Genevo One M User manual

USER MANUAL
Radar Detector GENEVO ONE M

Radar Detector GENEVO ONE M 01
Congratulations on your purchase of world´s most intelligent radar
and laser detector GENEVO ONE M.
Main functions of GENEVO ONE M
GENEVO ONE M is the most powerful detector from GENEVO family and is designed to protect the driver from speeding
fines. GENEVO ONE M communicates with driver in English and its main functions are detection of microwave radars
(K / Ka bands), laser guns, red light cameras and sectional speed cameras (using its own GPS database), MultaRadars
CT/CD and radars Gatso RT3 and RT4.
Notifications:
Text warning and voice alert appears on GENEVO ONE M during radar alert. Strength of the signal and beeps expresses
the intensity of the received signal. Signal strength has ten levels. GPS alerts are reported by voice. For example “Speed
Camera”.
Control:
1) Left button MENU / ON-OFF
Short press: You will enter into setup menu.
During the signaling radar you will mute the volume. The next alarm will be reported again in the standard volume.
Long press: Turn ON / OFF GENEVO ONE M.

Radar Detector GENEVO ONE M 02
2) Middle button BRIGHTNESS / ALERT SUPPRESSION
Short press: You can change the brightness of the display - Bright Dim Smart Dark Full Dark.
Long Press: If you hold it during an alert you will mark the place of false radar reporting so at a given point detector
during the next passage will be suppressed. If you suppress a false alert, detector will not detect radars in radius of about
150 meters. Hold button during the „suppressed“ radar alert and this listing will be canceled. After next passage radar alert
will be signaled acoustically.
3) Right button SENSITIVITY / ADD YOUR OWN GPS POINT
Short press: You can scroll between Highway / City / Auto City modes. In City or Auto City modes the sensitivity
of K / Ka bands can be reduced according to user preference.
Long Press: Add / Remove your own GPS point.
4) Buttons on the right side + / -
Short press: Changing volume of the detector.
Menu:
Press Left button for enter into menu.
Press Left button to go from one category to the next.
Press VOLUME +or –(on the right side of detector) to change your setting within a category.
To complete this change, simply wait a few seconds without pressing a button. The unit will display “Setting Completed”
to confirm your selection. Alternatively, you can get out of the menu by pressing the Right button.

Radar Detector GENEVO ONE M 03
Items in the menu are as follows:
(recommended settings are highlighted)
Sensitivity: Highway / City / Auto City
Setting the speed in Auto City (item is present only if the sensitivity is set to Auto City): Through Middle button you are selecting
between speeds for editing (left number indicates the speed below which the detector will not respond to alerts. Right number
indicates the speed below which the detector will detect alerts like in City mode). + / - buttons on the right side of the detector
change the specific speed. When detector is set up to “20 50” speed below 20 km/h on the radar will not respond. In the velocity
range 20-50 km/h will only respond to stronger radar signals. Maximum detector sensitivity on the radar starts from 50 km/h.
Setting values City and Auto City sensitivity (entry is present only if the detector sensitivity is set to other than Highway):
Via Middle button you can select radar band for editing. To change the signal level which will respond to radar signals use
+ / -. The level of suppression can be selected in the range 0-9. For example, when setting is K2 and Ka2 the level of detection
in all bands are slightly decreased.
Display Mode: Speed/Time, Speed/Voltage, Battery Voltage, Time, Speed, Speed/Compass
Alert type: Voice first / Beep first / No voice - Allows you to set if you want to be alerted first via voice alert or beeping sound.
Auto Mute: On / Off: If it´s activated, after two seconds of ongoing alert the volume will be reduced.
The minimum speed for signaling radar: Off, 10 km/h, 20 km/h, 30 km/h ........... 130 km/h
K-Band: Wide / Narrow / Instant Only / Off (In countries, where police use K band radars, it is recommend to use K Narrow
setting)

Radar Detector GENEVO ONE M 04
K Filter: Off / Low / High - Filtering false alerts from blind spots and ACC. (When K Filter is activated, pulsed radars such
as Iskra are not detected)
Ka-Band: Wide / Narrow / Off
Ka 34.0 On / Off (if you are sure that police in your region does not use this band, then Off)
Ka 34.3 On / Off (if you are sure that police in your region does not use this band, then Off)
Ka 34.7 On / Off (if you are sure that police in your region does not use this band, then Off)
Ka 35.5 On / Off (if you are sure that police in your region does not use this band, then Off)
Ka Filter: Off / Normal / High - Filtering false alerts from blind spots and ACC. (When Ka Filter is activated, detection distance
on Ka band radars is slightly reduced. We recommend using „Normal“ which is very good in sensitivity/false alerts immunity
ratio.)
Laser: On / Off
MR CT: Wide / Narrow / Off - These radars are being used in countries SR, A, PL, NL, ES, P, LT. We recommend to use „Narrow”
settings in these countries. In any other country we recommend to leave the function „Off”.
MR CD: Wide / Narrow / Off
Gatso RT3: On / Off

Radar Detector GENEVO ONE M 05
Gatso RT4: On / Off
MR Filter: Low / High / Off - Filtering false alerts from blind spots and ACC. (When MR Filter is activated, detection distance on
MR band radars is slightly reduced. We recommend using „Low“ which is very good in sensitivity/false alerts immunity ratio.)
Startup sound: On / Off
GPS connect announce: On / Off
GPS detection by database type: Via Middle button you can select the type of GPS points. For editing use + / -. You can turn
on and off particular type of point.
GPS warning distance: Normal (approx. 250 m) / Farther (approx. 375 m) / Farest (approx. 500 m)
Unit: English (mph) / Metrics (km/h)
Set local time: You can change time zone via + / -
Language: English / Deutsch / Czech
Factory reset: For reset press Middle button.
Delete all user points: For deleting all user points press Middle button.

Radar Detector GENEVO ONE M 06
SpeedMeter Option:
This function is intended for the legalization of the detector when used in countries where radar detectors are prohibited.
The detector stops alerting to radars and lasers. Nothing but your current speed will appear on the display and all radar and
laser detection settings will disappear from the menu. When entering the menu, you will be notified of deactivated functions.
To activate the SpeedMeter, you must have the detector turned on, press and hold the Middle button and Right button
together (on the top of the detector) for five seconds. Then the display will show SpeedMeter ON and the detection functions
of the radar and laser are completely deactivated. To reactivate your detector again, unplug it from the power source, hold
the Right button and „+“ button and then plug it into the power source. You need to hold the buttons for approximately
8 seconds. After 8 seconds display will show (SpeedMeter OFF). Now you have a fully working detector again.

Radar Detector GENEVO ONE M 07
Operating frequency:
GPS: SiRF STAR IV
Ka narrow: 34.0 GHz, 34.3 GHz, 34.7 GHz, 35.5 GHz
(±120 MHz)
Ka wide: 33.4 GHz ~ 36.0 GHz
K narrow: 24.125 GHz (±70 MHz)
K wide: 24.125 GHz (±150 MHz)
MultaRadar CD/CT, Gatso RT3, Gatso RT4
Laser: 904 nm
Technical parameters:
Operating temperature: -20 ~ +85 °C
Storage temperature: -20 ~ +85 °C
Operating voltage: 11 ~ 24 V DC
Energy consumption: 250 mA normal, 330 mA
max. (12 V)
Dimensions: 62 * 92 * 34 mm
Power input: 3.96 W
Connector polarity: Positive
Power supply fuse: F2A/250V

Radar Detector GENEVO ONE M 08
Declaration of Conformity:
The manufacturer, GENEVO s.r.o., hereby declares that GENEVO ONE M equipment complies with the
essential requirements and other relevant provisions of Directive 2014/53/EU. The full Declaration of Conformity can
be downloaded here: www.genevo.com/en/ce-one-m.pdf
Database Updates:
Database update is recommended monthly. Download of the new database
is performed according to the instructions www.genevo.com/en/updates
while at www.genevo.com/en/updates-subscription
you can register and receive notifications of new and updated database to your email.

Radar Detector GENEVO ONE M 09
Safety Instructions
We recommend that you install the p roduct using the included bracket with suction cups on the windshield so that it
does not obstruct your view. Alternatively, the product can be placed in another location provided it is securely fastened to
prevent the device from moving by itself. The location must have good GPS signal reception. The device must be powered
using the supplied 12 V cable (to be plugged into a 12 V plug in the vehicle) with a jack type connector to be connected to
the appropriately marked plug on the device.
Additional Information
Restrictions on placing in service or applicable requirements for permission to use:
County: AT, BG, CY, DE, DK, EE, ES, FI, FR, GR, IR, ITA, LT, LU, LV, MT, NL, PL, PT, SE, SK.
Requirements: Please check your legislation before use.
Please note: The product may only be used for the purposes specified in this manual. Never use damaged equipment.
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Manufacturer: GENEVO s.r.o., Radčina 497/22, 161 00 Praha 6

Radar Detector GENEVO ONE M 10
Your Dealer:
Manual REV: 2022-03-29
