Glab ALA-1 User manual

1
Version 1.0
Dear Customer!
Thank you for choosing our product.
G LAB Amp Loop Adapter ALA-1 assures correct functioning of the effects
connected to the amp effect loop. Adapter enables to adjust the signal level
of the amp effect loop to sensitivity of connected effects. Adapter also
resolves the high output impedance problem and the problem of ground loop
arising from SEND and RETURN cables. This problems occurs in many of
the guitar tube amp models what practically makes impossible to connect the
effects placed in pedal board (connected with few meters long cables).
Basic features
- lossless transmission, with one cable, of SEND and RETURN signals
independently from OUT and IN circuits of amp effect loop,
- possibility to adjust signal level by boosting or attenuating the signal
sent to the effects,
- attenuation module with regulation up to -16 dB (/6),
- boost module based on A class amp with regulation up to 14 dB (x5),
- possibility to bypass the boost and attenuation modules,
- high level of transmitted signal 18 dBu (17Vpp).
Package contents
ALA-1 adapter module
Loop Adapter Cable
2 Velcro fasteners
User manual

2
Structure
Adapter consists of the JACK cable to be connected to the amp effect loop
connectors and the adapter box containing SEND and RETURN connectors
for the effects.
1 - power supply indicator
2 - BOOST control
3 - BOOST module on/off switch
4 - module order switches
5 - ATTENUATION module on/off switch
6 - ATTENUATION control
7 - SEND out connector
8 - RETURN in connector
9 - LAC cable connector
10 - 9V DC power supply connector

3
1 - connector for ALA-1 adapter
2 - GROUND LIFT switch
3 - OUT connector
4 - IN connector
Power supply
The ALA-1 should be supplied from external regulated 9V DC power supply,
with capacity of 50 mA or more. It is recommended to use separated source
(e.g. G LAB PB-1) in order to avoid ground loop. Before connecting check if
the connector’s polarization is CTR – (center negative).
The device is protected against opposite polarity. If this protection switches
on it is needed to disconnect the power supply and wait few minutes before
reactivation of the device.
ATTENTION: Damages caused by improper power supply causes loss of the
warranty.

4
Connecting
Signal IN connector should be connected to the effect loop SEND output and
signal OUT connector should be connected to the amp RETURN input
connector. GROUND LIFT switch enables to cut OUT connector ground what
eliminates local ground loop (it is recommended to set in to ON position).
Adapter cable is 6 meters long what enables to place the device in pedal
board. Guitar effects (or the effect) should be connected to the adapter SEND
and RETURN connectors.
When signal doesn’t need level changes the switches should be set like on
the picture below (both module order switches can be set to opposite
position).
If signal on the amp loop is too high the switches should be set like on the
picture below.

5
If signal on the amp loop is too low the switches should be set like on the
picture below.
Attenuation and boost module settings
Attenuation and boost controls are placed on the front panel of the ALA-1.
They can be set by using small flat screwdriver.
If the effect features gain or peak indicator setting should be started either
from the ATTENUATION module (if order switches are set to AT/BO) or from
BOOST module (if order switches are set to BO/AT). For maximal utility
signal (very often it is a clean tone) the regulator should be set to maximal
value on which the peak indicator doesn’t light. After, the BOOST control
(for order AT/BO) or ATTENUATION control (for order BO/AT) should be set
to similar dB value in order to retain the signal level.
If the effect doesn’t feature gain or peak indicator both controls should be set
to minimum. Further, the signal level passing to the effect should be boosted
either with ATTENUATION module control (for order AT/BO) or BOOST
module control (for order BO/AT) up to the maximal value on which the signal
overdrive doesn’t appear. After, the BOOST control (for order AT/BO) or
ATTENUATION control (for order BO/AT) should be set to similar dB value in
order to retain the signal level.

6
Mounting
Package contains two Velcro fasteners to fix the device to smooth surfaces.
Adapter can be installed in the rack 19” using the GLAB 1U RMS FRONT
PANEL.

7
Technical parameters
Dimensions width 110 mm
depth 65 mm
height 40 mm
Weight 0,63 kg
Input impedance 400 kΩ
Output impedance 200 Ω
Maximal level of transmitted signal * 18 dBu (16 dBV, 18 Vpp)
Bandwidth * 20Hz to 20 kHz @ - 0,35 dB
* - with activated attenuation and boost modules
Power supply 9V DC 50 mA
(8,7 do 9,4V regulated)

8
DO NOT PLACE THIS PRODUCT INTO THE WASTE CONTAINER !
This device is marked with a cross-lined waste container symbol
according to 2002/96/EU Directive on Waste Electric and Elec-
tronic Equipment.
Such marking informs that after usage equipment can not be
trashed together with other household waste.
An user obligation is to return wasted equipment to a party collecting wasted
electric and electronic equipment. Parties collecting such equipment organise a
system, including local collection points, shops and other units, allowing to return
such equipment. This Directive assures an user free of charge utilisation of such
delivered equipment.
This device is made of materials which can be recycled or utilised after becoming
out of use. Proper handling of wasted electric and electronic equipment reduce
demand for row materials and contribute in avoiding harmful consequences for en-
vironment and health of people caused by dangerous components and not proper
storing and utilising of such equipment.
User Manual, Drawing No. G69INA00
