Glacier GL-F-10M User manual

www.aegisfridge.com
OPERATION MANUAL
Applicable product model:
GL-F-10M

This product consists of door, chamber, electric control system,
refrigeration system and accessories.
The Ultra-low Temperature Freezer offers a wide variety of research and
storage applications, such as low temperature scientific experiments,
preservation of plasma, biomaterials, tunny, biological product, and testing low-
temperature-resistant properties of military product.
It is suitable for blood bank, hospitals, sanitation and anti-epidemic,
sanitation, research institutes, electronic industries, university laboratories,
military industries, pelagic fishery companies.
Top control technique：
High precision microcomputer temperature control system，
platinum thermistor sensor，temperature could be set between -10°C to -
86°C；
LED touch screen controller with 7”, clear display, easy to operate.
Gorgeously design for excellent appearance.
Refrigerating system：
Imported international brand high-efficient compressor, EBM fan
motor，powerful and more energy-efficient；
2-times foaming thermal insulation door，multi-patents outdoor
insulation design； Effectively prevent the loss of cooling capacity.
Cabinet uses high-performance vacuum insulation board， greatly
improved the insulation effect；
Humanization design：
Mechanical door handle， easy to open；
Adjustable multi-level shelves，easy to store articles；
Universal wheels with fixed support ，easy to move and fix；
Safety system：
With keyboard lock and password protection system, prevent from
un-authorized change of the parameters.
Multiple failure alarm system: Sensor failure alarm、High and low
temperature alarm、door open /ajar alarm、filter clogging alarm、system
failure alarm. Make sure the safety of the articles stored inside the
freezer；
Door with lock, prevent from the un-authorized opening.
Start delay and interval stop system to protect the reliable operation .
1. Use Instruction
2. Safety tips
3. Precautions for use
4. Product installation
4.1Installation environment
4.2Installation Site
4.3Pre-installation
4.4First time use
4.5Power off operation
5. Components and Overview
6. Control panel description and function setting
7. Defrost, Unused and Maintenance
7.1Defrost, Unused and Maintenance
7.2Disposal of the Equipment
8. After-sales service
9. Specification
10. Performance
10.1Main Technical Parameter
10.2Packing List
10.3Electrical Diagram
1
2
4
4
4
4
5
5
6
6
8
11
9
11
11
9
9
9
11
10
Contents

2. PRECAUTIONS FOR SAFE OPERATION
1 2
For the first time to use this device, uses must read the meaning of the following
warning labels very carefully. Items and procedures are described so that you can
use this unit correctly and safely. If the precautions advised are followed, this will
prevent possible injury to the user and any other person.
WARNING.
Failure to observe WARNING signs could result in a hazard to personnel
possibly resulting in serious injury or death.
As with any equipment that uses CO2 gas, there is a likelihood of oxygen depletion in the
vicinity of the equipment. It is important that you assess the work site to ensure there is
suitable and sufficient ventilation. If restricted ventilation is suspected, then other
methods of ensuring a safe environment must be considered. These may include
atmosphere monitoring and warning devices.
Do not touch any electrical parts such as the power supply plug or any switches with a wet
hand. This may cause electric shock.
Only qualified engineers or service personnel should install the unit.
The installation by unqualified personnel may cause electric shock or fire.
WARNING.
Failure to observe WARNING signs could result in a hazard
to personnel possibly resulting in serious injury or death.
CAUTION.
Failure to observe WARNING signs could result in injury to
personnel and damage to the unit and associated property.
CAUTION HOT.
The sign inform the users about the danger of burns for high
temperature.
DANGER OF EXPLOSION.
The sign inform the danger of the application of volatile,
explosive chemical substances.
NO TILTING.
STAY OUT OF SUN.
BEWARE OF ELECTRIC SHOCK!
Dangerous voltage may cause personal injury! Please
disconnect the power supply before repair.
GROUNDING MARK.
NO TRAMPLING EQUIPMENT.
NO TUMBLING TRANSPORT
PACKAGES.
PRECISION INSTRUMENTS.
HANDLE WITH CARE.
THE CONTENTS MUST BE PLACED AT
THE ARROW.
FEAR OF THE RAIN.
NO STACKING.
NO CLAMPING.
Always use protective equipment correctly (including clothing, gloves, goggles, etc.)
Always adopt good hygiene habits.
Everyone has an obligation to be responsible for his or her own safety
1. Use Instructions
Thank you for choosing Glacier Products. For your safe, convenient use and reasonable
maintenance of this product, you are requested to read the instructions carefully before use and keep them
properly for reference.
Device operators can copy some chapters of this manual, but only use it internally, for example, to instruct
users such as：
How to deal with emergencies? These chapters are clearly identified in the catalogue of the manual. Glacier
is not obligated and responsible for any instrument damage caused by the user's failure to use the equipment in
accordance with the manufacturer's method as stated in the manual.
Due to the rapid upgrade of Glacier's products, the functions described in this manual may be
inconsistent with those of the products you purchased. Please refer to the physical functions.
Please read the notes and safety precautions carefully.
In order to make the equipment work properly, please install it according to the correct installation procedures.
Medical freezers can only be operated by trained and authorized person.
Maintenance of the equipment can only be performed by Glacier or Aegis Authorized Agents.
If the operator encounters situations not mentioned in this manual, please contact the authorized agent of
Glacier or Aegis and ask for the correct treatment.
If the equipment is not used according to the procedures prescribed, it may damage the equipment.
It is necessary to use the accessories provided by Glacier, such as compressors, controllers, sensors, etc. If
users want to use other accessories, they may have adverse consequences, such as affecting performance,
protection and service life.
Medical freezers must be inspected and maintained within a specified time interval.
Due to the upgrade of the products and the different models, the actual products may be different from the
sketch, please take the physical object as the criterion. The sketch is only an example of identifying the
function parts.
Friendly Reminder：

1. INTRODUCTION
1 2
Thank you for choosing Meiling's bio-medical products.Read this manual
carefully before using the appliance and follow the instructions for the safety
operation.Keep this manual in an adequate place to refer to it as necessary.
Meiling never guarantee any safety if the appliance is used for any objects other
than intended use or used by any procedures other than those mentioned in this
manual.The contents of the manual will be subjected to change without notice due
to the improvement of performance or functions.Contact Meiling sales
representative or agent if any point in this manual is unclear or if there are any
inaccuracies.No part of this manual may be reproduced in any form without the
expressed written permission of Meiling.
uPlease read the page4-page7 carefully as it contains the important safety
notices.
uOnly trained or authorized personnel could operate this Ultra-low temperature
freezer.
uOnly qualified service personnel or authorized agent could install and
maintenance this device.
uUse Meiling spare parts as always. If users want to use other accessories,
Meiling bio-medical will not be responsible for the adverse consequences.
However users could apply for verifying the eligibility of these accessories from
Meiling before use them.
uShould inspect and maintenance the device in a specified time interval.
uDue to the differences between each models and the improvements of products,
actual product may differ from the diagram. Please refer to the final product.
uEveryone has an obligation to be responsible for his or her own safety.
uPut on dry gloves when you take out refrigerated articles from the freezer.
ucontents or the inside walls with naked hands may cause frostbit.
Handing frozen.
ucontents or the inside walls with naked hands may cause frostbit.
2.Safety tips
When using this product for the first time, please pay attention to the following warning signs and read the
safety precautions carefully so that you can use the equipment safely and correctly
Failure to comply with precautions may
result in injury to personnel, equipment
failure and related property losses.
Warning: Failure to comply with
precautions may result in serious
personal injury or death
Grounding mark
Do not tilt
Handle with care
Flammable and explosive refrigerating
medium, away from the source of fire!
Avoid direct sunlight
Items in the box must be placed in the
direction of arrows.
Avoid rain
Prevent electric shock
No stacking
Warning: Failure to comply with precautions may result in serious personal injury or death.
Please keep the blood refrigerator stable and avoid shaking.
Do not touch the equipment with wet hands to avoid the danger of electric shock.
Please handle the power cord carefully to avoid short circuit. Turn off the power supply before
pulling out the power plug. Hold the power plug carefully and pull out. Do not pull the lead of the
power plug. Otherwise, it may cause electric shock or fire due to short circuit. Do not tie the
power cord, do not press under furniture or heavy objects, do not close to heat sources such as
compressors.
It is necessary to use a separate special socket and grounding reliably. The length of the power
line should not be lengthened at will. If it really needs to be lengthened, it is necessary to use
more than 2.5mm2 copper conductor. The cross-sectional area of the copper conductor in the wall
connected with the power socket must also be guaranteed to be more than 4mm2. In case of heat
or fire.
This equipment can only be installed by professional technicians or after-sales maintenance
personnel, otherwise it may lead to electric shock or fire.
Be sure to install the medical freezer on a solid, flat floor and pay attention to it in case turns
over. If the ground is not solid enough or the installation site is inappropriate, it may cause the
equipment to overturn and cause equipment damage or personnel injury.
Please insert the power plug firmly to avoid leakage.
Do not use power sources other than those specified in the design of equipment to avoid
overheating and short-circuit faults. If 110V rated voltage products are connected to 220V power
supply, overheating and burning equipment may occur. The machine uses 220V/50HZ AC
power supply. If the voltage is too low or too high, it needs to be equipped with appropriate
automatic regulator to cooperate with the use.
No clips!

3 4
Make sure a dedicated power source is used as indicated on the rating label attached to the
unit. Out of the rate, should install a property transformer and a proper voltage stabilizer for
securely operation. Or the freezer may be damaged, and may cause injury.
Make sure to put the freezer in a dry and ventilated environment, to ensure that equipment
vents and wall surface of the instrument or other items have not been blocked; Do not use the
device in a poorly ventilated environment, or the equipment may be damaged by the
release of heat.
Never disassemble, repair, or modify the unit yourself.
Any such work carried out by an unauthorized person may result in fire or injury due to a
malfunction. Meling will be no responsible for such work.
Use this unit in safe area when treating the poison, harmful or radiate articles. Improper use
may cause bad effect on your health or environment.
Never ground the unit through a gas pipe, water main, telephone line or lightning rod. Such
grounding may cause electric shock in the case of an incomplete circuit.
Use a power supply outlet with ground (earth) to prevent electric shock. If the power supply
outlet is not grounded, it will be necessary to install a ground by qualified engineers.
CAUTION.
Failure to observe WARNING signs could result in injury to personnel and
damage to the unit and associated property.
Ultra-low temperature freezer is not available to store living things, flowers, or other
critical articles which is not suitable for low temperature storage.
The temperature inside the freezer is very low during the normal working. Do not touch
the interior surface of the chamber or the object inside without wearing protective gear.
Always disconnect the power plug when the unit is not used for long periods.
Make sure to prepare a safety check sheet when you request any repair or maintenance
for the safety of service personnel. Be sure to check set point of the controller prior to
restart the freezer.
The ultra-low temperature freezer is a storage device, not a production equipment!
Always hold the handle when closing the door. This will reduce the likelihood of a trapped
finger.
Keep the key properly avoiding the children take it to open the door which may result in
unexpected injury.
Do not place the blood refrigerator in the area where the sun or rainwater drips, so as to prevent
dangerous accidents such as short circuit or overheating of the equipment.
Please put the blood refrigerator in a dry and dustless environment to avoid the danger of
overheating and short circuit.
Do not tilt or lie sideways, do not impact the fuselage of the equipment; the equipment is equipped
with refrigeration system, which is easily damaged by rolling or impact.
If unexpected sounds, smells, smoke and so on occur when the power supply is switched on,
please pull out the power supply in time and contact the manufacturer or supplier.
Please place the blood refrigerator in a dry and ventilated environment to ensure that the
ventilation outlet and the surface of the instrument are not blocked or blocked by walls or other
objects. Do not use it in a poorly ventilated environment to prevent damage caused by overheat
It is forbidden to dismantle or alter the equipment without authorization in order to avoid potential
safety hazards. Meiling Biomedical will not be responsible for any quality accidents in this case.
It is strictly forbidden to put inflammable, explosive dangerous goods and strong corrosive acid,
alkali and other articles which are not suitable for refrigeration in this medical freezer.
Metal objects such as nails or wires shall not be inserted into any orifice and clearance or any
outlet of the blood refrigerator, otherwise electric shock or injury may be caused by accidental
contact between the above-mentioned objects and the moving parts.
When storing toxic, harmful or radioactive materials, please use medical freezers in safe areas.
If improperly used, it may cause harm to human health or the environment.
In order to ensure the normal operation of the machine and ventilation and heat dissipation, the
back of the box body and the left and right sides are at least 30 cm away from the wall. Please do
not block the air inlet and outlet.
This device must be connected to the ground wire.
Note: Failure to comply with the precautions may result in injury or equipment failure and
related property losses.
When the medical freezer is not in use for a long time, please unplug the power plug and pack it for
properly.
When restarting the medical freezer after power off, please check the equipment
parameters first, otherwise the storage items may be damaged due to the change of parameters.
The medical freezer is a storage device for articles, and can not be used as a production
equipment!
Hold the handle and close the door so that it doesn't clip to your finger.
Keep the keys properly to avoid accidents when children open the door and play after they get them.
When moving the equipment, please be careful not to let the equipment turn over, in case the
equipment is damaged or personnel are injured.
When carrying, it should be lifted from the bottom. The inclined surface should not be greater than
45 degrees. It should be handled lightly.
Pay attention to check the filter in time and clean it regularly. In order to avoid dust blockage and
poor ventilation leading to temperature rise or malfunction of blood refrigerator.
Do not place this medical freezer in dangerous areas, do not operate equipment near
inflammable articles, to prevent explosion or fire accidents.

3 4
Be sure to install the unit on a sturdy floor. If the floor is not strong enough or the installation
siteis not adequate, this may result in injury from the unit falling or tipping over.
Carefully with the power cord to avoid short circuit or open circuit. When removing the plug
from the power supply outlet, grip the power supply plug, not the cord. Pulling the cord may
result in electric shock or fire by short circuit. Don't make the power line pack and pressed by
furnish or heavy goods. Also please don't close to the compressor and heat source.
Please insert the power plug firmly to avoid leakage.
Use a power supply outlet with ground (earth) to prevent electric shock. If the power supply
outlet is not grounded, it will be necessary to install a ground by qualified engineers.
Don't lengthen the line randomly. If you need, To use 2.5mm2 copper line, you should keep
4mm2 line to connect the electrical outlet. Or may cause fire.
Make sure a dedicated power source is used as indicated on the rating label attached to the
unit. Out of the rate, should install a property transformer and a proper voltage stabilizer for
securely operation. Or the freezer may be damaged, and may cause injury.
Be sure to install the unit on a sturdy floor, no shaking and tilting.
Never install the unit in a flammable or volatile location. This may cause explosion or fire.
Never install the unit in a humid place or outdoor or a place where it is likely to be basked
straightly. Deterioration of the insulation may result which could cause current leakage or
electric shock.
Do not place the device lateral tilt, do not impact the device; the device is equipped with
refrigeration systems, roll or shock will easily damage the freezer.
Be sure to install the device in a dry dust-free environment to avoid overheating, short circuit
and other dangers.
If there is an unexpected sound, smell, smoke when the power is turned on, unplug the power
and contact the manufacturer or supplier. Continued abnormal operation may cause electric
shock or fire.
3. Precautions for use
◆Before putting the items into the medicla freezer, please confirm whether the temperature in the
chamber has reached the set temperature, and then put the items in batches.Should put not
more than 1/3 of the items each time in order to prevent excessive temperature rise.
◆Clean the unit with diluted neutral detergent. Brushes, acids, gasoline, soap powder, polishes or hot
water should not be used to clean medical freezers, as the above materials may damage the painted
surface and plastic rubber parts. Be careful not to use volatile solvents such as gasoline to wipe
plastic rubber parts.
◆
◆
When the medical freezer is not used for a long time, the power supply should be cut off
There should be no obstruction around the medical freezer to keep ventilation smoothly.When the
medical freezer does not need to be restarted for a long time, there may be a low battery situation.
It should be ensured that the battery switch is in the “ON” . At this time, the battery can be charged.
The medical freezer can run continuously for about a week and the battery can be fully charged.
4. Product installation
4.1 Installation environment
Ambient temperature: 16℃～32℃,and the optimum temperature is
18℃～25℃ and air conditioning system should be used when necessary.
Relative humidity：≤ 80%RH
There is no strong vibration and corrosive gas around.
Avoid large amounts of dust
Avoid machine swing or vibration.
Unit working altitude: below 2000m
The input voltage 220V±10%。
Without the influence of direct sunlight and other cold and heat sources
and the existence of electromagnetic interference, electromagnetic interference will affect the normal
operation of the control system, and will directly damage the system in serious cases.
4.2 Installation Site
In order to make the blood refrigerator work normally and obtain the best performance level, the installation
site of the blood refrigerator should meet the following requirements：
Can not be installed in narrow and closed space, the door body of the room should not be less than the
equipment, at least ensure the normal entry and exit of the equipment, in order to avoid the maintenance
difficulties caused by the failure of the equipment, unable to repair the equipment in time, causing damage
to storage items;
The installation ground must be firm and smooth.
Good ventilation to avoid direct sunlight；
Do not share a socket with other devices. The plug is firmly connected to the socket；
If it is really necessary to lengthen the power cord, it is necessary to use more than
2.5mm2 copper-core conductors. The cross-sectional area of copper-core conductors in the wall connected
with the power socket must also be used.It is guaranteed to be over 4mm2. After installation, the power
plug must be accessible to the user, so that the power cord can be pulled out in case of emergency.
Check the working voltage before use. In areas where the voltage is unstable, the
voltage stabilizer suitable for equipment load should be considered. Guarantee
Input voltage is stable at 220V±10%，Voltage regulator power greater than 4KW；
Reliable grounding of medical freezers；
If the power line socket is equipped with grounding wire, check whether the
grounding is good before use. Terminal N and E
If the socket is not equipped with grounding wire, it must be installed by cannot be connected
professional engineers and technicians.

5 6
4. Installation
4.1 Installation environment：
ØAmbient temperature：10℃～32℃,optimal ambient temperature :18℃～25℃, air
conditioning system is required if necessary.
ØRelative humidity：≤80%RH.
ØNo strong vibration and no corrosive gases around.
ØWithout the presence of a lot of dust .
ØNo shaking or vibrating of the freezer.
ØAltitude of the place where the freezer is located ： ≤ 2000m
ØInput voltage ≤115±10% (V).
ØNo direct sunlight or any other cooling or heating source, no electromagnetic interference,
or the freezer will not run properly.
ØKeep the distance between the freezer and the surrounding wall of 30 cm or more, and the
air outlet must not be obstructed, pay attention to room ventilation or opening air conditioner
during the hot summer.
CAUTION.
Since the ambient temperature has a great impact on the operation of the freezer. If the
freezer is installed in the other situations instead of above conditions, the freezer will not
run properly.
4.2 Installation site：
This unit is a precision machine. When select a location to install this unit, keep the following
conditions for perfect performance ：
ØShould not be installed in a small confined space, the door of the room should not be less
than height of the present equipment.
ØInstall the unit on a sturdy floor to avoid excessive vibration and noise.
ØInstalling the unit in direct sunlight may cause malfunctioning and may shorten the life of the
unit. Keep good ventilation is necessary.
ØDo not share a socket with other equipment, plug and socket should be securely
connected。
ØSocket inputs should be connected to circuit protection facilities, such as: An air switch
which the rated current is bigger than 45A.
Ø2 If an extension cord is needed, be sure to use copper wire more than 2.5mm . The cross-
sectional area of the copper wire inside the wall connected with the power outlet must also
2
be more than 4mm .
ØChecking the working voltage of the place before start the freezer. A voltage stabilizer is
suggested to be used at the place where the voltage is not stable. Make sure the normal
input voltage stable at 115V ± 10% or 208V± 10%, Power of voltage stabilizer should be
more than 4KW.
ØBe sure to ground the unit.
ØGrounding prevents electric shock which occurs when the electrical insulation of the unit
becomes insufficient.
ØIf the power cord socket is equipped with grounding wire, check the connection before use.
ØIf the power supply outlet is not grounded, it will be necessary to install a ground by qualified
engineers.
ŸMake sure of using a plug with earth provision and to ground the unit to prevent the electric
shock in the event of the current leakage.
ŸSubstituting a water pipe for the ground terminal will not provide proper grounding in many
instances since plastic pipes are often used for water piping.
ŸNever ground the unit through a bas pipe, as it is very dangerous.
ŸNever ground the unit through the telephone line or lightning rod, as large currents flow if
lightning strikes, making it very dangerous.
WARNING.
This product should be responsible by a special person, check the running state and record every day (every 2 ~
4 hours record and check). In case of failure or shutdown, the temperature in the blood refrigerator will rise. If it
cannot be repaired within a short period of time, please take out the stored items and transfer them to a place that
meets their temperature requirements to avoid damage.
Before putting the samples into the blood refrigerator, the temperature required by the samples should be
confirmed in advance in accordance with the temperature range of the blood refrigerator, so as to avoid damage to
the stored goods because the temperature of the blood refrigerator does not reach the temperature required by the
samples.
Due to the inertia of refrigeration, there was some difference between the temperature actually displayed and the
set temperature, this is a normal phenomenon.
All the medical freezers are designed to store, it is forbidden to put too much relative hot items in one-
time, otherwise it will lead to compressor does not stop but keep refrigerating which is easy to get burnt. Items must
be put in batches, drop the temperature to the required temperature stage by stage.
It is not allowed to use unauthorized electric appliances inside of the refrigerator
Please make sure that there is a certain air circulation space around the chamber when putting in the items,
especially do not block the temperature sensor located inside of the refrigerator (for the temperature collection),
otherwise it will affect the stability and accurate display and control of the chamber temperature
●Do not ground the blood refrigerator through gas pipe, water pipe, telephone line or lightning rod, which
may easily cause electric shock
●After installation, the power plug must be accessible easily to convenient to unplug the power cord in case
of emergency
●Do not cover the vents of the blood refrigerator
4.3 Pre-installation
Remove all packaging components (including protective foam inside the box)
Note: do not put plastic bags within children's reach to prevent suffocation accidents
Counting accessories: please check the accessories and materials according to the packing list
Cleaning: the product should be cleaned before use.
Standing: after leveling and cleaning the cabinet, do not switch on the power supply firstly. It shall be placed for
more than 2 hours before switching on the power to ensure the normal running
4.4 First time use
1.When use medical freezer for first time, please follow these steps:
1. In the case of empty load, connect the power cord to the appropriate specifications of the special socket.
2. After turning on the power supply, turn on the power switch at the right bottom of the refrigerator.
3. This medical freezer has been preset to temperature (3-5℃), do not need to set temperature.
4. Press the mute button to eliminate the alarm buzzing.
5. Check the chamber temperature whether reach the required temperature or not, observed the medical
freezer whether running normally for more than 24 hours. After refrigerator temperature is normal and stable,
you can put a small amount of items placed in the medical freezer. Please store the goods in batches, each
time shall less than 1/3 of the refrigerator capacity. Ensuring that the blood refrigerator is running for another
more than 12 hours before putting in the other 1/3 items of the refrigerator capacity).
6. Try not to open the door in the process of cooling, otherwise it will cause temperature rise
Warning
Attention

5 6
3. Precautions for use
Select a level and sturdy floor for installation. This precaution will prevent the unit from
tipping. Improper installation may result in water spillage or injury from the unit tipping
over.
Check the filter mentioned in this manual and clean it as necessary. A dusty filter may
cause temperature rise or failure.
Do not tilt the unit more than 45 degrees when moving the unit. All transportation should
be carefully.
uWhen the freezer is running, the front part of the freezer may get hot. This is not a
malfunction: In order to prevent dew condensation around the case body, a heated anti-
condensation tube is installed in the cryogenic storage case.
uBefore putting the items in the freezer, please make sure the temperature inside the box has
reached the set temperature, and then put the items in batches. Add no more than 1/3 of the
container volume each time, in case the temperature rises too much.
uThe temperature display value shows the temperature of temperature sensors inside the
freezer. Although the displayed temperature may sometimes differ from the actual
temperature in the center of the freezer, it will get close to the real temperature gradually.
uA through-hole is installed on the right or back of the freezer to allow test lines to exit the
test box. After drawing out the test lines, be sure to re-plug the test hole with insulating
material, otherwise the temperature inside the box will not be completely lowered, resulting
in condensation around the outside of the hole.
uClean the freezer with diluted neutral detergent. Do not use brushes, acid, gasoline, soap,
polish or hot water to clean the frozen storage container, as these materials may damage
the painted surfaces and plastic rubber components.
uAfter a period of operation, a layer of frost will form on the inner wall and the inner door. If
the frost layer is too thick, it will affect the insulation effect of the freezer and increase the
power consumption. Therefore, after a period of time, when the frost layer reaches about
5mm, it should be defrosted with the defrost shovel attached.
uPlease remove the frozen items in the freezer and put them in a suitable storage
environment before defrost, so as to avoid the damage of goods for temperature rise.
uThere are many cooling coils on the back and side of the inner wall. Don't use sharp objects
such as knives, ice chisel, or screwdrivers to remove the frost on the inner wall. Be careful
not to scratch the inner wall when defrosting, otherwise it will cause a failure of the freezer .
uCut off the power when the refrigerated storage box will not be used for a long time.
※Our company guarantees the equipment under certain conditions but we are not responsible for any loss or
damage of the goods
5. Components and Overview
4.5 Power off operation
The medical freezer has the memory function regarding the set value, when power off and then connect to the
power supply again, the refrigerator will continue to operate before the power off. Once the power supply of
the blood refrigerator is interrupted in use, it needs to wait for 5 minutes before it can be reconnected to avoid
damage to the compressor
Temperature controller
Door handle
Adjustable foot
Cabinet
Door lock
Foam door
GL-F-10M
Due to the improvement of the product and the different models, the actual product may be
different from the simplified one. Please refer to the actual product!
Structure and composition: The product consists of a cabinet, a door , a refrigeration system,
and a control system.
Scope of application: This product is suitable for storing items in hospitals, pharmacies,
epidemic prevention stations, research institutions, biopharmaceuticals, etc.
The storage temperature inside the cabinet can be adjusted through the temperature button on
the control panel, which is convenient to use and reliable in performance.

8
5. Freezer Components
ØThe freezer controller has memory of the set point. The freezer will continue to follow the
previous operations when restart the freezer after the power failure. The restart should be
done after 5 minutes in case to damage the compressor.
Caution: Meiling will not be responsible for the safety ofthe stored articles.
4.7 Operation after power failure
File box
Touch screen
controller
Door handle
with lock
Wheels
Stand bar
USB port
Door
Power lock
and Back-up
Battery lock
(do not open it till power failure)
Air inlet and
Condenser
filter net
(Please clean it up regularly )
7
6.Control panel description and function setting
1. Temperature controller interface
1.1 Indicator light status
Indicator light
Set
indicator
Cooling
indicator
Measuring unit
indicator
The indicator
of checking
the
temperature
setting
Symbol Status
Light
Dark
Light
Dark
Blink
Light
Light
Meaning
Parameter settings
Measurement and control status
Refrigeration work
Refrigeration stop
Refrigeration delay
Display unit
Checking the temperature
setting
2. Function setting
2.1 Check temperature settings
In the normal running state, press and release the Set button to display the temperature setting
value, and the indicator light is on; Press the Set button or wait for 15 seconds without
operation to resume normal temperature display.
2.2 Modify the temperature set value
1) Pressing the Set button for 2 seconds;
2) The current temperature set value will be displayed and the Set indicator will light;
3) Modify the set value by pressing the ▲ or ▼ button in 15 seconds;
4) Press the Set button or wait for 15 seconds without operation to store the new set value.
3. Lock/unlock the keyboard
Press and hold the ▲+▼ button combination for more than 3 seconds. The panel displays the ‘oF’
character and the keyboard is locked. When the keyboard is locked, parameter adjustment cannot be
performed by button operation. Press and hold the ▲+▼ button combination for more than 3
seconds. The panel displays the ‘on’ character and the keyboard is unlocked.

8
4.3 Cautions before use：
ØRemove all package components (include the protection foam inside the package)
Caution: Do not put the packing plastic bag within reach of children as suffocation may result。
ØCheck the device, accessories and document with the device as per list of packing
ØClean：make a clean of the device before use it.
ØDo not turn on the freezer at once when the freezer is well located, must wait 24 hours for the
first start.
4.5 Standing
Operate as follows for the first start：
1. Connect the power cord to the appropriate socket during no-loading.
2. Turning on the power-lock at the right-side of the bottom. (If a back-up cooling system is
installed with, turn off its power at first ).
3. Set the desired temperature point between -10°C to -86°C, for the best performance of the
machine, when the user need to set the temperature below -80°C, should set the temperature
at -80°C at first, once the temperature of the freezer come down to -80°C, keep it work stable
at -80°C, after 3.5 hours, set the temperature below -80°C as desired. Factory setting at -80℃.
4. The high temperature alarm will be activated when the power is on. That's a normal
phenomenon. Once the temperature come down to the set point, the alarm will be closed. The
alarm buzzer voice could be eliminated by touch the MUTE button.
5. Articles could be stored inside the freezer after a 24-hour normal running. (Make batch
treatment to store articles, each time do not over a third, after 12 hours of normal running, then
store another a third .)
6. Do not open the door during the cooling process, will cause the temperature rise.
7. For back up cooling system, if installed, do not open it when the freezer is working properly.
When the freezer is failure, could turn on the system to keep the inside temperature at a proper
value.
4.6 First initial starting
ØThere must be an authorized person responsible for the freezer in customer's office, to
check the operation status and make daily record. The inside temperature of cabinet will rise
up during the failure problem, if it is not available to be repaired in a short time, take out the
stored items and transfer to other safe locations.
ØPrior to put the articles inside the freezer, should check if the temperature set range of this
device is matching the requirement of the articles.
ØDue to the Inertia of refrigeration, there is a little difference between the actual temperature
displayed on the controller and the set temperature. This is a normal phenomenon.
ØMeiling's ultra low temperature freezers are storage devices, do not put excess "hot"
samples into the freezers at one time, or will cause compressor damage after long time
working without stop. Attention to put in samples and set temperatures in batches.
ØDo not put electric devices in the freezers without permission.
ØDo not change the setting temperature frequently within a short time, or the current
temperature may not reach the setting temperature as the inertance; Do not cover sensors
in the freezer when you put in samples and keep some distances between the samples and
the inner side of the freezer to make sure the cold air will circulate successfully in the
freezer, or will cause the instability of the inner temperature and inaccuracy of the display
temperature.
CAUTION.
ØPlease use the wrench to rotate the supporting feet clockwise to extend them, so that it rests
on the ground. Make sure the freezer does not move when using.
4.4 Adjust the supporting Stand bar
7
4. Alarm code display
Alarm code Fault description
sensor failure
P1
high temperature alarm
HA
low temperature alarm
LA
door open alarm
dA
After the alarm sound is artificially eliminated in the fault state, the fault delay alarm will not start if a
new fault occurs, that is, the digital tube will flash to display the fault code, and the buzzer will no
longer alarm; The fault delay alarm will not be effective until all faults have been eliminated, and the
buzzer can re-alarm.
Do not immediately put any items in the medical freezer when just connect to the power. Let the
refrigerator run for a period (about 24 hours), and then put the items in the refrigerator.
When put in items to the refrigerator, if the item is too moist or too dry, it will affect the change of
humidity in the box. The item is best sealed and stored. Similarly, the humidity of the working environment of
the medical freezer will also affect the humidity change in the box, especially the excessive opening of the
door or the door is not closed.
Each time for storing items, they cannot exceed 1/3 of the cabinet capacity, after reach the
actual temperature and run normally for 24 hours, then put another 1/3 of the cabinet capacity items.
Please be careful not to block the air outlet and the air inlet when put in the items.
Do not place the item directly on the bottom of the medical freezer. It should be placed on the bottom
rack; otherwise it will affect the cooling effect of the medical freezer.
Do not open the door during the cooling process; otherwise it will cause the temperature to rise.
Due to the cooling inertia, the display temperature and the set temperature may be different when the
product reaches the set value and shutdown. This is a normal phenomenon.
Warning: Please keep the medical freezer out of reach of children.
7.Defrost, Unused and Maintenance
Warning:
In order to prevent personnel electric shock or injury, please cut off the power supply of the storage
box before any repair and maintenance to ensure that no drugs or suspended particles around the
device will be inhaled during the maintenance, otherwise it will endanger your health
7.1 Defrost, Unused and Maintenance
After working for a period of time, the inner surface of the product will be frosted, which will affect the
cooling effect and increase the power consumption. It is recommended that the frost layer should be
defrosted when it is too thick.
Turn off the power, open the door, and transfer the items to a cool place;
Use a defrosting shovel to gently remove the surface area cream (also let the temperature inside the
cabinet rise naturally, melting the frost);
In order to speed up the defrosting process, a flat-bottomed container filled with hot water of less than 50 °
C can be placed in a storage cabinet. Then use a dry cloth to clean the remaining ice water from other
places. Reload the item into the storage cabinet;
Turn on the power and turn it on.

11 9
6. Touch screen panel function description
On the normal working condition, the upper shows the real-time internal
temperature inside the freezer. (For example as 0.0℃), the lower
shows the setting temperature；
Fan running state: when the little symbol is rotating, shows the fan
that under the chamber is working normally.
Freezer running state: normally the freezer is working OK, and it
shows the “Normal running” .
if it happens the alarm, it will show the bell character.
The alarm system of this unit will be:
“communication error with control board” ,
Product expired,
Door open alarm,
PT100-1 failure(Sensor failure),
Condensor sensor failure error,
System failure,
High temperature alarm,
Low temperature alarm,
Ambient temperature sensor alarm,
Abnormal Voltage,
Abnormal current,
Condensor overheating and High ambient temperature.
CAUTION.
Alarm flashing can not be canceled until troubleshooting. When buzzer sound alarms, you
can press mute to turn off the alarm sound.
Warning：If the equipment is stored in an unsupervised area for a long time and unused, please ensure
that the child will not get close to the unit and the door cannot be completely closed. The disposal of
equipment should be carried out by corresponding personnel to prevent accidents such as asphyxiation.
Problem
The blood refrigerator does
not operate
Possible Cause
Is there electricity in the power plug?
Is the power switch ON ON the side of the blood refrigerator
turned ON?
Is the power plug plugged in or loose?
Is the power fuse disconnected?
Is the power supply voltage too low or too high?
Too noisy
The temperature does not
reach the set value
Frost in inner wall is too thick
Is the door not tight or open too many times?
Are you putting too many things in at once?
Is the ambient temperature too high?
Solution: Please leave the distance between the unit and the
wall around the best in more than 30 cm, and the outlet and
outlet should not be blocked, hot summer should pay
attention to room ventilation or open air conditioning.
(ambient temperature: 16 ~ 32 ℃)
Compressor does not work
Refrigerator is not leveled well.
Refrigerator leans upon the wall.
Is the ambient temperature too high for the compressor to
protect itself?
8.After-sales service
Any product has the possibility of failure, please observe the operation of the refrigerator in time in the process of
using. If there is any abnormality, please check and deal with it according to the table below. If the situation
cannot be changed, please contact our service center in time. We will serve you wholeheartedly so as not to
cause you any loss. Term of use: 10 years.
Note：DO NOT sprinkle water on the faces of cabinets, which may decrease insulating property of electric
parts and rust metal parts. DO NOT use hot water, corrosive cleanser and organic solvent! Condition:
Cannot shake heavily, strike, and prevent drench. Environment Temperature: -40℃～+55℃, Relative
humidity: 10％～90％.
7.2 Disposal of the Equipment
Note: Do not use sharp metal tools during defrosting to avoid damage to the storage cabinet.
If the product needs to be stopped for a long time, the power should be cut off, cleaned as
follows, and sealed after drying.
Before using it again, use a dry cloth to dry the water around the door of the cabinet.
Do not place heavy objects on top of the freezer to avoid deformation of the cabinet.

Temperature data download and read through U disk.
1.Downloading data to U disk：
(1).Find the USB port and insert the disk into the port, the screen will show dialogbox as
follows, click the “Upload”.
(Do not want to continue the next operation? No need to touch, will disappear in 10 seconds )
(2).Once click the “upload”,will popup the following dialog box: enter password “11111
1”,and click “OK”.
(3).choose the path to save the data, here is ordered to use: “disk_a_1”(as shown below),
click “OK”.
2.reading the data: Connect the U disk to computer, find:\history\datalog\001 as shown as
following：
10 14
Below are normal operations：
(1) compressor start, stop, switch parts creates a slight crash sound.
(2) Rainy wet season, the door surface may condensation, dry cloth can be wiped away.
(3) power failure for a long time, and did not turn off the general power switch, resulting in battery loss, re-energized
after the display is not normal, when the need to turn off the general power switch, 1 minute after the re-open can.
Before notifying the maintenance engineer, the user shall clean and disinfect the machine. Storage and transportation
conditions: no violent vibration or collision shall be allowed during transportation or use to prevent rain. Storage and
transportation environment temperature: - 40 ℃ ~ + 55 ℃,
relative humidity: 10% ~ 90%. Only when the machine is repaired, maintained or improved by the engineers approved
by Zhongke Meiling bio-medical treatment can we guarantee its normal operation and meet the corresponding safety
standards. The warranty period of the machine, if due to improper use of users caused by failure or damage, the
company will not assume the warranty obligations.
9. Specification
Medical Freezer/Ultra low temperature freezer
GL-F-10M
PCM color plate
Epoxy polyester powder coated steel plate
Built-in galvanized tube
Wire tube
Rigid polyurethane foam filling
Name
Model
Outside cabinet
Outside door
Condenser
Evaporator
Insulation
Compressor
Thermostat
Temperature sensor
Alarm system
Fully enclosed
Microcomputer control system
NTC
High/low temperature alarm, door ajar alarm, sensor
error alarm.

13 11
Setting temperature (Temperature): -10 ~ -86.
Correct the system time via this page.
High temperature alarm deviation value set (High Alarm): Normally we suggest to set at ℃ 10
(optional 5~15). When the internal temperature of freezer > “ Setting temperature + High
temperature alarm deviation value”, the High temperature alarm will be activated.
Low temperature alarm deviation value set (Low Alarm): Normally we suggest to set at ℃ 10
(optional 5~15)..When the temperature inside the freezer < “ Setting temperature + Low
temperature alarm deviation value”, the Low temperature alarm will be activated.
Mute. This function only temporarily close the alarm sound, will not affect the alarm
displays.
Data print(optional). The freezer is optional with printer, you can turn on the auto
print. Or select the historical data print.
. Performance
.1 Main Technical Parameter
10.2 Packing List
Name Operation manual Keys
GL-F-10M11×2
Model Ambient
temperature
Refrigerant Rated
frequen
cy
Rated
voltage
（V) （Hz）
Net
capacity
（L）
Rated
current
（A）
Exterior
dimension
(W*D*H)（mm）
Net
weight
（Kg）
Storage
temperature
(℃)
GL-F-10M16～32℃ R600a/97g 220 50 -10~-25 270 1.08 87 700×640×1792
(℃)
10.3 Electrical Diagram
If the product design is improved, the technical data and electrical schematic diagram shall be subject to the nameplate of the
product.
GL-F-10M
Defrost shovel
