Gison Machinery GPW-215 User manual

GISON Machinery Co., Ltd.
GPW-215 Wet Air Grinder
Feature

Spindle Oil Hole
Loosen the screw in counter clockwise direction with a 5mm hex. Spanner and
lubricating the gear set with oil directly from the hole. Fabricators can maintain the
machine themselves, save maintenance cost and extend duration of gear.

Safe Lever Knob
Before operating the tool, users need to press the knob to unlock the lever. Such
device is designed to keep users away from danger for unintentional press of the
lever.

Lever
Press the lever to start the tool. Just release the lever and the tool will stop
performing immediately.

Water Valve
Connecting water hose to this area to bring the waterfed function to the tool while
Operating on materials easy to come up with dusts.

Water Regulator
Water regulator enables users to adjust frequency of water to proper speed according
To various needs of profiling.

Air
Inlet
Adaptor
Connecting the tool to air hose with suggested proper air supply.

57
56
12
Pad Installation
Installation：
Dovetail the stop spanner (56) to fix the spindle (12), and tighten the pad (57) in
clockwise direction.
Replace：
Dovetail the stop spanner (56) to fix the spindle (12), and loose the pad (57) in
Counter clockwise direction.
Operation Manual
Check the following items prior to operation.
Working Environment
Make sure that the work site is in order prior to polishing operations.
Air supply Quality
Select and install a compressor with sufficient capacity for the recommended air
consumption. Use of compressed air with water and oil may cause rusting and
other problems. Before operating the compressor, drain out the water and oil
completely through the drain port provided at the bottom of the compressor tank.
The Operating Air Pressure
This sander is designed for operation in the optimum air pressure at 90 PSI/6 BARS

(Max. air pressure at 8.0 kgf/cm²). Excessive air pressure levels can cause the
sander to run at excessively high r.p.m. and may cause harm to the operators. Only
operating this sander within the specified air pressure ranges.
The Air Regulator Function
Grip the body while press the lever. Then switch the air regulator to turn the
tool“on”. For faster r.p.m, turn the air regulator valve for air flow control from zero
to max.
Conncetion Of The Air Hose From The Compressor To The Tool
Check the air hose conection plug for small stone particles and dust. Foreign
Object damage (FOD) can be caused by these small stone particles if they get into
the tool.
(1)
Prior
to
connecting
the
air
hose,
make
sure
that
it
is
not
damaged
and
the
connecting joint is tightly clamped. Connect the air hose to the compressor and
the tool and make sure they are air secure.
Test Run
CAUTION
Prior to switching on, make sure that the tool is not in contact
with the work piece.
This may damage the work piece or cause personal injury.
When switching on, the operator should be positioned away
from the exposed portion of the disc.
Before polishing, perform a test run with the sander. Take care to ensure
that no one is in the immediate area during the test run.
During the test run, make sure that the tool is running normally and that the
pad disc is properly set.
WARNING

Turn
the
air
regulator
off
and
release
the
lever
whenever
operations are interrupted, discs are changed, after
completion of polishing, and when the air hose is to be
disconnected.
Handle your sander with care. Improper contact with other
materials may cause damage to the disc or to the sander.
Continuing polishing operations with cracked or damaged
discs is hazardous and could result in physical injury. If the
polisher is dropped, perform a test run before resuming
operation. Make sure that the tool is working properly
before continuing.
