Gemini CDJ-10 User manual

CDJ-10
PROFESSIONALCDPLAYER
OPERATIONSMANUAL
Bedienungsanleltung
Manualdefuncionamiento
Manualdefonctionnement
Manualdelutente

Page 1
1 3
2
10
45
6
7
8
9
16
15
14
13
12
11

Page 2
INTRODUCTION
Congratulations on purchasing a Gemini CDJ-10 CD Player. This state of
the art professional CD player is backed by a three year warranty,
excluding lasers. One year warranty on CD lasers. Prior to use, we
suggest that you carefully read all the instructions.
CAUTIONS
Do not use this CD Player at temperatures below 41°F/5°C or higher
than 95°F/35°C.
Place the unit in a clean and dry location.
Do not place the unit in an unstable location.
When disconnecting the power cord from an AC outlet, always grasp it
by the plug. Never pull the power cord.
To prevent electric shock, do not remove the cover or the bottom screws.
There are no user serviceable parts inside. Please refer servicing to a
qualified technician.
Do not use chemical solvents to clean the unit.
Keep the laser pickup clean by keeping the tray closed.
Keep this manual in a safe place for future reference.
SAFETY CERTIFICATIONS
Laser Diode Properties
Material: Ga - Al - As
Wavelength: 755 - 815 nm (25° C)
Laser Output: Continuous Wave, max. 0.5mW
LINE VOLTAGE SELECTION
Model CDJ-10 is a dual voltage unit. It will operate at 115 or 230 volts. To
set the proper voltage follow these steps:
1. Place the head of a screw driver in the center of the VOLTAGE
SELECTOR SLIDE SWITCH (3) found on the rear panel.
2. Slide the switch left for 115 volts or push the switch right for 230 volts.
3. Do not force or twist the switch. Excessive force may cause damage.
If the switch does not move smoothly, contact a qualified technician.
CONNECTIONS
1. Plug one end of a set of RCA connectors into each of the LINE
OUTPUT JACKS (1).
2. Plug the other end of the RCA connectors into any available line level
input jacks on your mixer. If you are playing the CDJ-10 through a
receiver, you can plug the RCA connectors into the CD or AUX input
jacks on your receiver. If there are no CD or AUX inputs, use any line
level (not phono) inputs.
FUNCTION DESCRIPTIONS
POWER SWITCH : After making sure that the VOLTAGE SELECTOR
SLIDE SWITCH (3), found on the rear panel, is properly set, plug the
unit in and press the POWER SWITCH (2). The unit will turn on.
Pushing the POWER SWITCH (2) a second time will turn the unit off.
DISC TRAY : The DISC TRAY (10) is where the CD is held. Pressing the
disc tray OPEN BUTTON (16) will open the tray.
OPEN BUTTON : Press the OPEN BUTTON (16) to open the DISC
TRAY (3).
DISPLAY : The DISPLAY (4) shows the track numbers, play mode, pause
mode, and 3 different time displays. These time displays are time
elapsed on the track, time remaining on the disc and time remaining
on the track.
PLAYBACK DISPLAY : The PLAYBACK DISPLAY (5) displays the time
remaining to play and flashes slowly when the track has 30 seconds
left. The PLAYBACK DISPLAY (5) flashes quickly when the track
has 15 seconds left.
PLAY/PAUSE : Each press of the PLAY/PAUSE BUTTON (9)
causes the operation to change from play to pause or from pause
back to play. See the CUE INSTRUCTIONS section for more
information.
TRACK SKIP : The TRACK SKIP BUTTONS (6) let you select
the track to play.
SEARCH BUTTONS : The SEARCH BUTTONS (7) are used
to move foward or reverse while in play mode. The SEARCH
BUTTONS (7) are also used to accurately position the disc at the
point where you wish the track to start playing. This position on the
track is memorized as the cue point. See the CUE INSTRUCTIONS
section for more information.
STOP : The STOP BUTTON (11) will end the playing of the CD.
TIME : The TIME BUTTON (12) switches the time display between the
three available choices listed under DISPLAY .
CUE : With the unit in the play mode, and after memorizing the cue point,
pressing the CUE BUTTON (8) will cause the CD player to enter the
pause mode at the memorized cue point. Holding down the cue
button changes the cue function to preview (allowing you to hear the
music play from the cue point) and releasing the cue button returns
you to the preset cue point. If a cue point is not memorized, pressing
the CUE BUTTON (8) will cause the unit to return to the beginning of
that track.
PITCH : Pushing the PITCH BUTTON (14) activates the pitch section of
the unit. The pitch of the CD will change according to the position of
the PITCH CONTROL (15).
CONTINUOUS : The CONTINUOUS (13) function will cause the unit to
play continuously (after the last track, the unit will return to the first
track of the disc and continue to play).
OPERATING INSTRUCTIONS
1. Make sure that the VOLTAGE SELECTOR SLIDE SWITCH (3),
found on the rear panel, is set for the proper voltage. Plug the unit in
and press the POWER SWITCH (2).
2. Press the OPEN BUTTON (16), place a CD in the DISC TRAY (10)
and close the tray door. The display will initially show the number of
tracks and the total time of the CD.
3. Push the TRACK SKIP BUTTONS (6) to select the track you want to
play.
4. Press the PLAY/PAUSE BUTTON (9) and the unit will instantly play.
CUE INSTRUCTIONS
1. To start the play at a point other than the beginning of a track, follow
these instructions:
First choose the track you wish to play, and then press the PLAY/
PAUSE BUTTON (9) so the unit goes into the play mode. Press the
PLAY/PAUSE BUTTON (9) to pause play at the spot where you want
the play to start -- the CUE POINT. Press the PLAY/PAUSE BUTTON
(9) again to save the cue point. Press the CUE BUTTON (8) to pause
play at the cue point (the unit will go into the pause mode and the
location indicated on the display will be the memorized cue point).
You can preview the cue point by pressing and holding down the CUE
BUTTON (8). Press the PLAY/PAUSE BUTTON (9) to begin play
from the cue point.
Note: After a cue point is set, pressing the TRACK SKIP BUTTONS
(6) clears the cue point. When you press the CUE BUTTON (8) in
the new track, the beginning of that track will be the new cue
point.
2. Once you have saved a cue point you can fine tune or change the
memorized cue point:
To change a cue point, push the PLAY/PAUSE BUTTON (9) so the
unit plays from the cue point, then press the PLAY/PAUSE BUTTON
(9) at the spot you wish your new cue point to be. Press the PLAY/
PAUSE BUTTON (9) again to save the cue point. The unit will go into
the pause mode and the location indicated on the display will be the
new memorized cue point.

Page 3
To fine tune a cue point, pause play at the memorized cue point, then
use the SEARCH BUTTONS (7) to scan frame by frame (1/75th of a
second) to where you want play to begin. Press the PLAY/PAUSE
BUTTON (9) to save the new cue point.
Note: During fine tuning there will be a stutter effect (to help you
find the beat). The stuttering effect will end when you press the
PLAY/PAUSE BUTTON (9) to save the cue point. Also, during fine
tuning if you hold down the SEARCH BUTTONS (7), the unit will
scan quickly after 10 frames.
TROUBLE SHOOTING
•If the disk will not play, check to see if the disc was loaded correctly
(label side up). Also check the disc for excessive dirt, scratches, etc.
• If the disc turns but there is no sound, check the cable connections. If
they are okay, check your amplifier or receiver.
• If the CD skips, check the CD for dirt or scratches. Do not assume
that the CD player is defective. Many CDs are recorded out of spec
and will skip on most or all CD players. Before sending the unit in for
repair, try playing a CD that you are sure plays properly.
SPECIFICATIONS
GENERAL:
Disc Type...............................Standard Compact discs (12 cm & 8 cm)
Time Display.....................Track Elapsed, Track Remain, or Total remain
Variable Pitch...........................+/- 16% Slider with Resume Switch
Start....................................................Within 0.03 seconds
Track Selection....................................................1 to 99 Tracks
AUDIO SECTION:
Quantization......................................1 Bit Linear/Channel, 3 Beam Laser
Oversampling Rate..................................................................8 Times
Sampling Frequency......................................................44.1 kHz
Frequency Response....................................20 Hz to 20 kHz
Total Harmonic Distortion......................................Less Than 0.005%
Signal to Noise Ratio...................................................>96 dB
Dynamic Range.................................................................>94 dB
Output Level (nominal).............................................1.9 Volts R.M.S.
Power Supply......................................AC 120/230V, 60/50 Hz
Dimensions...............................8.38” x 8.86” x 3.75” (213 x 225 x 95 mm)
Weight....................................................................4.5 lbs. (2 kg)
* Specifications and design are subject to change without notice for
purpose of improvement.
Parts of the design of this product may be protected by worldwide patents. Information in this manual is subject to change without notice and does not represent a
commitment on the part of the vendor. Gemini Sound Products Corp. shall not be liable for any loss or damage whatsoever arising from the use of information or any error
contained in this manual.
No part of this manual may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, electrical, mechanical, optical, chemical,
including photocopying and recording, for any purpose without the express written permission of Gemini Sound Products Corp..
It is recommended that all maintenance and service on the product should be carried out by Gemini Sound Products Corp. or it’s authorized agents. Gemini Sound Products
Corp. cannot accept any liability whatsoever for any loss or damage caused by service, maintenance or repair by unauthorized personnel.
Worldwide Headquarters • 8 Germak Drive, Carteret, NJ 07008 • USA • Tel [phone] • Fax [phone]
© Gemini Sound Products Corp. 1999 All Rights Reserved 11/99-1277
