Gigabyte G291-280 User manual

G291-280
G291-281
Dual LGA3647 sockets motherboard for Intel®Xeon®Scalable Family processors
User Manual
Rev. 1.1

Copyright
© 2019 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of documentation:
 User Manual: detailed information & steps about the installation, conguration and use of this
product (e.g. motherboard, server barebones), covering hardware and BIOS.

User Guide: detailed information about the installation & use of an add-on hardware or
software component (e.g. BMC rmware, rail-kit) compatible with this product.
Quick Installation Guide: a short guide with visual diagrams that you can reference easily for
installation purposes of this product (e.g. motherboard, server barebones).
Please see the support section of the online product page to check the current availability of these
documents.
For More Information
For related product specications, the latest rmware and software, and other information please visit our website at
http://www.gigabyte.com
For GIGABYTE distributors and resellers, additional sales & marketing materials are available from our reseller
portal: http://reseller.b2b.gigabyte.com
For further technical assistance, please contact your GIGABYTE representative or visit
https://esupport.gigabyte.com/ to create a new support ticket
For any general sales or marketing enquiries, you may also message GIGABYTE server directly by email:
server[email protected]

Conventions
The following conventions are used in this user's guide:
NOTE!
Gives bits and pieces of additional
information related to the current topic.
CAUTION!
Gives precautionary measures to
avoid possible hardware or software problems.
WARNING!
Alerts you to any damage that might
result from doing or not doing specic actions.

Server Warnings and Cautions
Before installing a server, be sure that you understand the following warnings and cautions.
WARNING!
To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug the power cord from the power supply to disconnect power to the equipment.
• Do not route the power cord where it can be walked on or pinched by items placed against it.
Pay particular attention to the plug, electrical outlet, and the point where the cord extends from
the server.
WARNING!
To reduce the risk of personal injury from hot surfaces, allow the drives
and the internal system components to cool before touching them.
WARNING!
This server is equipped with high speed fans. Keep away from hazardous
moving fan blades during servicing.
CAUTION!
• Do not operate the server for long periods with the access panel open or removed. Operat-
ing the server in this manner results in improper airow and improper cooling that can lead to
thermal damage.
• Danger of explosion if battery is incorrectly replaced.
• Replace only with the same or equivalent type recommended by the manufacturer.
• Dispose of used batteries according to the manufacturer’s instructions.

Electrostatic Discharge (ESD)
CAUTION!
ESD CAN DAMAGE DRIVES, BOARDS, AND OTHER PARTS. WE RECOMMEND THAT YOU
PERFORM ALL PROCEDURES AT AN ESD WORKSTATION. IF ONE IS NOT AVAILABLE,
PROVIDE SOME ESD PROTECTION BY WEARING AN ANTI-STATIC WRIST STRAP AT-
TACHED TO CHASSIS GROUND -- ANY UNPAINTED METAL SURFACE -- ON YOUR SERVER
WHEN HANDLING PARTS.
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by
their edges without any component and pin touching. After removing a board from its protective
wrapper or from the system, place the board component side up on a grounded, static free sur-
face. Use a conductive foam pad if available but not the board wrapper. Do not slide board over
any surface.
System power on/o󰀨: To remove power from system, you must remove the system from
rack. Make sure the system is removed from the rack before opening the chassis, adding, or
removing any non hot-plug components.
Hazardous conditions, devices and cables: Hazardous electrical conditions may be
present on power, telephone, and communication cables. Turn off the system and discon-nect
the cables attached to the system before servicing it. Otherwise, personal injury or equipment
damage can result.
Electrostatic discharge (ESD) and ESD protection: ESD can damage drives,
boards, and other parts. We recommend that you perform all procedures in this chapter only at
an ESD workstation. If one is not available, provide some ESD protection by wearing an antistatic
wrist strap attached to chassis ground (any unpainted metal surface on the server) when handling
parts.
ESD and handling boards: Always handle boards carefully. They can be extremely
sensi-tive to electrostatic discharge (ESD). Hold boards only by their edges. After removing a
board from its protective wrapper or from the system, place the board component side up on a
grounded, static free surface. Use a conductive foam pad if available but not the board wrapper.
Do not slide board over any surface.
Installing or removing jumpers: A jumper is a small plastic encased conductor that slips
over two jumper pins. Some jumpers have a small tab on top that can be gripped with n-gertips
or with a pair of ne needle nosed pliers. If the jumpers do not have such a tab, take care when
using needle nosed pliers to remove or install a jumper; grip the narrow sides of the jumper with
the pliers, never the wide sides. Gripping the wide sides can dam-age the contacts inside the
jumper, causing intermittent problems with the function con-trolled by that jumper. Take care to
grip with, but not squeeze, the pliers or other tool used to remove a jumper, or the pins on the
board may bend or break.

CAUTION!
Risk of explosion if battery is replaced incorrectly or with an incorrect type. Replace the battery
only with the same or equivalent type recommended by the manufacturer. Dispose of used bat-
teries according to the manufacturer’s instructions.

- 7 -
Table of Contents
Chapter 1 Hardware Installation ................................................................................... 11
1-1 Installation Precautions.................................................................................. 11
1-2 Product Specications.................................................................................... 12
1-3 System Block Diagram................................................................................... 16
Chapter 2 System Appearance.....................................................................................17
2-1 Front View...................................................................................................... 17
2-2 Rear View....................................................................................................... 17
2-3 Front Panel LED and Buttons ........................................................................ 18
2-4 Rear System Button and LEDs ...................................................................... 19
2-5 Hard Disk Drive LEDs .................................................................................... 20
2-6 Hard Disk Back Plane Board Jumper Settings............................................... 21
Chapter 3 System Hardware Installation ......................................................................23
3-1 Removing Chassis Cover............................................................................... 24
3-2 Removing and Installing the Fan Duct ........................................................... 25
3-3 Installing the CPU and Heat Sink................................................................... 26
3-4 Installing the Memory..................................................................................... 28
3-4-1 Six Channel Memory Conguration........................................................................28
3-4-2 Installing a Memory ...............................................................................................29
3-4-3 DIMM Population Table ..........................................................................................29
3-4-4 Intel Optane DCPMM DIMM Population Rule ........................................................30
3-5 Installing the GPU Card ................................................................................. 31
3-6 Installing a PCI Express Card ........................................................................ 39
3-7 Installing an OCP Card .................................................................................. 43
3-8 Installing the Hard Disk Drive......................................................................... 45
3-9 Replacing the FAN Assembly......................................................................... 47
3-10 Replacing the Power Supply.......................................................................... 51
3-11 Cable Routing ................................................................................................ 52
Chapter 4 Motherboard Components ...........................................................................53
4-1 Motherboard Components ............................................................................. 53
4-2 Jumper Setting .............................................................................................. 55
Chapter 5 BIOS Setup ..................................................................................................57
5-1 The Main Menu .............................................................................................. 59
5-2 Advanced Menu ............................................................................................. 62
5-2-1 iSCSI Conguration ................................................................................................63

- 8 -
5-2-2 Intel(R) Virtual RAID on CPU .................................................................................64
5-2-3 Intel(R) Ethernet Connection X722.........................................................................65
5-2-4 Trusted Computing .................................................................................................69
5-2-5 Serial Port Console Redirection .............................................................................70
5-2-6 SIO Conguration...................................................................................................74
5-2-7 PCI Subsystem Settings.........................................................................................77
5-2-8 Network Stack ........................................................................................................78
5-2-9 CSM Conguration .................................................................................................79
5-2-10 Post Report Conguration ......................................................................................81
5-2-11 NVMe Conguration ...............................................................................................82
5-2-12 USB Conguration..................................................................................................83
5-2-13 Chipset Conguration.............................................................................................84
5-3 Chipset Setup Menu....................................................................................... 85
5-3-1 Processor Conguration .........................................................................................86
5-3-2 Common RefCode Conguration ...........................................................................90
5-3-3 UPI Conguration ...................................................................................................91
5-3-4 Memory Conguration ............................................................................................93
5-3-5 IIO Conguration ....................................................................................................97
5-3-6 Advanced Power Management Conguration ......................................................100
5-3-7 PCH Conguration ...............................................................................................107
5-3-8 Miscellaneous Conguration ................................................................................112
5-3-9 Server ME Conguration ......................................................................................113
5-3-10 Runtime Error Logging .........................................................................................114
5-4 Server Management Menu........................................................................... 118
5-4-1 System Event Log ................................................................................................120
5-4-2 View FRU Information ..........................................................................................121
5-4-3 BMC Network Conguration .................................................................................122
5-4-4 IPv6 BMC Network Conguration.........................................................................123
5-5 Security Menu .............................................................................................. 124
5-5-1 Secure Boot .........................................................................................................125
5-6 Boot Menu.................................................................................................... 128
5-6-1 UEFI NETWORK Drive BBS Priorities ................................................................130
5-6-2 UEFI Application Boot Priorities ................................................................. 131
5-7 Save & Exit Menu......................................................................................... 132
5-8 BIOS POST Codes ...................................................................................... 134
5-8-1 AMI Standard - PEI...............................................................................................134
5-8-2 AMI Standard - DXE.............................................................................................134
5-8-3 AMI Standard - ERROR .......................................................................................136
5-8-4 Intel UPI POST Codes..........................................................................................137
5-8-5 Intel UPI Error Codes ...........................................................................................137
5-8-6 Intel MRC POST Codes .......................................................................................138

- 9 -
5-8-7 Intel MRC Error Codes .........................................................................................138
5-8-8 Intel PM POST Codes ..........................................................................................139
5-8-9 Intel PM POST Codes ..........................................................................................139
5-9 BIOS POST Beep code (AMI standard)....................................................... 140
5-9-1 PEI Beep Codes...................................................................................................140
5-9-2 DXE Beep Codes .................................................................................................140
5-10 BIOS Recovery Instruction........................................................................... 141

- 10 -

- 11 - Hardware Installation
1-1 Installation Precautions
The motherboard/system contain numerous delicate electronic circuits and components which
can become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully
read the service guide and follow these procedures:
• Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
• Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
• When connecting hardware components to the internal connectors on the motherboard,
make sure they are connected tightly and securely.
• When handling the motherboard, avoid touching any metal leads or connectors.
• It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist
strap, keep your hands dry and rst touch a metal object to eliminate static electricity.
•
Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
• Before unplugging the power supply cable from the motherboard, make sure the power
supply has been turned off.
• Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
• Before using the product, please verify that all cables and power connectors of your
hardware components are connected.
• To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
• Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
• Do not place the computer system on an uneven surface
.
• Do not place the computer system in a high-temperature environment.
• Turning on the computer power during the installation process can lead to damage to
system components as well as physical harm to the user.
• If you are uncertain about any installation steps or have a problem related to the use of the
product, please consult a certied computer technician.
Chapter 1 Hardware Installation

Hardware Installation - 12 -
1-2 Product Specications
CPU 2nd Generation Intel® Xeon® Scalable and Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon®
Silver Processor and Intel® Xeon® Bronze Processor
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be
unavailable.
Socket 2 x LGA 3647
Socket P0
Mounting pitch: Narrow ILM
Chipset Intel® C621 Express Chipset
Memory 24 x DIMM slots
DDR4 memory supported only
6-channel memory architecture
RDIMM modules up to 32GB supported
LRDIMM modules up to 64GB supported
Support Intel® Optane™ DC Persistent Memory
1.2V modules: 2933 (1DPC)/2666/2400/2133 MHz
NOTE:
1. 2933MHz for 2nd Generation Intel® Xeon® Scalable Processors only
2. Intel® Optane™ DC Persistent Memory for 2nd Generation Intel® Xeon®
Scalable Processors only
LAN 2 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2)
1 x 10/100/1000 management LAN
Expansion Slot 8 x PCIe x16 slots (Gen3 x16)
1 x PCIe Gen3 x16 mezzanine slot (MEZZ_1)
1 x PCIe Gen3 x16 mezzanine slot (MEZZ_2/MEZZ_3)
1 x OCP Gen3 x16 mezzanine slot (MEZZ_2/MEZZ_3)
System is validated for population with a uniform GPU model
Support is not provided for mixed GPU populations
Video Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Storage 8 x 2.5" SATA/SAS hot-swappable HDD/SSD bays
SAS Supported via add-on SAS Card

- 13 - Hardware Installation
Internal
Connectors
1 x 18-pin power connector (system power rail)
1 x 18-pin power connector (CPU0 all power rail)
1 x 18-pin power connector (CPU1 all power rail)
4 x SlimSAS connectors
1 x TPM header
1 x HDD back plane board header
1 x 23-pin front panel header
1 x JTAG connector
1 x Serial header
1 x IPMB connector
2 x SSATA connector
1 x RAID key connector
1 x P12V standby connector
1 x Clear CMOS jumper
1 x LT debug jumper
Front Panel
LED/Buttons
1 x Power button with LED
1 x ID button with LED
2 x LAN activity LEDs
1 x HDD activity LED
1 x Reset button
1 x System status LED
Rear Panel I/O 2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
Backplane I/O 8 x SAS/SATA ports
Bandwidth: SATAIII 6Gb/s or SAS 12Gb/s per port
SAS card is required for SAS devices support
TPM 1 x TPM header

Hardware Installation - 14 -
System
Management
Aspeed® AST2500 management controller
Avocent® MergePoint IPMI 2.0 web interface:
Network settings
Network security settings
Hardware information
Users control
Services settings
IPMI settings
Sessions control
LDAP settings
Power control
Fan proles
Voltages, fans and temperatures monitoring
System event log
Events management (platform events, trap settings, email settings)
Serial Over LAN
vKVM & vMedia (HTML5)
Power Supply
(G291-280)
2 x 2200W redundant PSUs
80 PLUS Platinum
AC Input:
100-127V~/ 14A, 47-63Hz
200-240V~/ 12.6A, 47-63Hz
DC Output:
Max 1200W/ 100-127V~
+12.12V/ 95.6A
+12Vsb/ 3.5A
Max 2200W/ 200-240V
+12.12V/ 178.1A
+12Vsb/ 3.5A

- 15 - Hardware Installation
Power Supply
(G291-281)
2 x 2000W redundant PSU
80 PLUS Titanium
AC input:
1000W: 100-127V/ 12-9.5A, 50-60Hz
1800W: 200-220V/ 10-9.5A, 50-60Hz
1980W: 220-230V/ 10-9.8A, 50-60Hz
2000W: 230-240V/ 10-9.8A, 50-60Hz
DC output:
Max 1000W@100-127V:
+12V/ 83.3A
+12Vsb/ 2.1A
1800W@200-220V
+12V/ 150.0A
+12Vsb/ 2.1A
1980W@220-230V
+12V/ 165.0A
+12Vsb/ 2.1A
2000W@200-240V
+12V/ 166.7A
+12Vsb/ 2.1A
NOTE: The system power supply requires C19 type power cord
Environment
Ambient
Temperature
Relative
Humidity
Operating temperature: 10°C to 35°C
Non-operating temperature: -40°C to 60°C
Operating humidity: 8-80% (non-condensing)
Non-operating humidity: 20%-95% (non-condensing)
System
Dimension
2U
438mm (W) x 87.5mm (H) x 800mm (D)
* We reserves the right to make any changes to the product specications and product-related information without
prior notice.

Hardware Installation - 16 -
1-3 System Block Diagram
PCIe3.0 x16 PCIe3.0 x16
2666/2400/2133 MHz 3 x UPI 9.6/10.4 GT/s 2666/2400/2133 MHz
2A~2D
PCIe x16 (Gen3 x16)
PCIe x16 (Gen3 x16)
MEZZ_2 x8
MEZZ_3 x8
PCIe3.0 x16
PCIe3.0 x4
PCIe3.0 x16
PCIe3.0 x8
PCIe3.0 x8
PCIe3.0 x16
PCIe x16 (Gen3 x16)
PCIe x16 (Gen3 x16)
MEZZ_1 x16
Base-T
2 x10G LAN
(Support Low-Profile)
Intel
X550-AT2
PCIe3.0 x1
LPC/eSPI
NCSI
COM
ASPEED
AST2500
LAN
(for Management)
10/100/1G
PHY(1ch)
MACBMC
2 x sSATAIII
8 x SATAIII
8 x SATAIII
2 x sSATAIII
DMI3 x4
Rear 2 x USB 3.0
2 x USB 2.0
SPI Flash
32MB
PCH
Intel C621
Lewisburg
VGA
Skylake-SP
LGA 3647
Socket P0
CPU0
Skylake-SP
LGA 3647
Socket P0
CPU1
DDR4
2DPC
6-Channel
DDR4
2DPC
6-Channel
12 x DIMM slots 12 x DIMM slots
Combine to MEZZ_2/MEZZ_3
Support:
a. Low-Profile x16 MD2 Card
b. Option OCP mezzanine x16
c. Option H type mezzanine
d. MEZZ_3 share Support NVME X2
TPM

- 16 - System Appearance
Chapter 2 System Appearance
2-1 Front View
• Please Go to Chapter 2-3 Front Panel LED and Buttons for detail description of function
LEDs.
3
1
2 114 5 6 7 8 9 10
2-2 Rear View
No. Description No. Description
1. System fan (GPU12E_FAN) 9. USB 3.0 ports
2. VGA port 10. System fan (GPU56E_FAN)
3. 10/100/1000 Server Management LAN port 11. Power Supply (PSU1) Fan
4. Power button/LED 12. Power supply module cord socket
5. ID button 13. NMI button
6. Reset button 14. Power Supply (PSU2) Fan
7. System status LED 15. Power supply module cord socket
8. RJ-45 LAN ports
432 5 6 7 8 9
13
110
12 15
11 14
No. Description No. Description
1. Front panel LED and buttons 7. 2.5-inch hard disk drive #4
2. System fan (GPU78_FAN) 8. 2.5-inch hard disk drive #5
3. 2.5-inch hard disk drive #0 9. 2.5-inch hard disk drive #6
4. 2.5-inch hard disk drive #1 10. 2.5-inch hard disk drive #7
5. 2.5-inch hard disk drive #2 11. System fan (GPU34_FAN)
6. 2.5-inch hard disk drive #3

System Appearance - 17 -
2-3 Front Panel LED and Buttons
1
2
3
4
5
6
7
No. Name Color Status Description
1. Power button
with LED
Green On System is powered on
Green Blink System is in ACPI S1 state (sleep mode)
N/A Off
• System is not powered on or in ACPI S5 state (power
off)
• System is in ACPI S4 state (hibernate mode)
2. ID Button Press the button to activate system identication
3/4. LAN 1/2 Active/
Link LEDs
Green Solid On Link between system and network or no access.
Green Blink Data trasmission or receiving is occuring
N/A Off No data transmission or receiving is occuring
5. HDD Status
LED
Green On HDD locate
Blink HDD access
Amber On HDD fault
Green/
Amber Blink HDD rebuilding
N/A Off No HDD access or no HDD fault.
6. System
Status LED
Green Solid On System is operating normally.
Amber
Solid On
Critical condition, may indicate:
System fan failure
System temperature
Blink
Non-critical condition, may indicate:
Redundant power module failure
Temperature and voltage issue
Chassis intrusion
N/A Off
System is not ready, may indicate:
POST error
NMI error
Processor or terminator missing
7. Reset Button Press the button to reset the system.

- 18 - System Appearance
2-4 Rear System Button and LEDs
No. Name Color Status Description
1. Power button
with LED
Green On System is powered on
Green Blink System is in ACPI S1 state (sleep mode)
N/A Off
• System is not powered on or in ACPI S5 state
(power off)
• System is in ACPI S4 state (hibernate mode)
2. ID Button Press the button to activate system identication
3. Reset Button Press the button to reset the system.
4. NMI button
Press the button server generates a NMI to the
processor if the multiple-bit ECC errors occur, which
effectively halt the server.
5.. System
Status LED
Green Solid On System is operating normally.
Amber
Solid On
Critical condition, may indicate:
System fan failure
System temperature
Blink
Non-critical condition, may indicate:
Redundant power module failure
Temperature and voltage issue
Chassis intrusion
N/A Off
System is not ready, may indicate:
POST error
NMI error
Processor or terminator missing
1 2
3
4
5

System Appearance - 19 -
2-5 Hard Disk Drive LEDs
/('
/('
RAID SKU LED1 Locate Rebuilding
HDD
Fault
HDD
Access
HDD Present
(No Access)
No RAID configuration
(via HBA, ICH)
RAID configuration
(via HW RAID Card or
SW RAID Card)
Disk LED
(LED on
Back Panel)
Amber
Removed HDD Slot
(LED on Back Panel)
Disk LED
Removed HDD Slot
Green ON(*1) OFF Green OFF
ON
OFF
ON(*1)
OFF
OFF
ON
OFF
ON
Alternately
(Low Speed: 2 Hz)
(*3)
(*3)
OFF
OFF
--
--
Green
Amber
Green
ON(*1) OFF Green --Green
OFF OFF Amber --
Amber
Amber OFF OFF Amber OFF
LED 2 HDD Present No HDD
Green ON OFF
