GLG MKI User manual

User Manual
Replay MKI
GLG is a brand name of GOED licht en geluidwww.goedlichtengeluid.nl

The GLG Replay MKI is a very useful and versatile DMX tool. It can works as
a DMX recorder, signal booster, signal converter and merger. To optimize the
performance of this product, please read the user manual carefully before use.
INTRODUCTION
Safety Instruction
WARNING!!! To reduce the risk of electric shock, or injury to
persons, follow these important safety instructions:
1
▪This product is intended for indoor use only!
▪
▪
▪Please keep this User Guide for future consultation.
▪
▪The unit must be installed in a location with adequate ventilation. Be sure no
ventilation slots are blocked.
▪Make sure power cord is never crimped or damaged.
▪Do not remove the top cover under any conditions. There are no user
serviceable parts inside.
• Disconnect the unit’s main power when left unused for long periods of time.
• Never connect this unit to a dimmer pack.
• Never operate this unit when it’s cover is removed.
warranty.
What Is Included
Carefully unpack the carton, check the contents to ensure that all parts are
present, and have been received in good condition. Contact your supplier
immediately and retain packing material for inspection if any part is missing or
damaged.
The following items are included in the box:
▪1pc Replay MKI
▪1pc Power cable
▪1pc User Manual
10
IMPORTANT INFORMATION!
In order to optimize the recovery and recycling of the materials
that old appliances contain and reduce the impact on human
health and the environment, ensure that this product is recycled
at the end of its life.
SPECIFICATIONS
1) Copy the new software (SSCR10AM & SSCR10AS) to the root directory of
SD card.
2) Insert SD card and press Menu button till “SYSTEM setup [new software]”
shows on display.
3) Press Enter button.
Software updating
The software can be upgraded via SD card as following steps:
Default IP address: 2.114.34.200
DMX In: 2 x 3pin (or 5pin) XLR male
DMX Out: 2 x 3pin (or 5pin) XLR female
Power consumption: 6w max.
Power In: AC 100-240V 50-60Hz
Dimension: 225*130*55 mm
Weight: 0.70 kg
GLG Lighting Netherlands
GLG is a brand of GOED licht en geluid
www.goedlichtengeluid.nl
Version Manual V1.3 October 2017

Features
Product Overview
2
▪Supports ArtNet and DMX
▪1024 channels DMX in & out
▪Real-time record and replay via DMX or WiFi
▪8 Memories and each up to 20 hours can be stored in SD card
▪Replay can run in solo or loop mode
▪Replay can run on iPad/iPhone via TouchOSC
▪DMX signal booster
▪DMX input to Arnent output via wi or Lan cable
▪Artnet input to Artnet output via wi
▪Artnet input via wi to Artnet output via Lan cable
▪Artnet input via Lan cable to 2 DMX outputs
▪Artnet input via wi to 2 DMX outputs
▪DMX Merger
▪24CH DMX (Simple Desk)
1. Ethernet In 2. USB power out (5V DC/120mA) 3. Power In 4. DMX In 5.
DMX Out 6. Menu/Enter/Up/Down 7. LCD display 8.
BRIDGE/RECORD/REPLAY 9. LEFT/PAUSE/RIGHT 10. Speed & Dimmer
slider 11. Memory button 1-8
DMX O u t 1 DMX O u t 2
S D
DMX I n 1
Wi fi
DM X I n 2
LCD panel
B ri dg e R ec o r d R ep la y
Men u E nte r U p D o wn
Mem ory 1
DMX I n 1 DMX O u t 1
DMX I n 2 DMX O u t 2
Mem ory 2 Me mory 3 Mem ory 4 Me mory 5 M emor y 6 Mem ory 7 Mem ory 8
S peed D imm er
9
12. To select Replay or 24CH DMX, click the layout and select the tool you’d
like to use, and then click Done.
13. When Replay MKI is selected, you have the same layout as the unit.
Now you can use your iPhone/iPad to replay the memories.
When 24CH DMX is selected, you have a 24ch desk in your hand. Use page
slider to select 1-3 page.
Page slider

3
OPERATING INSTRUCTIONS
BRIDGE
MENU System Ready
Recorder V.xx
Under BRIDGE, the unit works as a signal converter. Press BRIDGE button and
its LED is lit up. Then use MENU/ENTER/UP/DOWN to select different modes
as below.
Bridge mode01
[DMXin-DMXout]
System Setup
[New software]
Bridge mode02
[DMXin-LAN]
Bridge mode03
[DMXin-WiFi]
Bridge mode04
[LAN-DMXout]
Bridge mode05
[LAN-WiFi]
Bridge mode06
[WiFi-DMXout]
Bridge mode07
[WiFi-LAN]
Bridge mode08
[OSC 24CH DMX]
Please wait...
ENTER
ENTER
ENTER
Bridge mode09
[DMX MERGE]
ENTER
8
10. Click on OSC:192.168.16.254 (IP of RECORDER)，and then set
Port(outgoing): 6454 and Port(incoming): 8000 as figure below.
11. Click DONE and now your iPHONE/IPAD is ready for Replay and 24CH
Done

4
RECORD
MENU
1. Press RECORD button and its LED is lit up.
2. Use UP/DOWN to select record modes as below.
Data of lighting show can be recorded from the Ethernet network , WiFi or 2
DMX inputs. Each memory can be up to 20 hours.
3. Press 1-8 button to select Memory for recording. The LED of selected
Memory is blinking and corresponding number ”MEMX(1-8)” will be showed
on LCD.
4. Press ►button to start recording, ▌▌ to pause and ◄to end recording.
Record Mode01
[DMXin-SD&DMXout]
Record Mode02
[DMXin-SD&LAN]
[WiFi-SD&LAN]
Record Mode03
[DMXin-SD&WiFi]
Record Mode04
[LAN-SD&DMXout]
Record Mode05
[LAN-SD&WiFi]
Record Mode06
[WiFi-SD&DMXout]
Record Mode07
err: - Lframe: 000
MEM1
Number of Memory Time of recording
■00:00:00
7
8. Click “Sync” on TouchOSCEditor and the name of PC/laptop will be shown
on your iPHONE/IPAD.
9. Click the name of PC/laptop on your iPHONE/IPAD and confirm OK, then
you will see the name in layout list. Click and select it.

5
REPLAY
Replay can be in solo or loop mode. And operation of replay can be on the
unit or iPhone/iPad via TouchOSC.
NOTE: MEM button without recording data can’t be selected in REPLAY.
1. Press REPLAY button and its LED is lit up. The unit goes to last stadus of
replay.
2. Use ◄and ►button to run in loop mode, ▌▌button to run in solo mode.
3. In loop mode, LED indicator of ◄(or ►) is blinking. ◄and ►button
indicate the dirrection of running. The LED indicators of selected memory are
lit up and the blinking one is in running.
4. When in loop mode, press ▌▌ button to pause, press ▌▌ button again
to enter solo mode and its LED is blinking. In solo mode, the selected MEM
(memorie) are lit up. Press the selected one to run in solo mode and its LED is
blinking.
5. Use SPEED slider to adjust running speed from 25% to 200%. Use DIMMER
slider to adjust output from 0 to 100%.
In order to use a iPhone or iPad to control the Replay MKI , you need to
install TouchOSC and upload the interface of RECORDER on your
iPhone/iPad.
1. Download TouchOSC from Apple Stores and install it on your iPhone/iPad.
2. Click on OSC and run it on your iPhone/iPad.
3. Power on Replay MKI.
4. Connect your iPhone/iPad with the RECORDER. Click WLAN setup on your
iPhone/iPad and select DMX RECORDER XX. Password is 12345678.
5. Download TouchOSCEditor.exe ( https://hexler.net/software/touchosc) and
install it on your PC/laptop.
6. Run TouchOSCEditor ，click “Open” and select
“Replay MKI.touchosc” and “24CH DMX.touchosc”le on your
PC/laptop.
Replay on unit
Replay or OSC 24CH DMX on a iPhone/iPad
6
7. Click on the dot in the upper right cornner of your iPhone/iPad, and then
click LAYOUT and Add.
