Global Machinery Company HM 350C User manual

HM350C
050308 ED2 JJ
• Melbourne • Perth • Auckland • Hong Kong • Shanghai
• Taipei • New York • Verona • London • Paris
INSTRUCTION MANUAL
350mm
Hand
Mower

Contents
Full 2 Years Home Use Warranty
Whilst every effort is made to ensure your complete
satisfaction with this tool, occasionally, due to the mass
manufacturing techniques, a tool may not live up to our
required level of performance and you may need the
assistance of our service department.
This product is warranted for a 2-year period for home
domestic use from the date of the original purchase. If
found to be defective in materials or workmanship, the
tool or the offending faulty component will be replaced
free of charge with another of the same item. A small
freight charge may apply.
The warranty replacement unit is only made available by
returning the tool to the place of purchase with a
confirmed register receipt. Proof of purchase is essential.
We reserve the right to reject any claim where the
purchase cannot be verified.
This warranty does not include damage or defects to the
tool caused by or resulting from abuse, accidents,
alterations or commercial or business use.
It also does not cover any bonus accessories unless the
tool is a GMC Platinum Professional model.
Please ensure that you store your receipt in a safe place.
Conditions apply to the above warranty.
If you need direction of what constitutes a free of
charge warranty claim, please review the guide given on
the rear of the Receipt Holder. An indication is given as
to the types of claim that are permissible, and those
that are not.
Warranty 2
Introduction 3
Environmental protection 3
Specifications 3
Safety instructions 3
Unpacking 4
Know your product 5
Assembly 6
Mowing height 6
Adjustment of lower blade 6
Maintenance and storage 6

3
Specifications
Cutting width: 350mm
Height adjustment: 25mm – 75mm
Blade reels: 5 x 146mm
Wheel diameter: 210mm
Roller diameter: 45mm
Weight: 8.5kg
Safety instructions
The tool must be used only for its prescribed purpose.
Any use other than those mentioned in this Manual will
be considered a case of misuse. The user and not the
manufacturer shall be liable for any damage or injury
resulting from such cases of misuse.
To use this tool properly, you must observe the safety
regulations, the assembly instructions and the operating
instructions to be found in this Manual. All persons who
use and service the machine have to be acquainted with
this Manual and must be informed about its potential
hazards. Children and infirm people must not use this
tool. Children should be supervised at all times if they
are in the area in which the tool is being used. It is
also imperative that you observe the accident prevention
regulations in force in your area. The same applies for
general rules of occupational health and safety.
The manufacturer shall not be liable for any changes
made to the tool nor for any damage resulting from such
changes.
WARNING. When using hand mowers, basic safety
precautions should always be taken to reduce the risk of
personal injury. Also, please read and heed the advice
given in the additional important safety instructions.
Save these instructions
Dear Customer
If you require any help with your product, whether it
is a Warranty claim, spare part or user information,
please phone our Help Line for an immediate response.
Phone [phone] in Australia or 0800 445 721 in
New Zealand.
Introduction
Your new GMC tool will more than satisfy your
expectations. It has been manufactured under stringent
GMC Quality Standards to meet superior performance
criteria.
You will find your new tool easy and safe to operate,
and, with proper care, it will give you many years of
dependable service.
CAUTION. Carefully read through this entire Instruction
Manual before using your new GMC Tool. Take special
care to heed the Cautions and Warnings.
Your GMC tool has many features that will make your job
faster and easier. Safety, performance, and
dependability have been given top priority in the
development of this tool, making it easy to maintain
and operate.
Environmental protection
Recycle unwanted materials instead
of disposing of them as waste. All tools,
hoses and packaging should be sorted,
taken to the local recycling centre and
disposed of in an environmentally
safe way.

4
Work area
• Keep work area clean and tidy. Before commencing
mowing, check your lawn to ensure that the area is
clean of debris such as stones and mulch. Remove all
obstructing material from the lawn, otherwise the hand
mower could pick up this debris and either damage the
cutting blades or eject it causing possible injury to the
user or other persons in the area.
• Keep visitors away from the work area. All visitors
and onlookers, especially children and infirm persons,
should be kept well away from where you are working.
Do not let others in the vicinity make contact with the
mower.
• Keep hands and feet well away from the cutting
blades. Even when you want to clean the blades, do
not insert your hands into the blade.
• Store tools safely. When not in use, tools should be
locked up out of reach.
• Do not force the tool. The tool will do the job better
and safer working at the rate for which it was designed.
• Dress correctly. Always wear safety footwear when
cutting the lawn with this hand mower. Leather gloves
are also recommended when working outdoors.
• Do not overreach. Keep your footing secure and
balanced at all times.
• Look after your tools. Keep tools sharp and clean for
better and safer performance. Follow the instructions
regarding lubrication and accessory changes. Should the
hand mower not be functioning correctly, it should be
inspected by an authorized repair centre.
Tool use and care
• Store idle tools out of the reach of children and do
not allow persons unfamiliar with the tool or these
instructions to operate the tool. Tools are dangerous in
the hands of untrained users.
• Maintain tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition
that may affect the tool’s operation. If damaged, have
the tool repaired before use. Many accidents are caused
by poorly maintained tools.
• Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
• Use the tool, accessories etc., in accordance with
these instructions and in the manner intended for
the particular type of tool, taking into account the
working conditions and the work to be performed.
Use of the tool for operations different from intended
could result in a hazardous situation.
Service
• Have your tool serviced by a qualified repair
personnel using only identical replacement parts.
This will ensure that the safety of the tool is
maintained.
Unpacking
Due to modern mass production techniques, it is unlikely
that your mower is faulty or that a part is missing. If you
find anything wrong, do not operate the mower until the
parts have been replaced or the fault has been rectified.
Failure to do so could result in serious personal injury.

5
Know your product
1. Lower handle
2. Middle handle
3. Upper handle
4. Metal shroud
5. Wheel
6. Rotating blades
7. Grass catcher (optional)
Screws
A = M6 x 25mm
B = M6 x 30mm
C = M6 x 35vmm
Nuts
N = M6
1
3
2
5
4
6
7
CN
N
AA
N
BB

6
G
F
1
2
3
E

Carefully read the entire Instruction Manual
before using this product.
Before returning this product for a
Warranty Claim or any other reason
Please Call 1300 880 001 (Australia)
or 0800 445 721 (New Zealand)
When you make your call, please have
the following information at hand:
• GMC Product Type • GMC Product Code
A GMC Service Engineer will take your call and, in
most cases, will be able to solve your problem over
the phone.
You are welcome to use this phone-in service to
make suggestions or give comments about any
GMC product.
With continuing product development changes may
have occurred which render the product received
slightly different to that shown in this instruction
manual. The manufacturer reserves the right to
change specifications without notice. Note:
Specifications may differ from country to country.
The GMC 777 Helpline operates from 7am to
7pm, 7 days a week (EST). This allows you
to contact GMC directly with any queries and
technical questions you have regarding
our products.
45–55 South Centre Road
Melbourne Airport
Victoria, Australia 3045
Tel: [phone] Fax: [phone] Save this Manual for future reference.
