Genelec 5040A User manual

The Genelec 5040A is a very compact
active subwoofer designed to complement
up to five Genelec 6010A active loud-
speakers or a pair of the slightly bigger
6020A’s. The 5040A extends the system’s
bass response down to 35 Hz and inte-
grates perfectly with the 6010A’s in any
environment. The playback level for the
whole system is conveniently controlled
by the remote volume control provided
with the 5040A subwoofer.
The 5040A features a magnetically
shielded downward firing 61/2” bass driver
attached to a die-cast aluminium base plate.
The base plate also serves as the chassis
for the 40 Watt amplifier and 5.1-channel
crossover filter circuitry The 5040A packs
a respectable punch of 96 dB maximum
SPL.
The built-in crossover unit features six
RCA input connectors for five main chan-
nels and LFE channel and five RCA output
connectors for the 6010A loudspeakers.
The main channels have a fixed high pass
filter to work with with Genelec 6010A
loudspeakers.The LFE channel can repro-
duce signals up to 120 Hz. In addition to
the RCA connectors, a 3.5 mm stereo jack
input connector is provided for convenient
connection to portable audio players or
computers.
Adjustable input sensitivity in combi-
nation with adjustable crossover phase
allows a seamless integration between
the subwoofer and the main loudspeakers.
Bass roll-off rate and input sensitivity can
also be adjusted to suit different acoustical
environments and subwoofer positioning.
Finding the correct place for the sub-
woofer is easy due to the compact size
and versatile acoustical adjustments of
the 5040A.
A combination of the 5040A and five
6010A’s can create a dynamic and
detailed soundstage like no other loud-
speaker system of the same size category.
Contact your local Genelec dealer for an
audition.
Genelec 5040A
Active Subwoofer
Data Sheet
5040A

5040A Data Sheet
Genelec Document BBA0078001. Copyright Genelec Oy 1.2008. All data subject to change without prior notice
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone [phone]
Fax [phone]
Email [email protected]
In the U.S. please contact:
Genelec, Inc., 7 Tech Circle
Natick, MA 01760, U.S.A.
Phone [phone]
Fax [phone]
Email [email protected]
In China please contact:
Genelec China Representative Office
SOHO New Town, 88 Jianguo Road
D-1504, Chaoyang District
Beijing 100022, China
Phone [phone]
Fax [phone]
Amplifier Section
connectorS
SyStem SpecificAtionS
5040A
Free field frequency response (± 3 dB) Main 35 Hz...85 Hz
LFE 35 Hz...120 Hz
Maximum short term sine wave SPL output
averaged from 40 to 85 Hz, measured in half
space at 1 meter
98 dB
Self generated noise level in half space at 1 m
on axis (A-weighted)
≤15 dB SPL
Driver, magnetically shielded 165 mm (61/2")
Weight 6.3 kg (13.9 lb)
Dimensions
Height
Diameter
251 mm (97/8”)
305 mm (12”)
5040A
Amplifier short term output power
(Long term output power is limited by driver
unit protection circuitry)
40 W
Amplifier system THD at nominal output ≤0.05 %
Mains voltage 100, 120 or 230 V
Power consumption (average)
Idle
Full output
7 VA
70 VA
5040A
Main channels IN/OUT, LFE channel IN and
LINK OUT unbalanced female RCA
connectors
pin
ring
+
gnd
Stereo IN 3.5 mm Jack female connector
Sleeve
Tip
Ring
gnd
Left channel
Right channel
Input impedance 10 kOhm balanced
Main channel OUT gain referred to IN 0 dB
croSSoVer Section
5040A
Subsonic filter (18 dB/octave) below 35 Hz
Crossover frequency, (sub/main channels) 85 Hz
LFE channel cutoff frequency 120 Hz
Midband rejection >400 Hz >50 dB
Sensitivity adjustment range -9 dBu for 90 dB SPL
Bass Roll-Off control operating range
in 2 dB steps
From 0 to -6 dB @ 35 Hz
Phase matching control in 90° steps From 0 to -270° @ 85 Hz
