6VX7-4X / 6VX7B-4X Summary of Features
1
Summary Of Features
Form Factor 30.4 cm x 20.3 cm ATX SIZE form factor, 4 layers PCB.
CPU Socket 370 processor
2nd cache in CPU(Depend on CPU)
Chipset VT82C694X (VIA Apollo Pro 133A)
VT82C686A / VT82C686B
Clock Generator ICS 9248DF-39
66/100/133 MHz system bus speeds (PCI 33MHz)
112/124/142/152 MHz system bus speeds (PCI 44MHz)
(reserved)
Memory 3 168-pin DIMM sockets.
Supports PC-100 / PC-133 SDRAM and VCM SDRAM
Supports up to 1.5GB(Max)
Supports only 3.3V SDRAM DIMM
Supports 72bit ECC type DRAM integrity mode.
I/O Control VT82C686A / VT82C686B
Slots 1 AGP Slot Supports 4X mode & AGP 2.0 compliant
5 PCI Slot Supports 33MHz & PCI 2.2 compliant
1 ISA Slot (6VX7-4X)
1 AMR(Audio Modem Riser)Slot
On-Board IDE 2 IDE bus master, DMA 33/ ATA 66 DIE/ ports for up
to 4 ATAPI devices
Supports PIO mode 3, 4, UDMA33/ATA66 IDE & ATAPI
CD-ROM
On-Board
Peripherals
1 floppy port supports 2 FDD with 360K, 720K,1.2M,
1.44M and 2.88M bytes
1 parallel ports supports SPP/EPP/ECP mode
2 serial ports (COMA & COMB)
4 USB ports
1 IrDA connector for IR
Hardware Monitor CPU/Power Supply/System fan revolution detect
CPU / Power / System temperature detect
System voltage detect (Vcore,Vcc3,Vcc,+12V)
CPU overheat shutdown detect
On-Board LAN 3 COM LAN (Optional)
PS/2 Connector PS/2 keyboard interface and PS/2 mouse interface
BIOS Licensed AMI BIOS, 4M bit flash ROM
On-Board Sound Build–in VIA sound (VIA VT82C686A / VT82C686B)
Creative CT5880 sound (Optional)
Additional
Features
Supports Wake-on-LAN (WOL)
Supports Internal / External modem wake up
Includes 3 fan power connectors
Poly fuse for keyboard over-current protection

6VX7-4X / 6VX7B-4X
2
6VX7-4X Motherboard Layout
DIMM3
PCI2
PCI3 VT82C686A
GAME & AUDIO COMB COMA
LPT
PS/2
SW1
PCI4
PCI5
ISA
DIMM2
DIMM1
SW2
AGP
AMR
JP16
6VX7-4X
PCI1
BAT1
PGA 370
CPU
JP9 JP19 JP30 JP15
JP5
USB
A
TX Power
JP11
Floppy
IDE1 IDE2
J11
JP23
JP1
Front USB
J3
JP2
J4
J12
JP22
J2
BIOS
JP20
Creative
CT5880
JP21
BZ1
JP8
JP7
JP18
J7
J8
J5
VT82C694X
USB2
J1
LAN
3 COM
LED1

6VX7-4X / 6VX7B-4X
3
6VX7B-4X Motherboard Layout
DIMM3
PCI2
PCI3 VT82C686B
GAME & AUDIO COMB COM
A
LPT
PS/2
SW1
PCI4
PCI5
DIMM2
DIMM1
SW2
AGP
AMR
JP16
6VX7B-4X
PCI1
BAT1
PGA 370
CPU
JP9 JP19 JP5
USB
A
TX Power
JP11
Floppy
IDE1 IDE2
J11
JP23
JP1
Front USB
J3
JP2
J4
JP22
J2
BIOS
Creative
CT5880
JP21
BZ1
JP8
JP7
JP18
J7
J8
J5
VT82C694X
USB2
J1
LAN
3 COM
LED1

6VX7-4X / 6VX7B-4X
4
CPU Speed Setup
The system bus speed is selectable at 66,100,133MHz and Auto. The user can select the system bus speed
(SW1) and change the DIP switch (SW2) selection to set up the CPU speed for 300 - 733MHz processor.
SW1: O : ON, X : OFF
CPU PCI
CLK 1 2 3 4 5 6
Auto 33.3 X X X X O O
66 33.3 O O X X X X
75 37.5 O O O X X X
83 41.6 O O X O X X
100 33.3 O X X X X X
112 37.3 O X O X X X
124 31 X X X O X X
133 33.3 X X X X X X
140 35 X X O O X X
150 37.5 X X O X X X


The CPU speed must match with the frequency RATIO. It will cause system hanging up if the
frequency RATIO is higher than that of CPU.
SW2:
DIP SWITCH
FREQ. RATIO 1 2 3 4
X 3 OXOO
X 3.5 XXOO
X 4 OOXO
X 4.5 XOXO
X 5 OXXO
X 5.5 XXXO
X 6 OOOX
X 6.5 XOOX
X 7 OXOX
X 7.5 XXOX
X 8 OOXX
X 8.5 XOXX
X 9 OXXX
X 9.5 XXXX


For Auto Jumper setting:
SW1
ON
1
2
3
4
5
6


Note:
1. If you use 66, 100, 133 MHz CPU, we recommend you to set up your system speed to “Auto” value.
2. We don’t recommend you to set up your system speed to 112, 124, 142,152 MHz because these
frequencies are not the standard specifications for CPU, Chipset and most of the peripherals. Whether
your system can run under 112, 124, 142,152 MHz properly will depend on your hardware
configurations: CPU, SDRAM, Cards, etc.

6VX7-4X / 6VX7B-4X
5
1. CeleronTM 300A / 66MHz FSB
SW2
ON
1
2
3
4
SW1
ON
1
2
3
4
5
6
2. CeleronTM 333 / 66MHz FSB
3. CeleronTM 366 / 66MHz FSB
4. CeleronTM 400 / 66MHz FSB
SW2
ON
1
2
3
4
SW1
ON
1
2
3
5
4
6
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6

6VX7-4X / 6VX7B-4X
6
5. CeleronTM 433 / 66MHz FSB
6. CeleronTM 466 / 66 MHz FSB
7. CeleronTM 500 / 66 MHz FSB
8. CeleronTM 533 / 66 MHz FSB
9. CeleronTM 566 / 66 MHz FSB
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW2
ON
1
2
4
SW2
ON
1
2
3
4
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6

6VX7-4X / 6VX7B-4X
7
10. Cyrix 300 / 100 MHz FSB (Optional)
11. Coppermine 500 / 100MHz FSB
12. Coppermine 550 / 100MHz FSB
13. Coppermine 600 / 100MHz FSB
14. Coppermine 650 / 100MHz FSB
SW2
ON
1
2
3
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6

6VX7-4X / 6VX7B-4X
8
15. Coppermine 700 / 100MHz FSB
16. Coppermine 533 / 133MHz FSB
Coppermine 600 / 133MHz FSB
17. Coppermine 667 / 133MHz FSB
18. Coppermine 733 / 133MHz FSB
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW2
ON
1
2
3
4
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6
SW1
ON
1
2
3
5
4
6

6VX7-4X
9
Connectors
Game & Audio Port
MIC In
GAME
Port
Line In
Line Out
COM A / COM B / LPT Port
COM A
LPT PORT
COM B
USB & LAN Connector (LAN is optional)
Pin No. Definition
1 USB V0
2 USB D0-
3 USB D0+
4 GND
5 USB V1
6 USB D1-
7 USB D1+
8 GND
2
1
1 – Green LED
(LAN Link LED)
2 – Yellow LED
(LAN Active LED)
1 2 3 4
5
6 7
8

6VX7-4X
10
PS/2 Keyboard & PS/2 Mouse Connector
PS/2 Mouse/ Keyboard
Pin No. Definition
1 Data
2 NC
3 GND
4 VCC(+5V)
5 Clock
6 NC
PS/2 Keyboard
PS/2 Mouse
1
2
3
4
5
6
JP16: CPU Cooling Fan Power Connector
Pin No. Definition
1 GND
2 +12V
3 SENSE
1
JP15: Power Cooling Fan Power Connector (optional)
Pin No. Definition
1 GND
2 +12V
3 NC
1

6VX7-4X
11
JP2: System Cooling Fan Power Connector
Pin No. Definition
1 GND
2 +12V
3 SENSE
1
ATX Power
Pin No. Definition
3,5,7,13,15-17 GND
1,2,11 3.3V
4,6,19,20 VCC
10 +12V
12 -12V
18 -5V
8 Power Good
9 5V SB stand by+5V
14 PS-ON(Soft On/Off)
10
11
20
1
USB 2 Connector
1
4
Pin No. Definition
1 VCC
2 USB D0-
3 USB D0+
4 GND
5 VCC
6 USB D1-
7 USB D1+
8 GND
5
8

6VX7-4X
12
IR Connector
PIN No. Definition
1 VCC(+5V)
2 NC
3 IR data input
4 GND
5 IR data output
1
Floppy Port
RED LINE
IDE1 (Primary), IDE2(Secondary) Port
IDE 1 IDE 2
RED LINE

6VX7-4X
13
J3: Ring Power On (Internal Modem Card Wake Up)
Pin No. Definition
1 Signal
2 GND
1
J1: Wake On LAN
Pin No. Definition
1 +5V SB
2 GND
3 Signal
1
J7: TEL: The connector is for Modem with internal voice connector
Pin No. Definition
1 Signal-In
2 GND
3 GND
4 Signal-Out
1

6VX7-4X
14
J5: AUX_IN
Pin No. Definition
1 AUX-L
2 GND
3 GND
4 AUX-R
1
J8: CD Audio Line In
Pin No. Definition
1 CD-L
2 GND
3 GND
4 CD-R
1
JP5: STR LED Connector & LED1: DIMM LED
STR LED Connector External
+
DIMM LED
1

6VX7-4X
15
Front USB Port (Optional)
Pin No. Definition
1,4,5,10 NC
2 +5V
3,7,9 GND
6 USBP0+
8 USBP0-
2
10
1
9
J11: SM BUS
1 Pin No. Definition
1 SMB CLK
2 NC
3 GND
4 SMB DATA
5 +5V

6VX7-4X
16
Panel And Jumper Definition
J2: For 2X11 Pins Jumper
RE
GN
GD PW P+ P−P−
S P K
HD
1
1
1
1
1
GN (Green Switch) Open: Normal Operation
Close: Entering Green Mode
GD (Green LED) Pin 1: LED anode(+)
Pin 2: LED cathode(−)
HD (IDE Hard Disk Active
LED) Pin 1: LED anode(+)
Pin 2: LED cathode(−)
SPKR (Speaker Connector) Pin 1: VCC(+)
Pin 2- Pin 3: NC
Pin 4: Data(−)
RE (Reset Switch) Open: Normal Operation
Close: Reset Hardware System
P+P−P−(Power LED) Pin 1: LED anode(+)
Pin 2: LED cathode(−)
Pin 3: LED cathode(−)
PW (Soft Power Connector) Open: Normal Operation
Close: Power On/Off
JP1: Clear CMOS Function
1
Pin No. Definition
1-2 close Normal (Default)
2-3 close Clear CMOS

6VX7-4X
17
JP7/JP8/JP18: Onboard AC97 & AMR (Primary or Secondary) Select
(AMR

Audio Modem Riser)
Jumper
Function JP7 JP8 JP18
AC97
(Default) 1-2 Close 1-2 Close Open
Only AMR
(Primary) 3-4 Close 3-4 Close Open
AC97+MR
(Secondary) 1-2 Close 1-2 Close 3-4 Close Close
1
JP8
JP7
JP18
JP11: STR Enable
Pin No. Definition
Open STR Disabled (Default)
Close STR Enabled
1
JP20: Onboard Sound Function Selection (Optional)
Pin No. Definition
1-2 close Enabled Onboard Sound
(Default)
2-3 close Disable Onboard Sound
1
