Geneva Lab XXL Wireless User manual

2

3
English
User Manual
Geneva Sound System
(Model XXL)

5
English
WARNING
TO PREVENT FIRE OR SHOCK HAZARD. DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
Warning: To reduce the risk of electric shock, do not remove the cover (or back), no user
serviceable parts inside. Refer servicing to qualified service personnel.
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION
RISQUE DE CHOC ÉLÉCTRIQUE
NE PAS OUVRIR
AVIS

6
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding type plug has
two blades and a third grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.

7
English
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods
of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is dama-
ged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or has been dropped.
15) This appliance shall not be exposed to dripping or splashing water and that no
object filled with liquids such as vases shall be placed on apparatus.

8
Caution: Use of controls or adjustments or performance of procedures other than herein
may result in hazardous radiation exposure or other unsafe operation.
Compact Disk Drive: The compact disk (CD) drive contains a laser. The laser radiates
visible and invisible laser radiation. Do not open optical housing. Avoid direct exposure
to the beam.
The compact disc player should not be adjusted or repaired by anyone except properly
qualified service personnel.
Class 1 laser product: This CD player is classified as a CLASS 1 LASER PRODUCT
according to EN 60825- 1:1994+A1+A2, IEC 60825-1:1993+A1+A2. The CLASS 1 LASER
PRODUCT label is located on the rear plate of the product. This product complies
with 21 CFR Part 1040.10.
Technical details about the incorporated laser diode: Wavelength: 790 nm ± 15nm.
Max accessible radiant power (during service): 0.492 mW.
CLASS 1 LASER
PRODUCT
CAUTION
Visible and invisible
laser radiation when open.
Avoid exposure to beam.

9
English
Ventilation: Do not block any ventilation openings on the back of the Geneva Sound
System. To ensure reliable operation of the Geneva Sound System and to protect it from
overheating, put the System in a position and locataion that will not interfere with its pro-
per ventilation. For example, do not place the Geneva Sound System very close to a wall
or in front of a curtain that may block the ventilation openings.
 
Ventilation holes

10
Cleaning: Please note we have included a cleaning cloth with your Geneva
Sound System, in the accessory bag. To avoid making scratches to the surface, we
recommend that you use the cleaning cloth included. Before cleaning, please unplug this
Geneva Sound System from the AC power outlet.
Overloading: To prevent risk of fire or electric shock, avoid overloading wall outlets or
extension cords.
Open fire: Keep this Geneva Sound System a safe distance away from any open flame
such as a lit candle. No open flame sources, such as lighted candles, should be placed
on the Geneva Sound System.
Operating Temperatures: The recommended operating temperature range for the
Geneva Sound System is 41 to 104 degrees Fahrenheit (5 to 40 degrees Celsius).
Unpacking: It is recommended to use two people when unpacking the Geneva Sound
System. The Geneva Sound System Model XXL weights more than 191 Pounds / 85kg.
Sitting or Leaning on Geneva Sound System: Do not lean against the Geneva Sound
System and do not sit on it under any circumstances.
Avoid Hearing Damage: Playing very loud music for an extended period of time can
result in permanent hearing loss.

11
English
The mains plug or appliance coupler is used as the disconnect device, such disconnect
device shall remain readily operable.
Label location: The product labels and safety related markings are located on the
Rear Panel of the Geneva Sound System.
Moving the unit: Once the Geneva Sound System is out of the transport carton, be care-
ful when moving it. Because the unit is very heavy, you will need two persons to do this.
Never rest the speaker on its front side (the side with the metal grill panel) - the weight of
the speaker will deform the grille.

12
Unplugging while in operation: Do not remove the AC power cord out of the AC outlet if
music is playing or if the Geneva Sound System is turned on. The drivers can be
damaged by such an action.
Batteries in the remote control: Keep the remote control battery away from children.
It may cause a fire or chemical burn if mishandled. Do not recharge, disassemble, heat
above 212ºF (100ºC), or incinerate. Replace only with a battery of the correct type and
model number.
CAUTION: Danger explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
Used batteries: Please dispose of used batteries properly, following any local
regulations. Do not incinerate.
iPod Universal Dock: Never insert the iPod into the iPod Universal Dock if the
appropriate plastic Dock Adapter is not inserted.
Compact Disks (CD’s): Do no insert smaller disks than 12 cm, such as a CD mini disk,
etc., which are not supported. Also, do not insert anything else than a CD, such as coins.
Outside Antenna: If an outside antenna or cable system is connected to this product, be
sure the antenna or cable system is grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810 of the National Electric Code,
ANSI/NFP No. 70 information, Section 54 of the Canadian Electrical Code, with regard to
proper grounding of the mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding conductors, location of antenna/discharge
unit, connection to grounding electrodes, and requirements for the grounding electrode.
Modification: Unauthorized modification of the receiver or radio remote control could
void the user’s authority to operate this equipment.

13
English
Note to CATV system installer: This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the NEC (of USA) that provides guidelines for
proper grounding. In particular, it specifies that the cable ground shall be connected to
the grounding system of the building, as close to the point of cable entry as is practical.
Opening of the electronics box by any unauthorized person also voids the Limited
Warranty.
This product can be recycled. Products bearing this symbol must NOT be
thrown away with normal household waste. At the end of the product’s life,
take it to a collection point designated for recycling of electrical and electronic
devices. Find out more about return and collection points through your local
authority.
The European Waste Electrical and Electronic Equipment (WEEE) Directive was
implemented to dramatically reduce the amount of waste going to landfills,
thereby by reducing the environmental impact on the planet and on human health.
Please act responsibly by recycling used products. If this product is still usable,
consider giving it away or selling it.

14
Contents
Chapter 1 Getting Started
Unpacking and setting up
Quick Start
Using your Remote Control
Listen to your iPod
Listen to a CD
Listen to the FM radio
16
16
21
24
25
27
28
Chapter 2 How To...?
General:
How to turn the Geneva Sound System on and off?
How to adjust Volume and Sound?
How to verify that the remote control works?
How to clean the speaker?
How to change battery in the remote control?
iPod:
How to select the right iPod Dock adapter for my iPod?
How to insert or remove a Dock Adapter?
How to play video from the iPod?
How to control the iPod using the Geneva Sound System’s remote control?
CD:
How to control the CD player using the remote control?
How to play CD’s with MP3 and other formats?
How to play MP3 CD-R/W with several Albums?
29
29
29
30
30
31
31
33
33
34
35
36
36

15
English
37
38
38
39
39
39
40
40
41
41
41
41
41
41
42
42
42
44
Chapter 3
Chapter 4
Chapter 5
FM radio:
How to control the FM radio using the remote control?
How to select a FM radio station?
How to store your favorite FM radio station in a preset?
How to play a FM radio station that is stored in the presets?
How to erase or overwrite a preset?
How to connect the External FM radio antenna?
Line in:
How to connect a Computer, iPod Shuffle or another MP3 player to the
Geneva Sound System using the 1/8 inch (3.5 mm) input?
How to connect a TV, Computer, VCR, DVD player or a game console to the
Geneva Sound System using the “Line in” input?
Troubleshooting, Service and Support
Troubleshooting and Support
Service and Repair
Technical Support
Customer Service Telephone Number
Website
Made for iPod & Technology Partners
Made for iPod
Technology Partners
Technical Specifications

16
1. Getting Started
Step 1: Unpack all components from the shipping box. Please be aware that the Geneva
Sound System model XXL is very heavy, so it is better to have two people lift it out of
the box. Please note that Geneva Lab Corporation‘s 30-day return policy only covers
products returned in the original packaging in as new condition.
Unpack the door, and mount the door to the cabinet (1) using the 2 screws that come
with the speaker unit. Then unpack the center and left grille. First mount the center grille
(2), then the left grille (3). Finally, mount the trays using the 4 pins which are enclosed (4).
Cabinet / model XXL
1
2
3
4

17
English
The shipping box should contain the following System components:
Remote control
External antenna
iPod dock adapters
AC Power cord
Line in cable
MP3 player cable
IR extender
3x
„Geneva may enclose one or several dock adapters together with this product.
The actual versions of these and number of dock adapters may change from time to time, as we seek to enclose adapters to the latest
and most common Apple iPhone and iPod products. If the adapter to the iPod or iPhone product you wish to use with this Geneva
system is not enclosed in this package, it should be available as an original accessory from your Apple dealer.“

18
Step 2: Insert the batteries into the remote control (see page 31). There are batteries
included in the package.
Step 3: Place the Geneva Sound System in a way that you can access the Rear Panel.
Insert the AC power cable into the AC connector on the Rear Panel (see picture below),
and then connect it to an AC outlet.
Rear Panel Put TV on top
Put your own equipment here

19
English
Step 4: Put your audio/video equipment, such as set top box, DVD/Blueray player or
game console into the compartment on the right. Put your TV set on top. Connect your
equipment with the rear panel of the Geneva Sound System on either Line1, Line 2 or
Line 3 (see picture above).
Line in
Jacks
FM radio
antenna plug
AC Connector
AIR-Connector
(for future use)
iPod video
output
Coaxial digital
input (Digi 2)
Infrared output
Fuse
Speaker output
(white connector)
Speaker output
(black connector)
Optical digital
input (Digi 1)

20
Step 5: If you intend to use the System with an iPod, open the lid on top of the cabinet.
To open, please press carefully on the rear part of the lid.
Select the right iPod Dock Adapters that fits with the iPod model you intend to dock by
following the table on page 32, or try the enclosed Dock Adapters until you find the one
that fits tightly with your iPod. Attach the Dock Adapter to the iPod Universal Dock by
pressing lightly on the top of the Dock Adapter (see picture) and it will snap in.
Open Attach

21
English
Quick start:
Universal Dock panel with control keys
for on/off, volume and CD Eject
LED Display showing system mode,
FM frequency, CD status, etc.
Electronics Panel
CD Player
iPod Universal Dock
Front Grille

22
Control buttons and iPod Universal Dock found on panel under the lid on top
of Cabinet:
iPod Connector
Power on/off
Volume down
1/8 inch / 3.5 mm
auxiliary audio input
Volume up
CD Eject
Dock Adapter
