Gigabyte GA-6IWMT User manual

MM
MM
MThe author assumes no responsibility for any
errors or omissions that may appear in this
document nor does the author make a
commitment to update the information
contained herein.
MM
MM
MThird-party brands and names are the
property of their respective owners.
MM
MM
MPlease do not remove any labels on
motherboard, this may void the warranty of
this motherboard.
MM
MM
MDue to rapid change in technology, some of
the specifications might be out of date
beforepublication of this booklet.

Declaration of Conformity
We, Manufacturer/Importer
(full address)
G.B.T. Technology Träding GMbH
Ausschlager Weg 41, 1F, 20537 Hamburg, Germany
declare that the product
( description of the apparatus, system, installation to which it refers)
Mother Board
GA-6IWMT
is in conformity with
(reference to the specification under which conformity is declared)
in accordance with 89/336 EEC-EMC Directive
oo
oo
oEN 55011 Limits and methods of measurement
of radio disturbance characteristics of
industrial,scientific and medical (ISM
high frequency equipment
oo
oo
oEN 61000-3-2*
TT
TT
TEN 60555-2 Disturbances in supply systems cause by household appliances and similar
electrical equipment “Harmonics”
oo
oo
oEN 55013 Limits and methods of measurement
of radio disturbance characteristics of
broadcast receivers and associated
equipment
oo
oo
oEN 61000-3-3* Disturbances in supply systems cause
by household appliances and similar
electrical equipment “Voltage fluctuations”
oo
oo
oEN 55014 Limits and methods of measurement
of radio disturbance characteristics of
household electrical appliances,
portable tools and similar electrical
apparatus
TT
TT
TEN 50081-1 Generic emission standard Part 1:
Residual commercial and light industry
TT
TT
TEN 50082-1 Generic immunity standard Part 1:
Residual commercial and light industry
oo
oo
oEN 55015 Limits and methods of measurement
of radio disturbance characteristics of
fluorescent lamps and luminaries
Generic emission standard Part 2:
Industrial environment
oo
oo
oEN 55081-2
Immunity from radio interference of
broadcast receivers and associated
equipment
Generic emission standard Part 2:
Industrial environment
oo
oo
oEN 55082-2
TT
TT
TEN 55022 Limits and methods of measurement
of radio disturbance characteristics of
information technology equipment
lmmunity requirements for household
appliances tools and similar apparatus
oo
oo
oENV 55104
Cabled distribution systems; Equipment
for receiving and/or distribution from
sound and television signals
EMC requirements for uninterruptible
power systems (UPS)
oo
oo
oEN50091-2
oo
oo
oEN 55020
oo
oo
oDIN VDE 0855
oo
oo
opart 10
oo
oo
opart 12
(EC conformity marking)
TT
TT
TCE marking
The manufacturer also declares the conformity of above mentioned product
with the actual required safety standards in accordance with LVD 73/23 EEC
Safety requirements for mains operated
electronic and related apparatus for
household and similar general use
oo
oo
oEN 60950
oo
oo
oEN 60065
Safety of household and similar
electrical appliances
oo
oo
oEN 60335
Manufacturer/Importer
Signature:
Name:
(Stamp) Date : December 31, 2002
TT
TT
TEN 60555-3
Timmy Huang
Timmy Huang
oo
oo
oEN 50091-1

FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2.1077(a)
Responsible Party Name:
Address:
Phone/Fax No:
hereby declares that the product
Product Name:
Conforms to the following specifications:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
causeharmful and(2) thisdevice mustaccept anyinference received,
including that may cause undesired operation.
Representative Person’s Name:
Signature: Eric Lu
Supplementary Information:
Model Number:
17358 Railroad Street
City of Industry, CA 91748
G.B.T. INC. (U.S.A.)
[phone]/ [phone]
Motherboard
GA-6IWMT
Date:
ERIC LU
December31,2002

GA-6IWMT(-C)
Socket 370 Processor Motherboard
USER'S MANUAL
Socket370ProcessorMotherboard
Rev.1101
12ME-6IWMT-1101

- 2 -GA-6IWMT(-C) Motherboard
English
Table of Content
Item Checklist .........................................................................................4
WARNING!...............................................................................................4
Chapter 1 Introduction .............................................................................5
Summary of Features.................................................................................. 8
GA-6IWMT(-C) Motherboard Layout........................................................... 7
Chapter 2 Hardware Installation Process................................................8
Step 1: Install the Central Processing Unit (CPU)....................................... 9
Step1-1:CPUInstallation .................................................................................................. 9
Step1-2:CPUHeatSinkInstallation................................................................................. 10
Step 2: Install memory modules................................................................ 11
Step 3: Install expension cards .................................................................12
Step 4: Connect ribbon cables, cabinet wires, and power supply ...........13
Step4-1:I/OBack PanelIntroduction ................................................................................ 13
Step4-2:ConnectorsIntroduction ..................................................................................... 15

Table of Content
English
- 3 -
Chapter 3 BIOS Setup ..........................................................................25
The Main Menu (For example: BIOS Ver. :F2).........................................26
Standard CMOS Features.........................................................................28
Advanced BIOS Features ..........................................................................31
Advanced Chipset Features ......................................................................34
Integrated Peripherals ..............................................................................36
Power Management Setup .......................................................................43
PNP/PCI Configuration..............................................................................47
PC Health Status........................................................................................49
Frequency/Voltage Control........................................................................51
Load Fail-Safe Defaults............................................................................. 52
Load Optimized Defaults...........................................................................53
Set Supervisor/User Password..................................................................54
Save & Exit Setup.......................................................................................55
Exit Without Saving ...................................................................................56
Chapter 4 Technical Reference ............................................................57
Block Diagram...........................................................................................57
BIOS update procedure ............................................................................58
@ BIOS Introduction.................................................................................. 62
Easy TuneIIITM Introduction .......................................................................63
Chapter 5 Appendix..............................................................................65

- 4 -GA-6IWMT(-C) Motherboard
English
Item Checklist
TheGA-6IWMT(-C)motherboard
IDE cable x 1/ Floppy cable x 1
CDformotherboarddriver&utility
GA-6IWMT(-C)user'smanual
I/O Shield *
Computermotherboards and expansioncards contain verydelicate Integrated Circuit(IC) chips. To
protectthemagainstdamagefromstaticelectricity,youshouldfollowsomeprecautionswheneveryou
workonyour computer.
1. Unplugyourcomputerwhenworkingontheinside.
2. Useagroundedwriststrapbeforehandlingcomputercomponents.Ifyoudonothave
one,touchbothofyourhandstoasafelygroundedobjectortoametalobject,suchas
the powersupply case.
3. Holdcomponentsbytheedgesand trynottouchtheICchips, leadsorconnectors,or
othercomponents.
4. Placecomponentsonagroundedantistaticpadoronthebagthatcamewiththe
componentswheneverthecomponentsareseparatedfromthesystem.
5. EnsurethattheATXpowersupplyisswitchedoffbeforeyou pluginor removetheATX
powerconnectoronthemotherboard.
Ifthemotherboardhasmountingholes,buttheydon’tlineupwiththeholesonthebaseandthereare
noslotstoattachthespacers,donotbecomealarmedyoucanstillattachthespacerstothemounting
holes.Justcutthebottomportionofthespacers(thespacermaybealittlehardtocutoff,sobecareful
ofyourhands).Inthiswayyoucanstillattachthemotherboardtothebasewithoutworryingaboutshort
circuits.Sometimesyoumayneedtousetheplasticspringstoisolatethescrewfromthemotherboard
PCBsurface,becausethecircuitwiremaybenearbythehole.Becareful,don’tletthescrewcontact
anyprintedcircuitwriteorpartsonthePCBthatarenearthefixinghole,otherwiseitmaydamagethe
boardorcauseboardmalfunctioning.
Installing the motherboard to the chassis…
WARNING!
* For GA-6IWMT only

Introduction
English
- 5 -
Chapter 1 Introduction
tobecontinued......
Features Summary
FormFactor 19.0cm x 23.0cm MicroATX size form factor, 4 layers PCB.
Motherboard GA-6IWMTSeries:
GA-6IWMT / 6IWMT-C
CPU Socket370 processor
supports all new Pentium®III processors (FC-PGA & FC-PGA2
package)
supportsCeleron processorsinFC-PGA &FC-PGA2 package
supports66/100/133MHzsystembusfrequency
2ndcachedepend onCPU
Chipset Intel 82810E HOST/AGP/SDRAM Controller
FW82801BA (ICH2)
Memory 2168-pin DIMMsockets
Supports PC-100 SDRAM
Supports only 3.3V SDRAM DIMM
Supports up to 512MB SDRAM (Max)
I/OControl W83627HF
Slots 3 PCI slot supports 33MHz & PCI 2.2 compliant
On-BoardIDE 2 IDEbusmaster(DMA33/ATA66/ATA100)IDEports forupto 4
ATAPI devices
SupportsPIO mode3,4(UDMA33/ATA66/ATA100)IDE &ATAPI
CD-ROM
On-BoardPeripherals 1 Floppyportsupports 2FDD with360K, 720K,1.2M,1.44M
and2.88M bytes.
1Parallel portsupports Normal/EPP/ECPmode
2 Serial port (COMA, COMB on board)
1 VGA port
4 USB ports (Rear USB x 2, Front USB x 2)
1IrDAconnectorfor IR

- 6 -GA-6IWMT(-C) Motherboard
English
MPleasesetthe CPUhostfrequency inaccordancewithyour processor’s specifications.
Wedon’trecommendyouto setthesystembusfrequency overtheCPU’sspecification
becausethesespecificbusfrequenciesarenotthestandardspecificationsforCPU,
chipsetandmostoftheperipherals.Whetheryoursystemcanrununder thesespecific
busfrequenciesproperlywilldepend onyourhardwareconfigurations,includingCPU,
Chipsets,SDRAM,Cards….etc.
HardwareMonitor CPU/System FanRevolution detect
CPUtemperaturedetect
SystemVoltageDetect
On-Board Sound AC97 CODEC
LineIn/Line Out/Mic In/CD In/GamePort
On-Board LAN* BuildinRTL8101LChipset
PS/2Connector PS/2KeyboardinterfaceandPS/2Mouseinterface
BIOS LicensedAWARD BIOS, 2M bit Flash ROM
AdditionalFeatures STR(Suspend-To-RAM)
AC Recovery
USB KB/Mouse wake up from S3~S5
Supports @BIOSTM
SupportsEasy Tune4TM
* For GA-6IWMT only

Introduction
English
- 7 -
GA-6IWMT(-C) Motherboard Layout
LED_CONN
GA-6IWMT
KB_MS
COMA
LPT
GAME
LINE_OUT
MIC_IN
82810E
SOCKET 370
CPU_FAN
ATXPOWWR
FLOPPY
LINE_IN VGA
CODEC
BIOS
SYS_FAN
ICH2
PCI2
PCI3
COMB F_USB
CD_IN
F_PANEL
IR
RTL8101L*
USB
F_AUDIO
BATTERY
IDE1
IDE2
PCI1
DIMM1
LAN*
DIMM2
W83627HF
WOL*
PWR_LED
MODEM
CNR
* For GA-6IWMT only

- 8 -GA-6IWMT(-C) Motherboard
English
Tosetupyourcomputer,youmustcompletethefollowingsteps:
Step1-InstalltheCentralProcessingUnit(CPU)
Step2-Installmemorymodules
Step3-Installexpansioncards
Step4-Connectribboncables,cabinet wires, and power supply
Chapter 2 Hardware Installation Process
Step 2Step 1
Step 4
Step 3
Step 5
Congratulations!Youhaveaccomplishedthehardwareinstallation!
Turnonthepowersupplyorconnectthepowercabletothepoweroutlet.Continuewiththe
BIOS/softwareinstallation.

Hardware Installation Process
English
- 9 -
Step 1-1: CPU Installation
CPU Top View CPU Bottom View
Socket Actuation Lever
1. Pull up the CPU socket level
andupto90-degreeangle.
Pin1 indicator
2. LocatePin1inthesocketandlook
fora(golden)cutedgeon theCPU
uppercorner.TheninserttheCPU
intothesocket.
Forexample: ThenewestPentium IIIprocessor (FC-PGA2package).
Step 1: Install the Central Processing Unit (CPU)
MPlease make sure the CPU type is supported by the motherboard.
MIf you do not match the CPU socket Pin 1 and CPU cut edge well, it will cause
improper installation. Please change the insert orientation.

- 10 -GA-6IWMT(-C) Motherboard
English
Step 1-2: CPU Heat Sink Installation
3. Fastentheheatsinksupporting-base
ontotheCPUsocketon themain-
board.
2. UsequalifiedfanapprovedbyIntel.
4. Make sure the CPU fan is
pluggedtotheCPUfan connector,
thaninstallcomplete.
1. Press down the CPU socket
leverandfinishCPUinstallation.
MPlease use Intel approved cooling fan.
MWe recommend you to apply the thermal paste to provide better heat
conduction between your CPU and heatsink.
MMake sure the CPU fan power cable is plugged in to the CPU fan connector,
this completes the installation.
MPlease refer to CPU heat sink user’s manual for more detail installation
procedure.

Hardware Installation Process
English
- 11 -
Step 2: Install memory modules
Themotherboardhas 2dualin-line memorymodule(DIMM)socketssupport 4banks.The BIOSwill
automaticallydetectsmemorytypeandsize.Toinstallthememorymodule,justpushitverticallyintothe
DIMMSlot.TheDIMMmodulecanonlyfitinonedirectionduetothetwonotch.Memorysizecanvary
betweensockets.
1. TheDIMMslot hastwo notch,sothe
DIMMmemory module can onlyfit in
onedirection.
2. InserttheDIMM memorymodule
verticallyinto theDIMMslot. Then
pushitdown.
3. Closetheplastic clipatboth edgesofthe DIMMslotsto lockthe DIMMmodule.
Reversetheinstallation stepswhenyou wishtoremovetheDIMM module.
SDRAM
MWhen STR/DIMM LED is ON, do not install/remove SDRAM from socket.
MPlease note that the DIMM module can only fit in one direction due to the two
notches. Wrong orientation will cause improper installation. Please change
the insert orientation.

- 12 -GA-6IWMT(-C) Motherboard
English
Step 3: Install expansion cards
1. Readtherelatedexpansioncard’sinstructiondocumentbeforeinstalltheexpansioncardinto
thecomputer.
2. Removeyourcomputer'schassis cover,necessaryscrewsand slotbracketfromthe computer.
3. Presstheexpansioncardfirmlyintoexpansionslotinmotherboard.
4. Besurethemetalcontactsonthecardareindeedseatedintheslot.
5. Replacethescrewtosecuretheslotbracketoftheexpansioncard.
6. Replaceyourcomputer’schassiscover.
7. Poweronthe computer,if necessary,setup BIOSutility ofexpansion cardfrom BIOS.
8. Installrelateddriverfromtheoperatingsystem.
PCI Slot
Issues To Beware Of When Installing CNR
Pleaseusestandard CNRcardlikethe oneinorderto avoidmechanicalproblem.
Standard CNR Card

Hardware Installation Process
English
- 13 -
Step 4: Connect ribbon cables, cabinet wires, and power
supply
Step 4-1: I/O Back Panel Introduction
uPS/2 Keyboard and PS/2 Mouse Connector
ØThisconnectorsupportsstandardPS/2keyboard
andPS/2 mouse.
PS/2Mouse Connector
(6pinFemale)
PS/2KeyboardConnector
(6pinFemale)
u
vwx
y
vUSB & LAN Connector
ØBeforeyou connect yourdevice(s) into USB
connector(s),pleasemakesureyourdevice(s)
suchasUSB keyboard,mouse, scanner,zip,
speaker..etc.Havea standardUSBinterface.
AlsomakesureyourOSsupportsUSBcontroller.
IfyourOSdoesnotsupportUSBcontroller,please
contactOSvendorforpossiblepatchordriver
upgrade.Formoreinformationpleasecontactyour
OS or device(s) vendors.
USB 0
USB 1
LAN*
*ForGA-6IWMT Only

- 14 -GA-6IWMT(-C) Motherboard
English
xGame /MIDI Ports
yAudio Connectors
ØThisconnectorsupports joystick,MIDIkeyboard
andotherrelateaudiodevices.
ØAfterinstall onboardaudiodriver, you may
connectspeakertoLineOutjack,microphoneto
MICIn jack. Devicelike CD-ROM, walkman etc
canbeconnectedtoLine-Injack.
Joystick/MIDI (15 pin Female)
ØThisconnectorsupports1standardCOM port
,1Parallel port and 1VGA port.Device like
printercanbeconnectedtoParallelport;mouse
andmodemetccanbeconnectedtoSerialports.
w Parallel Port , Serial Port and VGA Port (LPT/COMA/VGA)
ParallelPort
(25pinFemale)
COMA VGA
SerialPort
(9pinMale) VGA Port (15pinFemale)
LineIn
MIC In
LineOut

Hardware Installation Process
English
- 15 -
Step 4-2: Connectors Introduction
*ForGA-6IWMT Only
1) CPU_FAN 9) F_AUDIO
2) SYS_FAN 10) CD_IN
3) ATX 11) IR
4) IDE1/IDE2 12) F_USB
5) FDD 13) COMB
6) PWR_LED 14) MODEM
7) F_PANEL 15) WOL*
8) BATTERY
1
3
13
9
10
4
2
5
11 15
6
7
8
12
14

- 16 -GA-6IWMT(-C) Motherboard
English
1) CPU_FAN (CPU FAN Connector)
Please note, a proper installation of the CPU cooler is essential to prevent the CPU from running
under abnormal condition or damaged by overheating.The CPU fan connector supports Max.
current up to 600 mA.
Pin No. Definition
1 GND
2 +12V
3 Sense
1
2) SYS_FAN (System FAN Connector)
This connector allows you to link with the cooling fan on the system case to lower the system
temperature.
Pin No. Definition
1 GND
2 +12V
3 Sense
1
