INTRODUCTION
INTRODUCTION
The GECKO® EXO US audiophile mixing console is the perfect solution for the modern day multi-style
professional audio installations, live sound reinforcement and studio applications. Anyone who has used or
heard our GECKO® professional audio equipment, will be familiar with its ability to create a warm, smooth,
and clean sound that can inject more soul into your music masterpieces.
Everything about the EXO US has been designed to give you maximum audio fidelity, from the 32-BIT
UTOPIA igital Signal Processing ( SP) technology to the superb sounding C.R.I.S.T.A.L.® Audiophile
PreAmps.
Equipped with a comprehensive range of GROUP, AUX, and OUTPUT options, you can be sure that the
EXO US desk is not only a fantastic piece of engineering, it also makes complex mixes easy!
The EXO US is available in two options, the 16-channel MXR 1604 SP and 32-channel MXR 3204 SP,
and is highly recommended for singers, musicians, audiophile enthusiasts, and sound engineers seeking
pure sounds.
______________________________________________________________________________________
1
1
© GECKO MUSIC GROUP. All Rights Reserved.

CONTROL ELEMENTS
CONTROL ELEMENTS
FRONT PANEL
NOTES: Regardless of the HPF switch setting, the mixing console does not apply
this HPF to the LINE inputs of STEREO input channels.
______________________________________________________________________________________
2
2
© GECKO MUSIC GROUP. All Rights Reserved.
1
ON ON ON ON ON ON
CHANNEL CONTROL SECTION
2 3
4
5
6
7
8
9
10
11
12
1. GAIN CONTROL
This control adjusts the sensitivity of both
MIC (XLR) and LINE (¼” TRS) inputs. Both
the MIC and LINE inputs are electronically
balanced, and are located on the rear
connector panel.
The -60 to -16 scale indicates the MIC input
adjustment level. The –34 to +10 scale
indicates the LINE input adjustment level.
The EXO US GAIN structure employs the
revolutionary GECKO® C.R.I.S.T.A.L.®
Audiophile PreAmps technology.
2. PEAK LED
The PEAK LE detects the peak level of
the post-equalizer signal, and lights up red
when the level reaches 3dB below the
clipping level. On stereo input channels
equipped with XLR (female) MIC inputs
(Channels 9/10 and 11/12), the PEAK LE
detects both the post-equalizer and post-
preamp peak levels, and lights up red if
either of these levels reaches 3dB below
the clipping level.
3. HIGH PASS FILTER (HPF) SWITCH
This switch toggles the HPF ON or OFF. To
turn the HPF ON, press the switch in. The
HPF cuts frequencies below 80Hz.
Channels 1 to 8
(Monaural)
Channels 9/10, 11/12, 13/14, 15/16
(Stereo)

4. EQUALIZER (EQ)
MONAURAL CHANNELS (CHANNELS 1 TO 8):
This three-band equalizer adjusts the channel’s high, mid, and low frequency bands. Setting the knob to the
position produces a flat (linear) frequency response. Turning the knob to the right boosts the
corresponding frequency band, while turning to the left cuts the band. The following table shows the EQ type,
base frequency, and maximum cut/boost for each of the three bands.
Ba d Type Base Freque cy Maximum Cut/Boost
HIGH Shelving 10kHz
±15dB
MI Peaking 250Hz – 5kHz, variable
LOW Shelving 100Hz
STEREO CHANNELS (CHANNELS 9/10, 11/12, 13/14, 15/16):
This four-band equalizer adjusts the channel’s high, hi-mid, lo-mid, and low frequency bands. Setting the
knob to the position produces a flat (linear) frequency response. Turning the knob to the right boosts the
corresponding frequency band, while turning to the left cuts the band. The following table shows the EQ type,
base frequency, and maximum cut/boost for each of the four bands.
Ba d Type Base Freque cy Maximum Cut/Boost
HIGH Shelving 10kHz
±15dB
HI-MI Peaking 3kHz
LO-MI Peaking 800Hz
LOW Shelving 100Hz
5. AUX1 / AUX2 CONTROLS
The AUX1 knob controls the signal level that the channel sends to the AUX1 bus; the AUX2 knob controls the
signal level to the AUX2 bus. These knobs should generally be set close to the position.
If you are using stereo channels, the signals from the L (O ) and R (EVEN) channels are mixed and sent
to the AUX1 and AUX2 buses.
NOTES: These controls allow you to output the signal to the AUX buses regardless
of the setting of the ST switch [9].
6. PRE SWITCH
Selects whether the pre-fader or the post-fader signal is fed to the AUX2 bus. If you set the switch ON
(pressed in), the mixing console sends the pre-fader signal (the signal prior to passage through channel
fader [12]), to the AUX2 bus, so that AUX2 output is not affected by the fader. If you set the switch OFF (out
position) the mixing console sends the post-fader signal to the AUX2 bus.
NOTES: This switch applies to AUX2 only. The signal to the AUX1 bus always
passes through the channel fader first.
______________________________________________________________________________________
3
3
© GECKO MUSIC GROUP. All Rights Reserved.

7. EFFECT CONTROL
Adjusts the level of the signal sent from the channel to the EFFECT bus. Note that the signal level will also
vary according to the setting of the channel fader.
If you are using stereo channels (Channels 9/10, 11/12, 13/14, 15/16), the signals from the L (O ) and R
(EVEN) channels are mixed and then sent to the EFFECT bus.
8. PAN CONTROL (CHANNELS 1 TO 8), PAN/BAL CONTROL (CHANNELS 9/10, 11/12, 13/14, 15/16)
The PAN control determines the positioning of the channel’s signal on the GROUP 1-2/3-4 buses or on the
ST (STEREO) L and R buses.
The BAL control knob sets the balance between left and right channels. Signals into to the L input (O
channel) feed to the GROUP 1/3 bus or to the ST (STEREO) L bus; signals into the R input (EVEN channel)
feed to the GROUP 2/4 bus or the ST (STEREO) R bus.
NOTES: On channels where this knob provides both PAN and BAL controls (9/10,
11/12, 13/14, 15/16), the knob operates as a PAN control if you are inputting through
the MIC input or into the L (MONO) input only, and operates as a BAL control if you
are inputting into both L and R inputs.
9. ST SWITCH
This switch assigns the channel’s signal to the ST (STEREO) L and R buses. To send the signal to the
STEREO bus, set the switch ON by pressing it in. The switch lights up (amber) to indicate that it is ON.
10. PFL (PRE-FADER LISTEN) SWITCH
This switch lets you monitor the channel’s pre-fader signal. To set the switch ON, press it in. The switch lights
up (amber) in the ON mode. When the switch is ON, the mixing console outputs the channel’s pre-fader
signal to the PHONES and C-R OUT connectors, for monitoring.
11. GROUP SWITCHES
Use these switches to send the channel's signal to the GROUP 1-2 and/or GROUP 3-4 buses. Setting the
switch on (pressed in) causes the signal to be sent to the corresponding group buses.
NOTES: These switches allow you to assign the signal to either or both groups
regardless of the setting of the ST switch [9].
______________________________________________________________________________________
4
4
© GECKO MUSIC GROUP. All Rights Reserved.

12. CHANNEL FADER
Adjusts the output level of the channel's input signal. Use these faders to adjust the volume balance among
the various channels.
NOTES: To reduce noise, set the fader sliders for unused channels all the way
down. Always ensure that you work with clean sources.
MASTER CONTROL SECTION
______________________________________________________________________________________
5
5
© GECKO MUSIC GROUP. All Rights Reserved.
13. ST (STEREO) MASTER FADER
Adjusts the signal level to the STEREO OUT (ST OUT) output
connectors.
14. GROUP FADERS (1-2, 3-4)
Adjusts the signal level to the GROUP OUT 1 to 4 output
connectors.
15. TO ST SWITCH
If this switch is ON (pressed in), the mixing console sends the
signals processed by the GROUP FA ERS [14] onto the ST
(STEREO) bus. The GROUP 1/3 signals go to STEREO L and
the GROUP 2/4 signals go to STEREO R.
16. MASTER SEND
AUX1 / AUX2 CONTROLS
Adjust the level of the signal output to the AUX1 SEN and
AUX2 SEN output connectors.
MASTER EFFECT CONTROL
Adjusts the level of the signal on the EFFECT bus. This is the
signal that is output through the EFFECT output connectors.
1314
15
16
17
18
20
21
22
23
19
POWER
ST RL
PEAK
+5
+3
+1
0
-1
-3
-5
-7
-10
-15
-20
24
25
26
NOTES: These MASTER SEN
controls do not affect the level of the
signal sent from the internal digital
effects processor onto the MASTER
EFFECT bus.
ON

17. RETURN (AUX1, AUX2, ST CONTROLS)
AUX1 / AUX2 CONTROLS
Adjust the level of the mixed L/R signals sent from the RETURN connectors (L (MONO) and R) to the AUX1
and AUX2 buses.
ST CONTROL
Adjusts the level of the signals sent from the RETURN connectors (L (MONO) and R) to the STEREO bus.
NOTES:
If you supply a signal to the RETURN L (MONO) input connector only, the
mixing console outputs the identical signal to both the L and R STEREO buses.
18. 2TR IN CONTROL
Adjusts the level of the signals sent from the 2TR IN input connectors to the STEREO bus.
19. PHANTOM +48V SWITCH
This switch toggles phantom power ON and OFF. If you set the switch ON, the mixing console supplies C
+48V power to all channels (Channels 1 to 8, 9/10, 11/12) that provide MIC (XLR female) input connectors.
Set this switch ON (pressed in, red LE on switch lights up) when using one or more condenser
microphones.
WARNING: Be sure to leave this switch OFF (switch not pressed in) when you are
not using phantom power. Humming or damage may result if you connect to an
unbalanced device or to an ungrounded transformer while this switch is ON (pressed
in, red LE on switch lights up). But note that the switch may be left ON without
problem when connecting to balanced dynamic microphones.
To avoid damage to speakers, be sure to turn OFF amplifiers (or powered speakers) before turning this
switch ON or OFF.
20. LEVEL-METER SIGNAL SWITCHES
These level-meter switches, together with the channel PFL switches, select the signal that is sent through
the C-R/PHONES control to the C-R (CONTROL ROOM) OUT connectors, the PHONES connector, and the
LEVEL METER.
The following illustrates how the switch settings correspond to the signal selection.
•If the input channel’s PFL switch is ON (pressed in, amber LE on switch lights up), then only the
channel’s PFL output is sent to the C-R OUT connectors, PHONES connector, and LEVEL METER.
•If the 2TR IN switch is ON (pressed in), the signal supplied to the 2TR IN input connector is sent to
the C-R OUT connectors, PHONES connector, and LEVEL METER. If the 2TR IN switch is off (not
pressed in), then either the STEREO, GROUP 1-2, or GROUP 3-4 signal is sent to the C-R OUT
connectors (as determined by the ST-GROUP and GROUP toggle switches).
______________________________________________________________________________________
6
6
© GECKO MUSIC GROUP. All Rights Reserved.

21. C-R/PHONES CONTROL
Controls the level of the signals output to the PHONES connector and the C-R L and R connectors.
22. LEVEL METER
This 12-segment LE METER shows the level of the signals selected by the selection switches described in
[20] above (the level to the C-R OUT and PHONES connectors). The “0” point corresponds to the standard
output level. The indicator lights up red when the output hits the clipping level.
23. POWER INDICATOR
This indicator lights up when the mixing console's power is ON.
24. ST GRAPHIC EQUALIZER
This 7-band equalizer adjusts the sound of the signal send to the ST OUT connectors. The equalizer is
effective only if the GEQ switch is set ON (pressed in, amber LE on switch lights up). The equalizer cuts or
boosts each band (125Hz, 250Hz, 500Hz, 1kHz, 2kHz, 4kHz, and 8kHz) over a range of ±12dB.
25. PHONES CONNECTOR
Connector for headphones. This is a balanced stereo phone-type (¼” TRS) output connector.
NOTES: The signals monitored by this connector are selected by the LEVEL-
METER SIGNAL switches and the channel PFL switches.
26. UTOPIA DIGITAL EFFECTS
PROGRAM DIAL
Selects the internal UTOPIA 32-BIT SP to be applied. You can select from 16 effects, as shown in the table.
1HALL 1 9VOCAL ECHO 1
2HALL 2 10 VOCAL ECHO 2
3HALL 3 11 VOCAL ECHO 3
4ROOM 12 VOCAL ECHO 4
5 PLATE 1 13 VOCAL REVERB 1
6 PLATE 2 14 VOCAL REVERB 2
7 PLATE 3 15 VOCAL REVERB 3
8 GATE REVERB 16 VOCAL REVERB 4
For the full range standalone effects, please check out GECKO® UTOPIA SP 2206 IGITAL MULTI
EFFECTS.
PARAMETER CONTROL
Adjusts the parameter (depth, speed, etc.) for the selected effect.
AUX1 PRE / AUX2 PRE CONTROLS
Adjust the level of the signals sent from the internal UTOPIA 32-BIT igital Signal Processor ( SP) unit to
the AUX1 and AUX2 buses.
______________________________________________________________________________________
7
7
© GECKO MUSIC GROUP. All Rights Reserved.

EFX ON SWITCH
Switches the internal effect ON or OFF. The internal effect is applied only if this switch is turned ON (pressed
in, switch lights up in amber).
PFL SWITCH
Set this switch ON (pressed in) if you wish to output the effect signal to the PFL bus.The switch lights up
(amber) in the ON mode.
GROUP 1-2 / GROUP 3-4 SWITCHES
Set one or both switches ON (pressed in) to output the internal effect signal to the GROUP 1-2 and/or
GROUP 3-4 buses.
EFFECT RTN FADER
Adjusts the signal level from the internal digital effects unit to the STEREO bus.
REAR PANEL
27. CHANNEL INPUTS
MIC INPUT CONNECTORS
These are balanced XLR (female) type input connectors.
LINE INPUT CONNECTORS
These are balanced phone-type (¼” TRS) input connectors. You can connect either balanced or unbalanced
phone-type plugs to these connectors.
NOTES: Where an input channel provides both a MIC connector and a LINE
connector, you may use either one of these connectors but you must not use both at
the same time. Please connect to only one of these connectors on each channel.
______________________________________________________________________________________
8
8
© GECKO MUSIC GROUP. All Rights Reserved.
27
28
I
O
30
29
3138
37
32
33 34
35 36

28. INSERT I/O
These are balanced phone-type input/output connectors. Each of these connectors is positioned between the
equalizer and fader of the corresponding input channel (Channels 1 to 8). These connectors can be used to
independently connect these channels to devices such as graphic equalizers, compressors, external effects,
and noise filters. These are ¼” TRS (tip, ring, sleeve) phone-type connectors that support bidirectional
operation.
29. CHANNEL INPUTS (UNBALANCED)
These are unbalanced input connectors. Two connector types are provided: ¼” TS phone-type (Channels
9/10 to 15/16) and RCA (Channels 13/14, 15/16). Use these connectors to input stereo signals, inputting the
L signal(s) to the O -numbered channel(s) and the R signal(s) to the EVEN-numbered channel(s).
NOTES: Where a channel provides both phone-type (¼” TS) connectors and RCA
connectors, you must use either one of these connectors but you may not use both
at the same time. Please connect to only one of these connectors on each channel.
The phone-type (¼” TS) connectors for Channel 9/10 and 11/12 also support
monaural input. Specifically, if you input only into the L (MONO) connector of either
pair (while leaving the R connector empty), the mixing console will propagate the
same signal through both the L (MONO) and R inputs.
30. GROUP OUT (1-4)
These are impedance-balanced phone-type (¼” TRS) output connectors that output the GROUP 1-2/3-4
signals. Use these connectors to connect to the inputs of a multitrack hard disk recorder, external mixing
console or other such device.
31. ST (STEREO) OUT
These balanced XLR (male) and ¼” TRS connectors output the mixed signal whose level is adjusted by the
ST fader in the MASTER CONTROL SECTION. Output is in STEREO (L and R). You use these connectors,
for example, to connect to the power amplifier driving your main speakers.
32. C-R (CONTROL ROOM) OUT
These are impedance-balanced ¼” TRS output connectors. These connectors output the mixed signal
whose level is adjusted by the C-R/PHONES control. Output is in STEREO (L and R). These connectors are
typically used to connect to a monitor system in a control room.
NOTES: The signals by these output connectors are monitored by selecting the
level-meter signal switches and the channel PFL switches.
33. SEND
AUX1 / AUX2
These are impedance-balanced ¼” TRS output connectors. These connectors output the signal from AUX1
and AUX2, respectively. You use these connectors, for example, to connect to an external effects unit or to a
cue box or other such monitoring system.
______________________________________________________________________________________
9
9
© GECKO MUSIC GROUP. All Rights Reserved.

EFFECT
This is an impedance-balanced ¼” TRS output connector that outputs the signal from the EFFECT bus. You
use this output connector, for example, to connect to an external effects unit.
34. RETURN L (MONO), R
These are unbalanced ¼” TS input connectors. The signal received by these input connectors is sent to the
STEREO bus and the AUX1 and AUX2 buses. These input connectors are typically used to receive a return
signal from an external effects unit (reverb, delay, etc.).
NOTES: These input connectors can also be used as an auxiliary stereo input. If you
connect to the L (MONO) input connector only, the mixing console will recognize the
signal as monaural and will propagate the identical signal on both L and R
connectors.
35. REC OUT (L, R)
These are unbalanced RCA-type output connectors. By connecting these connectors to an external recorder,
you can record the same signal that is being output from the ST (STEREO) OUT connectors.
NOTES: The mixing console’s ST MASTER FA ER does not operate on the signal
output from these connectors. Be sure to make appropriate level adjustments at the
external recording device.
36. 2TR IN
These unbalanced RCA input connectors are used to input a stereo sound source. Use these connectors
when you want to connect a stereo sound sources (C or AT) directly to the mixing console for monitoring.
NOTES: You can adjust the signal level using the 2TR IN control in the MASTER
CONTROL SECTION.
37. POWER SWITCH
Use this switch to set the mixing console power to ON [I] or STAN BY [O].
WARNING: Note that trace current continues to flow while the switch is in the
STAN BY position. If you do not plan to use the mixing console again for a long
while, be sure to unplug the adaptor from the wall outlet.
______________________________________________________________________________________
10
10
© GECKO MUSIC GROUP. All Rights Reserved.

38. AC ADAPTOR
For GECKO® EXO US MXR 1604 SP, use the included power adaptor. For GECKO® EXO US MXR
3204 SP, use the built-in power cord.
WARNING: Be sure to verify your actual line voltage is the same as the voltage level
required by your mixing console. Connection to an inappropriate power source may
result in fire or electric shock, and extensive damage which is not covered by the
warranty.
MAKING CONNECTIONS
MAKING CONNECTIONS
The GECKO® EXO US MXR 1604 SP / MXR 3204 SP can be used for many professional applications in
both live and studio settings.
For all connections, refer to the following steps:
1. Before connecting to microphones and instruments, be sure that all devices are turned OFF. Also be
sure that all of the mixing console's channel faders and master control faders are set all the way
down.
2. For each connection, connect one end of the cable to the relevant microphone or instrument and
connect the other end to the appropriate LINE or MIC connector on the mixing console. Where an
input channel provides both a MIC connector and a LINE connector, you may use either one of these
connectors but you must not use both at the same time. Please connect to only one of these
connectors on each channel.
3. Make connections using quality audio cables (i.e. GECKO® TRUTH T3AL) and connectors (i.e.
GECKO® OLYMPIAN connectors) according to your requirements.
4. To avoid causing damage to speakers, power up the devices in the following order: Peripheral
devices → mixing console → power amplifiers (or powered speakers). When shutting the system
down, turn OFF the power in the reverse order: Power amplifiers (powered speakers) → mixing
console → peripheral devices.
5. Although it requires no special ventilation, ambient temperatures should not exceed 113°F (45°C)
when equipment is powered.
MOUNTING YOUR MIXING CONSOLE
MOUNTING YOUR MIXING CONSOLE
For mixing console mounting, refer to the following steps:
1. Two metal rack-mount supports are screwed onto the unit. Use a screwdriver to remove these
supports.
2. Turn the supports over, and fasten them into place again using the same screws.
3. Mount the unit into the rack, and fasten it into place.
______________________________________________________________________________________
11
11
© GECKO MUSIC GROUP. All Rights Reserved.

SPECIFICATIONS
SPECIFICATIONS
Pre-Amplifiers:
GECKO® C.R.I.S.T.A.L.® Audiophile PreAmps
Freque cy Respo se
10Hz ~ 25kHz
Cha els I puts:
GECKO® EXODUS MXR 1604DSP:
8 Monaural (8 MIC XLR Female, 8 LINE ¼” TRS), 4 Stereo (8 LINE ¼” TRS)
GECKO® EXODUS MXR 3204DSP:
24 Monaural (24 MIC XLR Female, 24 LINE ¼” TRS), 4 Stereo (8 LINE ¼” TRS)
Cha el I serts:
GECKO® EXODUS MXR 1604DSP:
Channel 1 ~ 8 (¼” TRS)
GECKO® EXODUS MXR 3204DSP:
Channel 1 ~ 24 (¼” TRS)
Other Co ectio s:
AUX SEN , +4dBu (2); EFFECT SEN , +4dBu (1); STEREO EFFECT RETURN (L, R), +40dBu; STEREO
AUX RETURN (L, R), -10dBu; PHONES; ST OUT: XLR Male (L, R), 1/4" TRS (L, R), +4dBu;
C-R OUT (L, R), +4dBu; GROUP OUT, +4dBu (4); REC OUT, RCA (L, R), -10dBV;
2TR IN, RCA (L, R), -10dBV
Systems:
GECKO® C.R.I.S.T.A.L.® Audiophile PreAmps, GECKO® UTOPIA 32-BIT SP, GECKO® Custom Ultra
Low-Noise Faders (60mm), 7-Band Stereo Graphic EQ (GEQ ON/OFF), Precision Channel EQ, +48V C
Phantom, 12-Segment LE Meters (ST OUT, PFL, GROUPS, 2TR IN, C-R OUT, PHONES), PFL, HPF,
PRE/POST Fader, PRE/POST EQ, PEAK Indicators, AUX Bus, GROUP Bus, MAIN STEREO Bus, EFX
Bus, PHONES Bus
Accessories:
Rack-Mounting Kit (2)
Physical Properties:
GECKO® EXODUS MXR 1604DSP:
Color: Metallic Grey
Net Weight: 5.70Kg
imension: (H) 110mm x (W) 425mm x ( ) 400mm
GECKO® EXODUS MXR 3204DSP:
Color: Metallic Grey
Net Weight: 10.80Kg
imension: (H) 110mm x (W) 830mm x ( ) 400mm
Specifications subject to change without prior notice. Manufactured under ISO9000 certified management
system.
______________________________________________________________________________________
12
12
© GECKO MUSIC GROUP. All Rights Reserved.

GECKO
GECKO®
® TERMS OF WARRANTY
TERMS OF WARRANTY
WARRANTY:
GECKO MUSIC GROUP warrants its GECKO® products for a period of three (3) years from the original date
of purchase, in accordance to the warranty regulations described below.
WHAT IS COVERED:
uring the applicable warranty period, GECKO MUSIC GROUP warrants the product against defects in
materials and workmanship and against malfunctions. GECKO MUSIC GROUP will remedy all such defects
and malfunctions without charge for parts or labour if the warranty applies. In the case that other parts are
used which constitutes an improvement, GECKO MUSIC GROUP may, at its discretion, charge the customer
for the additional cost of these parts. Final determination of warranty coverage lies solely with GECKO
MUSIC GROUP.
WHAT IS NOT COVERED:
1. If the product needs to be modified or adapted in order to comply with applicable technical or safety
standards on a national or local level, in any country which is not the country where the product was
originally developed and manufactured, this modification/adaptation shall not be considered a defect in
material or workmanship.
2. Normal wear and tear, in particular, of faders, cross faders, potentiometers, keys/buttons, valves,
guitar/bass strings, machine heads, pick-up covers, vinyl covers, illuminants, and similar parts are not
covered by this warranty.
3. Improper handling, neglect or failure to operate the unit in compliance with the instructions given in the
user or service manuals.
4. Connection or operation of the unit in any way that does not comply with the technical or safety
regulations applicable in the country where the product is used.
5. amages/defects caused by force of nature or any other condition that is beyond the control of GECKO
MUSIC GROUP.
6. Any repair or opening of the unit carried out by unauthorized personnel (user included) will void the
warranty.
7. Modification or removal of serial numbers.
OBTAINING WARRANTY SERVICE:
To return a GECKO® product for warranty service, first fill out the O li e Tech ical Report on
www.geckomusic. et and submit for an authorization/service number. Write the authorization/service
number so that it is prominently displayed on the outside of the shipping carton. Any products received
without an authorization/service number that is clearly visible upon arrival at the factory will be refused.
Enclose proof of the original delivery date or a copy of the original sales receipt/invoice. Enclose a
description of the suspected defect or malfunction and the condition, if any, which caused the problem.
Return the product to GECKO MUSIC GROUP.
WARRANTY SHIPPING:
You are responsible for prepaying shipping costs F.O.B. GECKO MUSIC GROUP, Melaka, Malaysia.
Shipped product(s) must be properly packaged. Use original shipping cartons and packing materials where
possible. GECKO MUSIC GROUP is not responsible for damages resulting from inadequate and or improper
packing. Products received with damages due to improper packaging will be deemed out of warranty.
______________________________________________________________________________________
13
13
© GECKO MUSIC GROUP. All Rights Reserved.

Products which do not meet the terms of this warranty will be repaired exclusively at the buyer’s expense.
GECKO MUSIC GROUP will inform the buyer of such circumstance. If the buyer fails to submit a written
repair order within six (6) weeks after notification, GECKO MUSIC GROUP will return the unit C.O. . with a
separate invoice for freight and packing. Such costs will also be invoiced separately when the buyer has sent
in a written repair order.
WARRANTY RIGHTS:
This warranty is exclusive and extended to the original buyer and is not transferable to anyone who may
subsequently purchase this product. No other person (apart from authorized GECKO® Stores) shall be
entitled to give any warranty promise on behalf of GECKO MUSIC GROUP.
______________________________________________________________________________________
14
14
© GECKO MUSIC GROUP. All Rights Reserved.
This manual suits for next models
1
Table of contents
Other Gecko Music Mixer manuals
