GEA GTR03BL series Operating instructions

350A4502P690 29-5697 03-11 ATS
GEAppliances.ca
Write the model and serial numbers here:
Model # __________________________
Serial # __________________________
Find these numbers on a label inside
the refrigerator on the side wall.
Refrigerators
GTR03BL...
Owner’s Manual
& Installation
Instructions
Safety Information . . . . . . .2–4
Operating Instructions
Care and Cleaning . . . . . . . . . . .7–9
Control Settings . . . . . . . . . . . . . . . .5
Refrigerator Features . . . . . . . . . . .6
Replacing the Light Bulb . . . . . . . .7
Installation Instructions . .10–12
Troubleshooting Tips . . .13, 14
Consumer Support
Consumer Support . . .Back Cover
Warranty . . . . . . . . . . . . . . . . . . . . .15
ATTENTION:
Defrosting—Do not use sharp,
pointed objects to remove frost or
ice from surfaces of the refrigerator
and/or freezer compartment. Doing
so could puncture the cooling coil,
causing the unit to lose its ability to
maintain cold temperatures and
voiding the warranty. See the Care
and Cleaning section for instructions
on defrosting the refrigerator
and/or freezer compartment.

Safety InstructionsOperating Instructions
Troubleshooting TipsConsumer Support Installation Instructions
DANGER! RISK OF CHILD ENTRAPMENT
Use this appliance only for its intended purpose as
described in this Owner’s Manual.
WARNING!
This refrigerator must be properly
installed and located in
accordance with the Installation
Instructions before it is used.
Do not allow children to climb,
stand or hang on the shelves
in the refrigerator. They could
damage the refrigerator and
seriously injure themselves.
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
Before replacing a burned-out
light bulb, the refrigerator
should be unplugged in order to
avoid contact with a live wire
filament. (A burned-out light bulb
may break when being
replaced.)
Keep fingers out of the “pinch
point” areas; clearances between
the doors and cabinet are
necessarily small. Be careful
closing doors when children
are in the area.
Unplug the refrigerator before
cleaning and making repairs.
Turning the temperature control
dial to the 0position stops
cooling but does not shut off
power to the refrigerator.
When using electrical appliances, basic safety precautions
should be followed, including the following:
SAFETY PRECAUTIONS
Child entrapment and suffocation
are not problems of the past.
Junked or abandoned refrigerators
are still dangerous… even if they
will sit for “just a few days.” If you
are getting rid of your old
refrigerator, please follow the
instructions below to help prevent
accidents.
Before You Throw Away Your
Old Refrigerator or Freezer:
Take off the doors.
Leave the shelves in place so
that children may not easily
climb inside.
Refrigerants
All refrigeration products contain
refrigerants, which under federal
law must be removed prior to
product disposal. If you are getting
rid of an old refrigeration product,
check with the company handling
the disposal about what to do.
PROPER DISPOSAL OF THE REFRIGERATOR
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
2

Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportInstallation Instructions
USE OF EXTENSION CORDS
Because of potential safety hazards under certain
conditions, we strongly recommend against the use of an
extension cord.
However, if you must use an extension cord, it is absolutely necessary
that it be a CSA-listed, 3-wire grounding type appliance extension cord
having a grounding type plug and outlet and that the electrical rating of
the cord be 15 amperes (minimum) and 120 volts.
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. For personal safety,
this appliance must be properly grounded.
The power cord of this appliance is
equipped with a 3-prong
(grounding) plug which
mates with a standard 3-prong
(grounding) wall outlet to minimize
the possibility of electric shock
hazard from this appliance.
Have the wall outlet and circuit
checked by a qualified electrician
to make sure the outlet is properly
grounded.
If you have only a standard
2-prong wall outlet, it is your
personal responsibility and
obligation to have it replaced with
a properly grounded
3-prong wall outlet.
The refrigerator should always be
plugged into its own individual
electrical outlet which has a
voltage rating that matches the
rating plate.
This provides the best
performance and also prevents
overloading house wiring circuits
which could cause a fire hazard
from overheated wires.
Never unplug your refrigerator by
pulling on the power cord. Always
grip plug firmly and pull straight
out from the outlet.
Repair or replace immediately all
power cords that have become
frayed or otherwise damaged.
Do not use a cord that shows
cracks or abrasion damage along
its length or at either end.
When moving the refrigerator
away from the wall, be careful
not to roll over or damage the
power cord.
3
GEAppliances.ca

WARNING!
USE OF ADAPTER PLUGS
ADAPTER PLUGS ARE NOT LEGAL IN CANADA.
READ AND FOLLOW THIS SAFETY
INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS
Safety InstructionsOperating Instructions
Troubleshooting TipsConsumer Support Installation Instructions
4
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.

Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportInstallation Instructions
Control Settings
The temperature control maintains the temperature in the refrigerator. 1
is the warmest setting; higher numbers are colder settings with 7being
the coldest setting. The typical setting is 3.
Allow 24 hours for the refrigerator to reach the desired temperature.
If you want a colder or warmer temperature, move the dial one setting at
a time. Moving the control to Ostops cooling but does not turn off the
power to the refrigerator. Setting the control too high may cause freezing
in the refrigerator depending on the room temperature.
How To Test Temperatures
Use the milk test. Place a container of milk on a shelf and check it
a day later. If the milk is too warm or too cold, adjust the temperature
control.
After changing the control, allow 24 hours for the refrigerator to reach
the temperature you have set.
The control will look like the one above.
The arrow indicates the setting selected.
0
7
6
5
4
3
2
1
5
About the control
on the refrigerator. GEAppliances.ca

6
Shelves
To remove a shelf, lift up the back slightly and pull forward.
Freezer Compartment
This compartment is designed for production of ice cubes and short-
term storage of some commercially frozen foods.
Door Shelves
Shelves on the door provide convenient storage for frequently
used items. The fresh food doors are capable of storing large bottles
for your convenience.
Safety InstructionsOperating Instructions
Troubleshooting TipsConsumer Support Installation Instructions
About the refrigerator features.
Fresh Food Storage Zones
For best results follow
the recommended
storage zones:
The top shelf is best
for storing fruits and
vegetables.
The bottom shelf is
best for storing
beverages, deli meats
and cheeses.
Case
Back Door
(Front)
BEST FOR BEVERAGES, DELI
MEATS, AND CHEESES
Bottom
Shelf
Top Shelf
deli
zone
FRUIT
zone
REFRIGERATOR STORAGE ZONES
BEST FOR FRUITS, VEGETABLES
Side View of Refrigerator

7
Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportInstallation Instructions
Cleaning the Outside
Keep the outside clean. Wipe with a clean cloth lightly dampened
with kitchen appliance wax or mild liquid dish detergent. Dry and
polish with a clean, soft cloth.
Do not wipe the refrigerator with a soiled dish cloth or wet towel.
These may leave a residue that can erode the paint. Do not use
scouring pads, powdered cleaners, bleach or cleaners containing
bleach because these products can scratch and weaken the paint
finish.
Protect the paint finish. The finish on the outside of the refrigerator
is a high quality, baked-on paint finish. With proper care, it will
stay new-looking and rust-free for years. Apply a coat of kitchen/
appliance wax when the refrigerator is new, and then at least
twice a year.
Cleaning the Inside
To help prevent odors, leave an open box of baking soda in the
refrigerator.
Unplug the refrigerator before cleaning. If this is not practical,
wring excess moisture out of sponge or cloth when cleaning
around the control.
Use warm water and baking soda solution–about a tablespoon
(15 ml) of baking soda to a quart (1 liter) of water. This both
cleans and neutralizes odors. Rinse and wipe dry.
Other parts of the refrigerator–including door gaskets, fruit
and vegetable drawers, and all plastic parts–can be cleaned
the same way.
Do not wash any plastic refrigerator parts in the dishwasher.
Care and cleaning
of the refrigerator. GEAppliances.ca
Replacing the Light Bulb
Unplug the refrigerator before replacing a burned-out bulb. Setting
the controls to 0does not remove power to the light circuit.
The light bulb is located behind the temperature control housing and
is visible through the clear lens.
Using a Philips screwdriver, unscrew the lens and pull horizontally until
the lens is removed. Gently unscrew the light bulb and replace with a
bulb of 15 watts or less.
5
6
4

Safety InstructionsOperating Instructions
Troubleshooting TipsConsumer Support Installation Instructions
Defrosting
Defrost whenever frost on the wall of the Freezer compartment
becomes 1/4” (64 mm) thick. Never use a sharp or metallic
instrument to remove frost as it may damage the cooling coils.
(A punctured cooling coil will cause serious problems and void the
warranty.) We recommend using a plastic scraper. Do not use any
electrical device in defrosting your refrigerator.
To defrost:
Remove foods from the Freezer and Fresh Food compartments.
Set the temperature control dial to 0.
Place a towel in the Freezer Compartment to soak up water.
Defrosting usually takes a few hours. To defrost faster, keep the
door open. Also using a hair dryer on the low setting may speed
defrosting.
Warning: using excessive heat may damage the plastic liner!
Do not pour water into the Freezer or Fresh Food compartments.
After defrosting:
Empty water from the drip tray. Wash the tray with warm water.
Wipe the Freezer and Fresh Food compartments with a damp cloth.
Turn the temperature control to the desired setting and return food
to the refrigerator.
NOTE: If ice buildup is very thick, it may keep the ice tray
compartment door from opening or closing completely. Don’t try to
force it open; after defrosting, the door will open and close easily.
Care and cleaning of the refrigerator.
8

Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportInstallation Instructions
Care and cleaning
of the refrigerator. GEAppliances.ca
Preparing for Vacation
For long vacations or absences, remove food and unplug the
refrigerator. Move the control to the 0position, and clean the interior
with a baking soda solution of one tablespoon (15 ml) of baking soda
to one quart (1 liter) of water. Leave the door open.
Preparing to Move
Secure all loose items such as shelves and ice trays by taping them
securely in place to prevent damage.
Be sure the refrigerator stays in an upright position during moving.
9

10
Preparing to install the refrigerator.
Read these instructions completely and carefully.
Refrigerator Location
Do not install the refrigerator where the temperature will go below
50°F (10°C) because it will not run often enough to maintain proper
temperatures.
Install it on a floor strong enough to support it fully loaded.
Do not install it closer than 5”(13 cm) next to a range.
Do not install it in a recessed area.
Do not build in the refrigerator.
Clearances
Allow the following clearances for ease of installation and proper
air circulation.
Sides 1/2” (13 mm)
Top 2” (51 mm)
Back 2” (51 mm)*
*From the rear cabinet surface to the wall
Leveling Legs (on some models)
Adjustable legs at the front corners of the refrigerator
should be set so the refrigerator is firmly positioned on
the floor and the front is raised just enough that the door
closes easily when opened about halfway.
To adjust the leveling legs, turn the legs
counterclockwise to lower the refrigerator, clockwise to
raise it.
Safety InstructionsOperating Instructions
Troubleshooting TipsConsumer Support Installation Instructions
