GEQNAUTE G-Eye 500 User manual

EN
G-Eye 500
TABLE OF CONTENTS
CAMERA OVERVIEW ........................................................ 2
FIRST STEPS .................................................................... 4
Charging the battery ......................................................................... 4
Inserting the micro SD card.............................................................. 4
Using a waterproof case ................................................................... 4
USING THE CAMERA ....................................................... 5
Turning on .......................................................................................... 5
Turning off .......................................................................................... 5
Recording a video.............................................................................. 6
Taking photos .................................................................................... 6
Enabling/Disabling Wi-Fi .................................................................. 6
CONFIGURING THE CAMERA .......................................... 7
Changing modes................................................................................ 7
Conguring video modes ................................................................. 8
Conguring photo modes................................................................. 9
General settings .............................................................................. 10
Default settings................................................................................ 11
TRANSFERRING FILES .................................................. 12
DISPLAYING PHOTOS / VIDEOS ON A TV...................... 12
ATTACHING A STICKER PAD ......................................... 12
PRECAUTIONS FOR USE................................................ 13
WARRANTIES, LEGAL NOTICES .................................... 14
Limited liability ................................................................................ 14
Warranty ........................................................................................... 14
Legal notices.................................................................................... 14

2
CAMERA OVERVIEW
LCD screen
On/Off/
Stop recording button
Red light (power / charging)
Green light (video recording/
data transfer)
Lens
Shutter button
End video recording button/
Wi-Fi activation (press and hold)
Wi-Fi status
indicator light
Recording
indicator light
MicroSD
card slot
Mini-USB port
Microphone
Standard screw thread (Kodak)

3
LCD SCREEN
100-0088
2H30
1080P-60
1
5 6
2
3
47
Icons Functions
1Video recording mode
APhoto mode
2
1080P-60 Video resolution
8MP Photo resolution
3
100-0088 Number of saved les
00:00:01 Recording time
4
02:30 Remaining recording time
1888 Remaining number of photos
5Wi-Fi
6Ambient light measurement mode
7Battery level

4
FIRST STEPS
CHARGING THE BATTERY
4h
12
6
39
INSERTING THE MICRO SD CARD
Compatible cards: Class 10 MicroSD cards from 8Gb to 64Gb.
USING A WATERPROOF CASE
Anti-fog paper (sold separately)
The waterproof case has been specially designed for your G-EYE camera. It is
waterproof up to 100 meters, and also provides shock protection.
It is designed to be used when performing water sports, diving or playing sports in
damp environments. Using the waterproof case greatly reduces the camera's
sound recording ability.
CAUTION
 In order to guarantee that it is perfectly watertight, it is important that the seal
gasket is kept clean. Dust or grains of sand could be enough to create a leak
in the case. You can easily remove the gasket to rinse it in clean water. Dry the

5
gasket and reinstall in the correct direction.
 In order to limit the presence of fog or condensation in the case caused by
temperature differences between the inside and outside of the case, we
strongly recommend that you place anti-fog paper in the case every time
you use it. This accessory is sold separately in all DECATHLON shops and at
decathlon.com.
USING THE CAMERA
TURNING ON
> 3 sec
TURNING OFF
> 4 sec

6
RECORDING A VIDEO
00:00:00
2H30
1080P-60
00:18:22
2H30
1080P-60
100-0088
1888
8M
1. START
2. STOP
2. STOP
1. START
The GEONAUTE G-EYE 500 camera is equipped with 2 TV standards, PAL and
NTSC, which you can choose between in the general settings (see page 10).
TAKING PHOTOS
100-0088
2H30
1080P-60
100-0088
1888
8M
100-0089
1887
8M
ENABLING/DISABLING WI-FI
100-0087
2H30
1080P-60
10 s
100-0087
2H30
1080P-60
10 s
> 4 s > 4 s
This camera features Wi-Fi technology which includes 2 options (AP for use with a
smartphone or STA for use with a remote control – see settings on page 10).

7
Once Wi-Fi is activated, you can choose to:
 Control and congure your camera from your smartphone by downloading the
'G-Eye APP', available on GOOGLE PLAY (Android) and APPLE STORE (iOS).
When the Wi-Fi is activated, the camera broadcasts a Wi-Fi hotspot. The
network name (SSID) is the name of the camera, and the default password is:
00000000.
 Control your camera using the GEYE 2 REMOTE control, sold separately.
Follow the instructions provided with the remote control.
CONFIGURING THE CAMERA
 Use the following buttons to navigate through all menus:
Select/
Conrm the selection
Next screen/
Scrolling Previous screen
CHANGING MODES
00:00:00
2H30
1080P-60
100-0088
1888
8M
Press and hold
Classic video mode (sound
and image).
Video mode without sound.
Audio recording only.
Time-lapse video mode(1) (2).
Video self timer.
Single photo mode.
Burst photo mode.
ATime-lapse photo mode(3).
Time delay photo.
M
Access settings for the
various modes.
(1) Creates a sped-up lm by recording images at regular intervals (mp4 format).
(2) Feature not available in 720 p 100/120 FPS or when using WVGA.
(3) Automatically takes photos at regular intervals (jpeg format).

8
CONFIGURING VIDEO MODES
00:00:00
2H30
1080P-60
M
M
Press and
hold Press oncePress once
Menus Options
Classic video mode
(sound and image)
Video mode without
sound
Audio recording only
Time-lapse video
mode(1)
Time interval between video
images:
1/2/5/10/30 sec.
Video self timer Video time delay:
5/10/20 sec.
Video resolution (2) 1920 x 1080 60 fps, 16:9
1920 x 1080 30 fps, 16:9
1280 x 720 120 fps, 16:9
1280 x 720 60 fps, 16:9
848 x 480 240 fps, 16:9
848 x 480 120 fps, 16:9
Viewing angle (1) Wide/Medium/Narrow/Small.
Video bitrate (3) Standard video bitrate/
High video bitrate.
Continuous recording (4) Enable/disable continuous
recording.
Self-righting image (5) (6) Enable/disable vertical image
self-righting.

9
Menus Options
Insertion of the date (6) Enable/disable insertion of
the date into the video.
(1) Feature not available in 720 p 100/120 FPS or when using WVGA.
(2) The number of frames per second (fps) can change depending on the TV standard
selected (see page 10). The maximum FPS given is for the NTSC TV standard. If you
select PAL, 30 fps becomes 25 fps, for example.
(3) A high video bitrate will give better image denition but will use more memory space.
(4) When the memory card is full, the camera overwrites the oldest le in order to continue
recording.
(5) May be required if the camera is positioned vertically.
(6) Feature not available in 1080 p 50/60 FPS, 720 p 100/120 FPS or when using
WVGA 200/240 FPS.
CONFIGURING PHOTO MODES
100-0088
1888
8M
M
M
Press and
hold Press oncePress once
Menus Options
Single photo mode
Burst photo mode Number of photos per
second:
3/6/8.
Time-lapse photo mode
A
Interval of time between
photos:
0.5/1/2/3/5/10/20 sec.
Photo self timer Photo time delay:
3/5/10 sec.
Photo resolution 8 MP
Insertion of the date Enable/Disable insertion of
the date into the photo.
