Gladorn SoundPlato GD538 User manual

USER MANUAL
i
SoundPlato GD538 Bluetooth Bookshelf Speakers Please read the manual carefully before useand keep it well for
further use
SoundPlato
WARNINGS
This appliance is intended for domestic household use only and should not be used for any other purpose or
in any other application, such as for non domestic use or in a commercial environment.
Ventilation
Allow at least a 10 cm gap all around the product.
The ventilation should not be impeded by covering the ventilation openings with items, such as newspapers,
table-cloths, curtains,
No naked flame sources, such as lighted candles, should be placed on the apparatus. Attention should be
drawn to the environmental aspects of battery disposal. Don’t throw usedbatteries in dustbin. Please contact
your retailer in order to protect the environment.
This apparatus is not suitable for use in a tropical climate. The apparatus shall not be exposed to dripping or
splashing and that no objects filledwith liquids, such as vases, shall be placed on the apparatus.To protect the
environment, use local recycling facilities for battery disposal.
Batteries (battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or
the like.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
IMPORTANT SAFETY INSTRUCTIONS
Keep the unit away from high temperature exposure and high humidity.
Do not disassemble, modify or attempt to repair the unit.
Only use the attachments/accessories recommended by the manufacturer.
Store the unit away from dirt or dust.
Symbol
This mark is applied to show the equipment conforms to European safety and electro-magnetic
compatibility standards.
Battery handling and usage
The product is supplied with one rechargeableLithium 3.7V 1200mAh battery incorporated in the product which
is not accessible and cannot be replaced. Therefore when the product reaches the end of its useful life it must
be disposed of at a recycling centre .

PARTS
1 2
Front View
Top View
1. Indicator light
2. Microphone
3. Volume down/previous button
4. Volume up/next button
5. Hands-free function/Play/Pause button
6. ON/OFF Switch
7. DC-5V IN Charging port
8. LINE IN Jack
9. Stand
3 4 5
6 7 8 9
Rear View
Accesories
CHARGING THE SPEAKER
The speaker has a built-in Lithium battery. It is recommended to charge the internal battery for about 2 hours before
using thespeaker.
The fully-charged battery can give up to 7-hour playing time at 50% volume depending on genres of music and
volume.
1.Connect the micro USB plug end of the supplied cable to the charging port on the back of the speaker. Connect
the standard USB plug end of the cable into the USB port on your computer or other USB charging device.
The indicator light will illuminate red.
2. When the indicator light goes out, the battery is fully charged.
3. After charging, remove the micro USB cable.
Low battery warning:
When you hear two beeps at regular intervals, please recharge the speaker.
PARING WITH A BLUETOOTH-ENABLED DEVICE
1. Turn on the speaker.
The speaker will enter Bluetooth modeand the indicator light will flash blue quickly.
2. To pair, go to Bluetooth settings on your Bluetooth enabled device and connect to “Gladorn SoundPlato”.
Enter “0000” if asked for a passcode.
Micro USB cable
3.5 mm audio cable

Once the speaker has been successfully paired to your music device, you can listen to music by using
, and .
Adjust the volume as desired by repeatedly pressing / .
Select the desired track to play by pressing and holding / for about 2 seconds.
To pause, press . To resume play, press again.
Mode Status
Bluetooth pairing The indicator light will flash
blue quickly.
Paired
You will hear jingle sound and the
indicator light will flash blue slowly
at regular intervals.
NOTE:
Once the Bluetooth device is
connected for the first time, the
speaker will remember the paired
setting and will automatically
reconnect to the same Bluetooth
device the next time they are in
range.
LISTENING TO MUSIC
NOTE:
When you want to playback from another Bluetooth device, press twice to disconnect the speaker by from
the Bluetooth device already in use.
HANDS-FREE FUNCTION:
1. To receive an incoming call, press .
2. To end a call, press again.
LINE IN

1. Connect the supplied audio cable from an auxiliary audio device to the LINE IN jack of the unit.
The indicator light will illuminate blue.
2. Adjust the volume by repeatedly pressing /
3. Press to mute the music,Press once more to listen again .
CLEANING AND MAINTENANCE
Clean the unit with a soft, damp cloth and wipe it with a dry cloth.
Never immerse it in water.Do not use abrasive or chemical cleaning agents.
Store the unit in a cool, dry place, away fromthe dust or dirt.
SPECIFICATIONS
DC input: 5 V 500mA
Rechargeable battery: 3.7V 1200mAh
Speaker power (RMS): 3W x 2
Frequency range: 2.402GHz – 2.480GHz
Output power: 4-6dBm
DISPOSAL
As a responsible company we care about the environment. As such we urge you to follow
he correct disposal procedure for the product, packaging materials and if applicable, accessories
and batteries. This will help conserve natural resources and ensure that the materials are recycled
in a manner that protects health and the environment.
You must follow laws and regulations about disposal. Waste electrical products and batteries must be disposed
of separately from household waste when the product reaches the end of its life. Contact the store where you
bought the product and your localauthority to learn about disposal and recycling.
The batteries must be disposed of at your local recycling point.
We apologise for any inconvenience caused by minor inconsistencies in these instructions, which may occur
as a result of product improvement and development.
