GilletteLabs Fusion ProGlide User manual
WELCOME TO YOUR SMART RAZOR EXPERIENCE
QUICKSTART GUIDE
STEP 1 – SETUP YOUR SMART RAZOR
Plug your base station in to the mains and dock your handle to
charge.
STEP 2 – COMPLETE YOUR DIAGNOSTIC SHAVE
On your first shave, the razor will analyse your shave pressure and
will automatically put you into the right pressure alert mode for you.
STEP 3 – FOLLOW YOUR PERSONALISED LIVE
PRESSURE FEEDBACK WHENEVER YOU SHAVE
The razor will show a low intensity green light to show that it is
switched on and activated. The razor will glow bright green when
you are shaving using optimal pressure. It will glow red if your
pressure is too high and you risk irritation.
STEP 4 – DOCK & CHARGE YOUR RAZOR IN
BETWEEN SHAVES
For the system to keep working effectively, please dock your razor
for it to charge and to keep both its software and your personal
profile fully up to date.
USER MANUAL
Please save these instructions for future reference.
INTRODUCTION
Thank you for purchasing a GilletteLabs product.
The Gillette smart razor is a new and revolutionary shaving
experience with real time pressure guidance for a close, irritation
free shave
As you shave, the razor handle continually monitors the pressure
applied by the razor on your skin and provides live feedback to
guide you to your optimal pressure range.
Note: If the pressure alert lights do not behave as expected,
please refer to the trouble shooting guide at the end of these
instructions. If you have any questions or problems don’t
hesitate to get in touch.
CUSTOMER CARE
Please contact us if you have any technical issues, questions or
would like to leave any general product comments.
Phone: 1-800-GILLETTE
Whenever you contact us you will always need to state your
panellist ID.
IMPORTANT SAFETY
INSTRUCTIONS
Important: Read all instructions before using this appliance.
This product is for household use only.
If the razor is dropped, please discontinue use and contact
GilletteLabs Customer Care.
For electrical specifications, see printing on the Smart Plug.
BASE
Detachable Power Supply
HANDLE
Lithium
-Ion Battery
Washable Device IPX7
Wet Device
When using an electrical appliance, basic precautions should
always be followed, including the following:
1. Do not attempt to disassemble device. No user serviceable
parts inside.
2. The base station is not for immersion in water or for use in
shower. Discontinue use if the wall charger or base station is
dropped or directly exposed to water.
3. Do not reach for a charger that has fallen into water. Unplug
immediately.
4. Do not place, store or charge the appliance where it can fall
or be pulled into a tub or sink. Do not place in or drop into
water or other liquid.
5. This appliance is provided with a Smart Plug with integrated
Safety Extra Low Voltage power supply. Do not exchange or
manipulate any part of it.
6. Use only power supply provided with system. The system
must only be supplied at safety extra low voltage
corresponding to the marking on the system.
7. In case of any malfunction, strange smell, or sounds, stop
use of the system immediately and disconnect the power.
8. Keep device away from high temperature environments
(direct sunlight, radiator, heater) when charging, storing, and
applying.
9. Keep the cord away from heated surfaces.
10. Clean razor by running it under warm water and clean base
by wiping with a damp cloth. Use of alternate methods may
damage device.
11. Unplug this appliance before cleaning.
12. External use only.
13. This appliance is not intended for use by children or persons
with reduced physical, sensory or mental capabilities or lack
of experience and knowledge, unless they are given
supervision by a person responsible for their safety. In
general, we recommend that you keep the system out of
reach of children. Children should be supervised to ensure
that they do not play with the system. For household use
only.
14. Close supervision is required when this appliance is used by,
on, or near persons with disabilities.
15. Keep out of reach of children. Small parts may come off in
case of rough handling or drop.
16. This product employs batteries that contains materials that
are hazardous to the environment and the complete
product/system must be returned at the end of the study
period as instructed by your study coordinator.
17. Do not use an extension cord with this appliance.
18. Use this appliance only for its intended use as described in
this manual. Do not use attachments not recommended by
the manufacturer.
19. Never operate this appliance if it has a damaged cord or
plug, if it is not working properly, if it has been dropped or
damaged, or if the power supply has been dropped into
water. Discontinue use and contact customer care
20. Never drop or insert any object into any opening of the
appliance.
21. Do not use outdoors or operate where aerosol (spray)
products are being used or where oxygen is being
administered.
22. Do not use this appliance with a damaged or broken shaving
system, as serious skin injuries may occur.
23. Always attach plug to appliance first, then to outlet. To
disconnect turn all controls to off, then remove plug from
outlet.
24. When plugging to an electrical outlet outside the USA, use a
plug adapter to match the outlet’s pin configuration.
25. The battery used in this device may present a fire or
chemical burn hazard if mistreated. Do not heat above 50 °C
(122 °F) or incinerate.
26. The razor handle and the charger contain NdFeB magnets
and generate magnetic fields. If you use a medical device or
have an implanted medical device, consult with the medical
device manufacturer or a physician, if you have questions
about safely using your GilletteLabs Smart Razor.
PRODUCT OVERVIEW
STEP1 - SETUP YOUR SMART
RAZOR
•Prior to using your Gillette smart razor, plug the base station in
to an appropriate electrical outlet.
•The base station status indicator light will glow green to indicate
the base is powered and ready.
•Once the base is ready, charge the razor by docking it to the
base station. The razor status indicator light will flash green to
indicate charging is in progress.
•On first setup, please leave the razor docked to the base until it
is fully charged. The razor status indicator light will stop flashing
green when the battery is fully charged.
•The base station communicates anonymous shave data to the
cloud in order to function
•Total charge time from empty is approximately two hours,
however, after the first full charge the razor can be used when
partially charged.
•It is recommended the razor handle is docked in the base station
between shaves.
•The razor handle battery can last for several shaves. It is
recommended that you charge the razor once every few days.
STEP 2 - COMPLETE YOUR
DIAGNOSTIC SHAVE
•Before your first shave, remove your razor from the base station
and hold the handle so that the pressure indicator light turns
blue to indicate that the handle is activated and in diagnostic
mode.
•On your fist shave with the product the pressure indicator light
will stay blue for the entire shave.
•Shave as normal during your diagnostic shave and the razor will
collect data about your shave to allow a personalised pressure
profile to be created.
•After you have completed your diagnostic shave return the razor
to the base station and check that the base station indicator light
turns blue to indicate that the razor and base station are
communicating with each other.
•After a short delay, your personalised mode recommendation
will be transferred automatically back to the razor handle and
you will then be able to shave with the live pressure feedback
feature.
•Once the razor is updated and is set in the mode the razor
recommends for you the light will show light / low level green.
The razor is then ready for your next shave.
STEP 3 - FOLLOW YOUR
PERSONALISED LIVE PRESSURE
FEEDBACK WHENEVER YOU
SHAVE
•Before each shave, remove your razor from the base station and
hold the handle so that the pressure indicator light turns light
green to indicate that the handle is on and activated.
•As you shave the pressure indicator light will show bright green
if you are shaving in the optimal pressure range or red if your
pressure is too high
•Once you have completed your shave, return your razor to the
base station. The base status indicator light will turn blue to
indicate that the base is communicating with the handle.
STEP 4 - DOCK & CHARGE YOUR
RAZOR IN BETWEEN SHAVES
•For the system to keep working effectively, please dock your
razor for it to charge and to keep both its software & your person
profile fully up to date.
CLEANING
The handle is waterproof, so you can rinse the handle and the
shaving system under warm running water until all residue has been
removed. You may use liquid soap without abrasive substances.
Rinse off all foam.
The appliance must not be cleaned in a dishwasher.
TROUBLESHOOTING
BASE
If you are having technical issues with your base, such as no blue
light to indicate communication between handle and base, please
try the following:
•Make sure your base is in a location believed to have good 3G
data signal.
•Unplug and restart your base without the handle docked.
•Dock the handle to the base once the base status light has
turned green.
•Dock the razor to the base, making sure that the razor status
light starts to flash green indicating that it is connected and
charging.
•If there is no green light on the handle, try applying pressure to
press the handle and base together.
HANDLE
If you are having technical issues with the handle, such as a red
flashing error light:
•Make sure the base is powered and that the base status light
is green.
•Dock the razor to the base, making sure that the razor status
light starts to flash green indicating that it is connected and
charging.
WARRANTY
Your GilletteLabs warranty starts on the day of purchase and runs
for 1 year. If your GilletteLabs product is defective during the
warranty period, we will replace it free of charge or reimburse your
purchase. Call customer care for further information.
The warranty does not cover cosmetic damage such as scratches,
or damage caused by:
•Normal wear and tear
•Accident, misuse, dirt or water
•The product being tampered with
•Improper use
•Repairs carried out by agents not authorized by GilletteLabs
•Failure to take proper care of the product, including recharging
•The product being altered or used for commercial purposes
Note: Not for resale. Warranty limited to products purchased directly
from approved retailers.
FCC COMPLIANCE STATEMENT
CAUTION: Changes or modifications not expressly approved
could void your authority to use this equipment
This device complies with Part 15 of the FCC Rules. Operation to the
following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation
