GIGAMEDIA IMX Series User manual

IMX Series Camera User manual
GGM CCDEHDI3VUTC
Version 1

1
Thank you for purchasing the products of our company.
This user manual contains instructions for our SONY
IMX camera.
This products use chipset of SONY IMX with clear image
and steady quality.
Before using the new cameras , p l ease read this user
manual carefully.
PREFACE:

3
2
(1) Do not aim the camera at strong light this may cause
CMOS damage.
(2) Please do not touch CMOS sensor. If need cleaning,
use a soft cloth soak with rubbing alcohol to gently
wipe.
(3) Power supply refer to specification.
(4) The mounting of cameras should be firm,do not cause
any damage to persons and other articles as they are
dropping.
(5) The cameras should never be placed near or over a
radiator or heat register.
(6)Please handle with care to avoid strong shaking.
A-PRECAUTIONS:
(1)IR-Cut function
Ours day and night camera uses an IR-cut filter.
IR light is filtered out so that it does not distort the colors
of images as the human eye sees them. When the
camera is in night (black and white) mode,the IR-cut
filter is removed, allowing the camera's light sensitivity
to reach down to 0.001 lux or lower.
(2)Auto Electronic Shutter (AES)
AES can modify the SONY IMX exposure time
automatically. Stable brightness and excellent exposure
image will be captured no matter the light is strong or weak.
(3)Back Light Compensation (BLC)
A new development digital illumination intensity control
function. It adopts SONY IMX technology to solve the
shadow problem by modifying iris and gain.
B-FEATURES:
This camera uses SONY IMX as image capture device,
so it is very small and light,anti-shock. It is your best
choice for CCTV system.

45
BNC
VCR
1.Make sure the power supply is correct.
2.Connect the Video output into monitor. Make sure the
power supply is on, and then the image captured by
camera should appear on the monitor.
3.Do not aim the camera at eave or roof. It will cause
reflection and influence the image quality.
OPERATION PROCEDURE:
Connect one monitor with one Camera.
Connect one monitor with one or more cameras
SYSTEM CONNECTION :
DC12V Monitor Adapter
(not included)
Camera
Monitor
Multiplexer
monitor

67
CAMERA OPERATION :
This operation is suitable for Camera with OSD/UTC function.
UP: Moving the cursor upward to chose the item of the
setting menu
Down: Moving the cursor downward to chose the item of the
setting menu
LEFT: Moving the cursor leftward to chose the item of the
setting menu
RIGHT: Moving the cursor rightward to chose the item of the
setting menu
Press MENU to carry our the item or exit next menu
MENU:
SETTING:
MAIN MENU
IMAGE →
DAY&NIGHT EXTERNAL
ZONE MASKING →
MOTION DETECTION →
VIDEO STANDARD PAL
LANGUAGE ENGLISH
LOAD DEFAULT
SOFT VERSION
SAVE&EXIT
EXIT
3D-NR ON/OFF
AE MODE CENTER WEIG/BACK LIGHT/FRONT
LIGHT/DISTINGUISH/INTELLIGENT/
GLOBAL
WB AWB-TEMPORA/AWB-AI/AWB-CCT/
AWB-GW /AWB-PRO
IMAGE ENHANCE SHARPNESS →
CONTRAST →
SATURATION→
RETURN
MIRROR OFF/ON
FLIP OFF/ON
BRIGHTNESS
ZOOM IN
RETURN
SETTING STEP:
DAY&NIGHT EXTERNAL/COLOR/B&W/AUTO
2.DAY&NIGHT
COLOR MOSAIC/BLACK/BLUE/MAGENTAGYAN
/WHITE/YELLOW
AREA NO.1 →
AREA NO.2 →
AREA NO.3 →
AREA NO.4 →
AREA NO.5 →
AREA NO.6 →
AREA NO.7 →
AREA NO.8 →
RETURN
1.IMAGE
3. ZONE MASKING

4. MOTION DETECTION
SENSITIVITY HIGH/LOW/WEAK
AREA NO.1 →
AREA NO.2 →
AREA NO.3 →
AREA NO.4 →
RETURN
5. VIDEO STANDARD
VIDEO STANDARD PAL /NTSC
6. LANGUAGE
LANGUAGE ENGLISH/CHINESE
7. LOAD DEFAULT
LOAD DEFAULT
8. SOFT VERSION
9. SAVE&EXIT
10. EXIT
89
PAL/NTSC
0Lux(IR ON)
1.0Vp-p/75Ω
Auto
1/50(1/60)~1/100000sec
C/CS/M12
10-50m
DC12V±10%
-40℃--+60℃
≦85%
1/3"SONY IMX
2.8mm/3 .6m m/6mm /8m m/
12mm/16 mm
IP66
1280(H)×960(V)
Sensor
Effective Pixels
Signal System
Minimum Illumination
Video Output
AGC
IR Distance
Power Input
Working Temps
Lens Support
Electronic Shutter
Lens Mount
Working Humidity
Waterproof Rate
SPECIFICATION:

10
Please check the power connection.
Please check the videos signal lineconnection.
Please check and make sure that the auto lens
switch is set to DCV(VIDEO) when using a
VIDEO(DC) lens.
Troubleshooting
Nothing appears
on the screen
Problems
There is a problem
with the camera
operation. The ca-
mera surface is too
hot and black stripes
appear on the screen
The screen is dark
The video image
is not clear
The screen is
flickering
Please check if the lens is clean.
Please clean the lens with a clean clothor brush.
Please adjust the contrast feature of the monitor.
Please make sure the screen is not exposed
directly to a bright light.
Please move the camera if necessary.
Please adjust the contrast feature of the monitor
if you have intermediate device, set the 75/Hi-z
Properly,and check the terminals.
Please check if auto iris lens is being used and
adjust the brightness level.
Please check if an appropriate power source
to the camera complies with the manufacture's
standard requirement or if the voltage keep
changing.
Please check the camera facing directly into
sunlight or fluorescent light Please check if an
auto iris lens is being used.
Please check the connection of the lens
connector cables.
If there are problems in operation, please refer to the items as below.
If the problem persists, Please contact the agent you purchase this
product from.
TROUBLESHOOTING:
