QUICK START GUIDE for GOelectronic Streaming Kit –
No Computer Needed (SDI Version)
First, let’s review what comes in this GOelectronic Streaming Kit:
1.GOelectronic GOHD400 PTZ Camera
2.GOelectronic RCC6000 PTZ Controller
3.Magewell 53020 UltraStream SDI
4.Blackmagic SDI to HDMI Converter
5.Coax Video Cables
6.VISCA PTZ Control Cable
7.Camera Wall Mount
Note, the preview monitor and related HDMI cable required for this system are NOT included.
You can use any TV/monitor with an HDMI input.

1Install the Camera
First, you will need to decide where you will be locating the camera. This is going
to depend on your application. Note, you will need to be able to plug the
camera’s power supply into a wall outlet near the camera’s mounted location. We
offer an optional wall mount for the camera should you need it.
You will make three connections to the GOHD400:
1. VISCA cable for PTZ control
2. Coax cable for video
3. Camera power supply
Both the video cable and PTZ control cable will run from the camera to your
“control room”.
Once you have plugged in the camera, power on the camera using the switch on
the back of the unit.
2Connect the Camera to the PTZ Controller
First, connect the controller’s power supply to the controller and plug it into a
wall outlet. Next, connect the VISCA PTZ control cable with the 9-pin serial
connector to the RCC6000 (you have already connected the other end of the PTZ
cable to the GOHD400).

3Connect the Camera to the Magewell
UltraStream
Now connect the coax video cable coming from the GOHD400 to the SDI INPUT on
the Magewell 53020 UltraStream.
You will also run audio out from your existing sound system (or microphone) and
into the audio input on the 53020 unit. The audio cable you require (not included)
will depend on the audio output of your existing equipment.

4Connect your Preview Monitor to the Magewell
UltraStream
First connect one end of the short coax video cable to the UltraStream SDI OUT and the
other end to the SDI IN on the Blackmagic SDI-to-HDMI converter.
Next connect one end of an HDMI cable (not included) to the HDMI OUT on Blackmagic
SDI-to-HDMI converter and the other end to the HDMI input on the TV/monitor (not
included).
5Setup up the Magewell UltraStream
Magewell’s UltraStream is used for streaming and recording (and previewing)
your broadcast. Download the preferred UltraStream user manual below and
follow instructions for setting up your UlstraStream.
User Manual (for Web GUI) here:
https://www.magewell.com/files/documents/User_Manual/UltraStream-
UserManual_en_US.pdf

User Manual (for App) here:
https://www.magewell.com/files/documents/User_Manual/ultra_stream_family
_user_manual_app_v1.4.34_en.pdf
Assuming your camera is powered on and you have correctly connected all
equipment, you should see video from the camera on your preview monitor.
6Test the PTZ Controller
Now is a good opportunity to test the ptz controller. Power on the ptz controller
via the switch on the back. Follow the steps below to add the camera:
1. Confirm that the ptz controller is in analog mode (on controller screen,
Active I/F reads “Analog”). If it does not read “Analog”, long press the
joystick button on the RCC6000 to switch to analog mode (until screen
reloads and Active I/F reads “Analog”).
2. Press and hold [CNTRLR SETUP] on the RCC6000 to set the camera address.
Now press [CAM 1] and try moving the camera using the joystick. You should see
the camera move and the picture change within Capture Express.
Now, try setting up some preset positions. Move (pan, tilt and/or zoom) the
camera to a desired location. Press and hold [PRESET 1] for 5-7 seconds. Move the
camera to a new position and press and hold [PRESET 2] for 5-7 seconds. Now
quick press [PRESET 1] and watch the camera move to the preset position. Quick
press [PRESET 2] and watch the camera move again. You may consider creating a
“cheat sheet” or legend for your presets.

For more detailed operating instructions for each
product in the system, please view the individual
product manuals.
For questions or for technical support, please contact
GOelectronic at 888-707-8024 or via our online
support request form at
https://www.goelectronic.com/pages/contact-us
