Gigabyte Booktop M1022 User manual

Copyright © 2009
All Right Reserved - Printed in China
Booktop M1022 User's Manual
Original Issue: 2009/3/27
This manual guides you in setting up and using your new Booktop PC. Information in the manual has been carefully checked for accu-
racy and is subject to change without notice.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mecha-
nical, photocopy, recording, or otherwise, without prior written consent.
Trademarks
Product names used herein are for identication purposes only and may be the trademarks of their respective companies.
Microsoft®, MS-DOS, Windows®, and Windows®Sound System are trademarks of Microsoft Corporation.
Intel®, Atom™ is registered trademarks of Intel Corporation.
Sound Blaster, Sound Blaster Pro are trademarks of Creative Technology.
All other brands or product names mentioned in this manual are trademarks or registered trademarks of their respective companies.

English
III
III
Safety Instructions
Use the following safety guidelines to help protect yourself and your
Booktop.
When Using Your Booktop M1022 Computer
CAUTION: Do not operate your portable computer for an
extended period of time with the base resting directly on
your body. With extended operation, heat can build up in the
base. Allowing sustained contact with the skin can cause
discomfort or a burn.
• Do not attempt to service the Booktop yourself. Always follow
installation instructions closely.
• Do not carry a battery in your pocket, purse, or other container
where metal objects (such as car keys) could short-circuit the
battery terminals. The resulting excessive current flow can generate
extremely high temperature and may cause burns to your skin.
• Be sure that nothing rests on your AC adapter's power cable and
that the cable is not located where it can be tripped over or stepped
on.
• While you are using the computer or charging the battery, place the
AC adapter in a ventilated area, like on a desktop or on the floor.
Do not cover the AC adapter with papers or other items that may
prevent ventilation. Also, do not use the AC adapter while it is inside
a carrying case.
• Do not insert objects into the air vent of your Booktop computer.
Doing so can cause short-circuiting and may result in fire or
electrical shock.
• Use only the AC adapter and batteries that are supplied by your
Booktop manufacturer. Using other types of battery or AC adapter
may heighten the risk of fire or explosion.
• Incorrectly placed batteries may result in an explosion.
• Replace only with the same or compatible battery recommended by
the manufacturer.
• Please discard used batteries according to the manufacturer's
instructions.
• Before you connect your Booktop to a power source, ensure that
the voltage rating of the AC adapter matches that of the available
power source.
- 115 V/60 Hz in most of North and South America and some Far
Eastern countries such as South Korea.
- 100 V/50 Hz in eastern Japan and 100 V/60Hz in western Japan.
- 230 V/50 Hz in most of Europe, the Middle East, and the Far East.
• If you use an extension cord with your AC adapter, ensure that the
total ampere rating of all devices plugged into the extension cord
does not exceed its total capacity.
• When removing battery from your Booktop, first turn off the system,
disconnect the AC adapter from the electrical outlet, and then
remove the battery.
• To avoid risk of an electrical shock, do not connect or disconnect
any cables, or perform maintenance or reconfiguration of this
product during a thunderstorm.
• Do not throw batteries into fire, doing so may cause explosion.
Check with local authorities first for battery disposal instructions.
• When setting up your Booktop for work, place it on a level surface.

III
English
Booktop M1022 USER’S MANUAL
III
• When traveling, do not check your Booktop as baggage. You can
put your Booktop through an X-ray security machine, but never put
your Booktop through a metal detector. If you have your Booktop
checked by hand, be sure to have a charged battery ready in case
you are asked to turn on your Booktop.
• When traveling with the hard drive removed from your Booktop,
wrap the drive in an insulated material, such as cloth or paper. If
you have the drive checked by hand, you may be asked to install
the drive into your Booktop. Your can have the hard drive checked
through an X-ray machine, but never put the drive through a metal
detector.
• When traveling, do not place your Booktop in the overhead storage
compartment where it could shift around. Do not drop your Booktop
or subject it to other mechanical shocks.
• Protect your Booktop, battery, and hard drive from environmental
hazards such as dirt, dust, food, liquids, extreme temperature, and
direct exposure to sunlight.
• When you move your Booktop in environments where there is a
substantial difference of temperature or humidity level, condensa-
tion may form on or within your Booktop. To avoid damaging your
Booktop, please allow sufficient time for the moisture to evaporate
before continue using.
NOTICE: When taking your Booktop from a colder to a warmer environ-
ment or vice versa, allow your Booktop enough time to adapt to the new
environment before turning on power.
• When unplugging the power cord, please make sure that you pull
on its connector or on its strain relief loop, and not on the power
cord itself. As you pull out the connector, please ensure that it is
pulled out evenly in order not to bend its connecting pins. Also, be-
fore you connect the power cord, make sure that both connectors
are correctly oriented and aligned.
• Before you clean your Booktop, turn it off first, unplug it from its
power source, and remove the battery.
• Handle interior components with care. When removing a compo-
nent, please hold it by the edge and not on the connecting pins
(such as the memory module).
When using your telephone equipments, safety instructions
should always be followed in order to prevent re, electrical
shock or injuries, these instructions include:
• Do not use this product near water, for example, near a bathtub,
washing basins, kitchen/laundry sinks, wet basements or swim-
ming pools.
• Avoid using cordless phones during an electrical storm as light-
ening may cause electrical shocks.
• Do not use the telephone to report a gas leak within the leakage
area.
WARNING: Void of Warranty
* If the battery is not properly handled, there may be a risk of ex-
plosion; make sure you are using the same or compatible battery.
* Please discard used batteries according to the instructions given
by the manufacturer.
* Please be aware that use of cracked, severely scratched or poor
quality discs may damage the optical drive and corrupt data in
the disc. Such discs may break while drive operates in high-
speed, in this case, your product warranty may be voided.

English
IVIII
IVIII
Regulatory Notices
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits
for a Class B digital service, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
Any changes or modications made to this equipment may void the
user’s authority to operate this equipment. This equipment gener-
ates, uses, and can radiate radio frequency energy. If not installed
and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television re-
ception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one
or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiv-
er.
● Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV technician for
help.
● All external cables connecting to this basic unit must be
shielded.
For cables connecting to PCMCIA cards, see the option
manual or installation instructions.
RF exposure
This equipment must be installed and operated in accordance with
provided instructions and must not be co-located or operating in con-
junction with any other antenna or transmitter. End-users and install-
ers must be provide with antenna installation instructions and trans-
mitter operating conditions for satisfying RF exposure compliance.
SAR Value: 0.112 W/kg

IVIII
English
Booktop M1022 USER’S MANUAL
IVIII
CE Notice (European Union)
This symbol indicates this Booktop M1022 computer complies
with the EMC Directive and the European Union’s Low Voltage Di-
rective. This symbol also indicates that M1022 meets the following
technical standards:
• EN 55022 — “Limitations and Methods of Measurement for the
Radio Interferences of Information Technology Equipment.”
• EN 55024 — “Information technology equipment - Immunity char-
acteristics - Limits and methods of measurement.”
• EN 61000-3-2 — “Electromagnetic compatibility (EMC) - Chapter
3: Limits - Section 2: Limits on the harmonic current emissions
(Equipment input current up to and including 16 A per phase).”
• EN 61000-3-3 — “Electromagnetic compatibility (EMC) - Chapter
3: Limits - Section 3: Limits on the voltage uctuations and icker
in low-voltage power supply systems for equipment with rate cur-
rent up to and including 16 A.”
• EN 60950 — “Safety of Information Technology Equipment.”
NOTE: EN 55022 emissions requirements provide for two
classications
• Class A governs commercial use
• Class B is governs residential use
For CB:
• Only use batteries designed for this computer. The wrong battery
type may explode, leak or damage the computer
• Do not remove any batteries from the computer while it is pow-
ered on
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in re.
• Recharge the batteries using the notebook’s system. Incorrect
recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair
or replacement to your service representative or qualied service
personnel.
• Keep children away from, and promptly dispose of a damaged
battery. Always dispose of batteries carefully. Batteries may ex-
plode or leak if exposed to re, or improperly handled or discard-
ed.
• Keep the battery away from metal appliances.
• Afx tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal ob-
jects.
Battery Disposal & Caution
The product that you have purchased contains a rechargeable bat-
tery. The battery is recyclable. At the end of its useful life, under
various state and local laws. It may be illegal to dispose of this bat-
tery into the municipal waste stream. Check with your local solid
waste officials for details in your area for recycling options or proper
disposal.

English
VIV
VIV
Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the manufac-
turer. Discard used battery according to the manufacturer’s instruc-
tions.
BSMI Notice (Taiwan Only)
Most Booktop computers are classied by the Bureau of Standards,
Meteorology and Inspection (BSMI) as Class B information technol-
ogy equipment (ITE).
The symbol above must be attached to the product indicating
compliance with the BSMI standard.

VIV
English
Booktop M1022 USER’S MANUAL
VIV

English
VIIIVII
VIIIVII
Preface
Congratulations on your purchase of a Booktop computer! Your
new Booktop features the most innovative features in portable
computing technology. It combines state-of-the-art ergonomics with
sophisticated architecture, providing you with a personal computer
that is compact, powerful, and easy to use. Designed for a wide
range of general, business, and personal productivity applications,
this Booktop is an ideal choice for use in the ofce, at home, and
on the road.
This Manual contains all the information you need to set up and
use your Booktop computer. It describes all of its features in a
thorough yet easy-to-read manner.

VIIIVII
English
Booktop M1022 USER’S MANUAL
VIIIVII
Content
Safety Instructions.............................................................................I
Regulatory Notices ..........................................................................III
Preface ...........................................................................................VII
Chapter 1 Introducing Your Booktop M1022
1.1 Panoramic View....................................................................... 2
1.2 M1022 Left Side ......................................................................3
1.3 Right Side ................................................................................ 3
1.4 Cover Side...............................................................................4
1.5 Bottom Side ............................................................................. 4
1.6 Status Indicators......................................................................5
1.7 Turning Your Booktop M1022 On and Off ............................... 6
1.8 Keyboard Functions................................................................. 6
1.9 Using the Touchpad ................................................................8
1.10 Using the built-in camera.........................................................8
1.11 Using the Audio ....................................................................... 8
1.12 Using the Wireless LAN (WLAN).............................................9
1.13 Using the Battery Pack............................................................9
1.14 Connecting the AC Adapter...................................................10
1.15 Installing M1022 Device Drivers............................................11
1.16 Operating Temperature ......................................................... 11
Chapter 2 Battery
2.1 Battery Pack ..........................................................................14
2.2 Recharging The Battery Pack................................................ 14
2.3 Questions And Answers ........................................................14
2.4 Battery Maintenance.............................................................. 15
2.5 Power Consumption ..............................................................15
2.6 Reducing Power Consumption ..............................................15
2.7 Removing The Battery Pack..................................................16
Chapter 3 The Docking
3.1 The Docking Instruction.........................................................20
3.2 Docking Panoramic View....................................................... 20
3.3 Rear View ..............................................................................21
3.4 Mounting The System Unit ...................................................22
Chapter 4 The BIOS Setup program
4.1 Using the BIOS Setup Utility.................................................. 24
4.2 The Main Menu...................................................................... 25
4.3 Advanced Menu..................................................................... 26
4.4 Security Menu........................................................................ 27
4.5 Boot menu .............................................................................27
4.6 Exit Menu............................................................................... 28
Chapter 5 Introduction to Smart Manager
Chapter 6 Troubleshooting / Q&A
6.1 Troubleshooting.....................................................................33
6.2 Q&A .......................................................................................36
Appendix I Specication
Appendix II Recovery Update Notices
Appendix III Service Centers

English
Booktop M1022 USER’S MANUAL
1PB
Chapter 1 Introducing Your
Booktop M1022
This chapter will show you how to operate your M1022 SERIES
Booktop M1022 computer, including connecting the AC adaptor,
turning the computer on/off, using touch-pad, keyboard, hot
keys, battery, and so on. If you are new to computers and to the
operating system, this chapter will guide you through some of the
new exciting features.

English
32
32
1.1 Panoramic View
2
11
1
6
34
5
10
789
No. Item Function
1Web camera Built-in 1.3M camera.
2LCD To display the content output form
the system.
3Speakers The built-in dual speakers output
stereo sound
4Power Button Turn the computer on and off, or
resumes whenever it is in suspend
mode.
5Six system LED
indicators
Six LED lights show the status of the
Booktop.
From left to right :
à3.5G Status àBluetooth signal
àWLAN signal àHDD signal à
Battery signal àPower on signal
6Touch Pad Use it to move the pointer, select and
activate items on the screen.
7Internal Mic Built-in Internal Mic
8Mic Jack To connect MIC to input audio signal.
9Line out To connect equipment to output
sound.
10 Keyboard To input characters and numbers
into your computer.
11 Battery Pack Installed in the battery compartment,
to supply power to Booktop M1022
when AC power is disconnected.

32
English
Booktop M1022 USER’S MANUAL
32
1.2 M1022 Left Side
1 2 3 4 5
No. Item Function
1Kensington Lock Connects a Kensington-compatible
security lock.
2D-SUB To connect external monitor.
3Air Vent To vent heat from Booktop M1022.
4Docking
Connector To connect the Docking.
5Docking Guider To x the Docking.
1.3 Right Side
No. Item Function
1Media Card Slot Media Card Reader.
2Express Card Slot To connect an Express Card.
3USB Port To connect USB Devices.
4LAN RJ45 Jack To connect LAN..
5DC-in Jack To connect AC adapter to power on
Booktop M1022.
1
2 3 4 5

English
54
54
1.4 Cover Side
1
No. Item Function
1Cover To Protect the Booktop M1022.
1.5 Bottom Side
No. Item Function
1Battery Pack Replaceable battery that serves as
Booktop M1022 power supply.
2Memory Door To upgrade the DDRII-Memory So-
Dimm.
3HDD Door To upgrade the SATA HDD.
1
3
2

54
English
Booktop M1022 USER’S MANUAL
54
1.6 Status Indicators
Icon Item Function
3.5G WWAN on/off status.
Bluetooth Bluetooth on/off status.
WLAN Status Wireless on/off status.
HDD Booktop M1022 is reading from, or
writing to hard disk.
Battery status
Blue off
Recharging is nished
or Booktop M1022 is not
powered by AC adapter.
Blue on Battery is in recharging.
Power status
Blue off System is turned off or in
hibernation mode.
Blue
ashing
System is in Standby
mode.
Blue on System is in operating.

English
76
76
1.7 Turning Your Booktop M1022 On and Off
Turning on the power
Open the Booktop M1022 lid, press the power button for one or two
seconds. The power indicator will glow blue once the computer is
powered on.
Turning off the power
If you are not going to use your Booktop M1022 computer for a
while, it is best to turn off its power. Before turning off power, close
all program rst and shut down the operating system.
After turning off your Booktop M1022 computer, make it a habit to
leave the LCD panel open for a while after it has been used for an
extended period of time. This allows the interior of your Booktop
M1022 computer to cool off. Closing the panel will force the heat up
against the LCD screen, and doing so after a while may damage
the screen. More importantly, never close the LCD panel for a long
period of time when the computer is on or when the power saving
function is disabled.
1.8 Keyboard Functions
Booktop M1022 computer is equipped with a standard typewriter-
layout keyboard and has extra features.
Icon Description
Caps Lock Press Caps Lock to set all the characters as
capital letters.
Num Lk To turn on the numeric keypad overlay, press
Num Lk.
Fn+Scrl Lk Press this key to scroll the screen under some
programs.
Press this key to activate Windows®START
menu.
Press this key to function as the right key of
mouse.

76
English
Booktop M1022 USER’S MANUAL
76
Fn Combination Keys (Hot Keys)
Use FnFn key combined with other keys to activate, close or set
special functions. These combinations are also called Hot Keys. To
use the Hot Keys, press and hold down <Fn> together with the keys
described below:
Icon Description
Fn+F1 Hibernation
Press this key combination to make system enter
hibernation mode.
In this mode, the back light of the LCD panel would be
turned off and a host of internal devices would enter
into a stage of lower power consumption.
Fn+F2 Wireless LAN
To activate Wireless LAN.
Fn+F3 Brightness decreasing
Press this key combination to decrease the brightness
of the LCD.
Fn+F4 Brightness increasing
Press this key combination to increase the brightness
of the LCD.
Fn+F5 LCD / Video-out Switch
Press this key combination to switch between：
LCD mode only;
Video-out mode only;
LCD and Video-out simultaneously mode
Notice：This function works under certain setting of
OS, please refer to your instruction of OS.
Fn+F6 Touch Pad Enable/Disable
Press this key combination to enable/disable Touch
Pad function.
Fn+F7 Mute
Press this combination to open/close output of audio
signal.
Fn+F8 Voice weakening
Press this key combination to weaken the voice
output.
Notice: This function works under certain setting of
OS, please refer to your instruction of OS.
Fn+F9 Voice strengthening
Press this key combination to strengthen the voice
output.
Notice: This function works under certain setting of
OS, please refer to your instruction of OS.
Fn+F10 3.5G
To activate 3.5G (Optional function)
Fn+F11 Bluetooth
To activate Bluetooth.

English
98
98
1.9 Using the Touchpad
The built-in touch pad is a PS/2-compatible pointing devise that
senses movement on its surface. This means that cursor responds
as you move your nger on the surface of the touchpad. The central
location on the palm rest provides optimum comfort and support.
The following teaches you how to use the touch pad:
Move your nger across the touch pad to move the cursor.
Press the left and right buttons located on the edge of the
touch pad to do selection and execution functions. These two
buttons are similar to the left and right buttons on a mouse.
Tapping on the touch pad produces similar results.
1.10 Using the built-in camera
The availability of the function depend on the configuration of
Booktop M1022 you bought. The model you bought may be
equipped with a built-in camera, and the built-in camera adds
video functionality to instant messaging software and video editing
software.
•••••••••••••••••••••••
Tips: For using the built-in camera, see the help le on the
utility software.
•••••••••••••••••••••••
Tips: The built-in camera cannot be shared by more than
on software application. If another application is using
the camera, exit the application before using the built-in
camera.



1.11 Using the Audio
You can Control volume under your Windows operation system:
Click the volume icon on task bar and use the button to adjust
volume.
Or you can double click the volume icon to activate Volume
Control to adjust control items of volume.
•••••••••••••••••••••••
Tips: You can use Fn combination keys to adjust volume.
Please refer to “FN combination keys”.
Please adjust the voice down before your connect an
external audio equipment, such as earphone or MIC.

98
English
Booktop M1022 USER’S MANUAL
98
1.12 Using the Wireless LAN (WLAN)
You can use Wireless LAN to connect to the network and use the
Internet in your home and ofce, so there is no need anymore to
pull cables or wires.
Connecting and using the wireless network
You can use the Function key (1.8 Using the Launch Keys) or Fn
combination keys (1.8 Keyboard Function) to turn on WLAN.
Right-click the Wireless network icon on the Taskbar and select View
available wireless network.
Select AP (Access Point) you want to connect to and type necessary
information. Click Connect. And If you place the mouse pointer on
the Wireless network icon on the Taskbar, you can see the status of
the wireless network.
•••••••••••••••••••••••
Tips: You can learn details by referring to instruction
document of wireless network.
•••••••••••••••••••••••
The availability of the functions depend on the conguration
of Booktop M1022 you bought, see the Spec to see whether
your model supports the function.
•••••••••••••••••••••••
Notice: Creating security settings for the wireless LAN is
important, we assume no responsibility for any security
problems that may arise from the use of the wireless LAN.
1.13 Using the Battery Pack
Booktop M1022 computer is designed to operate with one of the
following power sources:
AC power (using the AC adapter connected to an electrical
outlet)
Lithium-Ion (Li-Ion) battery pack
You should use the AC adapter whenever possible; use the battery
pack only when AC power is unavailable. The rechargeable Li-Ion
battery pack allows you to operate your Booktop M1022 computer
without an external power source. When you use the AC adapter to
connect your Booktop M1022 to a power outlet, the internal battery
will begin to recharge. While the battery is charging, the Battery
Charge icon on the indicator panel will be on. Once the battery is
fully charged, the Battery Charge icon will turn off. Quick charging
time is 2.5 hours for the Lithium-Ion (Li-Ion) battery when the
computer is turned off, while the normal battery charging time is 3.5
hours.
Operating video, or audio equipment can increase the use of
your computer’s power.
Decreasing monitor brightness can also save power.
When the battery is not fully charged, allow your battery to be
charged completely before using it (i.e., before disconnecting
AC power). Calibrating the battery before use is also highly
recommended.
Li-Ion Battery is vulnerable; do not charge it with other power
adapter, otherwise re or explosion may occur.







English
1110
1110
Replacing the Battery
The battery will gradually weaken over time. We recommend that
you replace your battery when you notice a signicant decrease of
battery capacity.
To change the battery pack, follow the steps below:
1. Turn off the computer.
2. Close the lid and ip the computer over.
3. Slide the battery latch. Continue to hold it until the battery is
removed.
4. Make sure the replacement battery is properly oriented before
inserting it into the battery compartment.
Note: The battery can not be charged to 100% when remaining
battery is no less than 95%. It is based on the supplier’s advice, and
to extend charging frequency and battery life.
Maintenance of the AC Adapter
Do not connect the adapter to any other device.
Do not step on the power cord or place heavy objects on top of it.
Carefully route the power cord and keep cables away from all trafc.
When unplugging the power cord, do not pull on the cord itself but on
the plug instead.
If you are using an extension cord, make sure that the devices
plugged onto the cord do not exceed its total capacity. Furthermore,
the devices plugged into the electrical outlet shall not exceed the fuse’
s total ampere rating.
Please verify power voltage before connecting the electrical cord to
the power outlet. If you are uncertain of its power specication, please
consult with your local vendors or power company for more details.





1.14 Connecting the AC Adapter
The AC adapter converts AC power to DC power and reduces the
voltage supplied to the computer. It can automatically adjust to any
voltage from 100 to 240 volts and outputs power at 12V, (12V, 3.0A
for M1022), allowing you to use your Booktop M1022 computer in
almost any region.
CAUTION: Use only the AC adapter and the power cord we
recommend. Using the wrong adapter may damage your computer.
We assume no responsibilities for damages arising from misuse of
AC adapters.
1
3
2
To properly connect the adapter, follow the steps as below:
1. Connect the power cord to the AC adapter.
2. Connect the AC adapter to the DC power port of your computer.
3. Connect the AC adapter power cord to an AC outlet.

1110
English
Booktop M1022 USER’S MANUAL
1110
1.15 Installing M1022 Device Drivers
If your Booktop M1022 Computer already has an operating system
installed, it is best to install all necessary device drivers in order for
he hardware to properly function.
Before installing drivers, check with your vendors to see if they have
already installed all the drivers with the operating system, if not,
please follow the steps below:
1. You can nd the Utility Driver CD like the one shown below:
2. Put the CD into the CD R-W or DVD-RW (optional) Drive. An
Auto Run installation screen will appear.
1.16 Operating Temperature
Operating Temperature : 10ºC to 40ºC
