GLOBAL OUTDOORS FP0121 User manual

WARNING
THIS APPLIANCE HAS A NAKED
FLAME; YOUNG CHILDREN, THE
ELDERLY, AND THE INFIRM SHOULD
NOT OPERATE WITHOUT
APPROPRIATE SUPERVISION.
WARNING
• Do not modify the appliance;
• Do not move the appliance during use;
• Turn o the gas supply at the tank
after use
• Accessible parts may be very hot. Keep
young children away
DANGER: CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor. Using it
in an enclosed space can kill you. Never use this appliance in an enclosed
space such as camper, tent, car or home.
These instructions are only valid if the country symbol appears
on the instruction manual and on the appliance.
ATTENTION: This appliance is tted with a exible gas rubber pipe and clamps that must
be used; never use a dierent kind and always use according to the National Rules in
force of the country of destination.
These components should be periodically replaced, according to the date reported on the
body of each of them, or according to the National Rules in force of the country of destination.
Gas regulator and LPG cylinder are not included and must be purchased to match indicated
LPG compartment shape and cylinder support.
WARNING
FOR OUTDOOR USE ONLY
DO NOT PLACE ON ANY ELEVATED SURFACE
WINE BARREL
GAS FIRE TABLE
ITM. / ART. 998854
MODEL #: FP0121
OWNER’S
MANUAL
IMPORTANT, RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY
1
CONTENTS
TM
SAFETY WARNINGS.....................................................................X
SPECIFICATIONS...........................................................................X
GAS (LPG) WARNINGS ................................................................X
TECHNICAL DATA.........................................................................X
EXPANDED VIEW..........................................................................X
INSTALLATION...............................................................................X
CONNECTING GAS CIRCUIT .....................................................X
OPERATION....................................................................................X
TESTING FOR LEAKS....................................................................X
MAINTANENCE .............................................................................X
STORAGE.........................................................................................X
TROUBLESHOOTING...................................................................X

DANGER
WARNING
DANGERS AND WARNINGS
2
• Minimum Clearance From Unit To Combustible Material: 72” (182.9cm)
from the top; 36”(91.5cm) from all sides and back.
• Do not locate this appliance under over-head unprotected combustible
surfaces.
• Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Read this Owner’s Manual thoroughly
before installing, operating or servicing this equipment.
• Keep these instructions for future reference. If you are assembling this
unit for someone else, give this manual to them to read and keep for
future reference.
• This gas replace should ONLY be used outdoors in a well-ventilated
space and should NOT be used inside a building, garage, or any other
enclosed area.
• DO NOT use this outdoor gas replace for indoor heating. Toxic carbon
monoxide fumes can accumulate and cause asphyxiation.
• Never leave this gas replace unattended when in use.
• Children and adults should be alerted to the hazards of high surface temperatures and kept at a safe distance while replace is in use.
• DO NOT operate light or use this replace within 8 feet of walls, structures or building.
• Storage of this replace indoors is permissible only if it has been disconnected from its fuel supply (LP gas cylinder).
• Gloves are strictly recommended to be used while moving this appliance, to protect your hands.
• Any parts sealed by the manufacturer or its agents are not to be altered by the user.
• DO NOT store or use gasoline or other ammable vapors and liquids within 25 feet (7.62m) of this or any other similar appliance.
• DO NOT store any combustible materials in the base enclosure.
• The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or safely operate this appliance.
• DO NOT use in an explosive atmosphere. Keep gas replace area clear and free from combustible materials, gasoline and other ammable vapors
and liquids.
• This outdoor replace is NOT to be operated by children. Young children should be closely supervised when in the vicinity of this outdoor replace.
• This outdoor replace is not to be installed or used in or on recreation vehicles and/or boats.
• Always use in accordance with all applicable local, state and national codes. Contact your local re department for details on outdoor res.
• Use the same precautions you would with any open re with this outdoor replace.
• DO NOT burn solid fuels such as: wood, charcoal briquettes, lump charcoal, manufactured logs driftwood, trash, leaves, paper, cardboard, plywood,
painted or stained or pressure treated wood in this outdoor replace.
• DO NOT alter this outdoor replace in any manner.
• DO NOT use this outdoor replace until it is COMPLETELY assembled and all parts are securely fastened and tightened.
• DO NOT store another LP gas tank within 10 feet (3.05 m) of this outdoor replace while it is in operation.
• DO NOT use this outdoor replace near automobiles, trucks, vans or recreational vehicles.
• DO NOT use this outdoor replace under any overhead or near any unprotected combustible materials.
• Avoid using near or under overhanging trees and shrubs.
• Always use this outdoor replace on a hard, level, non-combustible surface such a concrete, rock or stone. An asphalt or blacktop surface may not
be acceptable for this purpose.
• DO NOT use this outdoor replace if any part has been under water. Immediately call a qualied service technician to inspect the replace and to
replace any part or control system and any gas control which has been under water.
• DO NOT wear ammable or loose clothing when operating this outdoor replace.
• DO NOT use in windy conditions.
• Keep all electrical cords away from a hot outdoor replace.
Failure to follow the Dangers, Warnings and Cautions contained in this Owner's Manual may result in serious bodily injury or death,
or in a re or an explosion causing damage to property.
If you smell gas:
1. Shut o gas to the appliance.
2. Extinguish any open ame.
3. Do not try lighting any other appliance
nearby.
4. Do not touch any electrical switch or use
any phone nearby.
5. Immediately call your gas supplier from a
neighbor’s phone.
6. Follow the gas supplier’s instructions.
7. If you cannot reach your gas supplier, call
the re department.

GAS (LPG) WARNINGS
DANGERS AND WARNINGS
3
• Certain areas of this outdoor replace will become too hot to touch during and after use. Do not touch hot surfaces until the unit has cooled unless
you are wearing protective gear such as insulated pot holders or heat resistant gloves or mittens to avoid burns.
• Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or clothing ignition.
• DO NOT hang or place clothing or other ammable materials on or near the gas replace.
• Any guard or other protective device removed for servicing the replace must be re-placed prior to operation.
• DO NOT attempt to move or store this outdoor replace until all parts are cool.
• DO NOT lean over this outdoor replace when lighting or when in use.
• Use only the regulator and hose assembly provided. Use only replacement regulator and hose assemblies specied by the manufacturer.
• Storage of this outdoor replace indoors is permissible only if the tank is disconnected, removed from the outdoor replace and properly
stored outdoors.
• DO NOT attempt to disconnect the gas regulator from the tank or any gas tting while the outdoor replace is in use.
• Always shut o gas supply at the tank valve and disconnect regulator from the tank when the replace is not in use.
• DO NOT sit on the mantle when the unit is in operation.
• DO NOT throw anything onto the re when the unit is in operation.
• Lava rocks are very hot; please keep children or pets away at a safe distance.
• It is essential to keep the outdoor replace valve compartment, burners, and circulating air passages clean. Inspect outdoor replace for debris
before each use.
• Prior to each gas replace operation, check the hose for evidence of excessive abrasion or wear by looking through the visual check hole. If the
hose is damaged, cut or cracked, it must be replaced before using the gas replace. The hose assembly can only be replaced by a hose assembly
specied by the manufacturer.
• Before each use, remove the lava rocks. Examine the burner and its components. If dirty, clean with a soft brush and soapy water solution. Also
examine the area around the burner. Any dirt or foreign material, such as spider webs or nests in this area should be removed. If it is evident that
the burner is damaged, it must be replaced be-fore the gas replace is used.
• The burner assembly can only be replaced by a burner specied by the manufacturer. Place the hose out of the pathways where people may trip
over it.
• DO NOT cross the hose between outdoor replace and the propane tank.
• WARNING: It is required to replace the exible tube in accordance to your local and national regulations.
• LP gas is ammable and hazardous if handled improperly. Please review the characteristics before using any LP gas product.
Propane Characteristics:
-- Flammable, explosive under pressure, heavier than air, and settles in pools in low areas. In its natural state, propane has no odor. For your
safety, an odorant is typically added. Contact with propane could burn the skin.
-- Propane is extremely ammable and hazardous if handled improperly.
• Cylinders must be stored outdoors in a well-ventilated area out of reach of children.
• Disconnected cylinders must have threaded valve plugs tightly installed and must not be in a building, garage or any other enclosed area.
• Never use a propane cylinder with a damaged body, valve, collar or footing.
• Dented or rusted propane cylinders may be hazardous and should be checked by your propane gas supplier.
• LP gas tank must be arranged for vapour withdrawal.
• The LP gas tank must have a tank collar to protect the tank valve.
• Never use an LP gas tank with a damaged body, valve, collar, or footing. Dented or rusted LP gas tanks may be hazardous and should be
checked by your LP gas supplier prior to use.
• The LP gas tank should not be dropped or handled roughly.
• Tanks must be stored outdoors out of the reach of children. Do NOT store in a building, garage, or any other enclosed area.
• Never store your LP gas tank where temperatures can reach over 125°F.
• Do not store the LP gas cylinder in direct sunlight or near a source of heat or combustion.
• Never keep a lled LP gas tank in a hot car or car trunk. Heat will cause the gas pressure to increase, allowing gas to escape.
• Place dust cap on valve outlet whenever the LP gas tank is not in use. Only install the type of dust cap on the LP gas tank valve outlet that is
provided with the LP gas tank valve. Other types of caps or plugs may result in leakage of propane.
• Do not store a spare LP gas cylinder under or near this appliance.
• Never ll the LP gas cylinder beyond 80% full.

DANGERS AND WARNINGS
GAS (LPG) WARNINGS, CONTINUED
• If the information in (a) and (b) is not followed exactly, a re causing death or serious injury may occur.
• LP gas cylinders should be lled only by a certied LP gas dealer.
• The pressure regulator is indicated to comply with national regulator pressure standards.
• Regulator outlet pressure is indicated to comply with national regulator pressure standards.
• Never attempt to attach this appliance to the self-contained LP gas system of a camper trailer, motor home or house.
• Always use the pressure regulator and hose assembly provided with the appliance to connect to a LP gas cylinder. Never connect to an
unregulated LP gas supply.
• Contact your retailer’s customer service department for replacement parts.
• Hand turn the manual gas control valve. Never use tools. If the valve will not turn by hand, do not try to repair it. Call a certied gas
technician. The use of force or any self-attempted repair may result in a re or explosion.
• Use only the type of gas and the type of LPG cylinder specied by the manufacturer.
• Appliance is tted with gas regulator, exible gas rubber pipe and clamps that comply with national standards in force of the country of
destination.
• Appliance must use an approved gas regulator (approved for a working temperature not lower than 50˚C) according to the EN Standard
(see minimum, nominal and maximum pressure - gas regulator inlet and outlet connection according to the National Rules in force) and
exible gas hose according to EN Standard (with proper inner diameter according to gas inlet connection and National Rules in force)
with a length not over 1.5 m and approved for a working temperature not lower than 60 ˚C. When replacement is necessary, you must
purchase suitable gas regulator, exible gas rubber pipe and clamps from your local gas dealer; gas regulator should replaced at least
every 10 years.
• Flexible gas rubber pipe must be handled carefully, avoiding any twisting. Never use a damaged gas regulator.
• Never connect this appliance to an unregulated LPG source (gas regulator must be used).
• When the appliance is not in use, turn the LPG cylinder in “OFF” position.
• Always perform a leakage test on gas connections whenever a LPG cylinder is connected. If bubbles form in exible gas rubber pipe, it must
be looked for in the LPG compartment carefully, avoiding any twisting.
• Never use a damaged gas regulator.
• Always perform a leakage test on gas connections whenever a LPG cylinder is connected. If bubbles form in the leakage test
solution, do not use it. Never use a ame to test for leakages. It is strictly forbidden and dangerous!
4
PIN NO:
Product Name:
Wine Barrel Fire Pit
1. “Maximum diameter or height:
320mmX490mm
2 “Maximum height (regulator included):
Recommend use 5kg
Factory/supplier:
Global Outdoors, Inc.
www.globaloutdoorsinc.com
Distributor/Importer
Will dier per order
Appliance
category
Gas type/Gas
Pressure
Heat input
Injector size
Destination
countries
BE-CY-DK-EE-FI-FR-HU-I
T-LT-NL-SE-SI-SK-RO-HR
TR-GB-IS-LU-MT
AT-CH-DE-SK
BE-CH-CY-CA-ES-FR-GB-GR
IE-I-T-LT-LU-LV-PT-SK-SI
1.98mm 1.78mm 1.98mm
15KW(G30:1091g/h; G31:1072g/h)
G30 Butane and G31
Propane at 30mbar
G30 Butane and G31
Propane at 50mbar
G30 Butane
at 28-30mbar
G31 Butane
at 37mbar
I 3B/P(30) I 3B/T(50) 13+(28-30/37)
Type No:
FP0121
Serial No:

6
ASSEMBLY/INSTALLATION
4. Turn the cylinder valve clockwise to
close the gas supply on the gas cylinder.
Screw the regulator coupling clockwise
by hand only. Make sure it is fastened.
5. Replace door (C) onto the body (B).
6. To install the battery (H), unscrew the rubber cap of the electric igniter (K) and place battery (H) into the battery case.
Make sure the positive pole ("+") faces out towards the cap. Screw the cap back to the battery case tightly.
7. Place the re glass (F) evenly
in the re bowl (A).

ASSEMBLY/INSTALLATION
Tools required: Phillips head screwdriver, adjustable spanners, pliers and wrenches. Before assembly, make sure all protective packing material has been
removed. Flexible gas hose (1763-1) and clamps (if necessary) are supplied with this appliance and must be used, according to National Rules in force. You
must purchase one gas regulator and one gas cylinder. The gas regulator has to be set according to specic gas category (see page 2) and proper gas
consumption (g/h) specication. The LPG cylinder should be standard (5kg is recommended). Replacement must be that specied in “Gas
Requirements”section of this Instruction Manual. Caution: do not kink exible gas rubber pipe of gas circuit. If pipe holder is not provided, the gas inlet
connection thread must comply with Standards ISO 7-1 or ISO 228-1, according to National Rules in force of the country of destination.
• Make sure appliance gas knob is turned "OFF" (full disk) before assembling .
• Put the LPG cylinder inside of the tank bracket,and tight the screw(see the Fig 8).
9. Connect the regulator to LPG cylinder by hand.
(Hand-tighten only).
10. Connect the hose to the appliance and the regulator. Tighten
the screw of the hose clamp with a screwdriver.
7
8
9
10

8
OPERATING INSTRUCTIONS
MAINTENANCE/CLEANING
To Light
1. Turn the cylinder valve on the gas tank counterclockwise to open the gas supply.
2. Close the storing door on the body for the gas tank (see step 5 listed on page 6).
3. Press and hold the electric igniter.
4. Push and turn the control knob counterclockwise to the "LOW" position.
5. Keep pushing the control knob to light the burner.
6. After ignition, release the electric igniter.
7. Continue to push and hold the control knob for 45 seconds.
8. If ignition does NOT immediately take place in seconds, push and turn
the control knob clockwise to "OFF". Wait 5 minutes, then repeat the lighting
procedure as above.
Note: Flame should be yellow/blue color.
To enjoy years of outstanding performance from your appliance, perform these services at regular intervals:
• The appliance should be inspected before at least one time a year by a Qualied Service only. More frequent cleaning may be required according to
the use of the appliance.
• Any guard or other protective device removed for servicing the appliance must be replaced before operating it.
• Keep exterior surfaces clean, free and clear from combustible materials.
• Use warm soapy water for cleaning. Never use ammable or corrosive cleaning agents.
To Extinguish
1. Push and turn the control knob clockwise to the "OFF" position.
2. Turn the cylinder valve on the gas tank to close the gas supply if not in use for a long time.
Leakage Testing
Never check for gas leakages with a ame or while smoking. This appliance needs to be periodically checked for leakages and an immediate
check is required if the smell of gas is detected.
• Make a soap solution using 1 part of liquid dish-washing soap to 3 parts water. The
soap solution can be applied with a soap bottle, brush, or rag to the leakage tested
points shown in the gure beside.
• The valve of the LPG cylinder should be in the “OFF” position at this point of the
leakage test. Once the soapy solution is applied to the gas connections, the valve of
the LPG cylinder needs to be turned to the “ON”position.
• Soap bubbles will begin to form in the soapy solution if any leakage is present.
• In the event of gas leakage, the appliance shall not be used or if alight, the gas supply
shall be shut-o and the appliance shall be investigated and rectied before it is used
again. Tighten any leaking ttings, then turn on gas supply and recheck.
• If necessary, substitute gasket (according to EN 549 Class B2) or material used to
guarantee tightness (according to EN 751-1 Class I).

9
MAINTENANCE/CLEANING
STORAGE (AFTER USE)
• While washing your unit makes sure to keep the area around the burner assembly dry at all times. If the gas control is exposed to water in any way,
DO NOT try to use it. It must be replaced.
• Burner and LPG compartment circulating air passageways of the appliance must be kept clean.
• Airow must be unobstructed. Keep controls, burner and circulation air passageways clean. Signs of possible blockage include:
-- Gas odor with extreme yellow tipping of ame / Appliance glow is excessively uneven / Appliance makes popping noises.
• Spiders and insects can nest in burner or orices. This dangerous condition can damage the appliance and render it unsafe for use. Clean burner
holes by using a heavy duty pipe cleaner. Compressed air may help clear away smaller particles.
• Carbon deposits may create a re hazard. If any carbon deposits develop, clean dome and engine with warm soapy water.
• After the burner and lava rocks are completely cooled down, remove it from the bowl and use a soft brush to get rid of the mild stains, loose dirt and
soil. Wipe with a soft cloth.
• Clean the bowl and afterward put lava rocks again in proper position.
• For proper cleaning, a vacuum cleaner can be used.
Note: In a salt-air environment (such as near the sea), corrosion occurs more quickly than normal. Frequently check the corroded areas and repair them
promptly. Stubborn stains, discoloration and possibly rust pitting can occur from exposure to harsh outdoor conditions. Be careful not let any powder or
solvent come in contact with painted or plastic components as damage may occur.
After long use, some discoloration can come up and it screen is normal.
Make sure both gas supplies is in OFF position before changing battery. Please refer to the process of assembling battery.
Please contact the Manufacturer or dealer for information regarding replacement hoses, thermocouples, igniters, lava rocks, etc.
Attention: Never use unauthorized parts or component for this appliance.
Use only original equipment replacement spare parts and components.
Otherwise may void the warranty of this product and result in a hazardous condition.
• Turn control knob in “OFF” position (full disk).
• Turn LPG cylinder in “OFF” position.
• Store the appliance in a cool dry place away from direct sunlight; store it upright in an area sheltered from direct contact with inclement weather
(such as rain, sleet, hail, snow, dust and debris).
• If desired, cover to protect exterior surfaces and to prevent build up in air passages.
• Note: Wait until appliance is cool before covering.
During periods of extended inactivity or when transporting:
• Turn control knob in “OFF” position (full disk).
• Disconnect LPG cylinder and move to a secure, well ventilated location outdoors. DO NOT store in a location that will exceed 50 °C.
• Store appliance upright in an area sheltered from direct contact with inclement weather (such as rain, sleet, hail, snow, dust and debris).
• If desired, cover appliance to protect exterior surfaces and to prevent build up in air passages.
• Note: Wait until appliance is cool before covering.

EXPANDED VIEW
PART DESCRIPTION QTY
A Fire Bowl 1
B Body 1
C Door 1
D Burner 1
E Guard 1
F Fire glass 2 boxes
G PVC Cover 1
H Battery 1
I Feet (preassembled) 4
J Control Knob (preassembled) 1
K Electric Igniter (preassembled) 1
L Lid with handle 1
M Burning components 1
(preassembled)
ASSEMBLY/INSTALLATION
1. Make sure the gas supply system is turned to “OFF”.
2. Remove door (c) to insert propane
tank (see step #3). Lid (L) must be
removed when burner is in operation.
3. Place propane tank (not
included) in the metal stand
inside body(B) and make sure
the gas tank sits on the metal
stand completely. Turn the wing
screw on the outer part of metal
stand clockwise to secure the
gas tank tightly.
5

Please call customer service if you have any questions.
Toll free number: 1-844-613-9170 (English)
Monday to Friday from 9:00 AM to 5:00 PM (Eastern time)
TM
10
TROUBLESHOOTING
PROBLEM:
Burner won’t light
Burner won’t stay lit
Burner ame is low
(note: Do not operate
appliance below 5° C
Carbon build-up
Flash back (ame inside
burner)
Thick black smoke
CONDITION:
Control knob is not in Low position (low ame)
LPG cylinder valve is closed/empty
Blockage in the injector
Air in the gas circuit
Low gas pressure
Igniter fails
Dirty build-up around burner
Low ame or not full running around the burner
Termocouple is not operating correctly
Low gas pressure
Outdoor temperature is greater than 5°C and LPG
cylinder is less than 25% full
Gas pipe is bent or kinked
Control knob is fully in Maximum position (large ame)
Dirty or lm on burner
Burner ports are blocked
Blockage in the burner
SOLUTION SUGGESTED:
Turn control knob in Maximum position (low ame)
Open the valve/Replace LPG cylinder with new one
Clean or replace injector
Open gas line and bleed it (pressing control knob in) for
not over 1 minute or until you smell gas
Replace LPG cylinder with new one
Use match to light burner, change battery or obtain new;
ignite and replace it
Clean dirt around burner
Flame spreader holes partially closed; clean the burner
Replace thermocouple (FSD)
Replace LPG cylinder with new one
Replace LPG cylinder with new one
Straighten hose and perform leakage test on gas pipe
Turn control knob to “OFF” position (full disk), let cool
to room temperature and check burner and orices for
blockage
Clean burner
Switch OFF the appliance. Close LPG cylinder valve. Wait 2
minutes,, following the ignition procedure. Ignite burner. If
problem continues, switch o and contact your dealer
Turn control knob to “OFF” position (full disk), let cool
to room temperature, remove blockage and clean burner
inside and outside
