Owner’s Manual
Washers
Safety Instructions ..........2,3
Operating Instructions
Care and Cleaning
oftheWasher......................7
ControlPanels.....................4
ControlSettings .................4,5
Features...........................6
Loading and Using
theWasher........................7
Troubleshooting Tips.....10–12
Consumer Support
Consumer Support................16
Warranty..........................15
Write the model and serial
number here:
Model # _____________
Serial # ______________
You can find them
under the lid of
the washer.
Printed in the United States 49-90529 11-14 GE
G188
English/Français/Español

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill you or hurt you and others. All safety
messages will follow the safety alert symbol and the word “DANGER”, “WARNING”, or “CAUTION”. These words are defined as:
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
DANGER
WARNING
CAUTION
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of death, fire, explosion, electric shock, or injury to persons when using your appliance,
follow basic precautions, including the following:
 Read all instructions before using the appliance.
 DO NOT wash or dry articles that have been previously cleaned in, washed in, soaked in or spotted with gasoline, dry-
cleaning solvents, or other flammable or explosive substances, as they give off vapors that could ignite or explode.
 DO NOT add gasoline, dry-cleaning solvents, or other flammable or explosive substances to the wash water. These
substances give off vapors that could ignite or explode.
 Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used for 2 weeks
or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using a
washing machine, turn on all hot-water faucets and let the water flow from each for several minutes. This will release
any accumulated hydrogen gas. As the gas is flammable, DO NOT smoke or use an open flame during this time.
 DO NOT allow children to play on or in this appliance. Close supervision of children is necessary when this appliance is
used near children. Before the washer is removed from service or discarded, remove the door or lid. Failure to follow
these instructions may result in death or injury to persons.
 DO NOT reach into the appliance if the tub or agitator is moving to prevent accidental entanglement.
 DO NOT install or store this appliance where it will be exposed to the weather.
 DO NOT tamper with controls, repair or replace any part of this appliance or attempt any servicing unless specifically
recommended in the user maintenance instructions or in published user repair instructions that you understand and
have the skills to carry out.
 Keep the area around your appliance clean and dry to reduce the possibility of slipping.
 DO NOT operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts
including a damaged cord or plug.
 Unplug the appliance or turn off the circuit breaker before servicing. Pressing the Power button DOES NOT disconnect power.
 See “Electrical Requirements” located in the Installation Instructions for grounding instructions.
SAVE THESE INSTRUCTIONS
WARNING
2

GEAppliances.ca
WHEN NOT IN USE
Turn off water faucets to minimize leakage if a break or
rupture should occur. Check the condition of the fill hoses;
GE recommends changing the hoses every 5 years.
Ensure that the hot water hose is connected to the “H”
(internal red screened) valve and the cold water hose is
connected to the “C” (internal blue screened) valve.
Install or store where it will not be exposed to
temperatures below freezing or exposed to the weather,
which could cause permanent damage and invalidate the
warranty.
Properly ground washer to conform with all governing
codes and ordinances. Follow details in the Installation
Instructions.
To ensure proper installation, run two small load size
Whites cycles BEFORE washing the first load.
This washer does not include water supply hoses.
GE strongly recommends the use of factory specified
parts. A list of factory hoses available for purchase are
listed below. These hoses are manufactured and tested to
meet GE specifications.
GE strongly recommends the use of new water supply
hoses. Hoses degrade over time and need to be replaced
every 5 years to reduce the risk of hose failures and water
damage.
Parts and Accessories
Call 1.800.661.1616 during normal business hours or contact
your local authorized GE parts distributor.
Part Number Accessory
PM14X10002 4 ft Rubber Water Supply Hoses
Or
PM14X10005 4 ft Braided Metal Water Supply Hoses
PROPER INSTALLATION
This washer must be properly installed and located in accordance with the Installation Instructions before it is used.
If you did not receive an Installation Instructions, you can receive one by visiting GEAppliances.ca or by calling
800.561.3344.
SAVE THESE INSTRUCTIONS
3

• Add items.
Quick Start Guide
$ERXWWKHFRQWUROSDQHO³IRUPRGHOVZLWK´SXOONQREµVWDUW
Load Size
Loosely load items in the washer basket. Overloading may negatively impact wash performance. Adjust the load size
accordingly.
Reset
If you decide that you want a higher water level, move the Load Size first to Reset and then to the higher water setting.
Temperature
Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care label or
instructions when laundering.
Options (on some models)
Fabric Softener and Power Rinse
Set this option when adding fabric softener during the rinse cycle or when you use extra detergent or bleach to clean
heavily soiled items. It provides an enhanced rinse.
A
B
C
• Add detergent.
• Add diluted fabric
softener (on models
with a fabric softener
dispenser).
Step 1 Step 2
• Select load size and
other wash options
• Select wash cycle
• Select OPTIONS
Step 3
• Close lid.
• Pull knob.
Step 4
Controls
AB C D
LOAD SIZE TEMPERATURE OPTIONS
4

GEAppliances.com
:DVK&\FOH³&\FOH6HOHFWRU.QRE
The chart below will help you match the wash cycle setting with your items. The chart is ranked from greatest to least
wash intensity.
Your washer may not have all these cycles. (Cycles vary by model.)
Whites For heavy to lightly soiled cottons, household linens, work and play items.
(Regular Wash/Fast Spin)
Colors For non-colorfast clothes and blends and items that are labeled for cold wash.
(Regular Wash/Fast Spin)
Permanent Press For wrinkle-free and permanent press items, and knits.
(Pulsed Wash/Fast Spin)
5LQVH6RDN For rinsing chlorine, perspiration, stains, etc., out of items. (Followed by Drain & Fast Spin.)
Drain & Spin For draining the tub and spinning water out of the clothes. (Fast Spin)
D
Liquid Bleach Funnel
The water fill dilutes liquid chlorine bleach as the washer fills for the wash cycle.
1Check clothing care labels for special instructions.
2Measure liquid bleach carefully, following instructions on the bottle.
 Never pour undiluted liquid chlorine bleach directly onto clothes or into the wash
basket.
 Do not pour powdered bleach into bleach funnel.
3Before starting the washer, pour measured amount of bleach directly into bleach funnel.
Avoid splashing or over-filling dispenser. If you prefer to use powdered bleach, add it into
the wash basket with your detergent.
 Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust
remover. Mixing can produce a toxic gas which may cause death.
FAQ
Q: What is the difference between Heavy and Light settings?
A: For Whites and Colors, the wash agitation time is increased by 6 minutes and for Permanent Press, by 12 minutes. (Times are
approximate)
Q: Which cycle is best for heavily soiled items?
A: Whites or Colors cycles have the greatest wash intensity. This cycle provides the best overall cleaning . Permanent Press
should be used for wrinkle-free and permanent press items.
Q: How can I reduce linting?
A: Sort wash loads by fabric type and whether they collect lint (velveteen, corduroy) or produce lint (terry cloth, chenille). Wash
small loads for a shorter amount of time.
Q: How much detergent do I use?
A: For best performance, always follow the detergent manufacturer’s instructions on usage. Many detergents are concentrated,
so consult the product label and follow the clearly marked lines on the detergent measuring cups. Excessive detergent can
negatively impact the wash performance.
Q: How does the selection of Power Rinse or Fabric Softener affect water usage of my washer?
A: Selecting the Power Rinse or Fabric Softener feature will increase the amount of water used by your washer during the rinse
cycle. The added water assists in the proper dilution of fabric softener. The quantity of water used in this cycle is comparable to
the amount used in the initial fill.
5

Separate for cleaning
6
About washer features.
Cleaning the Fabric Softener Dispenser (on some models)
1Remove the dispenser from the top of the agitator.
2Separate the dispenser cup from the cover by grasping the top and pushing down on the
inside of the cup with your fingers. Dispenser cup will pop free from the cover.
3To clean the dispenser, soak both the dispenser cup and the dispenser cover in the
following solution:
 1 US gallon (3.8 liters) warm water
 1/4 cup (60 ml) heavy-duty liquid detergent
 1 cup (240 ml) bleach
4If necessary, loosen buildup with a clean, soft cloth after soaking. Do not use a stiff brush;
you may roughen the surface of the dispenser.
5Rinse and reassemble dispenser. Place dispenser back on the agitator.
Fabric Softener Dispenser (on some models)
The fabric softener dispenser automatically
releases liquid fabric softener. Setting the
knob ensures that it dispenses at the proper
time.
Do not stop the washer or raise the lid
during the first spin. This will cause the
dispenser to empty too soon.
To use, follow these steps:
1Make sure dispenser is securely attached
to agitator.
2Use only diluted liquid fabric softener.
Pour into dispenser, using amount
recommended on package.
Never pour fabric softener directly on items.
It may stain them.
3Add water to dispenser until it reaches
the maximum fill line.
Select Fabric Softener setting knob to
activate the cycle.
Note: Fabric softener will not dispense if the
knob is in the “OFF” position.
Do not pour anything into the
agitator if the agitator cap or
dispenser is removed.
4
The Agitator Cap (on some models)
The agitator cap fits into the top of the
agitator. If it accidentally comes off, simply
put it back on.
OPTIONS
OFF FABRIC SOFTENER
and/or POWER RINSE
Set when adding

7
Sorting Wash Loads
Sort by color (whites, lights, colors), soil level, fabric
type (sturdy cottons, easy care, delicates) and
whether the fabric produces lint (terry cloth, chenille)
or collects lint (velveteen, corduroy).
Proper Use of Detergent
Loading the Washer
Load dry items loosely in the washer basket. When
loading wet items, make sure you set the load/water
level high enough to allow the items to move freely.
Water level should just cover the items. To add items
after washer has started, lift the lid and submerge
additional items next to the agitator.
Do not wrap long items like sheets or pants around
the agitator.
Do not wash fabrics containing flammable
materials (waxes, cleaning fluids, etc.).
Washer will not agitate or spin with the lid up,
however the timer will continue to run.
Add detergent before adding items so that the
detergent can work effectively. Using too little or
too much detergent is a common cause of laundry
problems.
For spots, apply pre-treatment to items as
recommended on the product label. Application
should be made in the basket to prevent overspray
which may cause the coloring on the lid or graphics
to fade.
You can use less detergent if you have soft water, a
smaller load or a lightly soiled load.
When using high efficiency or concentrated
detergents, consult the product label to determine
amount required for optimum performance.
Excessive detergent will negatively impact wash
performance.
Loading and using the washer. GEAppliances.com
Always follow fabric manufacturer’s care label when laundering.
- Fire Hazard
WARNING
Never place items in the washer that are dampened with gasoline or other flammable liquids.
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on it (including cooking oils).
Doing so so can result in death, explosion, or fire.

8
Care and cleaning of the washer.
:DVK%DVNHWLeave the lid open after washing to
allow moisture to evaporate. If you want to clean the
basket, use a clean soft cloth dampened with liquid
detergent; then rinse. (Do not use harsh or gritty
cleaners.)
Fill Hoses: GE recommends changing the hoses every
5 years.
Exterior: Immediately wipe off any spills. Wipe with
damp cloth. Try not to hit surface with sharp objects.
Moving and Storage: Ask the service technician to
remove water from drain pump and hoses. See the
Installation Instructions packed with product for
information on how to reinstall the shipping rod to
keep the tub stationary when moving the washer. For
more information, visit GEAppliances.com or call 800.
GE.CARES (800.432.2737). Do not store the washer
where it will be exposed to the weather.
Long Vacations: Be sure water supply is shut off at
faucets. Drain all water from hoses if weather will be
below freezing.

Notes. GEAppliances.com
9

WATER Possible Causes What To Do
Too many suds Too much detergent • Measure your detergent carefully. Use less soap if you have
soft water, a smaller load or a lightly soiled load.
Type of detergent • Switch to a lower sudsing detergent brand and follow
instructions on package.
Soft water • Try less detergent.
:DWHUOHDNV Using too much detergent • Use less detergent. Use less soap if you have soft water,
in washer a smaller load or a lightly soiled load.
Fill hoses or drain hose is • Make sure hose connections are tight at faucets and
improperly connected rubber washers are installed. Make sure end of drain hose
is correctly inserted in and secured to drain facility.
Household drain may • Check household plumbing. You may need to call
be clogged a plumber.
Drain hose loose • Make sure drain hose is fully seated in back of washer and
that the two retaining screws are fully seated.
Drain hose rubs on wall • Make sure drain hose does not make contact with the wall.
May cause excessive wear on the hose.
Constant water pressure • Tighten hoses at the faucets and turn the water off after
to the fill hoses at the each use.
water source • Check condition of the fill hoses; they should be replaced
every 5 years.
Water temperature Cooler water temperatures • New laundry detergents have been formulated to work
seems incorrect provide improved energy with cooler water temperatures without affecting wash
efficiency performance.
Water supply is turned off • Turn both hot and cold faucets fully on and make sure
or improperly connected hoses are connected to correct faucets.
Water valve screens are • Turn off the water source and remove the water connection
stopped up hoses from the upper back of the washer. Use a brush or
toothpick to clean the screens in the machine. Reconnect
the hoses and turn the water back on.
House water heater is • Make sure house water heater is delivering water at
not set properly 120°F–140°F (48°C–60°C).
Water pumped out before Lid lifted or cycle was put in • Reset cycle.
cycle is complete pause for over 24 hours
Water won’t drain Drain hose is kinked or • Straighten drain hose and make sure washer is not
improperly connected sitting on it.
• Top of drain outlet should be less than 6 ft (1.8 m)
above floor.
Washer pauses during This is normal • This is normal. The washer alternates between agitate and
wash cycle soak during some wash cycles to get your clothes cleaner
with less wear.
Washer pauses during This is normal • The washer may pause during the spin cycle to remove
spin cycle soapy water more efficiently.
Troubleshooting Tips
Save time and money! Review the charts on the following pages,
or visit GEAppliances.com. You may not need to call for service.
Before you call for service…
10

OPERATION Possible Causes What To Do
Washer won’t operate Washer is unplugged • Make sure cord is plugged securely into a working outlet.
Water supply is turned off • Turn both hot and cold faucets fully on.
Controls are not set properly • Check controls.
/LGLVRSHQ³VDIHW\IHDWXUH • Close lid and reset cycle, to the beginning if necessary.
prevents agitation and
spinning when lid is up
Circuit breaker/fuse is • Check house circuit breakers/fuses. Replace fuses or
tripped/blown reset breaker. Washer should have separate outlet.
Timer knob not pulled • Pull timer knob.
Lid magnet missing • Call for service.
Movement inside machine Shifting mechanism is • When the machine is manually turned off, the shifter will
when shut off disengaging the motor disengage the motor before completely shutting down.
If lid is raised before the motor is disengaged, the process will
stop and will resume when lid is closed.
PERFORMANCE Possible Causes What To Do
Clothes too wet Incorrect spin cycle • Make sure the spin cycle selected matches the load you are
selected washing. Some fabrics will feel wetter when rinsed with cold water.
Colored spots Incorrect use of fabric • Check fabric softener package for instructions and follow
softener directions for using dispenser.
• Make sure you have selected the Fabric Softener option.
• Pretreat stain and rewash.
Dye transfer • Sort whites or lightly colored items from dark colors.
Grayed or yellowed Not enough detergent • Use more detergent (especially with larger loads).
clothes Be sure to follow detergent manufacturer’s directions.
Hard water • Use a water conditioner or install
a water softener.
Water is not hot enough • Make sure water heater is delivering water at
120°F–140°F (48°C–60°C).
Washer is overloaded • Select load size to match clothes load.
Detergent is not • Add detergent before you load items.
dissolving
Dye transfer • Sort clothes by color. If fabric label states wash separately,
unstable dyes may be indicated.
Lint or residue on Clothes are air or line dried • If you do not dry your clothes with a clothes dryer, your
clothes clothes may retain more lint.
Incorrect sorting • Separate lint producers from lint collectors.
Washing too long • Wash small loads for a shorter time than larger loads.
Detergent not dissolving • Add detergent before you load items.
• Try a liquid detergent.
• Use warmer water temperature.
Overloading • Load clothes loosely in the washer basket. Adjust load size
based on items size and materials.
• Make sure load size selected matches clothes load size.
Incorrect use of fabric • Check fabric softener package for instructions
softener and follow directions for using dispenser.
• Make sure you have selected the Fabric Softener option.
GEAppliances.com
11

PERFORMANCE (cont.) Possible Causes What To Do
Pilling Result of normal wear on • While this is not caused by the washer, you can slow the
poly-cotton blends and pilling process by washing garments inside out.
fuzzy fabrics
Snags, holes, tears, rips Pins, snaps, hooks, sharp • Fasten snaps, hooks, buttons and zippers.
or excessive wear buttons, belt buckles, • Remove loose items like pins, objects in pockets and
zippers and sharp objects sharp buttons.
left in pockets • Turn knits (which snag easily) inside out.
Undiluted chlorine bleach • Check bleach package instructions for proper amount.
• Never add undiluted bleach to wash or allow clothes to
come in contact with undiluted bleach.
Chemicals like hair bleach or • Rinse items that may have chemicals on them before
dye, permanent wave solution washing.
:ULQNOLQJ Improper sorting • Avoid mixing heavy items (like work clothes) with light items
(like blouses).
• Try a fabric softener.
Overloading or incorrect • Load your washer so clothes have enough room to move
water level freely with water covering all of the clothes.
Incorrect wash and • Match Cycle selection to the type of fabric you are washing
dry cycles (especially for easy care loads).
Repeated washing in • Wash in warm or cold water.
water that is too hot
SOUNDS Possible Causes Reason
´0HWDOOLFFOLFNLQJµ Shifter mechanism is • The drive system will engage at the start of agitate and
engaging or disengaging disengage when agitate is complete. This occurs multiple
times during the wash.
%DFNDQGIRUWK´VZRRVKµ Electric motor reversing • This machine has a drive system that doesn’t use gears.
RUOLJKW´FOLFNLQJµVRXQG direction This sound is the motor rotating back and forth to clean
during agitate your laundry.
´&OLFNµZKHQZDWHU Relay switch • The relay makes a click sound when activated. The water
stops filling level activates the relay and stops filling.
´&OLFNLQJµEHKLQG&RQWURO Automatic Temperature • Two valves mix cold and hot water. The “clicking” is when either
Panel during fill Control Valve valve turns on or off to raise or lower the fill water temperature.
Water flow changes Automatic Temperature • Two valves mix cold and hot water. The flow changes when either
during fill Control Valve valve turns on or off to raise or lower the fill water temperature.
0RWRU´ZKLQLQJXSµRU Motor ramping up/down • The motor will speed up incrementally during the spin cycle.
´FRDVWLQJGRZQµLQVSLQ during spin cycle When spin is complete, it will coast until it stops.
´+XPPLQJµ Water drain pump • The drain pump will make a humming sound when pumping
out water after agitation stops and continue until spin is
complete.
´*XUJOLQJµ Water drain pump • When the pump starts drawing in air, It starts to gurgle.
The washer should then begin spinning and the sound will
continue until it is done spinning.
Washer is noisy Washer is uneven • To level the front of the washer, adjust the front leveling legs
by rotating the individual leg in the proper direction for up
or down. To level the back of the washer, lift the back of the
machine 4” (11 cm) and set down.
Shipping rod is still assembled • To remove the shipping rod from the washer, pull the yellow
in the unit tag and remove the attached rod from the bottom right hand
side of the washer.
Before you call for service…
12
Troubleshooting Tips

Notes. GEAppliances.com
13

14
Notes.

15
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. To schedule service,
on-line, visit us at GEAppliances.com, or call 800.GE.CARES
(800.432.2737). Please have serial number and model number
available when calling for service.
For The Period Of: We Will Replace:
One Year Any factory specified part of the washer which fails due to a defect in materials or workmanship.
From the date of the During this limited one-year warranty, we will also provide, free of charge, all labor and related
original purchase service to replace the defective part.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the
USA. If the product is located in an area where service by a GE Authorized Servicer is not available, you may be responsible for a
trip charge or you may be required to bring the product to an Authorized GE Service location. In Alaska, the warranty excludes the
cost of shipping or service calls to your home.
If you need to order replacement parts, we recommend that you only use GE factory specified parts. These parts are designed to
work with your appliance and are manufactured and tested to meet GE specifications.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal
rights, and you may also have other rights which vary from state to state. To know what your legal rights are, consult your local
or state consumer affairs office or your state’s Attorney General.
:DUUDQWRU*HQHUDO(OHFWULF&RPSDQ\/RXLVYLOOH.<
Service trips to your home to teach you how to use the
product.
Improper installation, delivery or maintenance.
Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
Replacement of house fuses or resetting of circuit
breakers.
Products which are not defective or broken, or which are
working as described in the Owner’s Manual.
Damage to the product caused by accident, fire, floods or
acts of God.
Incidental or consequential damage caused by possible
defects with this appliance.
Defects or damage due to operation in freezing
temperatures.
Damage caused after delivery.
Product not accessible to provide required service.
What Is Not Covered:
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
GE Washer Warranty. GEAppliances.com
(;&/86,212),03/,(':$55$17,(6³<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQWKLV/LPLWHG
Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular
purpose, are limited to one year or the shortest period allowed by law.

Consumer Support.
Contact Us GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
GE Appliances Website GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any
day of the year! For greater convenience and faster service, you can now download Owner’s Manuals, order
parts or even schedule service on-line.
Schedule Service GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your
convenience any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours.
Real Life Design Studio GEAppliances.com
*(VXSSRUWVWKH8QLYHUVDO'HVLJQFRQFHSW³SURGXFWVVHUYLFHVDQGHQYLURQPHQWVWKDWFDQEHXVHGE\SHRSOH
of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental
abilities and impairments. For details of GE’s Universal Design applications, including kitchen design ideas
for people with disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.GEAC
(800.833.4322).
Extended Warranties GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty
is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours. GE
Consumer Home Services will still be there after your warranty expires.
Parts and Accessories GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone at
800.626.2002 during normal business hours.
If you need to order replacement parts, we recommend that you only use GE factory specified parts. These
parts are designed to work with your appliance and are manufactured and tested to meet GE specifications.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Register Your Appliance GEAppliances.com
5HJLVWHU\RXUQHZDSSOLDQFHRQOLQH³DW\RXUFRQYHQLHQFH Timely product registration will allow for
enhanced communication and prompt service under the terms of your warranty, should the need arise. You
may also mail in the pre-printed registration card included in the packing material.
16

ELECTROMENAGERSGE.CA
Manuel d’utilisation
Laveuse
Consignes de sécurité ......2,3
Consignes d’utilisation
Entretien et nettoyage
delalaveuse.......................8
Panneau de commandel........... 4
Réglage des commandes .......4–5
Fonctions ..........................6
Chargement et Utilisation
de la Laveuse . . . . . . . . . . . . . . . . . . . . . . 7
Conseils de dépannage . 10–12
Assistance à la clientèle
Assistance à la clientèle...........16
Garantie ..........................15
Inscrivez ici les numéros de
modèle et de série :
Numéro de modèle
Numéro de Série
Ces numéros sont
inscrits sous le couvercle
de la laveuse.
Imprimé aux Etats-Unis

2
IMPORTANTES CONSIGNES DE SÉCURITÉ
VEUILLEZ LIRE TOUTES LES CONSIGNES AVANT UTILISATION.
INSTRUCTIONS DE SÉCURITÉ IMPORTANTES
Pour réduire le risque de décès, d’incendie, d’explosion, de choc électrique ou de blessure aux
personnes utilisant cet appareil, observez des précautions élémentaires dont les suivantes :
 Lisez toutes les instructions avant d’utiliser l’appareil.
 NE séchez NI ne lavez les articles qui ont été précédemment nettoyés, lavés, trempés ou détachés à l’aide d’essence, de
solvants de nettoyage à sec ou d’autres substances inflammables ou explosives, puisqu’ils peuvent émettre des vapeurs
susceptibles de s’enflammer ou d’exploser.
 N’ajoutez PAS d’essence, de solvants pour nettoyage à sec ni d’autres substances inflammables ou explosives dans l’eau
de lavage. Ces substances émettent des vapeurs susceptibles de s’enflammer ou d’exploser.
 EXPLOSIF. Si le système d’eau chaude n’a pas été utilisé sur une telle durée, avant d’utiliser la laveuse, ouvrez tous les
robinets d’eau chaude pour faire couler l’eau de chaque robinet pendant plusieurs minutes. Cette mesure libérera tout
gaz d’hydrogène accumulé. Étant donné que ce gaz est inflammable, NE fumez NI n’utilisez une flamme nue durant
cette manoeuvre.
 NE laissez PAS les enfants jouer sur ou dans cet appareil ou tout autre. Une surveillance étroite est requise lorsque des
enfants se trouvent à proximité de l’appareil en fonctionnement. Enlevez la porte ou le couvercle de la laveuse lorsque
l’appareil est mis hors service ou au rebut. L’omission d’observer ces instructions peut causer le décès ou des blessures.
 NE vous penchez PAS dans l’appareil si la cuve ou l’agitateur est en mouvement afin de prévenir l’emmêlement.
 N’installez NI ne rangez cet appareil dans un endroit exposé aux intempéries.
 NE modifiez PAS les commandes, ne réparez NI remplacez une quelconque pièce et ne tentez aucune réparation de
cet appareil, à moins que cela ne soit expressément recommandé dans les instructions d’entretien ou de réparation
destinées à l’utilisateur et dont vous avez une compréhension et une compétence suffisantes pour les appliquer.

Gardez la zone autour de l’appareil propre et sèche afin de réduire le risque de glissement.
 NE faites PAS fonctionner cet appareil s’il est endommagé, ne fonctionne pas correctement, est en partie démonté, ou encore
si des pièces sont manquantes ou abîmées, y compris le cordon électrique ou sa fiche.
 Débranchez l’appareil ou fermez le disjoncteur avant une réparation. Le fait d’appuyer sur le bouton Power (Alimentation) NE
coupe PAS l’alimentation électrique.
 Consultez la section « Exigences électriques » des instructions d’installation pour connaître la procédure de mise à la
terre.
CONSERVEZ CES INSTRUCTIONS
Ceci est un symbole d’alerte de sécurité. Ce symbole prévient d’un risque mortel ou de blessures encouru par
vous et d’autres personnes. Tous les messages de sécurité s’inscriront à la suite du symbole d’alerte et du mot
« DANGER », « AVERTISSEMENT » ou « MISE EN GARDE ». Ces mots sont associés aux définitions suivantes :
Indique une situation dangereuse qui, si elle n’est pas évitée, causera des blessures sévères, voire la mort.
Indique une situation dangereuse qui, si elle n’est pas évitée, peut causer des blessures sévères,
voire la mort.
Indique une situation dangereuse qui, si elle n’est pas évitée, peut causer des blessures mineures
ou modérément graves.
DANGER
AVERTISSEMENT
MISE EN GARDE
AVERTISSEMENT

3
electromenagersge.ca
LORSQUE L’APPAREIL N’EST PAS UTILISÉ
Fermez les robinets pour minimiser les fuites dans
l’éventualité d’un bris ou d’une rupture. Vérifiez l’état des
flexibles de remplissage ; GE recommande de remplacer
les flexibles tous les 5 ans.
Assurez-vous que le flexible d’eau chaude est connecté au
robinet en « H » (grillage interne rouge) et que le flexible
d’eau froide est connecté au robinet en « C » (grillage
interne bleu).
Installez ou rangez l’appareil là où il ne sera pas exposé
à des températures inférieures au point de congélation
ou aux intempéries, sinon il y a risque de dommage
permanent et invalidation de la garantie.
Mettez correctement la laveuse à la terre conformément
à tous les codes et règlements en vigueur. Observez
la procédure détaillée décrite dans les instructions
d’installation.
Pour garantir une installation adéquate, laver petites
brassées au cycle Whites (Blancs) AVANT de laver la
première brassée normale.
Cette laveuse n’est pas livrée avec les flexibles
d’alimentation d’eau.
GE recommande vivement l’utilisation de pièces spécifiées
par le fabricant. La liste ci-dessous énumère les flexibles
que l’on peut se procurer auprès du fabricant. Ces flexibles
sont fabriqués et essayés de façon à satisfaire aux
spécifications de GE.
GE recommande vivement l’utilisation de flexibles
d’alimentation d’eau neufs. Les flexibles se détériorent
avec le temps et ils doivent être remplacés tous les 5 ans
afin de réduire le risque de défaillance ou de dégât d’eau.
Pièces et accessoires
Appelez le 800.661.1616 ou contactez votre marchand de
pièces GE local.
Numéro de pièce Accessoire
PM14X10002 Flexibles d’alimentation d’eau en
caoutchouc – 1,2 m (4 pi)
Ou
PM14X10005 Flexibles d’alimentation d’eau en métal
tressé – 1,2 m (4 pi)
INSTALLATION APPROPRIÉE
Cette laveuse doit être installée correctement et positionnée conformément aux instructions d’installation avant
l’utilisation.Si vous n’avez pas reçu le guide d’installation, vous pouvez le recevoir en visitant electromenagersge.ca
ou en appelant le 800.561.3344.
CONSERVEZ CES INSTRUCTIONS

4
Taille de la brassée
Placez les vêtements dans le panier de la laveuse sans les comprimer. Toute surcharge pourrait avoir un impact
négatif sur les performances de laveuse. Adaptez la taille de la brassée en conséquence.
Reset (Réinitialisation)
Si vous souhaitez un niveau d’eau plus élevé, placez d’abord la commande Load Size (Taille de la brassée) à Reset
(Réinitialisation), puis à un niveau d’eau plus élevé.
Température
Choisissez la température de l’eau pour les programmes de lavage et de rinçage. Observez toujours les
recommandations indiquées sur les étiquettes d’entretien du fabricant ou ses instructions pour le lavage.
Options (sur certains modèles)
Assouplissant et Puissance Rinçage
Si vous utilisez le distributeur d’adoucissant, vous devez sélectionner cette option au cours du cycle rinçage et lorsque
vous utilisez du détergent ou du javellisant supplémentaire pour nettoyer des vêtements très sales pour fournir un
meilleur rinçage.
A
B
C
Controls
• Ajoutez le détergent
• Ajoutez l’assouplissant
dilué (sur les
modèles équipés
d’un distributeur
d’assouplissant)
• Ajoutez les articles • Sélectionnez la taille de
la brassée et les autres
options de lavage
•Sélectionnez le
programme de lavage
•Sélectionnez le Options
• Fermez le couvercle
• Tirez sur le bouton
Guide de démarrage rapide
A propos du tableau de commande.Pour les modèles avec
bouton de mise en marche « à tirer ».
Étape 1 Étape 2 Étape 3 Étape 4
AB C D
LOAD SIZE TEMPERATURE OPTIONS
