule distributrice dans cette laveuse. Elles ne fonctionnent pas correctement dans les laveuses ultra-
performantes.
Commandes
• Ajoutez l’assouplissant (sur les
modèles équipés d’un distributeur
d’assouplissant); voir page 6 pour
plus d’information
• Ajoutez le détergent. GE
recommande l’utilisation de
détergent à grande efficacité
dans toutes les laveuses
homologuées Energy Star
• Sélectionnez les options
de lavage, y compris
l’option Assouplissant
• Sélectionnez le
programme de lavage
• Appuyez sur Marche
Étape 2 Étape3 Étape 4
•Placez les vêtements autour de
l’Infusor™ sans les comprimer. oute
surcharge pourrait avoir un impact
négatif sur les performances de
laveuse. Adaptez la taille de la
brassée en conséquence.
•Fermez le couvercle
REMARQUE: Le remplissage, essorage
et agitation sont impossibles avec le
couvercle ouvert
A
B
C
A B C
D
E F
SIGNAL EMPERA URE OP IONS
MARCHE
ARRE /PAUSE
Étape 1
REMPLISSAGE REMPAGE LAVAGE RINCAGE ESSORAGE
Assistance à la clientèleConseils de dépannageConsignes d’utilisationConsignes de sécurité
electromenagersge.ca
Voyants d’état
/<(8B+7=<.>#;81;+66/37.3:>/7=5VI=+9/.>-B-5/F5+:>/55/</=;8>?/5+5+?/></8;<:>/5/,8>=87./%I5/-=387
/<=;I15I<>;>778>?/+>9;81;+66/5/<(8B+7=<-53178=/7=686/7=+7I6/7=37.3:>+7=5/<.300I;/7=/<I=+9/<.>-B-5/
%>;5/<68.J5/<<+7<89=387Trempage automatique5/?8B+7=Trempage 7/<V+55>6/;+9+<
Programme de lavage —Bouton de élection du Programme
/<9;81;+66/<./5+?+1/-87=;M5/7=5+.>;I/.>9;8-/<<><./5+?+1/5/<=98<<3,5/./0+3;/=8>;7/;5/,8>=87.+7<
5/<./>A</7<%3?8><0+3=/<=8>;7/;5/,8>=87./%I5/-=387.>#;81;+66/+9;J<+?83;5+7-I>79;81;+66/5+5+?/></
<V+;;K=/;+/=</;+;I15I/<>;5/78>?/+>9;81;+66/99>B/C<>; +;-2/98>;.I,>=/;5/78>?/+>9;81;+66/
/=+,5/+>-3./<<8><?8><+3./;+F<I5/-=3877/;5/<9;81;+66/<./5+?+1/<+.+9=I<F?8<?K=/6/7=<
Cotons (LAVAGE NORMAL/ESSORAGE RAPIDE)
#8>;5/-8=875/5371/./6+3<875/<?K=/6/7=<./=;+?+358>./<98;=9/>
<+5/<F=;J<<+5/</9;81;+66/?8><800;/5/5+?+1/5/95><9/;08;6+7=98>;5+6+48;3=I./<?K=/6/7=</=/<=+.+9=IF
>7/>=353<+=387:>8=3.3/77/%/=/;637/9+;>7/<<8;+1/F1;+7./?3=/<</
Prélavage #8>;;/=3;/;5/<<+53<<>;/</7<>;0+-/./<?K=/6/7=<=;J<<+5/<(/355/CF5/0+3;/<>3?;/.V>79;81;+66/./
5+?+1/78;6+5
out-aller (lavage doux/essorage lent) #8>;5/<?K=/6/7=<370;83<<+,5/</=<+7<;/9+<<+1//=5/<?K=/6/7=</76+355/
%/=/;637/9+;>7/<<8;+1/F0+3,5/?3=/<</
Perma Press (lavage doux/essorage lent) #8>;5/<?K=/6/7=<370;83<<+,5/</=<+7<;/9+<<+1//=5/<?K=/6/7=</7
6+355/%/=/;637/9+;>7/<<8;+1/F1;+7./?3=/<</
Délicats (lavage doux/essorage rapide)
#8>;./<9/=3=/<,;+<<I/<./5371/9/><+5/.87=87+>7,/<837>;1/7=%/
=/;637/9+;>7/<<8;+1/F1;+7./?3=/<</
Vidange & Essorage ESSORAGE RAPIDE) #8>;?3.+71/;5+->?//=/<<8;/;5/<?K=/6/7=<%/=/;637/9+;>7/<<8;+1/F
1;+7./?3=/<</
Rinçage rapide (ESSORAGE RAPIDE) $37-//=/<<8;/5/5371/787<+5358;<:>/</>5>7;37H+1//<=;/:>3<%/=/;637/9+;
>7/<<8;+1/F1;+7./?3=/<</
MARCHE
99>B/C<>; +;-2/98>;.I6+;;/;5/9;81;+66/%3?8><+99>B/C./78>?/+><>; +;-2/5/9;81;+66/</6/=/7
9+><//=5/(8B+7=.>#;81;+66/-53178=/
#8>;-87=37>/;5/9;81;+66/+99>B/C./78>?/+><>; +;-2/%35+6+-237//<=63<//79+></9/7.+7=95><./
2/>;/<5/9;81;+66/</;++77>5I#8>;+;;K=/;5/9;81;+66/6+37=/7/C5/,8>=87+99>BI9/7.+7=</-87./<%V35
;/<=/./5V/+>.+7<5+6+-237/<I5/-=3877/C5/9;81;+66/(3.+71//<<8;+1/98>;?3.+71/;5+->?//=98>;/<<8;/;
5V/+>;/<=+7=.+7<5+->?/
%3?8><5/?/C5/-8>?/;-5/5V+13=+=3878>5V/<<8;+1/</;87=+;;K=I<6+3<5/9;81;+66/7/</;+9+<63</79+></
D
E
F
/68.J5//<=I:>39I.V>7<B<=J6/Détection automatique de la brassée/==/<I5/-=387?8><.877/+>=86+=3:>/6/7=
5+:>+7=3=I.V/+>+99;89;3I/98>;5+=+355//=5/=B9/./,;+<<I/95+-I/.+7<5+5+?/></+5+?/></7/</;/6953;+9+<
.V/+><35+.I=/-=387+>=86+=3:>/./,;+<<I//<=<I5/-=3877I//=5/-8>?/;-5/7V/<=9+<0/;6I8;<:>/5/-8>?/;-5//<=
0/;6I5+5+?/></-866/7-/F</;/6953;.V/+>98>;/<=36/;5+,;+<<I/
Remarque: Ceci est une laveuse ultra-performante avec un lavage par Infusor ™ qui demande une moins grande quantité
d’eau tout en offrant un lavage efficace. Vous remarquerez peut-être que le niveau d’eau est plus bas que dans votre
précédente laveuse. Ceci est normal pour une laveuse équipée d’un Infusor™.
Distributeur de javellisant liquide
>686/7=.>;/6953<<+1/./5+5+?/></5V/+>.35>/5/4+?/553<+7=
(I;303/C5VI=3:>/=+1/./<?K=/6/7=</7-+<.V37<=;>-=387<9+;=3->53J;/<
/<>;/C<8317/></6/7=5+:>+7=3=I./4+?/553<+7=/7<>3?+7=5/<37<=;>-=387<<>;5+
,8>=/355/
n Ne versez jamais de javellisant non dilué directement sur les vêtements ou dans le
panier de la laveuse.
n Ne versez pas de javellisant en poudre dans le distributeur de javellisant.
?+7=./.I6+;;/;5+5+?/></?/;</C5+:>+7=3=I./4+?/553<+7=6/<>;I/.3;/-=/6/7=.+7<
5/.3<=;3,>=/>;./4+?/553<+7=E?3=/C5/<I-5+,8><<>;/</=I?3=/C./=;89;/6953;5/
.3<=;3,>=/>;%3?8><9;I0I;/C>=353</C.>4+?/553<+7=/798>.;/+48>=/C5/.+7<5/9+73/;./
5+?+1/+?/-?8=;/.I=/;1/7=
n Ne mélangez jamais de javellisant avec de l’ammoniaque ou des acides tels que du
vinaigre et/ou de l’antirouille. Le mélange peut produire des gaz toxiques pouvant
entraîner la mort.
3
2
1
REMPLISSAGE REMPAGE LAVAGE RINCAGE ESSORAGE
Consignes d’utilisation Consignes de sécuritéAssistance à la clientèle Conseils de dépannage
A propos des fonctions de la laveuse.
Nettoyage du distributeur d'assouplissant (sur certains modèles)
/.3<=;3,>=/>;.V+<<8>953<<+7=/<=+>=87/==8B+7=/.3<=;3,>=/>;7/./6+7./9+<>7/7=;/=3/7
;I1>53/;-866/<>;5/<.3<=;3,>=/>;<.V+<<8>953<<+7=<=+7.+;.<%37I-/<<+3;//<<>B/C5/<
<>;0+-/</A=I;3/>;/<.>.3<=;3,>=/>;%35/<-8698<+7=<37=/;7/<.>.3<=;3,>=/>;.83?/7=K=;/
7/==8BI<<>3?/C5/<I=+9/<-3./<<><+9;J<>79;81;+66/
Distributeur d'assouplissant (sur certains modèles)
%8>5/?/C5/-8>?/;-5/<>;5/2+>=.>
.3<=;3,>=/>;.V+<<8>953<<+7=
/<>;/C5+:>+7=3=I.V+<<8>953<<+7=
;/:>3</.+7<5/,8>-2879>3<?/;</C5/
9+;5/2+>=.>.3<=;3,>=/>;
V+<<8>953<<+7=<VI-8>5/;+.+7<5/
-869+;=36/7=<3=>IF5V37=I;3/>;.>
.3<=;3,>=/>;'=353</C>73:>/6/7=./<
+<<8>953<<+7=<R'5=;+S8>-87-/7=;I<
/;6/C5/-8>?/;-5//7+99>B+7=./<<><
<<>;/C?8><:>/5/-8>?/;-5//<=
-8;;/-=/6/7=0/;6I/=/7-5/7-2I
%I5/-=3877/Cl'option Assouplissant sur
le =+,5/+>./-866+7./<
REMARQUE: %3?8><;/6953<</C=;895/
.3<=;3,>=/>;5V+<<8>953<<+7=<VI-8>5/;+9+;5/<
=;8><<3=>I<<>;5/<-M=I<./5V70><8;Q!/5/
;/6953<</C9+<=;89
4
3
2
1
/.3<=;3,>=/>;.Vassouplissant 53,J;/+>=86+=3:>/6/7=5V+<<8>953<<+7=53:>3./+>686/7=
+99;89;3I.>9;81;+66/.
N’arrêtez pas la laveuse et n’ouvrez pas le couvercle pendant son premier essorage sinon
le distributeur se videra précocement.
!/?/;</C4+6+3<5V+<<8>953<<+7=.3;/-=/6/7=<>;5/<?K=/6/7=</-398>;;+3=5/<=G-2/;.
Pour utiliser le distributeur, suivez les étapes suivantes :
%8>5/?/C5/-8>?/;-5/.>.3<=;3,>=/>;/=
0+3=/<=8>;7/C5/.3<=;3,>=/>;.+7<5/</7<
+7=328;+3;//7>=353<+7=5/<5+71>/==/<
-866/37.3:>I%8;=/C5/.3<=;3,>=/>;./
5V70><8;Q
!/==8B/C=8>=.I9M=F5V37=I;3/>;./
5V70><8;Q+?/->7-230087.8>A8>>7/
,;8<</F./7=<<>;/C?8><:>/5/<=;83<
=;8><+>087..>.3<=;3,>=/>;9/;6/==+7=
F5V+<<8>953<<+7=./<VI-8>5/;7/<87=9+<
,8>-2I<
E-+;=/C.I53-+=/6/7=5/-8>?/;-5/.>
-869+;=36/7=.3<=;3,>=/>;98>;5/<
<I9+;/;
<<>B/C5/<<>;0+-/<F5V+3./.V>7-230087
.8>A8>0+3=/<=;/69/;5/<93J-/<.+7<
>7/<85>=387./53=;/<1+5587.V/+>
-87=/7+7=X=+<</./.I=/;1/7=53:>3./
/==+<</./4+?/553<+7=<<>;/C?8><
:>/5/9/=3==;8><>;5/./<<><.>
-8>?/;-5//=5/=>,/-8;;/<987.+7=7/
<87=9+<8,<=;>I<
$I+<</6,5/C5/-869+;=36/7=
.3<=;3,>=/>;/=5/-8>?/;-5//75/<0/;6+7=
.V>7-8>9</-
$/95+-/C5V/7</6,5/.3<=;3,>=/>;.+7<
5V70><8;Q+3=/<=8>;7/;5/2+>=.+7<5/
</7<28;+3;/F5V+3././<5+71>/==/<
-866/37.3:>I99>B/C<>;5/-8>?/;-5/
98>;0/;6/;5/.3<=;3,>=/>;<<>;/C?8><
:>/5/-8>?/;-5//<=-8;;/-=/6/7=0/;6I
/=/7-5/7-2I
2
6
5
4
3
1
1
2
3
4
Couvercle
Languettes permettant
la rotation du
distributeur
1
3
5
Languettes permettant
la rotation du
distributeur
6
%%"$
OP IONS
J6/
$!D %%"'#%%!&
+?/-
J6/$!D
$$W&
Assistance à la clientèleConseils de dépannageConsignes d’utilisationConsignes de sécurité
electromenagersge.ca
Chargement et utilisation de la laveuse
Observez toujours les recommandations du fabricant indiquées sur les étiquettes d’entretien.
Tri du linge
%&;3/C9+;-8>5/>;,5+7-<-8>5/>;<-5+3;/<-8>5/>;<
73?/+>./<+5/=I=B9/./=3<<>-8=87/7=;/=3/70+-35/
.I53-+=</=+>-+<8N5/=3<<>9;8.>3=./5+-2+;93/
=3<<>I9871/-2/7355/8>+-->6>5/./5+-2+;93/
?/58>;<./-8=87?/58>;<-M=/5I
Utilisation correcte du détergent
48>=/C5/.I=/;1/7=+?+7=.V+48>=/;5/<+;=3-5/<F
5+?/;98>;:>/5/.I=/;1/7=<83=95></003-+-/
>=353<+=387.>7/:>+7=3=I37<>003<+7=/8>=;89
3698;=+7=/./.I=/;1/7=/<=>7/-+></-8>;+7=/./
9;8,5J6/./5+?+1/
(8><98>?/C>=353</;6837<./.I=/;1/7=<3?8><+?/C
>7//+>.8>-/>7/,;+<<I/95><9/=3=/8>9/><+5/
7-+<./=+-2/<9;I=;+3=/C5/<+;=3-5/</7<>3?+7=5/<
37<=;>-=387<.877I/<<>;5VI=3:>/==/&8>=/+9953-+=387
./.I=+-2+7=.83=K=;/0+3=/.+7<5/9+73/;./5+
5+?/></98>;I?3=/;./=;89?+98;3</;5V+;=3-5//=
.VI?3=/;./.I-858;/;5/<1;+923<6/<8>5/-8>?/;-5/
;/-866+7./5V>=353<+=387./.I=/;1/7=F1;+7./
/003-+-3=I.+7<=8>=/<5/<5+?/></<2868581>I/<
7/;1B%=+;/<.I=/;1/7=<<87=08;6>5I<98>;
087-=3877/;+?/-./<9;81;+66/<>=353<+7=>70+3,5/
?85>6/.V/+>./5+?+1//=./;37H+1//<.I=/;1/7=<
;I.>3</7=5/<9;8,5J6/<./68><<+1/=;89
3698;=+7=+<<8-3I<+>A.I=/;1/7=<2+,3=>/5<
8;<:>/?8><>=353</C./<.I=/;1/7=<F2+>=
;/7./6/7=8>-87-/7=;I<-87<>5=/C5/<
;/-866+7.+=387<.877I/<<>;5VI=3:>/==/.>9;8.>3=
98>;.I=/;637/;5/<:>+7=3=I<89=36+5/<;/:>3</<
98>;./<;I<>5=+=<89=36>6'7/:>+7=3=I=;89
3698;=+7=/./.I=/;1/7=9/>=+?83;>7369+-=7I1+=30
<>;5V/003-+-3=I.>5+?+1/
Chargement de la laveuse
#5+-/C5/<?K=/6/7=<.+7<5/9+73/;./5+5+?/></
<+7<5/<-869;36/;8;<:>/?8><95+-/C./<+;=3-5/<
68>355I<.+7<5+5+?/></+<<>;/C?8><:>/5/73?/+>
.V/+>./5371//<=+<</CI5/?I98>;9/;6/==;/+>A
+;=3-5/<./,8>1/;53,;/6/7=/73?/+>.V/+>.83=
4><=/;/-8>?;3;5/<+;=3-5/<#8>;+48>=/;.>5371/+9;J<
+?83;.I6+;;I>79;81;+66/<8>5/?/C5/-8>?/;-5/
/=<>,6/;1/C5/<+;=3-5/<<>995I6/7=+3;/<F9;8A363=I
./5V+13=+=/>;
nN’enroulez pas des articles de grande longueur tels
que des draps ou des pantalons autour de l’Infusor.
nNe lavez pas les tissus imbibés de substances
inflammables (cires, liquides de nettoyage, etc.).
nLe lavage et l’essorage ne sont pas en marche
lorsque le couvercle est ouvert, toutefois, la
minuterie continuera à fonctionner.
Entretien et nettoyage de la laveuse.
Panier: +3<</C5/-8>?/;-5/8>?/;=+9;J<>7/5/<<3?/
98>;9/;6/==;/5VI?+98;+=387./5V2>63.3=I%3?8><
<8>2+3=/C7/==8B/;5/9+73/;>=353</C>75371/9;89;//=
.8>A5I1J;/6/7=36,3,I./.I=/;1/7=53:>3./9>3<;37-/C
!>=353</C9+<./9;8.>3=<7/==8B+7=<+,;+<30<
Tuyaux de remplissage : ?8><;/-866+7././5/<
-2+71/;=8><5/<+7<
Extérieur: <<>B/C366I.3+=/6/7==8>=9;8.>3=;/7?/;<I
F5V+3./.V>7-2300872>63./?3=/C./0;+99/;5+<>;0+-/
+?/-./<8,4/=<=;+7-2+7=<
Intérieur: V>=353<+=3878--+<3877/55/.V>79;81;+66/
-87=/7+7=.>4+?/553<+7=6+37=3/7.;+?8=;/5+?/></
9;89;/
Couvercle en verre : '=353</C>7-2300879;89;//=.8>A/=
>7/<85>=387./?37+31;//=.V/+>
Remarque: !V>=353</C9+<./7/==8B+7=<F,+</
.V+66873+:>/
Déménagement et Entreposage : /6+7./CF>7
;I9+;+=/>;./?3.+71/;5V/+>./5+9869//=./<=>B+>A
87<>5=/C5+!8=3-/.V7<=+55+=38708>;73/+?/-5V+99+;/35
98>;./<3708;6+=387<<>;5+9;8-I.>;/F<>3?;/98>;
;I37<=+55/;5+-+5/.V/A9I.3=387:>33668,353</5+->?/
9/7.+7=5/.I6I7+1/6/7=#8>;./95><+695/<
3708;6+=387<-87<>5=/C5/<3=/
ELECTROMENAGER GE.CA
8>+99/5/C1.800.561.33447=;/98</C5+5+?/></F5V+,;3
./<37=/69I;3/<
Vacances prolongées : 8>9/C5V+536/7=+=387/7/+>+>
73?/+>./<;8,37/=<(3.+71/C5V/+>./<=>B+>A/7-+<./
;3<:>/./1/5
EAU Causes Possibles Que faire
Le niveau d’eau semble bas Ceci est normal • V/+>7/-8>?;/9+<7I-/<<+3;/6/7=5/5371//-3/<=78;6+5
98>;5/<5+?/></<>5=;+9/;08;6+7=/<
La laveuse se remplit d’eau Le tuyau de vidange • /=>B+>./?3.+71/?/;=3-+5.83=K=;/+>./<<><./-698
et se vide en même temps vertical est trop bas
Moussage excessif rop de détergent • /<>;/C<8317/></6/7=5+:>+7=3=I./.I=/;1/7='=353</C6837<
./.I=/;1/7=<3?8><+?/C>7//+>.8>-/>7/,;+<<I/95><9/=3=/8>
.>5371/9/><+5/
ype de détergent • .89=/C>7.I=/;1/7=
Eau douce • '=353</C6837<./.I=/;1/7=
Fuites d’eau Utilisation d’une trop grande • '=353</C6837<./.I=/;1/7='=353</C6837<./.I=/;1/7=<3?8><+?/C
quantité de détergent dans la laveuse >7//+>.8>-/>7/,;+<<I/95><9/=3=/8>.>5371/9/><+5/
ype de détergent • .89=/C>7.I=/;1/7=
Les tuyaux de remplissage ou de • <<>;/C?8><:>/5/<,;+7-2/6/7=<.V/+><83/7=,3/7</;;I<+>
vidange sont mal branchés 73?/+>./<;8,37/=</=5/<;87./55/</7-+8>=-28>-87=,3/7I=I63</<
/795+-/<<>;/C?8><:>/5V/A=;I63=I.>=>B+>./?3.+71//<=
-8;;/-=/6/7=37<I;I//=03AI/F5VI?+->+=387
La canalisation d’évacuation • (I;303/C5+9586,/;3/.>.863-35/(8><+>;/C9/>=K=;/
du domicile est peut être bouchée ,/<837.V+99/5/;>79586,3/;
uyau de vidange desserré P<<>;/C?8><:>/5/=>B+>./?3.+71//<=-8;;/-=/6/7=;I37<=+55IF5V
5V+;;3J;/./5+5+?/><//=:>/5/<./>A?3<./03A+=387<87=
-8;;/-=/6/7=37<=+55I/<
Le tuyau de vidange frotte P<<>;/?8><:>/5/=>B+>./?3.+71/7V/<=9+</7-87=+-=+?/-5/
contre le mur 6>;/-39/>=9;8?8:>/;>7/><>;//A-/<<3?/.>=>B+>
Pression d’eau constante vers • $/<</;;/C5/<=>B+>A+>73?/+>./<;8,37/=</=0/;6/C5/<;8,37/=<
les tuyaux de remplissage +9;J<-2+:>/>=353<+=387
•(I;303/C5VI=+=./<=>B+>A./;/6953<<+1/35<.83?/7=
K=;/;/695+-I<=8><5/<+7<
La température de l’eau L’utilisation d’eau aux températures •/<78>?/+>A.I=/;1/7=<87=I=I08;6>5I<98>;8,=/73;>7/,877/
semble incorrecte plus basses permettra une 9/;08;6+7-/./5+?+1/F./<=/69I;+=>;/<95><,+<</<
meilleure efficacité énergétique
La commande n'est pas bien réglée • (I;303/C5/-87=;M5/./5+=/69I;+=>;/./5V/+>/=+4><=/C
L’alimentation en eau est fermée • ">?;/C-8695J=/6/7=5/<;8,37/=<.V/+>-2+>.//=0;83.//=
ou branchée incorrectement +<<>;/C?8><:>/5/<=>B+>A<83/7=,;+7-2I<+>A,87<;8,37/=<
Les filtres des soupapes • /;6/C5/;8,37/=/=;/=3;/C5/<;+--8;.<./=>B+>AF5V+;;3J;/
sont obstrués <>9I;3/>;./5+5+?/></!/==8B/C5/<035=;/<./5+5+?/></F5V+3./.V>7/
,;8<</8>.V>7->;/./7=$/,;+7-2/C5/<=>B+>A/=8>?;/C5/<
;8,37/=<
Eau Froide/fraiche lorsque P/-3/<=78;6+5#/;0/-&/69.I=/-=/5+=/69I;+=>;/./5V/+>/=
Chaud est sélectionné 89=363</5V/003-+-3=I./5+5+?/></V/+>0;83.//<=+48>=I/F37=/;?+55/<
;I1>53/;<58;<:>V>75+?+1/F-2+>./<=<I5/-=3877I
Le chauffe-eau n’est pas • <<>;/C?8><:>/5/-2+>00//+>9;8.>3=>7//+>F>7/=/69I;+=>;/
réglé correctement ?+;3+7=./FOFO
L’eau est vidangée avant Le couvercle n’est pas fermé • $I373=3+53</C5/9;81;+66/
la fin du programme ou le programme a été en pause
pendant plus de 24 heures
La laveuse ne se vidange pas Le tuyau de vidange est • $/.;/<</C5/=>B+>./?3.+71//=+<<>;/C?8><:>/5+5+?/></
entortillé ou mal branché. 7/<83=9+<98<I/./<<><
•+9+;=3/<>9I;3/>;/.>=>B+>./?3.+71/.83=K=;/F6837<./6
93.><85
La laveuse s’arrête pendant L’option Prélavage ou • /-3/<=78;6+5+5+?/></+5=/;7//7=;/+13=+=387/==;/69+1/
le programme Trempage automatique 9/7.+7=-/<9;81;+66/<98>;8,=/73;./<?K=/6/7=<95><
a été sélectionnée 9;89;/<+?/-6837<.V><>;/
La laveuse s’arrête Ceci est normal • +5+?/></9/>=<V+;;K=/;9/7.+7=5V/<<8;+1/98>;I53637/;95><
pendant l’essorage 0+-35/6/7=5V/+><+?877/></
La laveuse ne se remplit pas Ceci est normal • /-8>?/;-5/.83=K=;/0/;6I98>;:>/5+5+?/></087-=3877/8>
lorsque le couvercle est ouvert </;/6953<</
Conseils de dépannage
Economisez du temps et de l’argent ! Consultez les tableaux sur les pages suivantes ou consultez
ELECTROMENAGER GE.CA. Vous n’aurez peut-être pas besoin d’appeler un technicien.
Avant d’appeler un réparateur...
Consignes d’utilisation Consignes de sécuritéAssistance à la clientèle Conseils de dépannage
Table of contents
Languages:
Other GE Washer manuals
Popular Washer manuals by other brands
Fisher & Paykel
Fisher & Paykel WA8560P INSTALLATION GUIDE/USER GUIDE
Bosch
Bosch WFMC2201UC - Nexxt 300 Series Washer Operating, care and installation instructions
Kärcher
Kärcher G 3600 OHT manual
Electrolux
Electrolux 300 Series Use & care guide
Hotpoint
Hotpoint WMSIF 8437 Instructions for use
Bosch
Bosch WAV28K02BY User manual and installation instructiions
