Genesi EFIKA MX User manual

E N G L I S H
E S P A Ñ O L
F R A N Ç A I S
D E U T S C H

Congratulations on purchasing
an Efika MX Cloud Computer.

S U P P O R T
For access to software updates,
product news and our development
blog, please visit
www.efikamx.info
For technical discussions, developer
support and resources, please visit
www.powerdeveloper.org

Package Contents
Before ou set up our computer, please ensure that
our product package includes the following items.
•Efika MX Cloud Computer (Smarttop)
•User Manual
•AC Adapter &
Power Cord
First Use Instructions
Before ou use our Efika MX Cloud
Computer for the first time, please read the
safet chapter included in this user manual.

Software Information
The default username and password on the provided
OS installation is as follows.
Username: oem
Password: oem
For additional documentation about our operating
s stem, please visit www.efikamx.info

Product Overview
Power Button
3G SIM Slot

USB Ports SD / MMC Card Slot
DC-IN HDMI
(Displa )
RJ45
(Ethernet)
Audio Out Mic In

Product Specifications
Processor Freescale i.MX515, 800MHz
Memor DDR2 512MB, up to 200MHz
Graphics & Video
Module
Embedded 2D / 3D AMD Core
Hardware Video Codec
Full HW accelerated HD720 pla back
Displa Modes HDMI (version 1.2a) 720P
Memor Card
Slot
MMC, SD, push / push t pe, b esdhc
(Enhanced Multi-Media Card Secure Digital
Host Controller)
Storage Device SSD 8G
Connectivit Ethernet support (default)
WLAN 802.11 b/g/n support (optional)
or 3G / UMTS support (optional)
LED Status
Indicator
Booting (Blue)
S stem on (Green)
DISK IO (flickering)
Interface 1x RJ 45 (10/100M)
1 x Audio jack : Audio out
1 x Mic - In
1x DC - In
2x USB 2.0 ports
1x HDMI port
1x SIM slot (optional with WWAN SKU)
20 pin connector for debugging (optional)

Audio 1x Built-in speaker (1.5 W)
Power
Management
Max power consumption: 15 watt
Power off: Press 4 times
AC adapter Output: 12V DC, 3A, 36W
Input : 100~240V AC, 50 - 60Hz universal
Dimensions /
Weight
Size: 160*115mm
Height: 20mm
Weight 250g
Temperature Working: 0°C~+40°C

Step-by-Step Setup
1. Please carefull read the safety precautions
chapter in this manual.
2. Connect our displa device to the HDMI port.
3. Connect our mouse and ke board to the
USB ports or preferabl to an external USB
hub, which will enable ou to use more than
two USB devices at the same time.
4. Optional: Connect our audio speakers or
headphones to the Audio Out port.
5. Optional: Connect our microphone or
headset to the Mic In port.
6. Connect the AC adapter to our Efika MX
Cloud Computer. Then, plug the power cord
into a power outlet.
7. Boot our computer b pressing the Power
button.

Safety Precautions
Do not pull out the AC adapter while the s stem is in
operating mode. Press the power button four times to
shut down the device manuall in case of a software
crash.
The following safet precautions will increase the life
of an Efika MX Cloud Computer. Please follow all
precautions and instructions. Except as described in
this manual, refer all servicing to qualified personnel.
Do not use damaged power cords, accessories, or
other peripherals. Do not use strong solvents such as
thinners, benzene, or similar chemicals on or near the
device casing.
Important: Disconnect the AC adapter before
cleaning. Wipe the Efika MX Cloud Computer
using a clean cellulose sponge or chamois
cloth dampened with a solution of nonabrasive
detergent and a few drops of warm water and
remove an extra moisture with a dr cloth.

DO NOT place this device on uneven
or unstable work surfaces. Seek
servicing if the casing has been
damaged.
DO NOT place together with small
items that ma scratch or enter the
Efika MX Cloud Computer.
DO NOT expose the device to dirt or
dust environments. DO NOT operate
the device during a gas leak.
SAFE TEMPERATURE: The Efika MX
Cloud Computer should onl be used
in environments with an ambient
temperature between 0 and 40
degrees Celsius / 32 and 104 degrees
Fahrenheit.
DO NOT throw the Cloud Computer in
a municipal waste bin. Check our
local regulations regarding the disposal
of electronic products.

DO NOT shove an foreign objects into
the device. DO NOT place or drop
objects on top of the device.
DO NOT expose the Efika MX Cloud
Computer to strong magnetic or
electrical fields.
DO NOT expose the device to or use it
near liquids, rain, or moisture. DO NOT
use the modem during an electronic
storm.
INPUT RATING: Refer to the rating
label on the bottom of the device and
be sure that our power adapter
complies with the rating

DO NOT expose the AC adapter to
extreme temperatures such as found
near a hot radiator or stove, or in a car
parked in the sun.
Plug the AC adapter directl into a wall
outlet. This product ma become
damaged or not function properl if
used with a power strip or plug adapter.
The power cable must be placed so it
is not likel to be stepped on or tripped
over.
Please onl use the AC adapter and
power cord that is provided b the
device manufacturer. If the AC adapter
or power cord is not functioning
properl , return it to the dealer from
which it was purchased.

For access to the most recent version of this manual
and additional documentation, please visit:
www.efikamx.info

Felicidades por su compra de
una Efika MX Cloud Computer.

S O P O R T E
Para obtener acceso a actualizaciones
de software novedades acerca de
productos nuestro blog de desarrollo,
por favor visite
www.efikamx.info
Para debates técnicos, obtener
soporte recursos para desarrolla-
dores,por favor visite
www.powerdeveloper.org

Contenido de la caja
Antes de conectar su computadora, por favor
asegúrese de que su caja del producto inclu a los
siguientes elementos:
•Computadora Efika MX Cloud Computer
(Smarttop)
•Manual de usuario
•Adaptador cable de corriente
Instrucciones para el primer uso
Antes de utilizar su computadora Efika MX
Cloud Computer por primera vez, por favor
lea el capítulo acerca de la seguridad en éste
manual de usuario.
