OPERATION MANUAL
Applicable product model:
GL-F-16M

This product consists of door, chamber, electric control system,
refrigeration system and accessories.
The Ultra-low Temperature Freezer offers a wide variety of research and
storage applications, such as low temperature scientific experiments,
preservation of plasma, biomaterials, tunny, biological product, and testing low-
temperature-resistant properties of military product.
It is suitable for blood bank, hospitals, sanitation and anti-epidemic,
sanitation, research institutes, electronic industries, university laboratories,
military industries, pelagic fishery companies.
Top control technique：
High precision microcomputer temperature control system，
platinum thermistor sensor，temperature could be set between -10°C to -
86°C；
LED touch screen controller with 7”, clear display, easy to operate.
Gorgeously design for excellent appearance.
Refrigerating system：
Imported international brand high-efficient compressor, EBM fan
motor，powerful and more energy-efficient；
2-times foaming thermal insulation door，multi-patents outdoor
insulation design； Effectively prevent the loss of cooling capacity.
Cabinet uses high-performance vacuum insulation board， greatly
improved the insulation effect；
Humanization design：
Mechanical door handle， easy to open；
Adjustable multi-level shelves，easy to store articles；
Universal wheels with fixed support ，easy to move and fix；
Safety system：
With keyboard lock and password protection system, prevent from
un-authorized change of the parameters.
Multiple failure alarm system: Sensor failure alarm、High and low
temperature alarm、door open /ajar alarm、filter clogging alarm、system
failure alarm. Make sure the safety of the articles stored inside the
freezer；
Door with lock, prevent from the un-authorized opening.
Start delay and interval stop system to protect the reliable operation .
Content
1. Operation Instruction
2. Safety Notices
3. Precautions for Use
4. Installation
4.1 Installation Environment
4.2 Installation Site
4.3 Preparation Before Using
4.4 Standing
4.5 Power on for the First Time
5. Components and Overview
6. Display Panel Function Description
7. Defrost ●Unused ● Maintenance
7.1 Defrost
7.2 Unused and Maintenance
7.3 Disposal
8. After-sale Service
9. Specifications
10. Performance
10.1 Main Technical Parameter
10.2 Packing List
10.3 Electrical Diagram
1
2
4
4
4
4
5
5
6
10
10
12
13
15
15
15
15
5
7
10
11

2. PRECAUTIONS FOR SAFE OPERATION
1 2
For the first time to use this device, uses must read the meaning of the following
warning labels very carefully. Items and procedures are described so that you can
use this unit correctly and safely. If the precautions advised are followed, this will
prevent possible injury to the user and any other person.
WARNING.
Failure to observe WARNING signs could result in a hazard to personnel
possibly resulting in serious injury or death.
As with any equipment that uses CO2 gas, there is a likelihood of oxygen depletion in the
vicinity of the equipment. It is important that you assess the work site to ensure there is
suitable and sufficient ventilation. If restricted ventilation is suspected, then other
methods of ensuring a safe environment must be considered. These may include
atmosphere monitoring and warning devices.
Do not touch any electrical parts such as the power supply plug or any switches with a wet
hand. This may cause electric shock.
Only qualified engineers or service personnel should install the unit.
The installation by unqualified personnel may cause electric shock or fire.
WARNING.
Failure to observe WARNING signs could result in a hazard
to personnel possibly resulting in serious injury or death.
CAUTION.
Failure to observe WARNING signs could result in injury to
personnel and damage to the unit and associated property.
CAUTION HOT.
The sign inform the users about the danger of burns for high
temperature.
DANGER OF EXPLOSION.
The sign inform the danger of the application of volatile,
explosive chemical substances.
NO TILTING.
STAY OUT OF SUN.
BEWARE OF ELECTRIC SHOCK!
Dangerous voltage may cause personal injury! Please
disconnect the power supply before repair.
GROUNDING MARK.
NO TRAMPLING EQUIPMENT.
NO TUMBLING TRANSPORT
PACKAGES.
PRECISION INSTRUMENTS.
HANDLE WITH CARE.
THE CONTENTS MUST BE PLACED AT
THE ARROW.
FEAR OF THE RAIN.
NO STACKING.
NO CLAMPING.
1. Operation Instruction
I. Please use proper protective equipment.
II. Please keep good health habits.
III. Everyone is bound to be responsible for his/her safety.
Dear Customer:
Thank you for choosing to use Glacier Products. For your safe and convenient
use and reasonable maintenance of this product, please read the operation manual
carefully before use and keep it for your reference.
Equipment operators can copy some of the sections of this operating manual, but only
for internal use, such as: instructing users on how to handle incidents. The chapters
are clearly marked in the manual's catalog.
Glacier is not responsible or liable for any damage to the instrument caused by the
user's failure to use the device in accordance with the manufacturer's instructions.
Due to the rapid improvement of Glacier Products, the functions described in this
manual may not be consistent with the functions of the products you purchased.
Please refer to the actual functions.
Please read carefully the cautions and safety issues.
In order to make the device work properly, please follow the correct installation
method!
Medical freezer, ultra-low temperature freezer, combined refrigerator and
freezer can only be operated by trained and authorized personnel.
Maintenance of the equipment can only be carried out by agents authorized by
Glacier.
If the operator encounters a situation not mentioned in this manual, please contact the
authorized agent of Glacier to inquire
about the correct treatment.
Failure to use the equipment in accordance with the methods specified by the
factory may damage the protection provided by the equipment.
It is necessary to use accessories supplied by Glacier, such as compressors,
thermostats, sensors, fan motors, etc. If the user wants to use other accessories, it may
have adverse consequences such as performance, protection and service life.
The storage box must be inspected and maintained at regular intervals.
Due to the improvement of the product and the different models, the actual product
may be different from the simplified one. Please refer to the actual product!
The diagram is only an example to identify the function!
Warm tips:

1. INTRODUCTION
1 2
Thank you for choosing Meiling's bio-medical products.Read this manual
carefully before using the appliance and follow the instructions for the safety
operation.Keep this manual in an adequate place to refer to it as necessary.
Meiling never guarantee any safety if the appliance is used for any objects other
than intended use or used by any procedures other than those mentioned in this
manual.The contents of the manual will be subjected to change without notice due
to the improvement of performance or functions.Contact Meiling sales
representative or agent if any point in this manual is unclear or if there are any
inaccuracies.No part of this manual may be reproduced in any form without the
expressed written permission of Meiling.
uPlease read the page4-page7 carefully as it contains the important safety
notices.
uOnly trained or authorized personnel could operate this Ultra-low temperature
freezer.
uOnly qualified service personnel or authorized agent could install and
maintenance this device.
uUse Meiling spare parts as always. If users want to use other accessories,
Meiling bio-medical will not be responsible for the adverse consequences.
However users could apply for verifying the eligibility of these accessories from
Meiling before use them.
uShould inspect and maintenance the device in a specified time interval.
uDue to the differences between each models and the improvements of products,
actual product may differ from the diagram. Please refer to the final product.
uEveryone has an obligation to be responsible for his or her own safety.
uPut on dry gloves when you take out refrigerated articles from the freezer.
ucontents or the inside walls with naked hands may cause frostbit.
Handing frozen.
ucontents or the inside walls with naked hands may cause frostbit.
2.Safety Notices
For the first time to use this device, uses must read the meaning of the following warning labels
very carefully. Items and procedures are described so that you can use this unit correctly and safely.
If the precautions advised are followed, this will prevent possible injury to the user and any other
person.
CAUTION.
Failure to observe WARNING signs could result in injury to
personnel and damage to the unit and associated property.
WARNING：
Failure to observe WARNING signs could result in a hazard to
personnel possibly resulting in serious injury or death.
WARNING.
Failure to observe WARNING signs could result in a hazard to personnel possibly resulting in serious injury
or death.
As with any equipment that uses CO2 gas, there is a likelihood of oxygen depletion in the vicinity of the
equipment.It is important that you assess the work site to ensure there is suitable and sufficientventilation.If
restricted ventilation is suspected, then other methods of ensuring asafe environment mustbe considered.
These may include atmosphere monitoring and warning devices.
CAUTION HOT.
The sign inform the users about the danger of burns for high
temperature.
DANGER OF EXPLOSION
The sign inform the danger of the application of volatile,
explosive chemical substances.
NO TILTING . STAY OUT OF SUN.
Do not touch any electrical parts such as the power supply plug or any switches with a wet hand.This may
cause electric shock.
Only qualified engineers or service personnel should install the unit.
The installation by unqualified personnel may cause electric shock or fire.
Be sure to install the unit on a sturdy floor. If the floor is not strong enough or the installation site is not
adequate, this may result in injury from the unit falling or tipping over
Carefully with the power cord to avoid short circuit or open circuit.When removing the plug from the power
supply outlet, grip the power supply plug, not the cord.Pulling the cord may result in electric shock or fire by
short circuit. Don't make the power line pack and pressed by furnish or heavy goods.Also please don't close
to the compressor and heat source.
Please insert the power plug firmly to avoid leakage.
Use a power supply outlet with ground (earth) to prevent electric shock. If the power supply outlet is not
grounded, it will be necessary to install a ground by qualified engineers.
Don't lengthen the line randomly. If you need, To use 2.5mm2 copper line,you should keep 4mm2 line to
connect the electrical outlet. Or may cause fire.
Make sure a dedicated power source is used as indicated on the rating label attached to the unit. Out of the
rate, should install a property transformer and a proper voltage stabilizer for securely operation. Or the
freezer may be damaged, and may cause injury.
Be sure to installthe unit on a sturdy floor, no shaking and tilting.
Never install the unit in a flammable or volatile location. This may cause explosion or fire.
Never install the unit in a humid place or outdoor or a place where it is likely to be basked
straightly.Deterioration of the insulation may result which could cause current leakage or electric shock.
Do not place the devicelateral tilt, do not impact the device; the device is equipped with refrigeration
systems, roll or shock will easily damage the freezer.

3 4
Make sure a dedicated power source is used as indicated on the rating label attached to the
unit. Out of the rate, should install a property transformer and a proper voltage stabilizer for
securely operation. Or the freezer may be damaged, and may cause injury.
Make sure to put the freezer in a dry and ventilated environment, to ensure that equipment
vents and wall surface of the instrument or other items have not been blocked; Do not use the
device in a poorly ventilated environment, or the equipment may be damaged by the
release of heat.
Never disassemble, repair, or modify the unit yourself.
Any such work carried out by an unauthorized person may result in fire or injury due to a
malfunction. Meling will be no responsible for such work.
Use this unit in safe area when treating the poison, harmful or radiate articles. Improper use
may cause bad effect on your health or environment.
Never ground the unit through a gas pipe, water main, telephone line or lightning rod. Such
grounding may cause electric shock in the case of an incomplete circuit.
Use a power supply outlet with ground (earth) to prevent electric shock. If the power supply
outlet is not grounded, it will be necessary to install a ground by qualified engineers.
CAUTION.
Failure to observe WARNING signs could result in injury to personnel and
damage to the unit and associated property.
Ultra-low temperature freezer is not available to store living things, flowers, or other
critical articles which is not suitable for low temperature storage.
The temperature inside the freezer is very low during the normal working. Do not touch
the interior surface of the chamber or the object inside without wearing protective gear.
Always disconnect the power plug when the unit is not used for long periods.
Make sure to prepare a safety check sheet when you request any repair or maintenance
for the safety of service personnel. Be sure to check set point of the controller prior to
restart the freezer.
The ultra-low temperature freezer is a storage device, not a production equipment!
Always hold the handle when closing the door. This will reduce the likelihood of a trapped
finger.
Keep the key properly avoiding the children take it to open the door which may result in
unexpected injury.
CAUTION：
Failure to observe WARNING signs could result in injury to personnel and damage to the unit and associated
property.
Be sure to install the device in a dry dust-free environment to avoid overheating, short circuit and other dangers
If there is an unexpected sound, smell, smoke when the power is turned on, unplug the power and contact
the manufacturer or supplier.Continuedabnormal operation may cause electric shock or fire.
Make sure to put the freezer in a dry and ventilated environment, to ensure that equipment vents and wall
surface of the instrument or other items have not been blocked; Do not use the device in a poorly ventilated
environment, or the equipment may be damaged by the release of heat.
Never disassemble, repair, or modify the unit yourself.
Any such work carried out by anunauthorized person may result in fire or injury due to a malfunction. Meiing
will be no responsible for such work.
Never store volatile or flammable substances in this unit. This may cause explosion or fire.Never store
corrosive substances in this unit. This may lead to damage to the inner componentsor electric parts.
Use this unit in safe area when treating the poison, harmful or radiate articles. Improper use may cause bad
effect on your health or environment.
Never ground the unit through a gas pipe, water main, telephone line or lightning rod. Such grounding may
cause electric shock in the case of an incomplete circuit.
Use a power supply outlet with ground (earth) to prevent electric shock. If the power supply outlet is not
grounded, it will be necessary to install a ground by qualified engineers
The medical freezeris not available to store non-living things, flowers, or other critical articles which is not
suitable for low temperature storage.
The temperature inside the freezer is very low during the normal working.Do not touch the interior surface of
the chamber or the object inside without wearing protective gear.
Always disconnect the power plug when the unit is not used for long periods.
Make sure to prepare a safety check sheet when you request any repair or maintenance for the safety of
service personnel. Be sure to check set point of the controller prior to restart the freezer.
The medical freezer is a storage device, not a production equipment!
Always hold the handle when closing the door. This will reduce the likelihood of a trapped finger.
Keep the key properly avoiding the children take it to open the back door which may result in unexpected injury.
Select a level and sturdy floor for installation. This precaution will prevent the unit from tipping.
Improper installation may result in water spillage or injury from the unit tipping over.
Check the filter mentioned in this manual and clean it as necessary. A dusty filter may cause.
Do not tilt the unit more than 45 degrees when moving the unit. All transportation should be carefully.

3 4
Be sure to install the unit on a sturdy floor. If the floor is not strong enough or the installation
siteis not adequate, this may result in injury from the unit falling or tipping over.
Carefully with the power cord to avoid short circuit or open circuit. When removing the plug
from the power supply outlet, grip the power supply plug, not the cord. Pulling the cord may
result in electric shock or fire by short circuit. Don't make the power line pack and pressed by
furnish or heavy goods. Also please don't close to the compressor and heat source.
Please insert the power plug firmly to avoid leakage.
Use a power supply outlet with ground (earth) to prevent electric shock. If the power supply
outlet is not grounded, it will be necessary to install a ground by qualified engineers.
Don't lengthen the line randomly. If you need, To use 2.5mm2 copper line, you should keep
4mm2 line to connect the electrical outlet. Or may cause fire.
Make sure a dedicated power source is used as indicated on the rating label attached to the
unit. Out of the rate, should install a property transformer and a proper voltage stabilizer for
securely operation. Or the freezer may be damaged, and may cause injury.
Be sure to install the unit on a sturdy floor, no shaking and tilting.
Never install the unit in a flammable or volatile location. This may cause explosion or fire.
Never install the unit in a humid place or outdoor or a place where it is likely to be basked
straightly. Deterioration of the insulation may result which could cause current leakage or
electric shock.
Do not place the device lateral tilt, do not impact the device; the device is equipped with
refrigeration systems, roll or shock will easily damage the freezer.
Be sure to install the device in a dry dust-free environment to avoid overheating, short circuit
and other dangers.
If there is an unexpected sound, smell, smoke when the power is turned on, unplug the power
and contact the manufacturer or supplier. Continued abnormal operation may cause electric
shock or fire.
3.Precautions for Use
4. Installation
◆Before you put the items to the medical freezer, please make sure whether the temperature in the refrigerator has
reached the set temperature and then put the items to the refrigerator in batches. No more than 1/3 of the refrigerator
rating volume per time, in case the temperature rises too much.
◆Medical freezer temperature display value shows the temperature around the temperature sensors. Sometimes, there
is certain difference between the display temperature and the actual temperature in the center of the refrigerator, but it
will gradually close to the real temperature.
◆Clean the refrigerator with the diluted neutral detergent. Do not use brushes, acid, gasoline, soap powder, polish or
hot water to clean the medical freezer, as the above material may damage the painted surface and plastic rubber parts.
Be careful not to use volatile solvents such as gasoline to wipe plastic rubber parts.
◆The power should be cut off while the medical freezer does not use for a long time. .
4.1 Installation environment：
Ambient temperature：16℃ ～ 32℃ ,optimal ambient temperature : 18℃ ～ 25℃ ， Air conditioning
system is required if necessary.
Relative humidity：≤80%RH.
No strong vibration and no corrosive gases around.
Without the presence of a lot of dust .
No shaking or vibrating of the freezer.
Altitude of the place where the freezer is located ：≤ 2000m
Input voltage ≤220+10% (V).
No direct sunlight or any other cooling or heating source, no electromagnetic interference, or the freezer
will not run properly.
4.2 Installation site：
This unit is a precision machine. When select a location to install this unit, keep the following conditions for perfect
performance
Should not be installed in a small confined space, the door of the room should not be less than height of the
present equipment.
Install the unit on a sturdy floor to avoid excessive vibration and noise.
Installing the unit in direct sunlight may cause malfunctioning and may shorten the life of the
unit. Keep good ventilation is necessary.
Socket inputs should be connected to circuit protection facilities,
Checking the working voltage of the place before start the freezer. A voltage stabilizer is
suggested to be used at the place where the voltage is not stable. Make sure the normal input voltage
stable at or 220V± 10%, Power of voltage stabilizer should be more than 4KW.
Be sure to ground the unit；
If the power cord socket is equipped with grounding wire, check the connection before use.
If the power supply outletis not grounded, it will be necessary to install a ground by qualified engineers

5 6
4. Installation
4.1 Installation environment：
ØAmbient temperature：10℃～32℃,optimal ambient temperature :18℃～25℃, air
conditioning system is required if necessary.
ØRelative humidity：≤80%RH.
ØNo strong vibration and no corrosive gases around.
ØWithout the presence of a lot of dust .
ØNo shaking or vibrating of the freezer.
ØAltitude of the place where the freezer is located ： ≤ 2000m
ØInput voltage ≤115±10% (V).
ØNo direct sunlight or any other cooling or heating source, no electromagnetic interference,
or the freezer will not run properly.
ØKeep the distance between the freezer and the surrounding wall of 30 cm or more, and the
air outlet must not be obstructed, pay attention to room ventilation or opening air conditioner
during the hot summer.
CAUTION.
Since the ambient temperature has a great impact on the operation of the freezer. If the
freezer is installed in the other situations instead of above conditions, the freezer will not
run properly.
4.2 Installation site：
This unit is a precision machine. When select a location to install this unit, keep the following
conditions for perfect performance ：
ØShould not be installed in a small confined space, the door of the room should not be less
than height of the present equipment.
ØInstall the unit on a sturdy floor to avoid excessive vibration and noise.
ØInstalling the unit in direct sunlight may cause malfunctioning and may shorten the life of the
unit. Keep good ventilation is necessary.
ØDo not share a socket with other equipment, plug and socket should be securely
connected。
ØSocket inputs should be connected to circuit protection facilities, such as: An air switch
which the rated current is bigger than 45A.
Ø2 If an extension cord is needed, be sure to use copper wire more than 2.5mm . The cross-
sectional area of the copper wire inside the wall connected with the power outlet must also
2
be more than 4mm .
ØChecking the working voltage of the place before start the freezer. A voltage stabilizer is
suggested to be used at the place where the voltage is not stable. Make sure the normal
input voltage stable at 115V ± 10% or 208V± 10%, Power of voltage stabilizer should be
more than 4KW.
ØBe sure to ground the unit.
ØGrounding prevents electric shock which occurs when the electrical insulation of the unit
becomes insufficient.
ØIf the power cord socket is equipped with grounding wire, check the connection before use.
ØIf the power supply outlet is not grounded, it will be necessary to install a ground by qualified
engineers.
ŸMake sure of using a plug with earth provision and to ground the unit to prevent the electric
shock in the event of the current leakage.
ŸSubstituting a water pipe for the ground terminal will not provide proper grounding in many
instances since plastic pipes are often used for water piping.
ŸNever ground the unit through a bas pipe, as it is very dangerous.
ŸNever ground the unit through the telephone line or lightning rod, as large currents flow if
lightning strikes, making it very dangerous.
WARNING.
b. Check the device, accessories and document with the device as per list of packing
c. Clean：make a clean of the device before use it.
d.Before use, make sure the temperature control probe is immersed in the test liquid.
4.4 Standing
a. Remove all package components（include the protection foam inside the package）
Caution：Do not put the packing plastic bag within reach of children as suffocation may result
Do not turn on the freezer at once when the freezer is well located, must wait 24 hours for the first start.
4.5 Power on for the First Time
Operate as follows for the first start：
1. Connect the power cord to the appropriate socket during no-loading。
2. Check the temperature to achieve the required temperature, medical refrigerator for normal open stopped
more than 24 hours, after equipment performance is normal, can put a small amount of items placed in medical
refrigerating box.(please store items in batches of no more than 1/3 box volume each time. Make sure
the medical freezer is out of service, and have the normal opening and stopping for more than 12 hours
before putting into the other no more than 1/3 of the box volume items.
3. Do not open the door during the cooling process, will cause the temperature rise。
4. There must be an authorized person responsible for the freezer in customer's office, to check the operation
status and make daily record. The inside temperature of cabinet will rise up during the failure problem, if it is not
available to be repaired in a short time, take out the stored items and transfer to other safe locations.
5. Prior to put the articles inside the freezer, should check if the temperature set range of this device is
matching the requirement of the articles.
6. Due to the Inertia of refrigeration, there is a little difference between the actual temperature displayed on the
controller and the set temperature. This is a normal phenomenon.
7. Medical freezers are storage devices, do not put excess "hot" samples into the freezers at one time, or will
cause compressor damage after long time working without stop. Attention to put in samples and set temperatures in
batches.
8. Do not put electric devices in the freezers without permission.
9. Do not change the setting temperature frequently within a short time, or the current temperature may not reach the
setting temperature as the inertance; Do not cover sensors in the freezer whenyou put in samples and keep some distances
between the samples and the inner side of the freezer to make sure the cold air will circulate successfully in the freezer, or
will cause the instabilityof the inner temperature and inaccuracy of the display temperature.
10. Operation after power failure.
11. The freezer controller has memory of the set point. The freezer will continue to follow the previous
operations when restart the freezer after the power failure. The restart should be done after 5 minutes in case to
damage the compressor.
Warning
●Don't through gas pipe, water pipe, line or lightning rod to medical grounding cooler, easy cause electric shock
●After installation, power plug must be within reach, convenient unplug the power cord in time in case of an
emergency
●Any articles shall not cover medical air vents of the medical freezer
4.3 Preparation before using

5 6
3. Precautions for use
Select a level and sturdy floor for installation. This precaution will prevent the unit from
tipping. Improper installation may result in water spillage or injury from the unit tipping
over.
Check the filter mentioned in this manual and clean it as necessary. A dusty filter may
cause temperature rise or failure.
Do not tilt the unit more than 45 degrees when moving the unit. All transportation should
be carefully.
uWhen the freezer is running, the front part of the freezer may get hot. This is not a
malfunction: In order to prevent dew condensation around the case body, a heated anti-
condensation tube is installed in the cryogenic storage case.
uBefore putting the items in the freezer, please make sure the temperature inside the box has
reached the set temperature, and then put the items in batches. Add no more than 1/3 of the
container volume each time, in case the temperature rises too much.
uThe temperature display value shows the temperature of temperature sensors inside the
freezer. Although the displayed temperature may sometimes differ from the actual
temperature in the center of the freezer, it will get close to the real temperature gradually.
uA through-hole is installed on the right or back of the freezer to allow test lines to exit the
test box. After drawing out the test lines, be sure to re-plug the test hole with insulating
material, otherwise the temperature inside the box will not be completely lowered, resulting
in condensation around the outside of the hole.
uClean the freezer with diluted neutral detergent. Do not use brushes, acid, gasoline, soap,
polish or hot water to clean the frozen storage container, as these materials may damage
the painted surfaces and plastic rubber components.
uAfter a period of operation, a layer of frost will form on the inner wall and the inner door. If
the frost layer is too thick, it will affect the insulation effect of the freezer and increase the
power consumption. Therefore, after a period of time, when the frost layer reaches about
5mm, it should be defrosted with the defrost shovel attached.
uPlease remove the frozen items in the freezer and put them in a suitable storage
environment before defrost, so as to avoid the damage of goods for temperature rise.
uThere are many cooling coils on the back and side of the inner wall. Don't use sharp objects
such as knives, ice chisel, or screwdrivers to remove the frost on the inner wall. Be careful
not to scratch the inner wall when defrosting, otherwise it will cause a failure of the freezer .
uCut off the power when the refrigerated storage box will not be used for a long time.
5. Components and Overview
Dispaly control panel
Cabinet
Adjustable foot
Movable casters
Door handle
Door lock
Door handle
1. Due to the improvement of the product and the different models, the actual product may
be different from the diagram. The above figure is only an example of the identification function.
2. Structure and composition: Cabinet, door body, refrigeration system, control system and
accessories. Medical refrigerators and freezers are suitable for hospitals, epidemic prevention
stations, blood banks, research institutes, universities, genetic engineering, companies, etc.
3. The storage temperature inside the box can be adjusted through the temperature button
on the control panel, which is convenient to use and reliable in performance.
Door

8
5. Freezer Components
ØThe freezer controller has memory of the set point. The freezer will continue to follow the
previous operations when restart the freezer after the power failure. The restart should be
done after 5 minutes in case to damage the compressor.
Caution: Meiling will not be responsible for the safety ofthe stored articles.
4.7 Operation after power failure
File box
Touch screen
controller
Door handle
with lock
Wheels
Stand bar
USB port
Door
Power lock
and Back-up
Battery lock
(do not open it till power failure)
Air inlet and
Condenser
filter net
(Please clean it up regularly )
7
6. Display panel function description
（1）Control board introduction:
a. Both -25 are temperature display windows. In normal operation, the average
temperature of the upper and lower chambers of the cabinet is displayed in °C; different
prompt characters can be displayed in the setting state (see below for details).
b. Door opening indicator : when the door is opened, the indicator light will be on. when the
door is opened more than 1 minute, the indicator lighting with buzzer alarm, display "door".
c. Fault indicator: The indicator is off when the product is operating normally; the indicator is
on when the product is operating abnormally.
d.“PRINT”: The system can retain 7 days of data for printing. Press the Print key to print the
temperature for the set period of time.
e. : In parameter setting mode, move to the previous parameter or decrease the value of
the parameter. For example, when setting the set temperature, reduce the set temperature.
When setting the parameter value, long press the key to quickly decrease the parameter.
f. : In parameter setting mode, you can move to the next parameter or increase the value
of the parameter. For example, when setting the set temperature, increase the set
temperature value. When setting the parameter value, press and hold the up button for a long
time and the parameter will increase rapidly. Under normal conditions, press and hold the key
for 3 seconds to import the U disk for 12 months.
g. is the button for set/mute, when there is no alarm state and the key is not unlocked,
press , displaying ambient temperature for 5 seconds restores normal display; In the
unlocked state, press for 3 seconds, can enter the user menu. When buzzer alarm
(including cabinet temperature over temperature alarm, door open alarm, sensor fault alarm,
etc.), in the locked state, first time press , Buzzer stops tweeting, 5 seconds after
showing ambient temperature, resume normal display(The key mute is only to turn off the
buzzer of this abnormal state alarm. If the fault is eliminated, the buzzer will continue to alarm
when the next exception occurs), press again, buzzer alarms, After the ambient
temperature is displayed for 5 seconds, the cabinet temperature and alarm status are
restored. When the press is under unlocked state, can be used as a set button.
In the unlock state, in the parameter setting mode, press this key to display the value and the
parameter name. If the pressed time is longer than 3 seconds, the setting is saved and the
normal interface is returned.
ab
d printer(optional)
e
f
g
c

8
4.3 Cautions before use：
ØRemove all package components (include the protection foam inside the package)
Caution: Do not put the packing plastic bag within reach of children as suffocation may result。
ØCheck the device, accessories and document with the device as per list of packing
ØClean：make a clean of the device before use it.
ØDo not turn on the freezer at once when the freezer is well located, must wait 24 hours for the
first start.
4.5 Standing
Operate as follows for the first start：
1. Connect the power cord to the appropriate socket during no-loading.
2. Turning on the power-lock at the right-side of the bottom. (If a back-up cooling system is
installed with, turn off its power at first ).
3. Set the desired temperature point between -10°C to -86°C, for the best performance of the
machine, when the user need to set the temperature below -80°C, should set the temperature
at -80°C at first, once the temperature of the freezer come down to -80°C, keep it work stable
at -80°C, after 3.5 hours, set the temperature below -80°C as desired. Factory setting at -80℃.
4. The high temperature alarm will be activated when the power is on. That's a normal
phenomenon. Once the temperature come down to the set point, the alarm will be closed. The
alarm buzzer voice could be eliminated by touch the MUTE button.
5. Articles could be stored inside the freezer after a 24-hour normal running. (Make batch
treatment to store articles, each time do not over a third, after 12 hours of normal running, then
store another a third .)
6. Do not open the door during the cooling process, will cause the temperature rise.
7. For back up cooling system, if installed, do not open it when the freezer is working properly.
When the freezer is failure, could turn on the system to keep the inside temperature at a proper
value.
4.6 First initial starting
ØThere must be an authorized person responsible for the freezer in customer's office, to
check the operation status and make daily record. The inside temperature of cabinet will rise
up during the failure problem, if it is not available to be repaired in a short time, take out the
stored items and transfer to other safe locations.
ØPrior to put the articles inside the freezer, should check if the temperature set range of this
device is matching the requirement of the articles.
ØDue to the Inertia of refrigeration, there is a little difference between the actual temperature
displayed on the controller and the set temperature. This is a normal phenomenon.
ØMeiling's ultra low temperature freezers are storage devices, do not put excess "hot"
samples into the freezers at one time, or will cause compressor damage after long time
working without stop. Attention to put in samples and set temperatures in batches.
ØDo not put electric devices in the freezers without permission.
ØDo not change the setting temperature frequently within a short time, or the current
temperature may not reach the setting temperature as the inertance; Do not cover sensors
in the freezer when you put in samples and keep some distances between the samples and
the inner side of the freezer to make sure the cold air will circulate successfully in the
freezer, or will cause the instability of the inner temperature and inaccuracy of the display
temperature.
CAUTION.
ØPlease use the wrench to rotate the supporting feet clockwise to extend them, so that it rests
on the ground. Make sure the freezer does not move when using.
4.4 Adjust the supporting Stand bar
7
h. USB data (optional)
Automatic export: When the USB flash drive is connected to the USB interface, the buzzer
will beep once after the data transfer is completed, the upper room displays "Usb", and the
lower room displays "on". The U disk generates the PDF of the current month and the
previous month. After the data transmission is completed, the buzzer will beep once, "End"
will be displayed, and the normal display will be restored after 6 seconds
Note: when the data is small, the digital tube will not display "Usb", "on" and "End".
Manually export: If the button is under locked state, after connecting U disk well and
buzzer alarm for one time, press upper button for 3 seconds, digital tube display “d01”,
Press the up button or down button to adjust “d00~d12”, press , The U disk internally
generates a PDF file that generates this file (d00) or generates the data recorded in the
previous month (1-12).
Note: When the digital tube alarm flashes "LoF", the recorder does not start; press the
and for 3 seconds, "LoF" disappears and the recorder starts.
（2） Function settings
a. Power on, open the power switch on the back of the cabient, the machine can enter the
working state;
b. User parameter settings:
Unlock: In the normal running state, press the key and for 3 seconds at the same
time, the upper room digital tube will display the parameter code "PS1", the lower room
digital tube will display the parameter code "0000", press the and input the password
"0005" (enter the user menu password, enter "0099" to restore the key lock password to the
default "0005"), Unlock at this time. Press the key for 3 seconds after unlocking, the
digital tube displays the parameter code "PS1" and enters the setting adjustment.
①Use to scroll through the parameters. The display order is b1-b2-Set1-H01-L01-
Set2-H02-L02-n-y-r-S-F-Pt-tH1-P1-PS1.
② Use and to increase or decrease the value;
③ Press to temporarily store the modified value and return to the display parameter;
④ If you modify other parameters, please repeat steps 1~3.
⑤ Press for more than 3 seconds to store the modified parameters and return to the
display parameters interface.
c. Press for more than 3 seconds, or no button is pressed within 60 seconds, the
parameter setting will be exited.
d. Parameter display
1 b1 －－ 3.0 Hardware Version
2 b2 －－ 4.1 Software Version
3 Set1 YL:-10~-25 YL:-25 Temperature setting for upper chamber
4 H01 0.0~10.0 5.0 High temperature alarm setting value is set+H,
and when H is equal to 0, the alarm is canceled.
When the temperature is too high, the high
temperature alarm shows H01.
FL:-10~-40 FL:-40

9 10
As the product's improvement, the actual product may be different from the
illustration, please refer to the actual product.
The illustration is for reference only.
The moisture on the cabinet inner seal, inner door seal and outer door seal shall be
cleaned before using the storage box every time to poorrevent the door from freezing at
low temperature, which makes the door hard to open.
Inner door
seal
Outer door
seal
Inner door
Cabinet inner
seal
Test port
Shelves
Shelves frame
Inner door
Vacuum
release
port
Condenser
filter net
Printer Settings:
（1)Automatic printing: When the printing interval Pt is not 0, the printer will print the current
data every Pt minute.
Note: when the print interval Pt is less than the record interval SCy, print according to the record
interval;The remaining print intervals are printed at integer multiples of the record interval SCy, i.e.,
the print interval Pt shall set the integer multiples of the bit record interval.
(2) Manual printing: keys unlocked state and normal working voltage, digital tube display "P01",
press the print key press to raise or lower key adjustment "P00 ~ P07", press the set/mute reuse
key or the print button, cancel the manual printer print (P00) or print the current push days (1 ~ 7)
recorded data, print data with automatic printing intervals.
(3) Alarm code display
Alarm code Fault description
H01
L01
H02
L02
H03
Pr
E2
bL
Upper chamber high temperature alarm
Upper chamber low temperature alarm
Lower chamber high temperature alarm
Lower chamber low temperature alarm
High ambient temperature alarm
U disk generated file error
Upper chamber temperature sensor alarm
Low battery alarm
door
PF
Door ajar alarm
Power failure alarm
EE Communication failure alarm
Note: When adding USB or printer, ER (recorder not connected) and LoF (recorder not
activated) abnormal alarm are valid.
5L01 0. 0~10.0 5.0 Low temperature alarm setting value is set-L,
and when L is equal to 0, the alarm is canceled.
When the temperature is too low, the low
temperature alarm shows L01.
6Set2YL:-10~-25 YL:-25 Temperature setting for lower chamber
7H020. 0~10.0 5.0 High temperature alarm setting value is set+H,
and when H is equal to 0, the alarm is canceled.
When the temperature is too high, the
high temperature alarm shows H02.
8 L020. 0~10.0 5.0 Low temperature alarm setting value is set-L,
and when L is equal to 0, the alarm is canceled.
When the temperature is too low, the
low temperature alarm shows L02.
9 Pt 0~240 minutes 20 Print interval
10 tH1 20.0~50.0℃ 50 Upper limit of ambient temperature alarm
11 PS1 0000~9999 0005 Setting of user's menu password
E4 Lower chamber temperature sensor alarm
FL:-10~-40 FL:-40

9 10
Power lock
and Back-up
Battery lock
(do not open it till power failure)
Open to clean
the Condenser
filter net
Inner door
Cabinet inner
seal
Test port
Shelves
Shelves frame
Outer door
seal
Inner door
seal
Just to switch on the power supply for medical freezer do not immediately add items, make empty operation after a
period of time (about 24 hours), then refrigerated goods into storage box.
To add items, if the item is too much water or excessive drying will influence the change of the humidity, the best
goods sealed; the same medical freezer working environment humidity size will also affect the change of the humidity
of the door and the door body ,especially too much not close well.
For each store items can not exceed 1/3 box capacity, achieve the actual temperature and normal operation after 24
hours, then add another 1/3 box storage capacity.
To add items please do not block the outlet and inlet.
The goods can not be placed directly on the bottom of the medical freezer should be placed on the bottom shelf,
otherwise the effect of medical freezer cooling effect.
The cooling process as far as possible not to open the door, otherwise it will cause temperature rise.
Due refrigeration inertia, the product reaches a set value when stopping the display temperature and the set temperature
may have a certain difference, this is the normal phenomenon.
Note: children are not allowed to play games in a medical freezer.
Caution
For personal safety, please cut the power supply before any maintenance!
Don't inhale medications or aerosols around the device while maintaining a medical freezer, or it will endanger
your health.
7.Defrost ●Unused ● Maintenance
After the product has been working for a period of time, its internal surface will be frosted, which will affect the
cooling effect and increase the power consumption. It is recommended that defrosting should be performed when
the frost layer is too thick.
Cut off the power, open the door, and transfer the items to a cool place.
Use a defrost scoop to gently remove the surface area cream (Also allow the temperature inside the tank to
naturally rise, melt the frost)
In order to speed up the defrosting process, flat bottom containers with less than 50°C hot water can be placed in
a medical freezer.
Then use a dry cloth to wipe off any remaining ice water. Return items to the medical refrigerator.
Power on, power on cooling.
7.1 Defrost
Warning: Do not use sharp metal appliances during defrosting to
avoid damage to the medical freezer.
7.2 Unused and Maintenance
If the product needs to be stopped for a long time, the power should be cut off, cleaned
according to following methods, and sealed after opening and drying.
Before using it again, apply a dry cloth to dry the water around the door.

11 12
Telecommunication: Optional function, if do not order this function, please do not
touch it. The detail manual will be supplied once you choose this function.
Data Browser: The current or the latest temperature curve can be read. Please note
that there is a USB access port On the right side of screen board.
System time. The time is changeable by entering factory setting
mode.( this operation is only authorized to local service agent).
Parameter setting. The user's initial password is 0000.Before you enter the
password, only can browse the data, others operations are not available.
Enter initial password. When you put the wrong umber, it will show error:
Do not place heavy objects on the top of the medical freezer to avoid deformation
of the box.
At regular intervals, the medical freezers are cleaned and maintained once. (For
safety reasons, the power plug must be unplugged before scrubbing.)
Wipe the inner and outer surfaces of the freezer with a soft, damp cloth.
When the dirt is serious, wipe it with a neutral detergent for washing utensils, then wipe
the water with a soft cloth.
Once this product is activated, it is best to use it continuously.
Note: Do not spray water directly on the cabinet, so as to avoid degradation of electrical
components and metal parts rust. Do not use hot water and corrosive cleaners or organic
solvents to clean the cabinet.
7.3 Disposal
WARNING: If the equipment is left unused in an unsupervised area for extended
periods of time, make sure that the child does not get close to the cabinet and that the
door cannot be completely closed. Disposal of cabinets should be performed by
appropriate personnel to prevent accidents such as asphyxiation.

11 12
6. Touch screen panel function description
On the normal working condition, the upper shows the real-time internal
temperature inside the freezer. (For example as 0.0℃), the lower
shows the setting temperature；
Fan running state: when the little symbol is rotating, shows the fan
that under the chamber is working normally.
Freezer running state: normally the freezer is working OK, and it
shows the “Normal running” .
if it happens the alarm, it will show the bell character.
The alarm system of this unit will be:
“communication error with control board” ,
Product expired,
Door open alarm,
PT100-1 failure(Sensor failure),
Condensor sensor failure error,
System failure,
High temperature alarm,
Low temperature alarm,
Ambient temperature sensor alarm,
Abnormal Voltage,
Abnormal current,
Condensor overheating and High ambient temperature.
CAUTION.
Alarm flashing can not be canceled until troubleshooting. When buzzer sound alarms, you
can press mute to turn off the alarm sound.
③The slight flowing noise of running water in the refrigerant pipe.
④Before call the service engineer,Please clean and disinfect the freezer.
Condition:Cannot shake heavily,strike,prevent to drenching.
Storing environment temperature:-40℃～+55℃, Relative humidity: 10％～90％.
8. After-sale Service
Any product has the possibility of failure. Please observe the operation of the medical freezer in the process of use.
If there is any abnormality, please check and compare the errors with the following table.If you can't fix the issue, Please
inform our service center in time. We will serve you wholeheartedly to avoid any losses.
Term of use: 10 years
Troubles
Compressor doesn’t work
Reason and solutions
Does the power plug have electricity
The power plug is inserted or loose.
Is the power fuse disconnected?
Is the power supply voltage too low or too high
Whether the door is closed or the door is open too often?
Do you have too many items at one time?
Is the ambient temperature too high?
Temperature setting is correct or not ?
Is the temperature inside the box too low?
Is the box placed on a flat floor?
Does the cabinet hit the wall?
During the rainy and humid season, the window may
condense, which is normal. Wipe it off with a dry cloth.
The unit doesn’t work
Temperature does not reach
the set value
Big noise
Glass window surface
condensation
● Below are normal operations：
①There are some light clashes when the compressor starts up and stops.
②After opening the door and put in the hot subjects, the controlling system appears high temperature and high
humidity alarm.solution：The hot subjects should be cooled by natural cooling and then put into the cooler. Do not put
too many subjects at one time. After the system is stable, the high temperature and high humidity alarm will be relieved.

Temperature data download and read through U disk.
1.Downloading data to U disk：
(1).Find the USB port and insert the disk into the port, the screen will show dialogbox as
follows, click the “Upload”.
(Do not want to continue the next operation? No need to touch, will disappear in 10 seconds )
(2).Once click the “upload”,will popup the following dialog box: enter password “11111
1”,and click “OK”.
(3).choose the path to save the data, here is ordered to use: “disk_a_1”(as shown below),
click “OK”.
2.reading the data: Connect the U disk to computer, find:\history\datalog\001 as shown as
following：
13 14
9.Specifications
Name
Model
Outside cabinet
Outside door
Condenser
Evaporator
Insulation
Compressor
Alarm system
Rigid polyurethane foam filling
Fully enclosed
Medical freezer/Ultra-low temperature freezer
GL-F-16M
PCM color plate
Epoxy polyester powder spray coated steel plate
Wire tube condenser
Wire Tube Evaporator
Microcomputer control
NTC
High/low temperature alarm, door ajar alarm, power failure
alarm, low battery alarm, sensor error alarm.
Thermostat
Temperature
sensor

13 14
Setting temperature (Temperature): -10 ~ -86.
Correct the system time via this page.
High temperature alarm deviation value set (High Alarm): Normally we suggest to set at ℃ 10
(optional 5~15). When the internal temperature of freezer > “ Setting temperature + High
temperature alarm deviation value”, the High temperature alarm will be activated.
Low temperature alarm deviation value set (Low Alarm): Normally we suggest to set at ℃ 10
(optional 5~15)..When the temperature inside the freezer < “ Setting temperature + Low
temperature alarm deviation value”, the Low temperature alarm will be activated.
Mute. This function only temporarily close the alarm sound, will not affect the alarm
displays.
Data print(optional). The freezer is optional with printer, you can turn on the auto
print. Or select the historical data print.
a. Turn off the power switch and pull the plug from the socket (Pay attention to the electrical components in the
electrical cabinet. Power supply must be turned off and also unplug the power cord and turn off the power switch of the
freezer before opening. The electrical cabinet must be opened by qualified engineer or maintenance personnel).
b. Remove the battery connection plug.(Before unplugging the cord, pay attention to the sequence of the battery's
positive and negative levels and the connecting line, does not upside down the positive and negative levels to prevent the
control system damage from the installation of new batteries.The red line is usually connected to the positive pole, and the
black line is connected to the negative pole)
c. Remove two fixed screws from the battery plate with a screwdriver and remove the battery.
d. New replaced battery model: BT-12M4.0AC(12V4.0AH)；
e. The replacement battery is recyclable, please contact the local battery recycling agency for processing.
Note: In order to effectively ensure that the replacement tank battery meets therequirements of the control system and to
avoid the impact of improperoperation on the system during the replacement, it is recommended to contact
the Meiling after-sale service staff to replace or guide.
Anex2: About installation of printer paper for optional part printer.
The printing paper has been installed in the factory. When the paper is used out for a long
time, you can buy and replace it with the same roll paper .
The installation steps are as follows:
1. Press the cylinder button on the printer and open the cover of the printer.
2. put print paper into the printer box and pull the paper roll end of the printer cover after the note slightly exposed on
the box cover port;
Annex1：Rechargeable Battery Maintenance,Installation,Replacement
and Disposal
Long term power failure or in the process of transportation, the main power switch must be turned off. Otherwise, long
time discharge will cause battery loss or permanent damage, and it will be abnormal after re-energized.
Maintenance of rechargeable batteries: In order to prolong the battery life, please avoid idlingthe product. It is better to
run the product more than 24 hours monthly to recharge.
Battery Maintenance
A. If the freezer does not run in a long time, it should be connected to the poweron a regular basis (monthly), turn on the
power switch to charge the freezer for aperiod of time, and the charging time is not less than 24 hours.
B. When the power supply is interrupted, the power lock switch should be turnedoff in time, otherwise the battery will
lose power, which may cause permanentdamage to the battery.
C. The battery is expendable and the battery life is about 2 to 3 years. If thebattery is not properly used, such as the loss
of electricity or reach the batterylife, it will lead to low battery alarm.（It does not affect the usage of the refrigerator but
there is alarm failure and influence on printing function.It is suggested that users should contact company after-sales
service staff to replace.
1. Battery Installation Position: Top inside of electrical box
2. Battery replacement

15 16
7. Defrost ●Unused ● Maintenance
Caution:
Due to the inertia of the refrigerating, there is tiny difference between the set point and the
temperature value on the display. This is a normal phenomenon.
Caution:
The current and voltage vibrated a little during the running process is possible. It may have
a short time alarm. It is normal when the voltage is regular at the range between 115V ±
10% or 208V ± 10%.
WARNING
Cutting off the power supply before making any repair services, to prevent from electric
shock or injury.
Prepare a safety check sheet when you request any repair or maintenance for the safety of
service personnel.
Make sure do not inhale any noxious gas while operate service.
7.1 Defrost
uAfter a period time of working, there will be frost formed inside the freezer. If the frost inside
is more than 1.5 mm, will affect the performance, also increase the power consumption.
Normal defrosting is required.
uDefrost the inside wall of the freezer as follows:
uRemove the frost by the enclosed scraper. Take care not to damage the inside wall.
uThorough defrosting:
1. Take out and transfer all the contents to another freezer or container which contains liquid
CO2. Switch off the remote alarm.
3. Switch off the power supply.
4. Open the door and remove the inner lid. To remove theinner door, open and lift.
5. Leave the freezer as it is.
6. The water remaining in the freezer compartment should be wiped up.
7. After cleaning is completed, restart the operation according to the procedure. Put back
the articles into the sufficiently cooled freezer compartment
Caution:
Do not use the electric heater, metal tools, sharp weapon to defrost the freezer.
7.2 Unused
uIf the unit is to be stored unused for an extended period, should be powered off and be
cleaned as indicated as 7.3, then must be packed over without any articles inside.
uBefore reuse, use the dry cloth to wipe the water around the lining of the freezer. Especially
the door seals which could be directly connected with the inner doors to prevent the door
seal from been frozen by the low temperature.
Remote Alarm (opt): The terminal is nearby the power switch. When there is an alarm,
after 1~5 minutes it is going to be triggered.
If the product is improved, the technical data and circuit diagram shall be subject to the final product
nameplate and cabinet circuit label.
10.Performance
10.1 Main Technical Parameter
Model
Ambient
tempera
ture
Refriger
ant
Rated
voltage
（V～）
Rated
frequenc
y
（Hz）
Storage
temperatu
re
(℃)
Net
capacity
（L）
Rated
current
（A）
Net
Weight
（Kg）
Exterior
dimension
（W*D*H）
（mm）
Clim
ate
type
Name Operation manual
1
10.3 Electrical Diagram
Quantity
Defrost shovel
1
10.2 Packing List
GL-F-16M 16～32℃N
R600a/65g×2 220
50 Up:-10～-25℃450 1.55 144 810×735×1960
Down:-10～-25℃
