Gigabyte GA-EP45-UD3P User manual

GA-EP45-UD3P
LGA775 socket motherboard for Intel®CoreTM processor family/
Intel®Pentium®processor family/Intel®Celeron®processor family
User's Manual
Rev.1001
12ME-EP45UD3P-1001R

Sept. 15, 2008
Motherboard
GA-EP45-UD3P
Motherboard
GA-EP45-UD3P
Sept. 15, 2008

Copyright
©2008 GIGA-BYTE TECHNOLOGY CO., LTD.All rights reserved.
Thetrademarksmentionedinthismanualarelegallyregisteredtotheirrespectiveowners.
The logo is exclusively licensed to GIGABYTE UNITED INC. by GIGA-BYTE
TECHNOLOGY CO., LTD.
GIGABYTE UNITED INC. is designated by GIGA-BYTE TECHNOLOGY CO., LTD as the exclu-
siveglobaldistributorofGIGABYTEbrandedmotherboards.
Disclaimer
Informationinthis manualisprotected bycopyrightlaws andistheproperty ofGIGABYTE.
ChangestothespecificationsandfeaturesinthismanualmaybemadebyGIGABYTEwithoutprior
notice. Nopartofthismanualmaybereproduced,copied,translated,transmitted,orpublishedinany
formorbyanymeanswithoutGIGABYTE'spriorwrittenpermission.
Documentation Classifications
Inordertoassistintheuseofthisproduct,GIGABYTEprovidesthefollowingtypesofdocumentations:
Forquickset-upoftheproduct,readtheQuickInstallationGuideincludedwiththeproduct.
Fordetailedproductinformation,carefullyreadtheUser'sManual.
For instructions on how to use GIGABYTE's unique features, read or download the
informationon/fromtheSupport\Motherboard\TechnologyGuidepageonourwebsite.
Forproduct-relatedinformation,checkonourwebsiteat:
http://www.gigabyte.com.tw
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"
means the revision of the motherboard is 1.0. Check your motherboard revision before updating
motherboardBIOS,drivers,orwhenlookingfortechnicalinformation.
Example:

- 4 -
Table of Contents
BoxContents ................................................................................................................. 6
OptionalItems................................................................................................................. 6
GA-EP45-UD3PMotherboard Layout............................................................................ 7
BlockDiagram................................................................................................................ 8
Chapter 1 HardwareInstallation .................................................................................... 9
1-1 InstallationPrecautions ..................................................................................... 9
1-2 ProductSpecifications .................................................................................... 10
1-3 Installing the CPU and CPU Cooler.............................................................. 13
1-3-1 Installing the CPU ................................................................................................ 13
1-3-2 Installing the CPU Cooler ................................................................................... 15
1-4 InstallingtheMemory ..................................................................................... 16
1-4-1 Dual Channel Memory Configuration................................................................ 16
1-4-2 Installing a Memory............................................................................................. 17
1-5 Installing anExpansionCard ......................................................................... 18
1-6 InstallingtheSATABracket ............................................................................. 19
1-7 Back PanelConnectors ................................................................................. 20
1-8 InternalConnectors ........................................................................................ 22
Chapter 2 BIOSSetup................................................................................................. 35
2-1 StartupScreen................................................................................................ 36
2-2 TheMainMenu .............................................................................................. 37
2-3 MBIntelligentTweaker(M.I.T.) ....................................................................... 39
2-4 Standard CMOSFeatures ............................................................................. 47
2-5 Advanced BIOS Features.............................................................................. 49
2-6 IntegratedPeripherals ..................................................................................... 52
2-7 PowerManagementSetup ............................................................................. 56
2-8 PnP/PCIConfigurations................................................................................. 58
2-9 PC Health Status ........................................................................................... 59
2-10 LoadFail-SafeDefaults................................................................................... 61
2-11 LoadOptimizedDefaults ................................................................................. 61
2-12 Set Supervisor/User Password..................................................................... 62
2-13 Save & Exit Setup......................................................................................... 63
2-14 ExitWithoutSaving ....................................................................................... 63
2-15 SecurityChip Configuration(Note) .................................................................... 64

- 5 -
Chapter 3 DriversInstallation ...................................................................................... 65
3-1 InstallingChipsetDrivers ............................................................................... 65
3-2 ApplicationSoftware....................................................................................... 66
3-3 TechnicalManuals.......................................................................................... 66
3-4 Contact........................................................................................................... 67
3-5 System........................................................................................................... 67
3-6 DownloadCenter............................................................................................ 68
Chapter 4 UniqueFeatures......................................................................................... 69
4-1 XpressRecovery2 ......................................................................................... 69
4-2 BIOS Update Utilities..................................................................................... 74
4-2-1 Updating the BIOS with the Q-Flash Utility...................................................... 74
4-2-2 Updating the BIOS with the @BIOS Utility ....................................................... 77
4-3 EasyTune6.................................................................................................... 78
4-4 Dynamic Energy SaverAdvanced ................................................................ 79
4-5 Ultra TPM (Note) ............................................................................................... 81
4-6 Q-Share ......................................................................................................... 82
4-7 TimeRepair .................................................................................................... 83
4-8 Teaming .......................................................................................................... 84
Chapter 5 Appendix .................................................................................................... 87
5-1 ConfiguringSATAHard Drive(s) .................................................................... 87
5-1-1 Configuring Intel®ICH10R SATA Controllers.................................................... 87
5-1-2 Configuring GIGABYTE SATA2 SATA Controller ............................................. 93
5-1-3 Making a SATA RAID/AHCI Driver Diskette ..................................................... 99
5-1-4 Installing the SATA RAID/AHCI Driver and Operating System .................... 101
5-2 ConfiguringAudioInputandOutput............................................................... 109
5-2-1 Configuring 2/4/5.1/7.1-Channel Audio .......................................................... 109
5-2-2 Installing the S/PDIF In Cable (Optional).......................................................... 111
5-2-3 Enabling the Dolby Home Theater Function .................................................. 113
5-2-4 Configuring Microphone Recording ................................................................. 114
5-2-5 Using the Sound Recorder............................................................................... 116
5-3 Troubleshooting..............................................................................................117
5-3-1 Frequently Asked Questions ........................................................................... 117
5-3-2 Troubleshooting Procedure .............................................................................. 118
5-4 RegulatoryStatements ................................................................................. 120
(Note) This feature is optional due to different regional policy.

- 6 -
Box Contents
GA-EP45-UD3Pmotherboard
Motherboarddriverdisk
User'sManual
QuickInstallationGuide
OneIDEcableandone floppy disk drive cable
FourSATA3Gb/scables
OneSATAbracket
I/O Shield
Optional Items
2-portUSB2.0bracket (Part No. 12CR1-1UB030-51R)
2-portIEEE1394abracket(PartNo.12CF1-1IE008-01R)
2-portSATApower cable (PartNo.12CF1-2SERPW-01R)
S/PDIF in cable (Part No. 12CR1-1SPDIN-01R)
COM port cable (Part No. 12CF1-1CM001-32R)
LPTportcable(PartNo.12CF1-1LP001-01R)
•Theboxcontentsaboveare for reference only andtheactualitemsshalldepend on product package youobtain.
Thebox contentsare subject tochange withoutnotice.
•Themotherboardimageisforreferenceonly.

- 7 -
GA-EP45-UD3P Motherboard Layout
(Note) This feature is optional due to different regional policy.
KB_MS CPU_FAN
LGA775
ATX
GA-EP45-UD3P
F_AUDIO
ATX_12V_2X4
Intel®P45
PCIEX1_1 SYS_FAN2
F1_1394
F_PANEL
PWR_LED
F_USB2
IDE
CD_IN FDD
PCIEX8_1
CODEC
TSB43AB23
PCI1
PCI2
BAT
IT8718
Intel®ICH10R
CLR_CMOS
CI
DDR2_1
DDR2_2
DDR2_3
DDR2_4
SPDIF_I
SATA2_3
RTL8111C
SATA2_2
SATA2_1
SATA2_0
PHASELED
USB_LAN2
AUDIO
R_SPDIF
USB_1394_2
USB_1394_1
USB_LAN1
PWR_FAN
GIGABYTE
SATA2
M_BIOS B_BIOS
SATA2_5
SATA2_4
LPTCOMA
TPM IC (Note)
SPDIF_O
PCIEX16_1
PCIEX1_2
PCIEX1_3
RTL8111C
SYS_FAN1
F_USB1
GSATA2_0 GSATA2_1

- 8 -
Block Diagram
(Note) This feature is optional due to different regional policy.
1 PCI Express x8
1 PCI Express x16
LGA775
Processor
Host
Interface
Intel®
P45 MCH CLK (400/333/266/200 MHz)
DDR2 1366/1066/800/667 MHz
Dual BIOS
2 PCI
PCI Bus
Dual Channel Memory
6 SATA 3Gb/s
PCI CLK
(33 MHz)
3 IEEE 1394a
12 USB Ports
CPU CLK+/-
(400/333/266/200 MHz)
TSB43AB23
Center/Subwoofer Speaker Out
Line-Out
MIC
Line-In
SPDIF In
SPDIF Out
Side Speaker Out
Surround Speaker Out
CODEC
PCIe CLK
(100 MHz)
PCI Express x16
Intel®ICH10R
TPM (Note)
3 PCI Express x1
PCI Express Bus
x1
x1 x1 x1
PCIeCLK
(100MHz)
x1
RTL
8111C
LAN1
RJ45
RTL
8111C
LAN2
RJ45
PCIeCLK
(100MHz) PCI Express x8
Floppy
PS/2 KB/Mouse
LPT Port
COM Port
IT8718
LPC Bus
2 SATA 3Gb/s
ATA-133/100/66/
33 IDE Channel
GIGABYTE
SATA2

Hardware Installation- 9 -
1-1 Installation Precautions
Themotherboardcontainsnumerousdelicateelectroniccircuitsandcomponentswhichcanbecome
damagedasaresult of electrostatic discharge(ESD).Priortoinstallation,carefully read the user's
manualandfollowtheseprocedures:
•Priortoinstallation,donotremoveorbreakmotherboardS/N(SerialNumber)stickeror
warrantystickerprovidedbyyourdealer.Thesestickersarerequiredforwarrantyvalidation.
•AlwaysremovetheACpowerby unpluggingthepowercordfromthepoweroutlet before
installingorremovingthemotherboardorotherhardwarecomponents.
•Whenconnectinghardwarecomponentstotheinternalconnectorsonthemotherboard,
makesuretheyareconnectedtightlyandsecurely.
•Whenhandlingthemotherboard,avoidtouchinganymetalleadsorconnectors.
•Itisbesttowearanelectrostaticdischarge(ESD)wriststrapwhenhandlingelectronic
componentssuchasamotherboard,CPUormemory.IfyoudonothaveanESDwriststrap,
keepyourhandsdryandfirsttouchametalobjecttoeliminatestaticelectricity.
•Priortoinstallingthemotherboard,pleasehaveitontopofanantistaticpadorwithinan
electrostaticshieldingcontainer.
•Beforeunpluggingthepowersupplycablefromthemotherboard,makesurethepowersupply
hasbeenturnedoff.
•Beforeturningonthepower,makesurethepowersupplyvoltagehasbeensetaccordingto
thelocalvoltagestandard.
•Beforeusingtheproduct,pleaseverifythatallcablesandpowerconnectorsofyourhardware
componentsareconnected.
•Topreventdamagetothemotherboard,donotallowscrewstocomeincontactwiththe
motherboardcircuitoritscomponents.
•Makesuretherearenoleftoverscrewsormetalcomponentsplacedonthemotherboardor
withinthecomputercasing.
•Donotplacethecomputersystemonanunevensurface
.
•Donotplacethecomputersysteminahigh-temperatureenvironment.
•Turningonthecomputerpowerduringtheinstallationprocesscanleadtodamagetosystem
componentsaswell asphysicalharm totheuser.
•Ifyouareuncertainaboutanyinstallationstepsorhaveaproblemrelatedtotheuseofthe
product,pleaseconsultacertifiedcomputertechnician.
Chapter 1 Hardware Installation

GA-EP45-UD3P Motherboard - 10 -
1-2 Product Specifications
CPU Support for an Intel®CoreTM 2 Extreme processor/
Intel®CoreTM 2 Quad processor/Intel®CoreTM 2 Duo processor/
Intel®Pentium®Dual-Core processor/Intel®Celeron®processor
in the LGA 775 package
(Go to GIGABYTE's website for the latest CPU support list.)
L2 cache varies with CPU
Front Side Bus 1600/1333/1066/800 MHz FSB
Chipset North Bridge: Intel®P45 Express Chipset
South Bridge: Intel®ICH10R
Memory 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory (Note 1)
Dual channel memory architecture
Support for DDR2 1366/1066/800/667 MHzmemory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio Realtek ALC889A codec
High Definition Audio
2/4/5.1/7.1-channel
Support for Dolby®Home Theater (Note 2)
Support for S/PDIF In/Out
Support for CD In
LAN 2 x Realtek 8111C chips (10/100/1000 Mbit)
Support for Teaming
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16_1) (Note 3)
1 x PCI Express x16 slot, running at x8 (PCIEX8_1)
(The PCIEX16_1 and PCIEX8_1 slots support ATI CrossFireXTM technology
and conform to PCI Express 2.0 standard.)
3 x PCI Express x1 slots
2 x PCI slots
Storage Interface South Bridge:
- 6 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3,
SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5 and RAID 10
GIGABYTE SATA2 chip:
- 1 x IDE connector supportingATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors (GSATA2_0, GSATA2_1) supporting up to
2 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1 and JBOD
iTE IT8718 chip:
- 1 x floppy disk drive connector supporting up to 1 floppy disk drive
IEEE 1394 T.I. TSB43AB23 chip
Up to 3 IEEE 1394a ports (2 on the back panel, 1 via the IEEE 1394a bracket
connected to the internal IEEE 1394a header)

Hardware Installation- 11 -
USB Integrated in the South Bridge
Up to 12 USB 2.0/1.1 ports (8 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
Internal Connectors 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x floppy disk drive connector
1 x IDE connector
8 x SATA 3Gb/s connectors
1 x CPU fan header
2 x system fan headers
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In header
1 x S/PDIF Out header
2 x USB 2.0/1.1 headers
1 x IEEE 1394a header
1 x parallel port header
1 x serial port header
1 x power LED header
1 x chassis intrusion header
Back Panel 1 x PS/2 keyboard port
Connectors 1 x PS/2 mouse port
1 x coaxial S/PDIF Out connector
1 x optical S/PDIF Out connector
8 x USB 2.0/1.1 ports
2 x IEEE 1394a ports
2 x RJ-45 ports
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side
Speaker Out/Line In/Line Out/Microphone)
I/O Controller iTE IT8718 chip
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System/Power fan speed detection
CPU overheating warning
CPU/System/Power fan fail warning
CPU/System fan speed control (Note 4)

GA-EP45-UD3P Motherboard - 12 -
BIOS 2 x 8 Mbit flash
Use of licensed AWARD BIOS
Support for DualBIOSTM
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features Support for @BIOS
Support for Q-Flash
Support for Virtual Dual BIOS
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune(Note 5)
Support for Dynamic Energy Saver Advanced
Support for Ultra TPM (Note 6)
Support for Time Repair
Support for Q-Share
Bundled Software Norton Internet Security (OEM version)
Operating System Support for Microsoft®Windows®Vista/XP
Form Factor ATX Form Factor; 30.5cm x 24.4cm
(Note 1) Due to Windows Vista/XP 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
(Note 2) For Windows Vista/XP 32-bit operating system only.
(Note 3) If you are installing one PCI Express graphics card, be sure to install it in the PCIEX16_1 slot
for optimum performance. When two graphics cards are installed, the PCIEX16_1 slot will
operate at up to x8 mode.
(Note 4) Whether the CPU/System fan speed control function is supported will depend on the CPU/
System cooler you install.
(Note 5) Available functions in EasyTune may differ by motherboard model.
(Note 6) This feature is optional due to different regional policy.

Hardware Installation- 13 -
1-3 Installing the CPU and CPU Cooler
Read the following guidelines before you begin to install the CPU:
•Make sure that the motherboard supports the CPU.
(Go to GIGABYTE's website for the latest CPU support list.)
•Always turn off the computer and unplug the power cord from the power outlet before
installing the CPU to prevent hardware damage.
•Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly. (Or you
may locate the notches on both sides of the CPU and alignment keys on the CPU socket.)
•Apply an even and thin layer of thermal grease on the surface of the CPU.
•Do not turn on the computer if the CPU cooler is not installed, otherwise overheating and
damage of the CPU may occur.
•Set the CPU host frequency in accordance with the CPU specifications. It is not recom-
mended that the system bus frequency be set beyond hardware specifications since it
does not meet the standard requirements for the peripherals. If you wish to set the fre-
quency beyond the standard specifications, please do so according to your hardware
specifications including the CPU, graphics card, memory, hard drive, etc.
1-3-1 Installing the CPU
A. Locate the alignment keys on the motherboard CPU socket and the notches on the CPU.
NotchNotch
AlignmentKey
LGA775CPU
LGA775CPUSocket
Pin One Corner of the CPU Socket
Triangle Pin One Marking on the CPU
AlignmentKey

GA-EP45-UD3P Motherboard - 14 -
Step 5:
Once the CPU is properly inserted, replace
the load plate and push the CPU socket lever
back into its locked position.
B. Follow the steps below to correctly install the CPU into the motherboard CPU socket.
Before installing the CPU, make sure to turn off the computer and unplug the power
cord from the power outlet to prevent damage to the CPU.
Step 1:
Completely raise the CPU socket lever.
Step 3:
Remove the protective socket cover from the
load plate. (To protect the CPU socket, always
replace the protective socket cover when the
CPU is not installed.)
Step 2:
Lift the metal load plate from the CPU socket.
(DO NOT touch socket contacts.)
Step 4:
Hold the CPU with your thumb and index
fingers. Align the CPU pin one marking (triangle)
with the pin one corner of the CPU socket (or
you may align the CPU notches with the socket
alignment keys) and gently insert the CPU
into position.
CPU Socket Lever

Hardware Installation- 15 -
1-3-2 Installing the CPU Cooler
Follow the steps below to correctly install the CPU cooler on the motherboard. (The following procedure
uses Intel®boxed cooler as the example cooler.)
Step 1:
Apply an even and thin layer of thermal grease
on the surface of the installed CPU.
Step 2:
Before installing the cooler, note the direction
of the arrow sign on the male push pin.
(Turning the push pin along the direction of
arrow is to remove the cooler, on the contrary,
is to install.)
Male
Push Pin
Female
Push Pin
The Top
of Female
Push Pin
Direction of
the Arrow Sign
on the Male
Push Pin
Step 3:
Place the cooler atop the CPU, aligning the
four push pins through the pin holes on the
motherboard. Push down on the push pins
diagonally.
Step 4:
You should hear a "click" when pushing down each
pushpin. Checkthatthe Male andFemale push pins
are joined closely. (Refer to your CPU cooler instal-
lation manual for instructions on installing the cooler.)
Use extreme care when removing the CPU cooler because the thermal grease/tape between
the CPU cooler and CPU may adhere to the CPU. Inadequately removing the CPU cooler may
damage the CPU.
Step 5:
After the installation, check the back of the
motherboard. If the push pin is inserted as the
picture above, the installation is complete.
Step 6:
Finally, attach the power connector of the CPU
cooler to the CPU fan header (CPU_FAN) on
the motherboard.

GA-EP45-UD3P Motherboard - 16 -
1-4 Installing the Memory
Read the following guidelines before you begin to install the memory:
•Make sure that the motherboard supports the memory. It is recommended that memory of
the same capacity, brand, speed, and chips be used.
(Go to GIGABYTE's website for the latest memory support list.)
•Always turn off the computer and unplug the power cord from the power outlet before
installing the memory to prevent hardware damage.
•Memory modules have a foolproof design. A memory module can be installed in only one
direction. If you are unable to insert the memory, switch the direction.
Due to chipset limitation, read the following guidelines before installing the memory in Dual Channel mode.
1. Dual Channel mode cannot be enabled if only one DDR2 memory module is installed.
2. When enabling Dual Channel mode with two or four memory modules, it is recommended that
memory of the same capacity, brand, speed, and chips be used and installed in the same
colored DDR2 sockets for optimum performance.
When memory modules of different capacity and chips are installed, a message which says
memory is operating in Flex Memory Mode will appear during the POST. Intel®Flex Memory
Technology offers greater flexibility to upgrade by allowing different memory sizes to be
populated and remain in Dual Channel mode/performance.
Two Modules
Four Modules
DDR2_1 DDR2_2 DDR2_3 DDR2_4
DS/SS - - DS/SS - -
- - DS/SS - - DS/SS
DS/SS DS/SS DS/SS DS/SS
DualChannelMemoryConfigurationsTable
(SS=Single-Sided, DS=Double-Sided, "- -"=No Memory)
1-4-1 Dual Channel Memory Configuration
This motherboard provides four DDR2 memory sockets and supports Dual Channel
Technology. After the memory is installed, the BIOS will automatically detect the
specifications and capacity of the memory. Enabling Dual Channel memory mode
will double the original memory bandwidth.
The four DDR2 memory sockets are divided into two channels and each channel has two memory
sockets as following:
Channel 0: DDR2_1, DDR2_2
Channel 1: DDR2_3, DDR2_4
DDR2_1 DDR2_2 DDR2_3 DDR2_4

Hardware Installation- 17 -
1-4-2 Installing a Memory
Notch
Before installing a memory module , make sure to turn off the computer and unplug
the power cord from the power outlet to prevent damage to the memory module.
DDR2 DIMMs are not compatible to DDR DIMMs. Be sure to install DDR2 DIMMs on
this motherboard.
DDR2 DIMM
Step 1:
Note the orientation of the memory module. Spread the retaining
clips at both ends of the memory socket. Place the memory
module on the socket. As indicated in the picture on the left,
place your fingers on the top edge of the memory, push down
on the memory and insert it vertically into the memory socket.
Step 2:
The clips at both ends of the socket will snap into place when
the memory module is securely inserted.
A DDR2 memory module has a notch, so it can only fit in one direction. Follow the steps below to
correctly install your memory modules in the memory sockets.

GA-EP45-UD3P Motherboard - 18 -
1-5 Installing an Expansion Card
Read the following guidelines before you begin to install an expansion card:
•Make sure the motherboard supports the expansion card. Carefully read the manual that
came with your expansion card.
•Always turn off the computer and unplug the power cord from the power outlet before
installing an expansion card to prevent hardware damage.
Follow the steps below to correctly install your expansion card in the expansion slot.
1. Locate an expansion slot that supports your card. Remove the metal slot cover from the chassis back panel.
2. Align the card with the slot, and press down on the card until it is fully seated in the slot.
3. Make sure the metal contacts on the card are completely inserted into the slot.
4. Secure the card's metal bracket to the chassis back panel with a screw.
5. After installing all expansion cards, replace the chassis cover(s).
6. Turn on your computer. If necessary, go to BIOS Setup to make any required BIOS changes for
your expansion card(s).
7. Install the driver provided with the expansion card in your operating system.
Example: Installing and Removing a PCI Express Graphics Card:
•Installing a Graphics Card:
Gently push down on the top edge of the card
until it is fully inserted into the PCI Express slot.
Make sure the card is securely seated in the
slot and does not rock.
•Removing the Card from
the PCIEX16_1 slot:
Gently push back on
the lever on the slot
and then lift the card
straight out from the slot.
PCI Slot
•Removing the Card
from the PCIEX8_1 slot:
Press the white latch at
the end of the PCI Ex-
press slot to release the
card and then pull the
card straight up from the
slot.
PCI Express x1 Slot
PCI Express x16 Slot
PCI Express x16 Slot

Hardware Installation- 19 -
1-6 Installing the SATABracket
The SATA bracket includes one SATA bracket, one
SATA signal cable, and one SATA power cable.
Step 1:
Locate one free PCI
slot and secure the
SATA bracket to the
chassis back panel
with a screw.
Follow the steps below to install the SATA bracket:
Step 2:
Connect the SATA
cablefrom the bracket
to the SATA port on
your motherboard.
Step 3:
Connect the power
cablefrom the bracket
to the power supply.
Step 4:
Plug one end of the
SATA signal cable into
the external SATAcon-
nector on the bracket.
Then attach the SATA
power cable to the
power connector on
the bracket.
The SATA bracket allows you to connect external SATA device(s) to your system by expanding the
internal SATA port(s) to the chassis back panel.
•Turn off your system and the power switch on the power supply before installing or
removing the SATA bracket and SATA power cable to prevent damage to hardware.
•Insert the SATA signal cable and SATA power cable securely into the corresponding connec-
tors when installing.
Step 5:
Connect the other ends of the SATA signal cable and SATA power cable
to your SATA device. For SATA device in external enclosure, you only
need to connect the SATAsignal cable. Before connecting the SATA signal
cable, make sure to turn off the power of the external enclosure.
SATABracket
External
SATA
Connector Power
Connector External SATA
Connector
SATA Signal Cable SATA Power Cable

GA-EP45-UD3P Motherboard - 20 -
•When removing the cable connected to a back panel connector, first remove the cable
from your device and then remove it from the motherboard.
•When removing the cable, pull it straight out from the connector. Do not rock it side to side
to prevent an electrical short inside the cable connector.
ActivityLED
Connection/
Speed LED
LAN Port
ActivityLED:
State Description
Blinking Data transmission or receiving is occurring
Off No data transmission or receiving is occurring
Connection/Speed LED:
State Description
Orange 1 Gbps data rate
Green 100 Mbps data rate
Off 10 Mbps data rate
1-7 Back Panel Connectors
PS/2 Keyboard and PS/2 Mouse Port
Use the upper port (green) to connect a PS/2 mouse and the lower port (purple) to connect a PS/2
keyboard.
Optical S/PDIF Out Connector
This connector provides digital audio out to an external audio system that supports digital optical
audio. Before using this feature, ensure that your audio system provides an optical digital audio in
connector.
Coaxial S/PDIF Out Connector
This connector provides digital audio out to an external audio system that supports digital coaxial
audio. Before using this feature, ensure that your audio system provides a coaxial digital audio in
connector.
IEEE1394aPort
The IEEE 1394 port supports the IEEE 1394a specification, featuring high speed, high bandwidth
and hotplug capabilities. Use this port for an IEEE 1394a device.
USB Port
The USB port supports the USB 2.0/1.1 specification. Use this port for USB devices such as an
USB keyboard/mouse, USB printer, USB flash drive and etc.
RJ-45 LAN Port
The Gigabit Ethernet LAN port provides Internet connection at up to 1 Gbps data rate. The following
describes the states of the LAN port LEDs.
