Gigabyte GA-8IPE1000MT User manual

Whenyou installing AGPcard,please make surethefollowing notice
isfullyunderstood and practiced.IfyourAGPcardhas "AGP4X/8X
(1.5V)notch"(showbelow),please make sureyourAGPcardisAGP
4X/8X(1.5V).
Caution:AGP2XcardisnotsupportedbyIntel®845(GE/PE)/845(E/G)/
850(E)/E7205 /865(P/G/PE)/875P.You mightexperience systemunable
tobootup normally.Please insertanAGP4X/8Xcard.
Example1:Diamond VipperV770 golden fingeriscompatiblewith2X/4X
mode AGPslot. It can be switched between AGP2X(3.3V)or4X(1.5V)
mode byadjusting the jumper.The factorydefaultforthiscardis2X(3.3V).
The GA-8IPE1000MTmotherboardsmightnotfunction properly,ifyou
install thiscardwithoutswitching the jumperto4X(1.5V)mode init.
Example2:SomeATiRage 128 Prographics cardsmade by"PowerColor",
the graphics cardmanufacturer&someSiS305 cards,theirgolden fingeris
compatiblewith2X/4Xmode AGPslot, buttheysupport2X(3.3V)only.The
GA-8IPE1000MTmotherboardsmightnotfunction properly,If you install this
cardinit.
Note:Although Gigabyte'sAG32S(G)graphics cardisbased on ATiRage
128 Prochip,the design ofAG32S(G)iscompliancewithAGP4X(1.5V)
specification.Therefore,AG32S(G)will workfine withIntel®845(GE/PE)/845
(E/G)/850(E)/E7205 /865(P/G/PE)/875Pbased motherboards.
AGP4X/8Xnotch
8ipe1000mt_1001_f.p65 2003/4/15, 下午 05:121

Theauthorassumes no responsibilityforanyerrorsor
omissionsthatmay appearinthisdocumentnordoes the
authormake acommitmenttoupdatetheinformation
containedherein.
Third-partybrandsand names arethepropertyoftheir
respective owners.
Please do notremove anylabelson motherboard,thismay
voidthewarrantyofthismotherboard.
Duetorapidchangeintec hnology,someofthe
specificationsmightbeoutofdatebeforepublication of
thisbooklet.
8ipe1000mt_1001_f.p65 2003/4/15, 下午 05:122

Declaration ofConformity
We,Manufacturer/Importer
(full address)
G.B.T.TechnologyTräding GMbH
AusschlagerWeg41,1F,20537 Hamburg,Germany
declarethatthe product
(description ofthe apparatus,sy stem,installation towhichitrefers)
MotherBoard
GA-8IPE1000MT
isinconformitywith
(referencetothe specification underwhichconformityisdeclared)
inaccordancewith89/336 EEC-EMCDirective
oEN55011 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
industrial,scientificand medical(ISM
high frequency equipment
oEN61000-3-2*
TEN60555-2
Disturbancesinsupplysystemscause
byhouseholdappliancesand similar
electricalequipment“Harmonics”
oEN55013 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
broadcastreceiversand associated
equipment
oEN61000-3-3*Disturbancesinsupplysystemscause
byhouseholdappliancesand similar
electricalequipment“Voltage fluctuations”
oEN55014 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
householdelectricalappliances,
portabletoolsand similarelectrical
apparatus
TEN50081-1Genericemission standardPart1:
Residualcommercialand lightindustry
TEN50082-1GenericimmunitystandardPart1:
Residualcommercialand lightindustry
oEN55015 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
fluorescentlampsand luminaries
Genericemission standardPart2:
Industrialenvironment
oEN55081-2
Immunityfromradiointerferenceof
broadcastreceiversand associated
equipment
Genericemission standardPart2:
Industrialenvironment
oEN55082-2
TEN55022 Limitsand methodsofmeasurement
ofradiodisturbancecharacteristics of
information technologyequipment
lmmunityrequirementsforhousehold
appliancestoolsand similarapparatus
oENV55104
Cabled distribution systems;Equipment
forreceiving and/ordistribution from
sound and television signals
EMCrequirementsforuninterruptible
powersystems(UPS)
oEN50091-2
oEN55020
oDINVDE0855
opart10
opart12
(ECconformitymarking)
TCEmarking
Themanufactureralsodeclares theconformityofabove mentionedproduct
withtheactualrequiredsafetystandardsinaccordance withLVD73/23 EEC
Safetyrequirementsformainsoperated
electronicand related apparatusfor
householdand similargeneraluse
oEN60950
oEN60065
Safetyofhouseholdand similar
electricalappliances
oEN60335
Manufacturer/Importer
Signature:
Name:
(Stamp)
Date:April 14,2003
TEN60555-3
TimmyHuang
Timmy Huang
oEN50091-1
Safetyforinformation technologyequipment
including electricalbussiness equipment
Generaland Safetyrequirementsfor
uninterruptiblepowersystems(UPS)
8ipe1000mt_1001_f.p65 2003/4/15, 下午 05:123

FCC Part15,SubpartB,Section 15.107(a)and Section 15.109(a),
Class BDigitalDevice
DECLARATIONOFCONFORMITY
PerFCC Part2Section 2.1077(a)
ResponsiblePartyName:
Address:
Phone/FaxNo:
hereby declaresthattheproduct
ProductName:Motherboard
Conformstothefollowing specifications:
Thisdevice complieswithpart15 oftheFCC Rules.Operation is
subjecttothefollowing twoconditions:(1)Thisdevice maynot
causeharmfuland (2)thisdevicemustacceptanyinference received,
including thatmaycauseundesiredoperation.
RepresentativePerson’sName:
Signature:EricLu
SupplementaryInformation:
ModelNumber:GA-8IPE1000MT
17358RailroadStreet
CityofIndustry,CA 91748
G.B.T.INC.(U.S.A.)
[phone]/[phone]
Date:
ERICLU
April.14,2003
8ipe1000mt_1001_f.p65 2003/4/15, 下午 05:124

USER'SMANUAL
GA-8IPE1000MT
P4Titan SeriesMotherboard
Pentium®4ProcessorMotherboard
Rev.1001
12ME-8IPE1KMT-1001

-2-GA-8IPE1000MTMotherboard
English
TableofContent
ItemChecklist ..................................................................................... 4
Chapter1Introduction ........................................................................ 5
FeaturesSummary......................................................................................... 5
GA-8IPE1000MTMotherboardLayout ......................................................... 7
Block Diagram................................................................................................ 8
Chapter2HardwareInstallation Process ........................................... 11
Step 1:Install the CentralProcessing Unit(CPU)...................................... 12
Step 1-1:CPUInstallation ....................................................................................... 12
Step 1-2:CPUCooling Fan Installation ................................................................... 13
Step 2:Install MemoryModules.................................................................. 14
Step 3:Install expansion cards.................................................................... 16
Step 4:Connectribbon cables,cabinetwiresand powersupply............. 17
Step 4-1:I/OBack PanelIntroduction ..................................................................... 17
Step 4-2:ConnectorsIntroduction ........................................................................... 19
Chapter3BIOSSetup ...................................................................... 33
The MainMenu (Forexample:BIOSVer.:E13)....................................... 34
StandardCMOSFeatures........................................................................... 36
Advanced BIOSFeatures............................................................................. 39
Integrated Peripherals................................................................................. 41
PowerManagementSetup .......................................................................... 46
PnP/PCIConfigurations................................................................................ 49
PCHealthStatus........................................................................................... 50

TableofContent
English
-3-
Frequency/Voltage Control........................................................................... 52
Load Fail-SafeDefaults................................................................................ 54
Load Optimized Defaults.............................................................................. 55
SetSupervisor/UserPassword..................................................................... 56
Save&ExitSetup .......................................................................................... 57
ExitWithoutSaving ....................................................................................... 58
Chapter4TechnicalReference......................................................... 61
@BIOS™Introduction .................................................................................... 61
EasyTune™4Introduction ............................................................................ 62
FlashBIOSMethod Introduction ................................................................. 63
2-/4-/6-ChannelAudioFunction Introuction ............................................ 67
Jack-Sensing Introuction ........................................................................... 73
Chapter5Appendix......................................................................... 77

-4-GA-8IPE1000MTMotherboard
English
ItemChecklist
TheGA-8IPE1000MTmotherboard
CD formotherboarddriver&utility
GA-8IPE1000MTuser'smanual
Quick PCInstallation Guide
SATARAIDManual
GC-SATACard(optional)
(Manual;SATAcablex1;Powercablex1)
I/OShield
IDEcablex1/Floppycablex1
SerialATAcablex2
2PortUSB Cablex1
4PortUSB Cablex1
SPDIFKitx1(SPDIFOutKit)
IEEE 1394 Cablex1
AudioCombo Kitx1
(SURROUND-Kit+SPDIFOutKit)
MotherboardSettingsLabel
Computermotherboardsand expansion cardscontainverydelicateIntegrated Circuit
(IC)chips.Toprotectthemagainstdamage fromstaticelectricity,you shouldfollow
someprecautionswheneveryou workon yourcomputer.
1.Unplug yourcomputerwhen working ontheinside.
2.Useagroundedwriststrapbeforehandlingcomputercomponents.Ifyoudonothaveone,touch
bothofyourhandstoasafelygrounded objectortoametalobject, suchasthe powersupply
case.
3.Holdcomponentsbythe edgesand trynottouchthe ICchips,leadsorconnectors,orother
components.
4.Placecomponentson agrounded antistaticpadoron the bag thatcamewiththecomponents
wheneverthe componentsareseparated fromthe system.
5.EnsurethattheATXpowersupplyisswitched offbeforeyou plug inorremovethe ATXpower
connectoronthemotherboard.
Ifthemotherboardhasmountingholes,buttheydon'tlineup withtheholesonthebaseandthereare
noslotstoattachthe spacers,do notbecomealarmedyou can still attachthespacerstothemounting
holes.Justcutthebottomportionofthespacers(thespacermaybe alittlehardtocutoff,sobe carefulof
yourhands).Inthiswayyou can still attachthe motherboardtothe basewithoutworrying aboutshort
circuits.Sometimesyoumayneed tousetheplasticspringstoisolatethe screwfromthe motherboard
PCBsurface,becausethe circuitwiremaybe nearbythe hole.Becareful,don'tletthe screwcontact
anyprintedcircuitwriteorpartson thePCBthatarenearthe fixinghole,otherwiseitmaydamage the
boardorcauseboardmalfunctioning.
Installing themotherboardtothechassis...

Introduction
English
-5-
FormFactor—24.4cmx22.5cmMicroATXsizeformfactor,4layersPCB
CPU—Socket478 forIntel®MicroFC-PGA2Pentium®4processor
—SupportIntel®Pentium®4(Northwood,Prescott)processor
—SupportIntel®Pentium®4ProcessorwithHTTechnology*
—Intel®Pentium®4800/533/400MHzFSB
—2ndcache dependsonCPU
Chipset—Intel®Chipset865PE HOST/AGP/Controller
—Intel®ICH5I/OControllerHub
Memory—2184-pinDDR DIMM sockets
—SupportsDualChannelDDR400/DDR333/DDR266 DIMM
—Supports128MB/256MB/512MB/1GBunbuffered DRAM
—Supportsup to4GBDRAM(Max)
—SupportsonlyDDR DIMM
I/OControl—ITE8712F
Slots—3PCIslotsupports33MHz&PCI2.3compliant
On-BoardIDE—2IDEcontrollersprovidesIDEHDD/CD-ROM(IDE1,IDE2)with
PIO,BusMaster(UltraDMA33/ATA66/ATA100)operation modes
—Can connectup to4IDEdevices
SerialATA—2SerialATAconnectorsin150MB/soperation mode
—Controlled byICH5
On-BoardPeripherals—1Floppyportsupports2FDD with360K,720K,1.2M,1.44M
and 2.88Mbytes
—1ParallelportsupportsNormal/EPP/ECPmode
—2Serialports(COMAand COMB)
—8USB 2.0/1.1ports(4xRear,4xFrontbycable)
—1IrDAconnectorforIR
—1FrontAudioconnector
Chapter1Introduction
tobe continued......
Features Summary
Due tochipset(Intel865PE)architecturelimitation,DDR 400 memorymoduleisonlysupported
when using FSB 800 Pentium4processor.AFSB 533 Pentium4processorwill support
DDR333 and DDR266 memorymodule.AFSB 400 Pentium4processorwill onlysupport
DDR 266 memorymodule.

-6-GA-8IPE1000MTMotherboard
English
HardwareMonitor—CPU/Systemfan revolution detect
—CPUtemperaturedetect
—CPUwarningtemperature
—Systemvoltage detect
—CPU/Systemfan fail warning
On-BoardLAN—BuilitinRealtek8101L Chipset
—1RJ45 port
On-BoardSound —RealtekALC655 codec
—SupportsEZ-JackSensing function
—Line Out/2frontspeaker
—Line In/2rearspeaker(bys/wswitch)
—MicIn/center&subwoofer(bys/wswitch)
—CD In/AUXIn/Gameport
PS/2Connector—PS/2Keyboardinterfaceand PS/2Mouseinterace
BIOS—Licensed PhoenixBIOS,2MbitFWH
AdditionalFeatures—PS/2Keyboardpoweron bypassword
—PS/2Mousepoweron
—STR(Suspend-To-RAM)
—ACRecovery
—Polyfuseforkeyboardover-currentprotection
—USB KB/Mousewakeup fromS3
—Supports@BIOS
—SupportsEasyTune 4
—Supportsclearpasswordfunction
Pleasesetthe CPUhostfrequency inaccordancewithyourprocessor'sspecifications.
Wedon'trecommend you tosetthe systembusfrequency overthe CPU'sspecification because
thesespecificbusfrequenciesarenotthe standardspecificationsforCPU,chipsetand mostofthe
peripherals.Whetheryoursystemcan run underthesespecificbusfrequenciesproperlywill
depend on yourhardwareconfigurations,including CPU,Chipsets,SDRAM,Cards…etc.
"*"HTfunctionalityrequirementcontent:
Enabling the functionalityofHyper-Threading Technologyforyourcomputersystemrequiresall
ofthe following platformcomponents:
-CPU:AnIntel®Pentium4ProcessorwithHTTechnology
-Chipset: AnIntel®ChipsetthatsupportsHTTechnology
-BIOS:ABIOSthatsupportsHTTechnologyand hasitenabled
-OS:Anoperation systemthathasoptimizationsforHTTechnology

Introduction
English
-7-
GA-8IPE1000MTMotherboardLayout
GA-8IPE1000MT
KB_MS
COMA
ATX_12V
CD_IN
F_AU DIO
F_PANEL
BAT
SYS_FAN
IntelIC H5
Intel865PE
SOCKET478
CPU_FAN
ATX
FDD
IDE2
PCI1
PCI2
PCI3
DDR1
CODEC
ITE8712F
BIOS
Buzzer
F_USB2
CI
COMB
IDE1
CLR_PWD
RTL
81 01 L
F_USB1
AUX_IN
IR
RAM_LED
PWR_LED
USB LAN
R_USB
AUDIO1
DDR2
GAME
INFO_LINK
SUR_CEN
2X_DET
SATA0 SATA1
LPT
AGP

-8-GA-8IPE1000MTMotherboard
English
Block Diagram
CLKGEN
CPUCLK+/-(100/133/200MHz)
AGPCLK(66MHz)
MCHCLK(100/133/200MHz)
ICH3V66 (66MHz)
PCICLK(33MHz)
USBCLK(48MHz)
14.318 MHz
33 MHz
Intel865PE
Intel
ICH5
CPUCLK+/-(100/133/200MHz)
SystemBus
800/533/400MHz
MCHCLK(100/133/200MHz)
66 MHz
33 MHz
14.318 MHz
48 MHz
LPCBUS
AGP4X/8X
AGPCLK
(66MHz)
3PCI
PCICLK
(33MHz)
RJ45
AC97 Link
8USB
Ports
ATA33/66/100
IDEChannels
Realtek
8101L
IT8712F
24 MHz
33 MHz
GamePort
Floppy
LPTPort
PS/2KB/Mouse
2COMPorts
MIC
LINE-IN
LINE-OUT
Pentium4
Socket478
CPU
AC97
CODEC
400/333/266MHz
2SerialATA
DDR RAM
BIOS

Introduction
English
-9-

-10 -GA-8IPE1000MTMotherboard
English

-11 -HardwareInstallation Process
English
Chapter2HardwareInstallation Process
Tosetupyourcomputer,youmustcompletethe followingsteps:
Step 1-Install the CentralProcessingUnit(CPU)
Step2-Install memorymodules
Step3-Install expansion cards
Step 4-Connectribboncables,cabinetwires,andpowersupply
Congratulations!Youhaveaccomplishedthe hardwareinstallation!
Turnon thepowersupplyorconnectthepowercabletothepoweroutlet. Continue withthe
BIOS/softwareinstallation.
Step2
Step4
Step3
Step4
Step4
Step1

-12 -GA-8IPE1000MTMotherboard
English
Step1:Install theCentralProcessing Unit(CPU)
Step1-1:CPUInstallation
Angling the
rod to650
1.Anglingtherodto65-degreemaybe
feelakind oftight,andthen continue
pulltherodto90-degreewhenanoise
"cough"made.
2.Pull therodtothe90-degreedirectly.
Pin1indicator
3.CPUTop View
Pin1indicator
4.LocatePin1inthe socketand
lookfora(golden)cutedgeonthe
CPUuppercorner.Then insert
the CPUintothe socket.
Socket
Actuation
Lever
Beforeinstalling theprocessor,adheretothefollowing warning:
1.Please make suretheCPUtypeissupportedbythemotherboard.
2. Ifyou do notmatchtheCPUsocketPin1and CPUcutedgewell, itwill
cause improperinstallation.Please changetheinsertorientation.

-13 -HardwareInstallation Process
English
Step1-2:CPUCooling FanInstallation
1.Fasten the cooling fan supporting-
baseontothe CPUsocketon the
motherboard.
Beforeinstalling theCPUcooling fan,adheretothefollowing warning:
1.Please use Intelapprovedcooling fan.
2.Werecommend you toapplythethermaltapetoprovidebetterheat
conduction betweenyourCPUand cooling fan.
(TheCPUcooling fanmightstick totheCPUduetothehardening of
thethermalpaste.During thiscondition ifyou trytoremove thecool-
ing fan,you mightpull theprocessoroutoftheCPUsocketalonewith
thecooling fan,and mightdamagetheprocessor.To avoidthisfrom
happening,wesuggestyou toeitheruse thermaltapeinsteadof
thermalpaste,orremove thecooling fanwithextremecaution.)
3.Make suretheCPUfanpowercableispluggedintotheCPUfan
connector,thiscompletes theinstallation.
Please refertoCPUcooling fanuser'smanualformoredetail
installation procedure.
2.Makesurethe CPUfan isplugged
tothe CPUfan connector,than
installcomplete.

-14 -GA-8IPE1000MTMotherboard
English
Beforeinstalling thememorymodules,adheretothefollowing warning:
1.WhenRAMLEDisON,do notinstall /remove DIMM fromsocket.
2.Please notethattheDIMM modulecanonlyfitinonedirection dueto
theonenotch.Wrong orientation will cause improperinstallation.
Please changetheinsertorientation.
Step2:Install MemoryModules
The motherboardhas2dualinline memorymodule(DIMM)sockets.The BIOSwill automatically
detectsmemorytype and size.Toinstall the memorymodule,justpushitverticallyintothe DIMM
socket. The DIMM modulecan onlyfitinone direction due tothe notch.Memorysizecan vary
betweensockets.
DDR
Notch
1.The DIM M sockethasanotch,sothe DIMM memory
modulecan onlyfitinone direction.
2. Insertthe DIMM memorymoduleverticallyintothe DIMM
socket. Then pushitdown.
3.Closethe plasticclipatbothedgesofthe DIMM sockets
tolock the DIMM module.
Reversethe installation stepswhen you wishtoremove
the DIMM module.

-15 -HardwareInstallation Process
English
1.When one DDR memorymoduleisinstalled,the DualChannelTechnologywill not
operate.It will onlyworkasSingleChannel.
2.The DualChannelTechnologywill operatewhen twoDDR memorymodulesare
installed.(Pleasenotethatthe twoDDR memorymodulesmustbe the samememory
sizeand type.)
DualChannelDDR:
GA-8IPE1000MTsupportsDualChannelTechnology.
When DualChannelTechnologyisactivated,the bandwidthofmemorybuswill be double
the originalone,withthe fastestspeed at6.4GB/sDDR400.
GA-8IPE1000MTincludestwoDIMM slots,and eachChannelhas1DIMM asfollowing:
ChannelA:DIM M 1
ChannelB:DIM M 2
DDR Introduction
Established on the existing SDRAMindustryinfrastructure,DDR (DoubleDataRate)memoryisa
high performanceand cost-effectivesolution thatallowseasy adoption formemoryvendors,OEMs
and systemintegrators.
DDR memoryisasensibleevolutionarysolution forthe PCindustrythatbuildson the existing
SDRAMinfrastructure,yetmakesawesomeadvancesinsolving the systemperformancebottleneck
bydoubling the memorybandwidth.DDR SDRAMwill offerasuperiorsolution and migration pathfrom
existing SDRAMdesignsdue toitsavailability,pricing and overall marketsupport. PC2100 DDR
memory(DDR266)doublesthe dataratethrough reading and writing atboththe rising and falling edge
ofthe clock,achieving databandwidth2Xgreaterthan PC133 when running withthe sameDRAM
clock frequency.Withpeakbandwidthof2.664GBpersecond,DDR memoryenablessystemOEMs
tobuildhigh performanceand lowlatency DRAMsubsystemsthataresuitableforservers,workstations,
high-end PC'sand value desktop SMAsystems.

-16 -GA-8IPE1000MTMotherboard
English
When an AGP2X(3.3V)cardisinstalled the 2X_DETwill lightup,indicating anon-supported
graphics cardisinserted.Informing usersthatsystemmightnotbootup normallydue to
AGP2X(3.3V)isnotsupported bythe chipset.
Step3:Install expansion cards
1.Read the related expansion card'sinstructiondocumentbeforeinstall the expansioncardintothe
computer.
2.Removeyourcomputer'schassiscover,screwsand slotbracketfromthecomputer.
3.Press the expansion cardfirmlyintoexpansion slotinmotherboard.
4.Besurethe metalcontactsonthe cardareindeedseated inthe slot.
5.Replacethescrewtosecurethe slotbracketoftheexpansion card.
6.Replaceyourcomputer'schassiscover.
7.Poweron the computer,ifnecessary,setup BIOSutilityofexpansion cardfromBIOS.
8. Install related driverfromtheoperating system.
AGPCard
Pleasecarefullypull outthe small white-drawable
baratthe end ofthe AGPslotwhen you tryto
install/Uninstall the AGPcard.Pleasealign the
AGPcardtothe onboardAGPslotand press firmly
downon the slot.MakesureyourAGPcardis
locked bythe small white-drawablebar.
