Go-Float Sun Lounger Fusion User manual

Electric Boats
Electric Boats Electric Boats
Electric Boats
Sun Lounger Series
Sun Lounger Series Sun Lounger Series
Sun Lounger Series
2014 Owners Manual
2014 Owners Manual2014 Owners Manual
2014 Owners Manual
®

Go-Float Electric Boats
Welcome to Go-Float!
We appreciate your choice of Go-Float Electric Boats for your boating
pleasure. We hope you will be completely satisfied with your purchase
and enjoy it for many years.
Your new Go-Float has been designed to give you and your family
years of trouble free fun on the water. lease read this manual carefully
before operating your boat. This manual will assist you in operation,
safe use, and care of your Go-Float. By taking a few moments to
familiarize yourself with the functions of your Go-Float, you can help
make your investment last.
lease do not hesitate to contact us with questions or suggestions. We
want to ensure that your boating experience is as safe and relaxing and
as fun as possible. Enjoy your Go-Float!
Sincerely,
S. Be safe… always wear a personal flotation device. Know and
comply with all applicable local boating regulations.
Copyright 2014 Go-Float, LLC

TABLE OF CONTENTS
Overview
Go-Float Fusion & Impulse Overview ................................................4
Go-Float Vortex Overview .................................................................5
Operation
Getting Started ...................................................................................6
Speed Control.....................................................................................7
Steering & ower Control...................................................................7
Automatic Bilge ump ........................................................................7
Beach Buddy™...................................................................................8
Listening to the Stereo .......................................................................8
Monitoring the Battery Life .................................................................9
Charging the Battery ..........................................................................9
Boarding Safely ................................................................................10
Storage and Maintenance
Beaching...........................................................................................10
Storing On End .................................................................................10
Motor Maintenance...........................................................................10
ropeller, changing ..........................................................................11
Safety & Troubleshooting
Troubleshooting................................................................................12
Safety ...............................................................................................12
Go-Float, LLC
1605 North First Avenue
Fergus Falls, MN 56537
hone: [phone]
Fax: [phone]
Local: [phone]
Email: [e-mail]
Website: www.Go-Float.com

Overview of Go-Float Fusion & Impulse Features
Cup Holder
Cooler/ Storage
Compartment Stereo Control &
Battery Meter
Steering Handle
AC lug Input
Receptacle
Bow
(front)
Starboard
side
Port side
Stern
(rear)
Seat removes to
access Battery
Speed
Control
Fusion shown

Overview of Go-Float Vortex Features
Cup Holder
Cooler/ Storage
Compartment
Steering Handle
AC lug Input
Receptacle
Bow
(front)
Starboard
side
Port side
Stern
(rear)
Seat Back flips
forward to access
Battery
Speed
Control
Battery Meter
Stereo Control &
M 3 layer
Storage

Getting Started
Congratulations on your purchase of a Go-Float electric watercraft,
what we consider to be the finest and simplest electric boat on the
market today!
This manual will simplify getting you started and on the water, enjoying
your new Go-Float electric boat.
Battery Connection:
Go-Float boats are generally shipped with the battery(s) disconnected.
If your battery meter shows a green bar that indicates charge, your bat-
teries are already connected. If not, you will connect your battery(s) by
pulling forward the seat panel (Vortex) or removing the seat tray
(Fusion, Impulse).
To remove the seat tray, open your cooler and unlatch the seat tie-
downs that you will find in the front of the cooler. This is best accom-
plished with the boat resting on its hull, as the seat tray could slide for-
ward if it is set on its stern in the upright storage position. With the tie-
downs unlatched, lift the seat tray out.
Inside the equipment compartment you will find red and black connect-
ors coming from both the power buss bar and from the battery(s). Hook
one connector set from the buss to a battery, if you have two batteries,
hook one set to each battery. You should now have a battery charge
indication. Replace the seat tray or close the seat panel.
Operation
To make the boat go, select a speed on the speed selector knob and
push the go-button in the grip of the steering handle with your thumb. It
is best to not run the motor while the boat is out of the water, but a short
test to check your motor’s operation will not harm the motor.
Charging
lug an extension cord into the charging port. This can be done while
the battery(s) are connected or disconnected, but should not be done
while the boat is in the water. After charging, if the meter does not show
a full charge, disconnect the extension cord, disconnect the
battery(s), count to ten and reconnect the battery(s). Your meter should
now indicate a full charge.

Steering and Power Control Handle
ower “GO” Button: To turn on the mo-
tor, press the “GO” button with
your thumb at the end of the
steering handle. To turn off the
motor, release thumb pressure from the
“GO” button.
IMPORTANT! Be alert for swimmers
near your boat! Always release the
“GO” button to turn off your motor when
others approach your boat.
Steering: When in forward motion, to
steer right, push the handle forward. To steer left, pull the handle back.
Steering directions are opposite when in reverse.
Speed Control
Each number indicates a rate of speed.
“OFF 0” is neutral with no forward or reverse
motion.
FORWARD 1 thru 5. 1 is the slowest forward
speed, good for navigating around other boats,
for docking and beaching. Each higher number
increases speed, with 5 being the highest
speed.
REVERSE 1 is a slow speed, good for navigating around other boats
and for docking.
REVERSE 2 is a higher speed, good for quickly slowing the boat and
for spinning weeds off of the prop.
The speed can be changed while the boat is underway, but it is
recommended to stop the motor (release thumb pressure from the “GO”
button) to change direction. Changing direction suddenly while
underway could damage the motor.
“GO” Button
Right
Le turn
Automatic bilge pump. Any water that accu-
mulates inside the hull will activate the bilge pump
to automatically remove the water. Water is eject-
ed through the hull via the round plastic fitting
found on the port side of your Go-Float (shown at
left).
Keep this opening unobstructed during use of
your Go-Float.
Automatic Bilge Pump

Beach Buddy with optional wheel
kit for paved surfaces.
The Beach BuddyTM, is designed to protect the
motor and propeller from underwater objects
while cruising or beaching your Go-Float. It is
also used to stand your Go-Float on end for
storage in small areas. For instructions on
storing upright, see page 10. While underway it
may catch weeds. If you think you have slowed
because of weeds on the Beach Buddy, follow the same procedure as
for removing weeds from the propeller on page 11. Wheel Kits are avail-
able to add to your Go-Float Beach BuddyTM for easier movement
across lawns, driveways, etc.
Do not use the Beach Buddy as a step to enter the boat.
Beach BuddyTM
Stereo (optional). i od ready. Compati-
ble with most M 3 players and other audio
devices. Refer to the manufacturer’s man-
ual included with your boat.
Caution: close media tray before entering
or leaving the boat to prevent damage to it.
Stereo
Optional wheel kit for sand/soft
surfaces.

The Battery Status Indicator is
specifically designed to monitor the
charge status of the battery(s)
onboard your Go-Float.
Interpreting Battery Status. The
battery indicator has ten vertical
bars that light green to indicate the
charge status of your battery(s). If
no bar is lit, the battery(s) are dis-
connected or are dead. A fully
charged battery will indicate a green
bar on the right side of the meter, while a green bar on the left of the
meter indicates a depleted battery charge. A good time to recharge
your battery(s) is when three bars are lit.
CAUTION: This is not a fool-proof device and no warranty is made that
your battery(s) condition is good. All charge levels are approximate.
Monitoring the Battery
Keep your batteries fully charged prior to use.
Onboard charger. Your Go-Float is equipped
with the an onboard charger. Use a UL
approved, three-pronged extension cord
designed for outdoor use to connect to your
source of electricity. The AC lug Receptacle
is located on the deck of your Go-Float.
Battery(s) can also be charged with a standard
automobile battery charger. Access the battery
by removing the seat back (Vortex) or
removing the entire seat (Fusion, Impulse). The battery may remain in
the boat or be removed to recharge. Be sure to connect the battery
charger to the battery poles ositive-to-ositive and Negative-to-
Negative. Consult your charger’s operating manual to determine the
appropriate settings.
CAUTION Do not charge battery(s) while boat is in the water.
Move your boat to dry land first.
Charging the Battery
AC Plug Receptacle

Upright, Temporary Be sure that the battery hold down strap is
secured. Remove all items from the cooler-storage compartment and
the passenger area. Rest the boat on a flat surface on the Beach Buddy
and raise the bow until the boat is completely upright and resting on its
transom. Be sure that your Go-Float is out of the wind so as not to blow
over.
Upright, Long Term Follow the above procedure, but to extend the
life of your battery, remove it first. Store the battery on a wooden
surface, such as a piece of lumber, indoors. Use a trickle charger about
every 4-6 weeks to keep the battery powered up.
IMPORTANT! Use a heavy line attached to the bow eye to secure
your Go-Float to a solid fixture, such as a rafter. This will prevent your
Go-Float from accidently falling over. Do not store upright outdoors—
the wind may blow the boat over. Upright storage is not recommended
for the Vortex.
Storage
Beaching
IMPORTANT! When your Go-
Float is on shore in a horizontal
position, it is recommended that
you do not step into the boat. Seri-
ous damage may occur to the hull,
deck, and Beach BuddyTM.
Battery
The battery included with your boat
is sealed, so do not worry about it
leaking during upright storage.
Boarding Safely
With your Go-Float in the water, to
safely board, step as far as you are
able into the center aft portion of
the seat. This will keep the boat as
stable as possible while you are
boarding. This will also place your
weight onto the strongest area of
the deck. Reverse the procedure
for safe disembarking.
Bow Eye
Bow Eye
BeachBuddy

Motor Maintenance
We recommend after use to rinse the motor to remove sand and other
debris. Check the propeller for line or weeds. Regularly check for loose
fasteners, corroded or loose terminal connections and frayed wires.
Keep moving parts lubricated. An aerosol lubricant works well.
Electrical Connections
Before removing or installing the battery, ensure that all switches are in
the OFF position and have the propeller area clear. If replacing or
adding a battery, we highly recommend ordering your battery from Go-
Float to ensure safety and good performance.
Changing the Propeller
Before doing anything with the propeller, be sure the cables to the
battery are disconnected. Detaching the propeller is a simple mat-
ter of unscrewing and removing the locknut using the special tool sup-
plied. When doing this, take hold of the propeller to stop it from turning.
Under no circumstances should you attempt to loosen the locknut with
a hammer or similar tool as this may damage the locknut or shaft – or
both. (F)
Once the locknut is removed, you will be able to slide the propeller off.
When putting the propeller back on, verify there is a proper fit of the
groove and shear pin otherwise the propeller will not be locked in place.
(G)
After using the motor always check and clear any weed or fishing line
that may have become tangled around the propeller. Next, give the
motor a wipe down with warm water to remove any salt or sand
particles and then spray it with fresh water.

Troubleshooting
Symptom ossible Cause/Solution
•Speed loss 1. Check for weeds or fishing line on
the propeller and remove.
2. Check battery charge status.
3. Check battery connections.
•Weeds on prop
•Weeds on Beach BuddyTM Weed Removal while Underway
1. Set the speed control at Forward 5
and spin the propeller briefly.
2. Stop the motor, set the speed at
Reverse 2 and spin the propeller
briefly.
3. Reset the speed to forward and
check for improved performance.
4. Repeat steps 1-3 until weeds are
cleared and satisfactory
performance has returned.
•Weeds on prop
•Weeds on Beach BuddyTM Weed Removal Manually
CAUTION! TURN MOTOR OFF before
attempting to remove weeds by hand.
•Motor noise or vibration 1. Check propeller for weeds or
fishing line.
2. Check to see propeller is secure
and not damaged.
Personal Flotation Device. We recommend that a proper personal
flotation device be worn by all occupants of the boat.
Motor and Propeller Always watch for other boaters or hazards
while on the water. This boat is not designed to be a swimming or
diving platform. Watch out for swimmers near your boat.
Spinning props can cause serious injury or death.
Motor. Do not run the motor out of the water. The motor needs to
be submerged in water to stay cool. Running the motor when dry can
seriously damage the motor’s seals.
Go-Float, LLC can not be responsible for accidents due to misuse,
modifications or for use of the boat in any manner other than its
intended use.
Boating Safety
