Glab DR-2 User manual

LEVEL B
1
0
2
3
456
7
8
9
10
1
0
2
3
456
7
8
9
10
TIME A
1
0
2
3
456
7
8
9
10
1
0
2
3
456
7
8
9
10
B
PEAKREVERB
2
1
A
LEVEL A TIME B
REVERB
ON
IN
FOOT
PEDAL
OUT
2
512
6 11
8
7
9
10
3
413
14
15
1
DUAL REVERB
DR-3 ANALOG
ON//
OFF
A/B

1
Dear Customer!
Thank you for choosing our product.
G LAB Dual Reverb DR-3 (DR-2) is an analog-digital reverb type stompbox.
Basic characteristics:
- two reverb types (REVERB 1 or 2) with various sound characteristics
- two sets (A and B) of reverb time and effect intensity controls
- effect ON/OFF footswitch
- A or B parameters selection footswitch
- smooth ON/OFF and parameters switching (not cutting sounding of previously
played tones)
- signal overdrive indicator (PEAK)
- high level of maximal signal (8 dBu) what enables to use it at amps effect loops
- silent switching and low noise level
- FOOT PEDAL input for controlling it by a guitar controller e.g. G LAB GSC
- 9V DC power supply.
Edition 2.1

2
Structure
On the inner side of the instruction cover are placed the pictures with elements
numerated below.
1 - Effect ON/OFF footswitch
2 - A reverb LEVEL (intensity) control
3 - A reverb TIME control
4 - Effect switching on indicator
5 - “A” reverb switching on indicator
6 - reverb type selection 1 or 2
7 - output signal connector (OUT)
8 - 9V DC power supply connector
9 - FOOT PEDAL connector
10 - input signal connector (IN)
11 - signal overdrive indicator (PEAK)
12 - B reverb switching on indicator
13 - B reverb LEVEL (intensity) control
14 - B reverb TIME control
15 - Reverb A / reverb B footswitch

3
Diagrams of connecting
In case when you use only stompbox overdrives the DR should be connected as
the last stompbox pre amp.
When you use overdrive channel (or channels) of your amp the DR should be
connected at the and of the signal path what means, to the amp effect loop.

4
If your amp is equipped with SEND output signal level control then you should set
the active reverb LEVEL control to maximum and set in a such way your amp SEND
output signal level control to be at the edge of lighting up the DR PEAK indicator (it is
recommended to set the amp channels controls at typically used positions and to check
all the channels). Then you should adjust RETURN input gain control to receive the
same signal level (volume) when the effect loop is active or not.

5
Control settings
The REVERB 1 or 2 switch enables to select sound characteristics of the used reverb.
TIME controls enable adjusting the reverb time from hundreds of milliseconds up to few
seconds (REVERB 2 offers longer lasting sounding). LEVEL controls enable adjusting the
proportion of the resounded from zero signal to the level of 25% of the incoming one.
Thanks ability of setting two pairs of reverbs time and level parameters, and also thanks
footswitching between these two pairs (REVERB A and B) it is possible switching the used
reverb while playing, what reasonably increases a guitar tone performances.
Typical controls settings:
- quick support playing: REVERB = 2, TIME = 1 to 2, LEVEL = 3 to 5,
- slow support playing: REVERB = 2, TIME = 2 to 4, LEVEL = 4,
- solo: REVERB = 2, TIME = 3 to 5, LEVEL = 4 to 6.
Power supply
The DR should be supplied from external regulated 9V DC power supply, with 80 mA
output or more. Before connecting please check if the connector’s polarisation is proper.
REMARK: Damage of the DR caused by supplying it with power of improper
voltage effects in loss of the warranty.

6
Connecting to the GSC (Guitar System Controller)
The DR can be controlled and supplied form the GSC controllers of the G LAB
brand. In such a case the SW1&2 (or SW3&4) output of the GSC connect with the DR
FOOT PEDAL input by a Jack/Jack mono cable.
According to the signal (only in case when we don’t use the amp’s reverb) it is
recommended to connect the DR between the GSC and the amp input.

7
Specification
Dimensions: depth 120 mm
width 120 mm
height 60 mm
Weight 550 g
IN input impedance 1 MΩ
Maximal input signal 8 dBu
OUT output impedance 4 kΩ
Power supply 9V DC (8,7 do 9,4V regulated)
Power consumption 80 mA

8

9
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer for help.

10
Declaration of Conformity
ELZAB S.A., ul. Kruczkowskiego 39, 41-813 Zabrze, Poland,
declare under sole responsibility, that the following product:
G LAB/ Dual Reverb G LAB DR-3 (DR-2)
conforms with requirements of the EC Council Directives:
●2006/95/EEC Low Voltage Directive,
●2004/108/EEC Electromagnetic Compatibility,
and holds CE mark. Above named product conforms with the following standards:
●PN-EN 60065:2004 /EN 60065:2002/ Audio, video and similar apparatus -
Safety requirements.
●PN-EN 55103-1:2000 /EN 55103-1:1996/ Electromagnetic compatibility -
Product family standard for audio, video, audio-visual and entertainment
lighting control apparatus for professional use - Part 1: Emission
●PN-EN 55103-2:2001 /EN 55103-2:1996/ Electromagnetic compatibility -
Product family standard for audio, video, audio-visual and entertainment
lighting control apparatus for professional use - Part 2: Immunity
Jerzy Biernat
President of the ELZAB S.A. Board of Directors
Copy of original EC declaration of conformity is available for download on our
webside http://www.glab.com.pl

11

12
DO NOT PLACE THIS PRODUCT INTO THE WASTE CONTAINER !
This device is marked with a cross-lined waste container symbol
according to 2002/96/EU Directive on Waste Electric and
Electronic Equipment.
Such marking informs that after usage equipment can not be
trashed together with other household waste.
An user obligation is to return wasted equipment to a party collecting wasted
electric and electronic equipment. Parties collecting such equipment organise
a system, including local collection points, shops and other units, allowing to
return such equipment. This Directive assures an user free of charge utilisation
of such delivered equipment.
This device is made of materials which can be recycled or utilised after
becoming out of use. Proper handling of wasted electric and electronic
equipment reduce demand for row materials and contribute in avoiding harmful
consequences for environment and health of people caused by dangerous
components and not proper storing and utilising of such equipment.
User Manual, Drawing No. G57INA0021

LEVEL B
1
0
2
3
456
7
8
9
10
A/B
1
0
2
3
456
7
8
9
10
TIME A
1
0
2
3
456
7
8
9
10
1
0
2
3
456
7
8
9
10
B
PEAKREVERB
2
1
A
LEVEL A TIME B
ON/OFF
REVERB
ON
IN
FOOT
PEDAL
OUT
DUAL REVERB
DR-2
2
512
6 11
8
7
9
10
3
413
14
15
1
