Gianni Industries Micro Surface User manual

Statement
Features
Specification
The 10003S is recommended to be installed on
small doors, drawers and cabinets etc. With
stainless steel housing, it is suitable for outdoor
applications and severe weather conditions.
Standard Installation
10003S Micro Magnetic Lock
Surface Mount and Waterproof
Stainless steel casing
MOV provides spike and surge protection
Anti-residual magnetism function
Operating Voltage: Single Voltage: 12 or 24VDC
Current Draw:
Single Voltage: 300mA/12VDC, 260mA/24VDC
(at temperature 20ºC)
Operating temperature:-10~55ºC(14~131ºF)
Humidity: 0~95% non-condensing.
Holding force: Up to 300 lbs (136 Kg )
Dimensions:
Magnet:(L) 170, (W) 32, (D) 24 mm
Armature plate:(L) 152, (W) 32, (D) 10 mm
Zinc plated finish for magnet and armature plate
Epoxy potting compound: E87252 (S), UL94V-0
Net Weight: 1.5 Kg
The product is warranted against defects in material and
workmanship while used in normal service for a period of 5
years from the date of sale to the original client. The GEM
policy is one of continual development and improvement;
therefore GEM reserves the right to change specifications
without notice.
Warranty
Suitable for server cabinet
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-10003S Ver. F Published on 2011.08.24
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: [phone] / Fax: [phone]
E-Mail: [e-mail]
Website: gianni.tw
Magnet Armature
(Power Off)
Magnet Armature
(Power On)
Anti-residual statement
Our electromagnet locks feature Anti-Residual Magnetism
(ARM) which ensures the door can be opened without any
resistance from left over magnetism imparted to the armature
plate
GIANNI INDUSTRIES , INC.

Optional Brackets
A appropriate bracket fully complements the magnetic lock.
Brackets are selected according to the direction of door
swing, the thickness of door frame, and the materials of the
door.
Outswing doors: L-brackets are recommended for narrow
frame doors.
38 mm
L-150
Inswing doors: bracket is recommended for
use on doors that open inwards.
LZ-150
Inswing full frameless glass doors: bracket is
recommended for use on full frameless glass doors with
thickness of 10 mm.
GLZ-150
LZ-150
GIANNI INDUSTRIES , INC.
When the door frame thickness (marked
'A') is less than 38 mm it is highly
recommended to use an L-150 bracket to
enable installation.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-10003S Ver. F Published on 2011.08.24
Magnet
Armature
Door Frame
Door
Leaf
A
Outswing
10003S Micro Magnetic Lock
Surface Mount and Waterproof
No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: [phone] / Fax: [phone]
E-Mail: [e-mail]
Website: gianni.tw
