GA-C621-WD12(-IPMI) Quick Installation Guide/ 快速安装指南 Jumpers, Connectors, and LEDs/ 跳线 ,联接器 ,指示灯
1
20
24
39 235
4
5
6
7
10
14
16
18
17
15
19
25
12
9
13
23
22
11
8
33
1 BMC_VGA * 22 CI
2BMC_WATCHD * 23 CPU_FAN1~2
3 COM 24 SYS_FAN1~5
4 SMB_IPMB * 25 ATX
5 I_SGPIO1 26 ATX8P_1~2
6 I_SGPIO2 27 ATX12V 6P
7 WOL 28 S-SATA0~1
8 SMB 29 I-SATA0~7
9 TPM 30 PCIEX4_M2
10 TBT 31 U2_1~2
11 BMC_UART * 32 PWR_SW
12 SATA_DOM0 33 RST_SW
13 SATA_DOM1 34 S_SGPIO
14 VRM_SCL 35 F_AUDIO
15 VRM_SDA 36 VGA *
16 FUSB30 37 SMB_VMD
17 VROC 38 SPEAKER
18 FUSB2 39 BMC_LED2 *
19 F_PANEL 40 BAT
20 PMBUS 41 USB 3.0
21 CLR_CMOS
Pin Denition
1-2 Enable (Default)
2-3 Disable
Pin Denition
1BMC_UART_TXD
2 GND
3 BMC_UART_RXD
4Power (5V)
Pin Denition Pin Denition
1Power (5V) 2Power (5V)
3USB DX- 4USB DY-
5USB DX+ 6USB DY+
7GND 8GND
9-10 NC
Pin Denition
1Intrusion Input
2 GND
Pin Denition Pin Denition
1LPC_IO0 2Power (3.3V)
3LPC_IO1 4-
5LPC_IO2 6TPM_CLK
7LPC_IO3 8GND
9LFRAME# 10 NA
11 SERIRQ 12 TPM_RST
Pin Denition Pin Denition
1NA 2-
3SATA_DATA 4GND
5GND 6SATA_LOAD
7NA 8SATA_CLK
Pin Denition
1-2 Enable
2-3 Disable (Default)
Pin Denition
1 GND
2Power (3.3V)_AUX
3 GND
4 PCH RAID KEY
Pin Denition
1 SMB_CLK
2 SMB_DATA
3 PSU_ALERT
4 GND
5Power (3.3V)
Pin Denition
1-2 NA (Default)
2-3 Clear CMOS
Pin Denition
1GND
2Power (12V)
3FAN_TACH
4FAN_PWM
Pin Denition
1 GND
2Power (12V)
3 FAN_TACH
4 FAN_PWM
Pin Denition
1Power (5V)_AUX
2 GND
3 WAKE_EN
Pin Denition
1 SMB_DATA
2 GND
3 SMB_CLK
Pin Denition
1-2 SMB to PCH
2-3 SMB to BMC *
Pin Denition
1Power (5V)
2 GND
3 NA
1
2
9
1
10
2
2
1
2423
21
8
12
10
1
1
1
20
1
1
1
7
11
11
1
1
1
1
1
1
CPU_FAN2CPU_FAN1
1
1
1) BMC_VGA *
4) SMB_IPMB *
10) TBT
2) BMC_WATCHD *
5) I_SGPIO1 (For I-SATA0~3)
6) I_SGPIO2 (For I-SATA4~7)
17) VROC (RAID Key for CPU NVMe SSD)
20) PMBUS (Power supply I2C Connector)
22) CI
24) SYS_FAN1~5
8) SMB
11) BMC_UART *
18) FUSB2
21) CLR_CMOS
23) CPU_FAN1/CPU_FAN2
16) FUSB30
19) F_PANEL
3) COM
7) WOL (Wake On Lan)
9) TPM ( Tr usted Platfo rm Modul e/Por t 80 Header)
12) SATA_DOM0 (SATA DOM0 Power Header)
13) SATA_DOM1 (SATA DOM1 Power Header)
14) VRM_SCL (For VRM SMB_CLK)
15) VRM_SDA (For VRM SMB_DATA)
Pin Denition Pin Denition
1 VBUS 11 D2+
2 SSRX1- 12 D2-
3 SSRX1+ 13 GND
4 GND 14 SSTX2+
5 SSTX1- 15 SSTX2-
6 SSTX1+ 16 GND
7 GND 17 SSRX2+
8 D1- 18 SSRX2-
9 D1+ 19 VBUS
10 NC 20 -
Pin Denition Pin Denition
1Power LED+ 25V Standby
3-4ID LED+
5Power LED- 6ID LED-
7HDD LED+ 8System Status LED+
9HDD LED1 10 System Status LED-
11 Power Button 12 LAN1 Active LED+
13 GND 14 LAN1 Link LED-
15 Reset Button 16 SMBus Data
17 GND 18 SMBus Clock
19 ID Button 20 Case Open
21 GND 22 LAN2 Active LED+
23 NMI Switch 24 LAN2 Link LED-
Box Contents
27
26
3
32 21
30
29
38
31
28
34
5GA-C621-WD12 or GA-C621-WD12-IPMI motherboard
5Motherboard driver disk 5I/O Shield
5Quick Installation Guide 5One VGA bracket *
5Ten SATA cables
5One COM port bracket *
12QC1-SERW12-0GR
36
23
24
24
24
26
37
40
Pin Denition Pin Denition
1 NDCD- 2 NSIN
3 NSOUT 4 NDTR-
5 GND 6 NDSR-
7 NRTS- 8 NCTS-
9 NRI- 10 -
9
1
10
2
Pin Denition
1 SMB_DATA
2 GND
3 SMB_CLK
4 NA
1
1
5
Pin Denition
1 FORCE_POWER
2 SCI_EVENT
3 SLP_S3
4 SLP_S5
5 GND
1
1
SYS_FAN2SYS_FAN1~5
25) ATX (2x12 Main Power Connector)
1 13
12 24
28
1
A
A
B
B
C
C
2
3
4
5
7
6
8
Installing the CPU and Heatsink/ 安装处理器与散热器
LED State Description
Link (Right) Solid Green 100 Mbps
Solid Amber 1Gbps
Activity (Left) Blinking Yellow Active
GbE LAN Port LEDs:
USB 2.0/1.1 Port
PS/2 Keyboard/Mouse Port
USB 3.1 Gen 2 Type-A Port
(Red)
USB Type-C™ Port, with USB
3.1 Gen 2 support
GbE LAN Port (LAN1~2)
USB 3.1 Gen 1 Ports
Audio Jacks
Back Panel Connectors/ 后窗接口
* Only for the GA-C621-WD12-IPMI.
* Only for the GA-C621-WD12-IPMI.
41

Jumpers, Connectors, and LEDs/ 跳线 ,联接器 ,指示灯
