GNB SY-058 User manual

300KPixelsDigitalCamera

Owner’sManualv2.0



Warning:

1. Donotconnectthecameratothecomputerbeforethedriverandsoftwareisinstalled.

2. Downloadimagesfromthecamerabeforethebatteryrunsout;otherwise,theimageswillbe

deletedautomatically.

3. Usegoodqualityalkalinebatteriesonly.Thecamerarequires2xAAAbatteries.

4. Thiscamerahasinterpolationto1.3millionpixelsbyCCDsoftware.



ABOUTTHISCAMERA:



ProductPackageContents

1. DigitalCamera

2. SoftwareCD

3. User’sManual

4. USBCable



SystemRequirements

1. Win98/2000/ME/XP/Vista

2. 125MBfreeharddiskspace,64MBROM

3. ColorMonitor(atleast800x600,24bitorhigher)

4. AvailableUSBInterfaceandCD‐ROMDrive



BatterySavingMode

Inordertosavebatterylife,thecamerawillautomaticallyenterbatterysavingModeifthe

cameraisnotusedin30seconds.



SoftwareInstallation



NOTE:Installthecameradriveronyourcomputerbeforeconnectingthecameratothecomputer.



1. InserttheprovidedCDintoyourcomputer’sdiscdrive.

2. Apop‐upwindowwillappearonyourcomputerscreentitled‘WelcometotheDCsoftware

Page’.

3. Choosefromthefollowingoptions:

‐ArcSoftImagingSoftware:installphotoandvideoeditingsoftware(PhotoImpressionand

VideoImpression)toyourcomputer.

‐InstallDCDriver:installthenecessarydriverstoyourcomputertoenablepicture

downloading.

‐BrowsingCD:BrowsethecontentsoftheCD.

‐Exit:exittheset‐upprogram.

4. Followtheon‐screeninstructions.



NOTE:IfyourcomputersystemisWin98,youmustrunaprogramfoundontheCDnamed

E:/Win/DIRECTX8.1bREDISTPACKAGE.EXE(EisCDDriver)beforeyouinstallthecameradriver.



HOWTOUSETHISCAMERA



CameraButtons



1. ShutterButton

2. Flash

3. BatteryCompartment

4. LCDDisplay



5. LightButton

6. ModeButton

7. USBConnection

8. Viewfinder



CameraLCDDisplay



Pressthe“Mode”buttontocyclethroughtheModesofthedigitalcamera.TheModesareshownon

theLCDdisplayonthebackofthecamera.



‐‐PhotoCounter

‐‐PowerofftheCamera

‐ ‐Timer/Auto‐shoot

‐ ‐RecordVideo

‐ ‐Takethreephotoscontinuously

‐  ‐Deleteallphotosinmemory

‐ ‐Deletethelastphoto

‐‐Choose“HI”or“LO”PhotoResolution

‐ ‐Choose“Hd”or“Ld”photocompression

‐ ‐Choose50Hzor60Hzflashfrequency



TakingPhotosandVideo

1. Pressthe“Mode”buttontoturnonthecameraand“Hi”willshowontheLCDdisplayatthe

backofthecamera.Thecamerawillmakeabeepsoundindicatingthecamerahasturnedon.

2. Holdthecamerasteadyandpressthe“Shutter”buttontotakephotos.

3. Thecamerawillbeeponcewhenthephotohasbeentaken.

4. TheLCDdisplayhasapicturecounterthatshowsthenumberofpictureslefttobetaken,and

willshow“0”whennomorepicturescanbetaken.

5. Thequalityoflightwillaffectthepicturequality.

6. RefertoCameraModes(below)totakevideo,shootthreeconsecutivephotos,orusethetimer.



CameraModes



TurnontheCamera

1. Pressthe“Mode”buttontoturnthecameraon.

2. TheLCDdisplaywilldefaulttoshowinghowmanypicturesareavailabletotake.

Turnoffthecamera

1. Pressthe“Mode”buttonuntil“Off”isshownontheLCDdisplay.

2. Pressthe“Shutter”buttonwithin5secondstoturnoffthecamera.

FlashOperation

1. Determinewhethertoturntheflashonindarkconditions.

2. Turnonthecamera.

3. Push“Light”buttontoturnontheflash.Flashwillbelitonthefrontofthecamera.

AutoShoot/TimerMode

1. Pressthe“Mode”buttonuntil isshownontheLCDdisplay.

2. Pressthe“Shutter”buttonwithin5secondstoactivatethe10secondtimer.Thecamerawill

beeponceeverysecond.

3. After10seconds,thecamerawillbeeponcetoindicatethatthephotohasbeentaken.



Video/AVIMode

1. Pressthe“Mode”buttonuntil isshownontheLCDdisplay.

2. Pressthe“Shutter”buttonwithin5secondstoactivateVideoModeandstartrecording.Donot

releasethe“Shutter”buttonuntilyouwanttostoprecording.Thecamerawillbeeponcefor

eachframerecordeduntilthe“Shutter”buttonisreleasedorthememoryisfull.

3. InVideoMode,thevideoistakenwithQVGACompressionandsavedasanAVIvideofile.You

mayopenitfromthephotodownloadsoftware.



NOTE:Videomayfailduetopoorlighting.



TakeThreePhotosConsecutively

1. Pressthe“Mode”buttonuntil isshownontheLCDdisplay.

2. Pressthe“Shutter”buttonwithin5secondstotakethreeconsecutivephotos.Thecamerawill

beepthreetimesforeachpicturetaken.



DeleteAllPhotos

1. Pressthe“Mode”buttonuntil isshownontheLCDdisplay.

2. Pressthe“Shutter”buttonwithin5seconds.Thephotocounterwillflash.Pressthe“Shutter”

buttonagainwithin5secondstodeleteallthephotosstoredinthememory.



DeleteSinglePhoto

1. Pressthe“Mode”buttonuntil isshownontheLCDdisplay.

2. Pressthe“Shutter”buttonwithin5secondstodeletethelastphototaken.



PhotoResolution

NOTE:TheresolutionstatuswillalwaysshowontheLCDdisplayas“HI”or“LO”.

1. Pressthe“Mode”buttonuntil isshownontheLCDdisplay.

2. Pressthe“Shutter”buttononcetoswitchfrom“HI”Resolutionto“LO”Resolution(orfrom“LO”

backto“HI”).

3. HIResolution:640x480pixels.

4. LOResolution:320x240pixels.



PhotoCompression

NOTE:Photosstoredinthememorycaneitherbesavedwith“Hd”or“Ld”compression.Thehigher

thecompression,themorephotosyoucantakebeforefillingupthememory.



1. Pressthe“Mode”buttonuntil“Hd”isshownontheLCDdisplay.

2. Pressthe“Shutter”buttononcetoswitchfrom“Ld”to“Hd”compression.

3. Toswitchfrom“Hd”backto“Ld”compression,pressthe“Mode”buttonuntil“Ld”isshownon

theLCDdisplay.Pressthe“Shutter”buttononcetoswitchfrom“Hd”to“Ld”.



HowManyPhotosCanIStoreontheCamera?

NOTE:Thenumberofphotosthecameracanstorebeforethememoryisfulldependsonwhich

resolution(HIorLO)andwhichcompression(HdorLd)youareusing.



HIResolution(640x480pixels)andHdCompression:76photos

HIResolution(640x480pixels)andLdCompression:25photos

LOResolution(320x240pixels)andHdCompression:274photos

LOResolution(320x240pixels)andLdCompression:100photos



FlashFrequency

1. Pleasekeepthefrequencyofthecameraflashinlinewiththatofthenaturallightintheroom.

2. Normally,theUnitedStatesuses60Hzfluorescentlampfrequency,soUSusersshoulduse“60”.

JapanandEuropeuse50Hz,soJapaneseandEuropeanusersshouldsetthecamerato“50”.

3. Pressthe“Mode”buttonuntil“60”isshownontheLCDdisplay.

4. Pressthe“Shutter”buttononcetoswitchfrom“50”to“60”hertzfrequency.

5. Toswitchfrom“60”backto“50”hertzfrequency,pressthe“Mode”buttonuntil“50”isshown

ontheLCDdisplay.Pressthe“Shutter”buttononcetoswitchfrom“60”backto“50”.



NOTE:Ifthewrongfrequencyisselected,linebendingmayoccurinphotosorvideos.



DOWNLOADINGTOYOURCOMPUTER

Whenyourcamera’smemoryisfull(oratanytime),downloadyourphotostothecomputer.Thenyou

candeletetheoldphotosoffofthecameratofreeupmemory.



NOTE:Installthecameradriverandphotosoftwareonyourcomputerbeforeconnectingthecamerato

thecomputer.Pleasesee‘SoftwareInstallation’ifyouhavenotdonethis.



1. UsethesuppliedUSBcabletoconnectthecomputertothedigitalcamera.Thecamerawill

makeabeepsoundindicatingtheconnectionisworkingproperly.

2. Browsetothe“MyComputer”folderandopenthe“MyDSC2”folderinstalledonyourdesktop.

Next,openupthe“MyDSC2”program.



3. Clicktheiconofthepinkcameraonthebottomleftofthewindowtodownloadthepictures

fromthecameratothesoftware.Youcannowchoosetoselectallofthephotosfromthe

camera,edittheimages,orsavetheimages.Youcanalsoselectindividualimagesbyleft‐

clickingonanimage.Right‐clickanimagetopreviewit.



Interpolation

NOTE:Youcaninterpolateanimageto1.3MP(MegaPixels)throughthe“MyDSC2”interface.Click

the“EditImage”icon.Awindowwillpopupasshownbelow.Interpolateanimageto1.3MPby

clickingontheHighQualityModeoption.



PCCamera



1. UsethesuppliedUSBcabletoconnectthecomputertothedigitalcamera.Thecamerawill

makeabeepsoundindicatingtheconnectionisworkingproperly.

2. Browsetothe“MyComputer”folderandopenthe“MyDSC2”folder.Next,openupthe

“PCCam”program.

3. Thefollowinginterfacewillappear:



4. ThecameraisnowanactivePCCam.Navigatetothe“Capture”settingandchoose“Start

Capture”tobeginrecordingavideofile.Theprogramwillaskyoutodesignateaplacetosave

thevideofile,andfilesize.Navigateto“Capture”andchoose“StopCapture”tofinishrecording.



PhotoEditingusingPhotoImpression5



UsingPhotoImpression5youcandownloadphotosfromyourcamera,edit,print,andsharephotos.

Pleaserefertothehelpdocumentationincludedwiththesoftwarefordetails.



VideoEditingusingVideoImpression2



UsingVideoImpression2youcancreatecustommoviesandslideshowsusingyourownvideoclips,

pictures,andsoundtracks.Pleaserefertothehelpdocumentationincludedwiththesoftwarefor

details.



APPENDIX1:Specifications



Imagesensor:300KpixelsCMOSsensor

Productsize:96x53x25mm

InternalMemory:8*16MBbuilt‐inSDRAM

Modes:DigitalVideoRecording(nosound)

StillPhotos

PCCamera

Resolution:640x480(VGA)

 320x240(QVGA)

FileFormats:24‐bitJPEG/AVI

Storagecapacity:VGA25images,compress76images

QVGA100images,compress274images

Display:ThreeDigital“888ICON”MonochromeLCDDisplay

Interface:USB2.0

ShutterSpeed:1~1/10000seconds

VideoFrameRate:5~10fps(VGA),15~25(QVGA)

Lens:Fixed

FocusRange:30cm~infinity(Normal)

Aperture:F2.4

PowerControl:Autopoweroffafter30secondswithoutoperation.Manualpoweronandoff.

SelfTimer:10seconddelay

PowerSource:2xAAAalkalinebatteries/USBpower

LowVoltagealarm:Auto

Viewfinder:Built‐in



GNBI Technical Assistance

Technical Assistance Hours: Monday thru Friday

9:00 am – 4:00 pm (Central Standard Time)

Email: gnbitech@gnbiusa.com

[email protected]m

Telephone: 1-866-541-GNBI (4624)

Reference Number: SY-058 (PO 2568)


