Gigabyte GA-SBCAP3350 User manual

Box Contents
5Thermal pad kit
5Two VESA mounting screws
5Four rubber pads
5導熱矽膠片- 1組
5VESA 安裝螺絲- 2顆
5機殼腳墊- 4個
5导热胶垫- 1組
5VESA 安装螺丝- 2颗
5机箱脚垫- 4个
5써멀 패드 키트 1개
5VESA 장착 나사 2 개
5고무패드 4개
5サーマルパッドキット (x1)
5VESA取り付けネジ (x4)
5ゴムパッド (x4)
SBC Chassis
Quick Installation Guide
Installation
u v w
x y z
{
To reduce the impacts on global warming, the packaging materials of
this product are recyclable and reusable. GIGABYTE works with you
to protect the environment.
12QM-SBQUICK-101AR
SO-DIMM
SO-DIMM Thermal Pad
mSATA or Mini-PCIe Thermal Pad
mSATA or Mini-PCIe

VESA Mounting Instructions
v
u
