BEFORE YOU BEGIN
Read these instructions completely and
carefully.
IMPORTANT -I you,eceiveda
damaged commercial washer, you should immediately
contact your dealer or builder.
IMPORTANT - ObserveaH
governing codes and ordinances.
.Note to Installer- Be sure to leave these instructions
for the consumer's and local inspector's use.
, Skill revel - Installation of this commercial washer
requires basic mechanical and electrical skilrs. Proper
installation is the responsibility of the installer.
Product failure due to improper installation isnot
covered underthe GEAppliance Warranty.
FOR YOUR SAFETY
Read and observe all CAUTIONS and WARNINGS
shown throughout these instructions.
i i ii Hit i= i ==n = i
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
IPub,No,31-t5558
[Dwg,No,143BB310P032
ND 658-04(7/03)

TOOLS YOU WILL NEED:
Socketset
Slip]oint pliers
ii i i
Installation Preparation
i i i ] i
i i i i
ELECTRICAL AND PLUMBING
REQUIREMENTS
INSTALLATION REQUIREMENTS:
LOCATION
Washer must be installed on firm flooring to minimize
vibration during spin cycles. Concrete flooring is
best, but wood base [ssufficient providedthat floor
support meets FHA standards. Washer should not be
installed on rugs or carpet, be exposed to weather or
temperatures below freezing.
PLUMBING
•Water Pressure-Must be 10 psi minimum to 150psi
maximum dynamJc pressLire measured at faucet.
•Water Temperature-Water heater should be set to
deliver water at 120°F to 150% (50°Cto 66°C)IN
THEWASHER when HOTwash is selected.
•Shutoff Valves-Both hot and cold shutoff valves
(faucets) should be supplied.
•Drain-Water may be drained into a standpipe or set
tub. The discharge height MUST NOT BELESS
THAN 30INCHES nor more than 8 feet above the
base of the washer. The standpipe must be 1-1/2
inches minimum inside diameter and must be open
to the atmosphere.
i i i
COUNTDOWN DISPLAY
(WCCD AND WLCD MODELS ONLY)
The countdown display shows the remaining time in
the cycle. The display board isconfigured properly at
the factory for the correct cycle timer installed in the
washer. If you wish to change the cycle timer, or add a
debit card interface to the washer, you will need to
change the configuration setting of the countdown
display board as follows.
ON
1 2 3 4
32 Minutes
25 Minutes
21 Minutes
Debit Card
i i
Switch Numbers---]
1100'
0 1
1 0 10 _
o 0
iiii
i.iq
i
WARNING
• FORPERSONAL SAFETYDO NOTUSE
AN EXTENSION CORDORADAPTER
PLUGWiTH THIS APPLIANCE.
• DONOT,UNDERANY CIRCUM-
STANCE, CUTORREMOVETHETHIRD
GROUNDING PRONG FROMTHEPOWERCORD,
• FOLLOWNATIONAL ELECTRICCODEANSIINFPA
70 ORLOCALCODESAND ORDINANCES.
i i i i ii i
ELECTRICAL PREPARATION
This appliance must be supplied with 115V,60 Hz,and
connected to an individual, properly grounded branch
circuit, protected by a 15or
20 amp circuit breaker or
fuse.
• If the electric supply
provided does not meet
the above specifications,
call a licensed electrician. InsureProperGround ExistsBefareUse
GROUNDING INSTRUCTIONS
This appliance must be
grounded. In the event of
malfunction or breakdown,
grounding will reduce the risk
of electric shock by providing
a path of least resistance
for electric current. This
appliance is equipped with a
cord having an equipment- AttachGroun_l
grounding conductor and a (ObtainLocally)
grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and
grounded in accordance with all local codes and
ordinances.
If required, an external ground wire (not provided)
which meets local codes may be added. Attach to
washer cabinet with sheet metal screw (not provided)
to rear of washer as illustrated. The screw required is
a#8 sheet metal screw, 18 threads per inch, 1/2 inch
long. It can be obtained locally at any hardware store,
,_ WARNING: improper connection of the
equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician if
you are in doubt as to whether the appliance is
properly grounded. ii ii i

Installation Instructions
i i i
ii i i
rSTEP11 PREPARE WASHER ISTEP 3t ATTACH DRAIN HOSE
FOR INSTALLATION TO WASHER
•Grasp shipping rod on MoveWasherClose • Make certain all installation items have been
lower right side (it has a toFinalPosition removed from the washer basket.
tag or strap), and pull Shipping •IMPORTANT'.Remove red plug , Grommet
rod straight out and Roe from drain hose port. _i_ t /iI,__
discard, NOTE',Some water may be
present, this is normal, Plug
_gor . Locate plastic drain hose
adapter, Place hose clamp over
drain hose on& Insert drain
hose adapter into bent end of
drain hose, Position clamp to
Remove inner pack _ Inner secure hose adapter to drain
•hose, Push plastic hose clamp over hose adapter into
and installation _ Pack grooved slot.
NOTE:This requires some force to install, and has aaccessories from Partsand
under lid, Drain hose is _[_. _ Water positive click when forced into port. A positive click
in washer basket, __ Hoses(2) will ensure that the proper amount of force has been
applied,
[!,:_/1_ \ Drain Hose Drain
Ti Hose Adapter Hose
Screws Port
t
• Move washer to | Drain
installation location for _ Hose
remaining hose and
electrical preparation.
i i i ii iii i ]
ii] i i
ISTEP21ATTACH FILL HOSES •Push plastic conical end of drain hose adapter into
TO WASHER washer drain hose port. Insert two screws found in
insert rubber washers into both ends of each fill installation pack, and drive screws to mount drain
hose. Attach fill hose marked HOTto hot washer inlet hose to washer,
valve. Attach fill hose marked COLDto cold washer AntisiphanCip
inlet valve. Couplings should be hand
tightened plus 112turn with pliers, _,_!Cab!e tie
HandTightenPlus 3C)"_'_ : ,]
1/2TurnwithPliers Iti_r_ /
ColdWater_ Less
l-lose\ __ Hose _/_aa..._ _
Cabl_ Drain
Hose
NOTE:tf drain hose facility does not meet the 30"
minimum standpipe height requirement, thread drain
Water Washers ElectricalCord hose through supplied antisiphon clip and mount to
Hose cabinet back as shown. Mount antisiphon clip by
...... inserting top clip into top mounting hole and snap
second clip into position.
,ii

]1 , lu Installation Instructions iii i i i
iiii
ISTEP 41 ADJUST LEVELING LEGS
•Ptace level on front top edge of washer,
, Adjust front leveling legs until washer is level from
side-to-side. Remove level,
• Tilt washer forward (pivot on front legs) 4 to 6
inches, This action will set rear leg adjustments to
correspond to front setting.
•Gently set washer back down,
m
ide
ont
LevelingLegs
TiltWasherForward
4to6Inchesto Set
RearLegAdjustment.
ISTEP 5J INSTALL FILL HOSES
• Be sure water supply lines have been thoroughly
flushed,
• Move washer to final location, DO NOT let fill or
drain hoses drag and get under washer.
CAUTION - BESUREFILL
HOSESAREFIRMLY SECUREDTO FAUCETS.
• Determine which is the HOT water line before
attaching fill hoses to faucets. Traditionally, HOT
faucet is on the left. Be sure rubber washers are in
both ends of washer flit hoses, Connect hose from
inlet valve on washer (marked HOT)to hot faucet
and connect hose from COLDinlet valve to cold
faucet. Couplings should be hand tightened plus
t/2 turn with pliers.
HandTightenPius
1/2TurnwithPliers
,o
t _ scr=_ _. Cold
Water.. L=IRubber"Water
Hose "-_ wa_ Hose
ii
i
ii
!STEP 61 INSTALL DRAIN HOSE
•Insert one end of aluminum drain nozzle into
standpipe,
• Slip or cut wire wrap back approximately 2" below
top of standpipe,
• Cut drain hosejust below standpipe, Place silver
hose clamp over black drain hose end,
• Insert drain nozzle into end of drain hose, and
position clamp to secure drain nozzle to drain hose,
•Install drain hose in drain facility and secure with
cable tie strap provided as illustrated.
Secureto
Hose
Drain
CableTie Hose
NOTE:Drain hose nozzle may be shortened if original
length prevents full insertion into drain facility.
CAUTION - BESURE
DRAIN HOSEIS TAPEDORSECUREDTOSTANDPIPE
OROTHERDRAIN FACILITY.
NOTE:Water may be drained into a standpipe, The
discharge height must not be less than 30 inches, nor
more than 8 feet above base or washer. Standpipe
must be 1-1/2" minimum inside diameter and must be
open to atmosphere.
4

i
i
Installation Instructions= = = = i
ISTEP 71 ECONOMY WATER USAGE
The pressure sw tch sset n the factory for the high
water level and usage,
Tochange setting from high water level to medium or
low:
WARNING - MA*E
SUREWASHER IS UNPLUGGED FROM ELECTRICAL
OUTLET.
• Remove 4 torx screws from back of control panel
and lay control panel front on cover.
Remove
. From the front, move white plastic cam on pressure
switch in the clockwise position with your finger
[STEP 9] SPECIAL INSTRUCTIONS
COVERSECURITYLOCKINSTALLATION
Washer cover is designed to accept stud type lock
as shown below,
5/16"-t8 Thread 518"
!-*-L_f
I_- i-1/16"-"-I %arVbw
CamLockAvailable.__
FromGreenwald 11mF
Part#8-I222
To install lock:
• Remove plastic insert infront of cover,
•Install the lock washer on the lock shaft and locate
so that the lock can be engaged in a counterclock-
wise direction.
• Insert lock mechanism into cover opening and
tighten until snug. (Overtightening may damage
painted surfaces.)
until it clicks over into the medium or low water
position, (See illustration below,)
RotaLe
kwise
i iJ i
i ii i i i i
ISTEP 81 ELECTRICAL CONNECTION
CAUTION -BEFORE
PLUGGING INAPPLIANCE, READ ELECTRICALAND
PLUMBING REQUIREMENTSAND CHECKLIST,
Plug electrical power cord into a properly grounded
wall outlet.
• Install cam and tighten until snug,
ACCESSDOORLOCKINSTALLATION
Toremove the access door retainer before installing
a lock, place the door over a wood block with a t/2"
hole drilled in it and tap end of screw lightly with a
hammer.
_-Wood Bock
Nut
LockWasher
_) -SpringWasher
Nut_,,._l,._am

Installation Instructions
ii i
i i i i i i
[STEP 1OI CHECK LIST
i
i i
Review this list after installing the washer to avoid a
charge for a service call not covered by the warranty,
AFTER INSTALLATI0 NCHECK TtIE FOLLOWI NG:
[] Drain hose must be pulled tight and secured to
drain facility to prevent lifting out of drain facility
during discharge, Nozzle clamp must be securely
tightened to prevent leaks. MAKE SURE DRAIN
HOSE IS NOT RUBBING AGAINST CONCRETE OR
BLOCK WALL. RUBBING MAY WEAR HOLES IN
HOSE.
[] Hose Washers-Rubber washers in both ends offitl
hoses.
El Hose Connections-Hot side (left valve) connected
to hot water supply, cold side (right valve) to cold
water supply. All connections should be hand
tightened plus 1/2 turn with pliers.
[] Grounding-Must be properly grounded to conform
to !ocal codes and ordinances.
[] Leveling-Adjust front leveling legs as necessary
(preleveled from the factory at 1"). Check side to
side and front to back. Tilt forward approximately
4" to adjust rear self-leveling legs.
[] 0peration-Turn on faucets and run washer com-
pletely through cycle by hand. Check for leaks,
noise, vibration, correct water temperatures and
proper operation in wash and spin. While washer
is in spin, raise lid and check Lid switch and brake
operation,
i
i i
ISTEP 11tLITERATURE
• Be sure to leave complete literature package and
installationinstructions with consumer.
IL i
i i iji ii ii i i
TYPICAL HOSE INSTALLATIONS:
U
TypicalCompletedWasherAssembly
II J III
SPE01FICATIONSSUBJECTTOCHANGEWITHOUTNOTIOE
i ii i i.i i ii
ii ii i ii ii
WARNING
Foryoursafety,the informationin these instructions mustbe
followed to minimizethe risk of fire or explosion, electric shock,or to
prevent propertydamage,personal Injury,or lossof life.
WATER HEATER SAFETY
• Undercertain conditions hydrogengas maybe produced ina
water heater thathas not been usedfor two wealdsor more.
Hydrogengas can be explosiveunderthese circumstances.
• tf the hot water has not beenusedfor two weeks or more,prevent
the possibility ofdamageor injury byturning onall hotwater
faucets and allowing them torun for several minutes.Dothis
before using anyelectrical appliance which isconnected tothe
hot water system.This simple procedure will allow anybuilt-in
hydrogengas to escape, Sincethe gas is flammable,do not smoke
or usean openflame or appliance during this process.
YOUR LAUNDRY AREA
•Keepthe areaunderneath and aroundyourappliances freeof
• combustible materials such aslint,paper,rags,chemicals,etc.
Closesupervisionis necessaryif this appliance isused byor near
children. Donot allow children te play on.with, or insidethis or
any other appliance.
WHEN USING THE WASHER
•Neverreach intowasher while it is moving.Wait until the machine
has completely stopped before opening the _id.
•Do not mixchlorine bleachwith ammonia or acidssuch asvinegar
and/or rust remover.Mixing different chemicals canproduce a
• toxic gaswhich maycause death,
Do not washor dry articles that have beencleaned in, washedin,
soakedin, or spottedwith combustibleor explosivesubstances
(suchas wax, oil, paint,gasoline, degreaaers,dry-cleaning
solvents,kerosene,etc.). Thesesubstancesgive offvaporsthat
may ign_taor explode.Do not addthese substancesto thewash
water. Donot use or place these substances aroundyourwasher
or dryer during operation.
. Thelaundry process can reduce the flame retardancyof fabrics. To
avoidsuch aresult,carefully follow the garmentmanufacturers
wash andcareinstructions.
• Tominimizethe possibility of electric shock, unplug this appliance
fromthe power supply or disconnect the washer atthe household
distribution panelbyremoving the fuse or switching off thecircuit
breaker beforeattempting any maintenanceor cleaning.NOTE:
Turningthe Cycle Selector knobto anoff position doesNOT
disconnect the appliance from the power supply.
, Never attemptto o.j3eratethis appliance if it isdamaged,malfunc-
tioning,partially disassembled,or has missingor brokenparts,
including adamagedcord or plug.
WHEN NOT IN USE
• Turnoffwater faucets to relieve pressure onhoses andvalvesand
tominimizeleakageif a break or rupture shouldoccur.Checkthe
condition ofthe fill hoses;they shouldbe replacedevery5years.
• Beforediscarding a washer,or removingit from service, remove
the washer lid to prevent children fromhidlng inside.
• Donot attempt torepair or replace any partofthis appliance
unless specifically recommendedin these instructions or in
published user-repair instructions that youunderstandand have
the skills tocarry out.
• Donot tamper with controls.
READ AND FOLLOW THIS SAFETY
INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
