Geek Tek sonic boombox User manual

SONIC BOOMBOX PARTY SPEAKER
Wireless Stereo Speaker with Subwoofer
BLUETOOTH®INDOOR & OUTDOOR PARTY SPEAKER
Instruction Manual
Please Read All Instructions Carefully and
Retain For Future Use
1

2
PACKAGE CONTENTS
Bluetooth®Indoor and Outdoor Party Speaker
Shoulder Strap
USB Charging cable
3.5mm auxiliary cord
This instruction manual
FEATURES
1. Bluetooth®speaker with built-in Subwoofer
2. Clean, crisp, booming sound
3. Compatible with Bluetooth®devices
4. Can connect other devices via 3.5mm auxiliary cord
5. Durable, rugged and splash proof, perfect for indoor or outdoor use
6. Built-in USB/SD card slots for listening to music from digitally stored
les
7. USB rechargeable built-in battery
8. Detachable shoulder strap allows for easy portability
IMPORTANT SAFETY INFORMATION
1. Read all instructions before using this product.
2. Do not leave unattended while connected to the power supply.
3. Do not immerse in water or any other liquids.
4. Do not use if unit has been dropped or damaged in any way.
5. Repairs to electrical equipment should only be performed by qualied
personnel. Improper repairs may place user at serious risk.
6. When using unit, always place on even surface, free of vibrations and
away from sources of heat.
7. Do not use with wet hands.
8. Do not put objects into the openings.
9. Keep free of lint, dust, hair, etc…
10. Do not use this unit for anything other than its intended use.
11. This is not a toy.
12. Keep unit out of reach of small children.
13. Do not play music at excessive levels especially near children as
damage to hearing may occur.

3
INSTRUCTIONS FOR USE
Charging the Speaker (for best results, fully charge the unit before use.)
1. Connect the included USB cord to the charging port (#1 on gure
above) and insert the other end into a port on your computer or
similar power source.
2. The Red LED on the back turns on indicating that the battery is being
charged. Once it is fully charged, the Red LED will turn o. It takes
approximately 4 to 5 hours to fully charge.
Note: In order to have optimum battery life, it is recommended to not
charge in excess of 6 hours at any one time. Overcharging can adversely
impact the battery life.
On/O Controls of Speaker
1. To Turn “ON” slide the “POWER ON/OFF” Switch (#3 on gure above) to
the ON position.
2. To Turn “OFF” slide the “POWER ON/OFF” Switch (#3 on gure above) to
the OFF position.
DESCRIPTION OF CONTROLS
1. USB Charging Port
2. Auxiliary Port
3. ON / OFF Switch
4. Skip Backward
5. Play / Pause
6. Skip Forward
7. USB Port (Stream Music)
8. Volume Controller
9. LED Light Indicator
10. SD Slot (Stream Music)
11. Mode Button
Figure 1
MODE
SD
- VOL +
ON OFF

AUX
USB
DC 5V
1.
7.
2.
8.
3.
9.
4. 5.
10.
6.
11.

4
Pairing your device via Bluetooth®(will only work with Bluetooth®enabled
devices)
1. Turn ON the speaker.
2. You will hear a BEEP TONE and the LED Lights will blink steadily. The speaker is now
in pairing mode.
3. Turn on the Bluetooth®on your Bluetooth®device.
4. Your device will begin searching for Bluetooth®ready devices.
5. The pairing name of the Party Speaker is “GT PARTY SPEAKER” . Pair it with this
device.
6. If required, enter the password‘0000’ to conrm and nalize pairing.
7. Once paired successfully, the Blue LED will illuminate.
8. If you fail to pair it within the time frame or you want to pair it with a new device,
please repeat the instructions in this section.
(Note: Speaker will automatically pair with previously paired devices)
Listening to Music Wirelessly
Please ensure that your Bluetooth®enabled device (iPhone®, Tablet, iPad®, iPod®,
Computer or other Smartphone) is paired with the Bluetooth®Speaker to stream music
wirelessly. Once it is paired, play music from your device by selecting your favorite song,
album or playlist from it.
Function Operation Button
Increase /
Decrease
Volume
Playing Music Use the Volume Controller located on the control
panel to adjust the volume to your desired level
(see Figure 1)
Pause Playing Music Press Play/Pause button  once to pause music
(see Figure 1)
Play Pause Press Play/Pause button  again to resume (see
Figure 1)
Previous
Track
Playing Music Short press the button to go back to the
previous track (see Figure 1)
Next Track Playing Music Short press the button to advance to the next
track (see Figure 1)
Aux Function of the Speaker (to play music from non-Bluetooth®devices)
1. Turn on the speaker.
2. Plug the 3.5mm auxiliary cord (included) to the auxiliary port of the speaker (see
Figure 1).
3. Plug the other end of the 3.5mm cord into the audio device with the music.
(iPhone®, iPad®, Tablet, MP3 Player, Computer and other Smartphones)
4. Press “MODE”button to select the “Aux-In”function (see Figure 1).
5. Select your favorite song on the source audio device.

5
Note: Once the Aux cable is connected to the unit and device, music via
Bluetooth®connection will be stopped. Media and volume can be controlled
only through the source devices, while playing music in the Auxiliary mode.
Listening to Music using USB/SD Card Slot
1. Turn on the speaker.
2. Insert SD Card or USB Flash Drive into the correct slot (see Figure 1).
Music will automatically start to play.
3. Press Skip Forward or Skip Backward to move forward or backward on
your playlist.
4. Press Play/Pause to PLAY or PAUSE a track.
Note: While using Bluetooth®, if you insert SD Card or USB Flash Drive,
speaker will disconnect the Bluetooth®connection and switch to the
USB/SD card function. You can press the MODE button again to play via
Bluetooth®.
TIPS:
1. Press the MODE button to switch between dierent functions of the
speaker. Switch between Bluetooth®, SD Card and USB or AUX-In.
2. When the unit is not in use, turn OFF the device to save battery power.
3. Do not overcharge the unit. Do not exceed 6 hours of charging to
avoid overcharging the unit.
4. To preserve battery power while in use, play at moderate volume
instead of max volume.
Specications:
Bluetooth®Version: 2.1 + EDR
Subwoofer size: 3”
Speaker Output: 2x2 Watts + 1 x 5 Watts Subwoofer
Unit Size: 10” x 5.5” x 4.5”
Approx Unit Weight: 2.2 lbs
Play Time: Up to 1.5 hours (max volume) and 4 hours (moderate volume)
Charge Voltage: DC5V (USB)
Bluetooth®Range: 27 to 33 Feet
Built-In Rechargeable Battery: 3.7V/1000mAH
(Note: Battery life and charging time may vary based on usage and types of
devices connected.)

6
TROUBLESHOOTING
Problem Possible Cause Solution
Low Sound Level Source volume too low
Battery low
Raise source volume
Charge Battery
Sound Distorted Battery nearly dead Charge Battery
No Sound Source turned o
Speaker turned o
Volume turned down on source
Music paused on either source or speaker
Turn on source
Turn the speaker on
Adjust volume on source
Push play on source and/or speaker
CARE and MAINTENANCE
Clean the unit with a soft, damp cloth. Never use chemicals or hard
abrasives.
Keep this unit away from wet or damp surroundings.
The crossed out wheelie bin symbol on this item indicates that this
product needs to be disposed of in an environmentally friendly way when
it becomes of no further use or has worn out. Contact your local authorities
for details of where to take the item for recycling.
Note: iPhone®, iPod®and iPad®are trademarks of Apple, Inc, registered in
the US and other countries.

7
FCC Instructions
- Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate this product.
NOTE: This product has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This product generates, uses
and can radiate radio frequency energy and if not installed and used in
accordance with the instruction, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If the product does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try and
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the product and receiver.
- Connect the product into an outlet on a circuit dierent from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received
including interference that may cause undesired operation.
This device has been evaluated to meet general RF exposure requirement. The
device can be used in portable exposure condition without restriction.

8
LIMITED WARRANTY
This manufacturer’s product warranty extends to the original consumer
purchaser of the product. All warranties are covered by the retailer
involved in the sale or promotion of this product (co-warrantor) of this
manufacturer warranty. Do not contact the Manufacturer for replacement
parts and or for warranty related issues.
WARRANTY DURATION: All materials and workmanship are warranted to
the original consumer purchaser for a period of ninety (90) days from the
original purchase date.
WARRANTY COVERAGE: This product is warranted against defective
materials or workmanship. This warranty is void if the product has been
damaged by accident, in shipment, unreasonable use, misuse, neglect,
improper service, commercial use, repairs by unauthorized personnel or
other causes not arising out of defects in materials or workmanship. This
warranty doesn’t cover the following which may be supplied with this
product, including but not limited to; LCD Screens, glass parts, lenses, etc.
This warranty is eective only if the product is purchased and operated in
USA and Canada, and does not extend to any units which have been used
in violation of written instructions furnished by manufacturer or to units
which have been altered or modied or, to damaged products or parts
thereof which have had the serial number removed, altered, defaced or
rendered illegible.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties
expressed or implied and no representative or person is authorized to
assume for manufacturer any other liability in connection with the sale
of our products. There shall be no claims for defects or failure under any
theory of tort, contractor commercial law including but not limited to,
negligence, gross negligence, strict liability, breach of warranty and breach
of contract.
