Gigabyte Z490 VISION D User manual

Z490 VISION D
User's Manual
Rev. 1001
12ME-Z49VSD-1001R
For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product are
recyclable and reusable. GIGABYTE works with you to protect the environment.

Copyright
©2020 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the specications and features in this manual may be made by GIGABYTE
without prior notice.
No part of this manual may be reproduced, copied, translated, transmitted, or published in
any form or by any means without GIGABYTE's prior written permission.
Documentation Classications
In order to assist in the use of this product, GIGABYTE provides the following types of docu-
mentations:
For quick set-up of the product, read the Quick Installation Guide included with the product.
For detailed product information, carefully read the User's Manual.
For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV:
1.0" means the revision of the motherboard is 1.0. Check your motherboard revision before
updating motherboard BIOS, drivers, or when looking for technical information.
Example:

- 3 -
Table of Contents
Box Contents...................................................................................................................5
Optional Items .................................................................................................................5
Z490 VISION D Motherboard Layout..............................................................................6
Z490 VISION D Motherboard Block Diagram.................................................................7
Chapter 1 Hardware Installation .....................................................................................9
1-1 Installation Precautions ................................................................................... 9
1-2 ProductSpecications................................................................................... 10
1-3 Installing the CPU and CPU Cooler............................................................... 14
1-3-1 Installing the CPU ..................................................................................................14
1-3-2 Installing the CPU Cooler ......................................................................................16
1-4 Installing the Memory .................................................................................... 17
1-4-1 DualChannelMemoryConguration....................................................................17
1-4-2 Installing a Memory................................................................................................18
1-5 Installing an Expansion Card......................................................................... 19
1-6 Setting up AMD CrossFire™/NVIDIA®SLI™Conguration ............................ 20
1-7 Back Panel Connectors................................................................................. 21
1-8 Internal Connectors ....................................................................................... 24
Chapter 2 BIOS Setup ..................................................................................................39
2-1 Startup Screen............................................................................................... 40
2-2 The Main Menu.............................................................................................. 41
2-3 Favorites (F11) ............................................................................................... 43
2-4 Tweaker.......................................................................................................... 44
2-5 Settings.......................................................................................................... 50
2-6 System Info. ................................................................................................... 58
2-7 Boot................................................................................................................ 59
2-8 Save & Exit .................................................................................................... 62
Chapter3 ConguringaRAIDSet ...............................................................................63
3-1 ConguringSATAControllers........................................................................ 63
3-2 InstallingtheRAID/AHCIDriverandOperatingSystem ............................... 77
3-3 Installing an Intel®Optane™Memory ............................................................. 80

- 4 -
Chapter 4 Drivers Installation .......................................................................................83
4-1 Drivers & Software......................................................................................... 83
4-2 Application Software...................................................................................... 84
4-3 Information..................................................................................................... 84
Chapter 5 Unique Features...........................................................................................85
5-1 BIOS Update Utilities..................................................................................... 85
5-1-1 Updating the BIOS with the Q-Flash Utility.......................................................... 85
5-1-2 Updating the BIOS with the @BIOS Utility........................................................... 88
5-1-3 Using Q-Flash Plus............................................................................................... 89
5-2 APP Center.................................................................................................... 90
5-2-1 EasyTune ................................................................................................................91
5-2-2 Fast Boot ................................................................................................................92
5-2-3 Game Boost ...........................................................................................................93
5-2-4 RGBFusion........................................................................................................... 94
5-2-5 Smart Backup ....................................................................................................... 96
5-2-6 System Information Viewer................................................................................... 98
5-2-7 USB DAC-UP 2..................................................................................................... 99
Chapter 6 Appendix....................................................................................................101
6-1 ConguringAudioInputandOutput............................................................ 101
6-1-1 Conguring2/4/5.1/7.1-ChannelAudio................................................................101
6-1-2 ConguringS/PDIFOut.......................................................................................104
6-1-3 Stereo Mix ............................................................................................................105
6-1-4 UsingtheVoiceRecorder................................................................................... 106
6-1-5 DTS:X®Ultra.........................................................................................................107
6-2 Troubleshooting ........................................................................................... 109
6-2-1 Frequently Asked Questions ...............................................................................109
6-2-2 Troubleshooting Procedure .................................................................................110
6-3 Debug LED Codes........................................................................................112
RegulatoryNotices ..................................................................................................116
Contact Us ...............................................................................................................119

- 5 -
Box Contents
5Z490 VISION D motherboard
5Motherboard driver disc
5User's Manual
5Quick Installation Guide
5Four SATA cables
5One antenna
5One G Connector
5Two thermistor cables
5OneRGBLEDstripextensioncable
Optional Items
2-portUSB2.0bracket(PartNo.12CR1-1UB030-6*R)
eSATAbracket(PartNo.12CF1-3SATPW-4*R)
3.5"FrontPanelwith2USB3.2Gen1ports(PartNo.12CR1-FPX582-2*R)
The box contents above are for reference only and the actual items shall depend on the product package you
obtain. The box contents are subject to change without notice.

- 6 -
Z490 VISION D Motherboard Layout
(Note) For debug code information, please refer to Chapter 6.
DP_HDMI
LGA1200
ATX
AUDIO
DDR4_A1 DDR4_A2 DDR4_B1 DDR4_B2
BAT
Intel®Z490
CLR_CMOS
M_BIOS
Intel®GbE LAN
CODEC
PCIEX16
PCIEX8
PCIEX4
F_U32C
F_U32
SYS_FAN6_PUMP
DB_PORT (Note)
EC_TEMP2
EC_TEMP1
SYS_FAN1
80110
M2A_CPU
80110
M2M_SB
60
80110
Z490 VISION D
QFLASH_PLUSF_USB2F_PANEL
D_LED1
F_AUDIO
SPI TPM F_USB1
LED_C1
SYS_FAN5_
PUMP
SYS_FAN3
CPU_FAN
CPU_OPT
SYS_FAN 4
iTE®
Super I/O
D_LED2
LED_C2
ATX_12V_2X4ATX_12V_2X2
SATA3 351
240
CPU DRAM
VGA BOOT
USB20
TYPEC_1
U32G2_2
U32_LAN1
U32_LAN2
SYS_FAN2
PEG
PCIEX1_1
TYPEC_2
U32G2_1
CNVI
M2P_SB
Intel®2.5GbE LAN
USB 3.2 Gen 1 Hub
Intel®
Thunderbolt™ 3
Controller
USB 2.0 Hub
QFLED

- 7 -
Z490 VISION D Motherboard Block Diagram
LGA1200 CPU
CPU CLK+/- (100~500 MHz)
DDR4 3200/3000/2933/2666/2400/2133 MHz
PCI Express 3.0 Bus
DMI 3.0
LAN1
RJ45
Intel®
2.5GbE LAN
LPC
Bus
Center/Subwoofer
Speaker Out
Line Out
MIC
Line In
S/PDIF Out
Rear Speaker Out
CODEC
iTE®
Super I/O
4 USB 2.0/1.1
2 USB 3.2 Gen 1
1 USB Type-C™,
USB 3.2 Gen 2
2 USB 3.2 Gen 2
Type A
Intel®Z490
x1
USB 2.0
Hub
x16
1 PCI Express
x16
x8
2 PCI Express
x8
Switch
or
1 DisplayPort IN
LAN2
RJ45
Intel®
GbE LAN
x1
PCI Express 3.0 Bus
Intel®Thunderbolt™3
Controller
or
2 Intel®Thunderbolt™3 2 USB Type-C™,
with USB 3.2 Gen 2
support
1 M.2 Socket 3 (M2A_CPU)
Switch 2 SATA 6Gb/s
(SATA3 0, 1)
Switch 2 SATA 6Gb/s
(SATA3 4, 5)
1 M.2 Socket 3 (M2M_SB)
2 USB 2.0/1.1
2 SATA 6Gb/s (SATA3 2, 3)
PCI Express 3.0 Bus
1 PCI
Express x1
DDI HDMI 1.4
SPI
Bus
BIOS
TPM
x4 x1
1 PCI
Express x4
M.2 CNVi
WIFI
1 M.2 Socket 3 (M2P_SB)
4 USB 3.2 Gen 1
USB 3.2
Gen 1 Hub

- 8 -

- 9 -
Hardware Installation
1-1 Installation Precautions
The motherboard contains numerous delicate electronic circuits and components which can become
damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read the user's
manual and follow these procedures:
•Prior to installation, make sure the chassis is suitable for the motherboard.
•Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or
warranty sticker provided by your dealer. These stickers are required for warranty validation.
•Always remove the AC power by unplugging the power cord from the power outlet before
installing or removing the motherboard or other hardware components.
•When connecting hardware components to the internal connectors on the motherboard, make
sure they are connected tightly and securely.
•When handling the motherboard, avoid touching any metal leads or connectors.
•It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic
components such as a motherboard, CPU or memory. If you do not have an ESD wrist strap,
keepyourhandsdryandrsttouchametalobjecttoeliminatestaticelectricity.
•Prior to installing the motherboard, please have it on top of an antistatic pad or within an
electrostatic shielding container.
•Before connecting or unplugging the power supply cable from the motherboard, make sure
the power supply has been turned off.
•Before turning on the power, make sure the power supply voltage has been set according to
the local voltage standard.
•Before using the product, please verify that all cables and power connectors of your hardware
components are connected.
•To prevent damage to the motherboard, do not allow screws to come in contact with the
motherboard circuit or its components.
•Make sure there are no leftover screws or metal components placed on the motherboard or
within the computer casing.
•Do not place the computer system on an uneven surface.
•Do not place the computer system in a high-temperature or wet environment.
•Turning on the computer power during the installation process can lead to damage to system
components as well as physical harm to the user.
•If you are uncertain about any installation steps or have a problem related to the use of the
product,pleaseconsultacertiedcomputertechnician.
•If you use an adapter, extension power cable, or power strip, ensure to consult with its installation
and/or grounding instructions.
Chapter 1 Hardware Installation

- 10 -
Hardware Installation
1-2 ProductSpecications
CPU Support for 10th Generation Intel®Core™i9 processors/Intel®Core™i7
processors/Intel®Core™i5 processors/Intel®Core™i3 processors/Intel®
Pentium®processors/Intel®Celeron®processors in the LGA1200 package
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel®Z490 Express Chipset
Memory Intel®Core™i9/i7 processors:
- Support for DDR4 3200/3000/2933/2666/2400/2133 MHz
Intel®Core™i5/i3/Pentium®/Celeron®processors:
- Support for DDR4 2666/2400/2133 MHz
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor+Intel®Thunderbolt™3 Controller:
- 2 x Intel®Thunderbolt™3 connectors (USB Type-C™ports), supporting
DisplayPort and Thunderbolt™video outputs and a maximum resolution of
5120 x 2880@60 Hz with 24 bpp
* Because of the limited I/O resources of the PC architecture, the number of Thunderbolt™
devices that can be used is dependent on the number of the PCI Express devices being
installed. (Refer to Chapter 1-7, "Back Panel Connectors," for more information.)
* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
Integrated Graphics Processor-Intel®HD Graphics support:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.3.
Maximum shared memory of 512 MB
Audio Realtek®ALC1220-VB codec
* The back panel line out jack supports DSD audio.
Support for DTS:X®Ultra
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN 1 x Intel®2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)(LAN1)
1 x Intel®GbE LAN chip (1 Gbit/100 Mbit) (LAN2)
Wireless
Communication
Module
Intel®Wi-Fi 6 AX201
- WIFI a, b, g, n, ac with wave 2 features, ax, supporting 2.4/5 GHz Dual-Band
- BLUETOOTH 5.1
- Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.

- 11 -
Hardware Installation
Expansion Slots 1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is
populated, the PCIEX16 slot operates at up to x8 mode.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
* The PCIEX4 slot shares bandwidth with the M2P_SB connector. The PCIEX4 slot
operates at up to x2 mode when a PCIe SSD is installed in the M2P_SB connector.
1 x PCI Express x1 slot
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
1 x M.2 Socket 1 connector for an Intel®CNVi wireless module (CNVI)
Multi-Graphics
Technology
Support for NVIDIA®Quad-GPU SLI™and 2-Way NVIDIA®SLI™technologies
Support forAMD Quad-GPU CrossFire™and 2-Way AMD CrossFire™technologies
Storage Interface 1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe x4/x2
SSD support) (M2A_CPU)
1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe x4/x2
SSD support) (M2M_SB)
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe x4/x2 SSD
support) (M2P_SB)
6 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10
* Refer to "1-8 Internal Connectors," for the installation notices for the PCIEX4, M.2,
SATA connectors.
Intel®Optane™Memory Ready
USB Chipset+Intel®Thunderbolt™3 Controller:
- 2 x USB Type-C™ports on the back panel, with USB 3.2 Gen 2 support
Chipset:
- 1 x USB Type-C™port with USB 3.2 Gen 2 support, available through the
internal USB header
- 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
- 2 x USB 2.0/1.1 ports on the back panel
Chipset+USB 3.2 Gen 1 Hub:
- 4 x USB 3.2 Gen 1 ports on the back panel
Chipset+USB 2.0 Hub:
- 4 x USB 2.0/1.1 ports available through the internal USB headers
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin ATX 12V power connector
1 x PEG power connector
1 x CPU fan header
1 x water cooling CPU fan header
4 x system fan headers
2 x system fan/water cooling pump headers
2 x addressable LED strip headers
2 x RGB LED strip headers
3 x M.2 Socket 3 connectors
6 x SATA 6Gb/s connectors
1 x front panel header

- 12 -
Hardware Installation
Internal
Connectors
1 x front panel audio header
1 x USB Type-C™header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI
2.0 module only)
2 x temperature sensor headers
1 x Clear CMOS jumper
1 x Q-Flash Plus button
Back Panel
Connectors
1 x DisplayPort In port
2 x Thunderbolt™3 connectors (USB Type-C™port, with USB 3.2 Gen 2 support)
1 x HDMI port
2 x SMA antenna connectors (2T2R)
2 x USB 3.2 Gen 2 Type-A ports (red)
4 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
2 x RJ-45 ports
1 x optical S/PDIF Out connector
5 x audio jacks
I/O Controller iTE®I/O Controller Chip
Hardware
Monitor
Voltage detection
Temperature detection
Fan speed detection
Water cooling ow rate detection
Overheating warning
Fan fail warning
Fan speed control
*Whether the fan (pump) speed control function is supported will depend on the fan
(pump) you install.
BIOS 1 x 256 Mbit ash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features Support for APP Center
*Available applications in APP Center may vary by motherboard model. Supported
functions of each application may also vary depending on motherboard specications.
- @BIOS
- EasyTune
- Fast Boot
- Game Boost
- ON/OFF Charge
- RGBFusion
- Smart Backup
- System Information Viewer
- USB DAC-UP 2

- 13 -
Hardware Installation
Please visit GIGABYTE's website
for support lists of CPU, memory
modules, SSDs, and M.2 devices.
Please visit the Support\Utility List
page on GIGABYTE's website to
download the latest version of apps.
Unique Features Support for Q-Flash Plus
Support for Q-Flash
Support for Xpress Install
Bundled
Software
Norton®Internet Security (OEM version)
cFosSpeed
Operating
System Support for Windows 10 64-bit
Form Factor ATX Form Factor; 30.5cm x 24.4cm
*GIGABYTE reserves the right to make any changes to the product specications and product-related information without
prior notice.

- 14 -
Hardware Installation
1-3 Installing the CPU and CPU Cooler
1-3-1 Installing the CPU
A. Locate the alignment keys on the motherboard CPU socket and the notches on the CPU.
Please visit GIGABYTE's website for details on hardware installation.
ReadthefollowingguidelinesbeforeyoubegintoinstalltheCPU:
•Make sure that the motherboard supports the CPU.
(Go to GIGABYTE's website for the latest CPU support list.)
•Always turn off the computer and unplug the power cord from the power outlet before installing the
CPU to prevent hardware damage.
•Locate the pin one of the CPU. The CPU cannot be inserted if oriented incorrectly. (Or you may
locate the notches on both sides of the CPU and alignment keys on the CPU socket.)
•Apply an even and thin layer of thermal grease on the surface of the CPU.
•Do not turn on the computer if the CPU cooler is not installed, otherwise overheating and damage
of the CPU may occur.
•SettheCPUhostfrequencyinaccordancewiththeCPUspecications.Itisnotrecommended
thatthesystembusfrequencybesetbeyondhardwarespecicationssinceitdoesnotmeetthe
standard requirements for the peripherals. If you wish to set the frequency beyond the standard
specications,pleasedosoaccordingtoyourhardwarespecicationsincludingtheCPU,graphics
card, memory, hard drive, etc.
Triangle Pin One Marking on the CPU
NotchNotch
LGA1200 CPU
Alignment
Key
Alignment
Key
LGA1200 CPU Socket
Pin One Corner of the CPU Socket

- 15 -
Hardware Installation
B. Follow the steps below to correctly install the CPU into the motherboard CPU socket.
•Before installing the CPU, make sure to turn off the computer and unplug the power cord from
the power outlet to prevent damage to the CPU.
•To protect the socket contacts, do not remove the protective plastic cover unless the CPU is
inserted into the CPU socket. Save the cover properly and replace it if the CPU is removed.
Step 1:
Gently press the CPU socket lever handle down
andawayfromthesocketwithyournger.Then
completely lift the CPU socket lever and the metal
load plate/plastic cover will be lifted as well.
Step 2:
HoldtheCPUwithyourthumbandindexngers.
Align the CPU pin one marking (triangle) with the
pin one corner of the CPU socket (or you may align
the CPU notches with the socket alignment keys)
and gently insert the CPU into position.
Step 4:
Finally, secure the lever under its retention tab to
complete the installation of the CPU.
NOTE:
Hold the CPU socket lever by the handle, not the lever base portion.
Step 3:
Once the CPU is properly inserted, carefully
replace the load plate. When replacing the load
plate, make sure the front end of the load plate
is under the shoulder screw. Then press the CPU
socket lever. The protective plastic cover may
pop off from the load plate during the process of
engagingthelever.Removethecover.(Savethe
cover properly and always replace it when the
CPU is not installed.)

- 16 -
Hardware Installation
1-3-2 Installing the CPU Cooler
RefertothestepsbelowtocorrectlyinstalltheCPUcooleronthemotherboard.(Actualinstallationprocessmay
differdependingtheCPUcoolertobeused.Refertotheuser'smanualforyourCPUcooler.)
Step 5:
After the installation, check the back of the
motherboard. If the push pin is inserted as the
picture above shows, the installation is complete.
Step 6:
Finally, attach the power connector of the CPU
cooler to the CPU fan header (CPU_FAN) on the
motherboard.
Step 1:
Apply an even and thin layer of thermal grease on
the surface of the installed CPU.
Step 2:
Before installing the cooler, note the direction of the
arrow sign on the male push pin. (Turning the
push pin along the direction of arrow is to remove
the cooler, on the contrary, is to install.)
Step 3:
Place the cooler atop the CPU, aligning the
four push pins through the pin holes on the
motherboard. Push down on the push pins
diagonally.
Step 4:
You should hear a "click" when pushing down each
push pin. Check that the Male and Female push
pins are joined closely.
(RefertoyourCPUcoolerinstallationmanualfor
instructions on installing the cooler.)
Male
Push Pin
Female
Push Pin
The Top
of Female
Push Pin
Direction of
the Arrow Sign
on the Male
Push Pin

- 17 -
Hardware Installation
1-4 Installing the Memory
Readthefollowingguidelinesbeforeyoubegintoinstallthememory:
•Make sure that the motherboard supports the memory. It is recommended that memory of the same
capacity, brand, speed, and chips be used.
(Go to GIGABYTE's website for the latest supported memory speeds and memory modules.)
•Always turn off the computer and unplug the power cord from the power outlet before installing the
memory to prevent hardware damage.
•Memory modules have a foolproof design. Amemory module can be installed in only one direction.
If you are unable to insert the memory, switch the direction.
1-4-1 DualChannelMemoryConguration
This motherboard provides four memory sockets and supports Dual Channel Technology. After the memory
isinstalled,theBIOSwillautomaticallydetectthespecicationsandcapacityofthememory.EnablingDual
Channel memory mode will double the original memory bandwidth.
The four memory sockets are divided into two channels and each channel has two memory sockets as following:
ChannelA:DDR4_A1,DDR4_A2
ChannelB:DDR4_B1,DDR4_B2
Due to CPU limitations, read the following guidelines before installing the memory in Dual Channel mode.
1. Dual Channel mode cannot be enabled if only one memory module is installed.
2. When enabling Dual Channel mode with two or four memory modules, it is recommended that memory
of the same capacity, brand, speed, and chips be used.
DDR4_A1 DDR4_A2 DDR4_B1 DDR4_B2
RecommandedDualChannelMemoryConguration:
(SS=Single-Sided, DS=Double-Sided, "- -"=No Memory)
DDR4_A1 DDR4_A2 DDR4_B1 DDR4_B2
2 Modules - - DS/SS - - DS/SS
4 Modules DS/SS DS/SS DS/SS DS/SS

- 18 -
Hardware Installation
Notch
DDR4DIMM
ADDR4memorymodulehasanotch,soitcanonlytinonedirection.Followthestepsbelowtocorrectlyinstall
your memory modules in the memory sockets.
Step 1:
Note the orientation of the memory module. Spread the retaining clips
at both ends of the memory socket. Place the memory module on the
socket.Asindicatedinthepictureontheleft,placeyourngerson
the top edge of the memory, push down on the memory and insert it
vertically into the memory socket.
Step 2:
The clips at both ends of the socket will snap into place when the
memory module is securely inserted.
1-4-2 Installing a Memory
Before installing a memory module, make sure to turn off the computer and unplug the power cord
from the power outlet to prevent damage to the memory module. DDR4 and DDR3 DIMMs are not
compatible to each other or DDR2 DIMMs. Be sure to install DDR4 DIMMs on this motherboard.

- 19 -
Hardware Installation
1-5 Installing an Expansion Card
Readthefollowingguidelinesbeforeyoubegintoinstallanexpansioncard:
•Make sure the motherboard supports the expansion card. Carefully read the manual that came
with your expansion card.
•Always turn off the computer and unplug the power cord from the power outlet before installing an
expansion card to prevent hardware damage.
Follow the steps below to correctly install your expansion card in the expansion slot.
1. Locateanexpansionslotthatsupportsyourcard.Removethemetalslotcoverfromthechassisbackpanel.
2. Align the card with the slot, and press down on the card until it is fully seated in the slot.
3. Make sure the metal contacts on the card are completely inserted into the slot.
4. Secure the card's metal bracket to the chassis back panel with a screw.
5. After installing all expansion cards, replace the chassis cover(s).
6. Turn on your computer. If necessary, go to BIOS Setup to make any required BIOS changes for your
expansion card(s).
7. Install the driver provided with the expansion card in your operating system.
Example:InstallingandRemovingaPCIExpressGraphicsCard:
•Installing a Graphics Card:
Gently push down on the top edge of the card until
it is fully inserted into the PCI Express slot. Make
sure the card is securely seated in the slot and
does not rock.
•RemovingtheCard:
Gently push back on the lever on the slot and then lift the card straight out from
the slot.
PCI Express x1 Slot
PCI Express x16 Slot

- 20 -
Hardware Installation
B. Connecting the Graphics Cards
Step 1:
Observe the steps in "1-5 Installing an Expansion Card" and install the graphics cards on the PCIEX16 and
PCIEX8 slots.
Step 2:
Insert the CrossFire (Note 1)/SLI bridge connectors in the CrossFire/SLI gold edge connectors on top of the cards.
Step 3:
Plug the display cable into the graphics card on the PCIEX16 slot.
Procedure and driver screen for enabling CrossFire/SLI technology may differ by graphics cards and
driver version. Refer to the manual that came with your graphics cards for more information about
enabling CrossFire/SLI technology.
1-6 Setting up AMD CrossFire™/NVIDIA®SLI™ Conguration
(Note 1) The bridge connectors may be needed or not depending on your graphics cards.
(Note 2) When two graphics cards are installed, we recommend that you connect the power cable from the
power supply to the PEG connector to ensure system stability.
A. System Requirements
-Windows 10 64-bit operating system
-A CrossFire/SLI-supported motherboard with two PCI Express x16 slots and correct driver
-CrossFire/SLI-ready graphics cards of identical brand and chip and correct driver
-CrossFire (Note 1)/SLI bridge connectors
-A power supply with sufcient power is recommended (Note 2) (Refer to the manual of your graphics cards
for the power requirement)
C. Conguring the Graphics Card Driver
C-1. To Enable CrossFire Function
After installing the graphics card driver in the operating
system, go to the AMD RADEON SETTINGS screen.
Browse to Gaming\Global Settings and ensure AMD
CrossFire is set to On.
C-2. To Enable SLI Function
After installing the graphics card driver in the operating
system, go to the NVIDIA Control Panel. Browse to the
Congure SLI, Surround, PhysX screen and ensure
Maximize 3D performance is enabled.
