Go Rhino 24371T User manual

1
Parts List
Item
Qty.
Part #
Description
Item
Qty.
Part #
Description
Torque
1
1
24371T
Bumper Replacement shell
13
20
½” x 1 ½ ” Hex Bolt
64Ft. Lbs
2
1
Passenger Frame Bracket
14
6
½” x 1 ½” Carriage Bolt
64 Ft. Lbs
3
1
Driver Frame Bracket
15
34
½” Flat Washer
4
2
Driver Auxiliary Bracket
16
26
½” Lock Washer
5
1
Passenger Auxiliary Bracket
17
20
½” Hex Nut
6
1
Driver Vent Cover
18
6
7/16” x 2 ” Hex Bolt
42 Ft. Lbs
7
1
Passenger Vent Cover
19
12
7/16” Flat Washer
8
1
Winch Cover
20
6
7/6” Lock Washer
9
2
Light Pod Plate
21
6
7/6” Hex Nut
10
1
License Plate Bracket
22
38
¼” x ¾” Button Head Bolt
11
4
Hole Plug
23
10
¼” Nylon Lock Nut
24
2
3/8” x 1 ¼” Hex Bolt
26 Ft. Lbs
Required for Installation (Sold Separately)
25
2
3/8” Lock Washer
26
2
3/8” Flat Washer
12
1
24273TW
Mounting Plate/Winch Tray
27
2
3/8” Hex Nut
Installation Instructions
BR10 Front Bumper Replacement Part # 24371T
2011-2015 Ford F-250, F-350 Super Duty 2/4WD
Do not attempt to install this product on any vehicle other than the one listed above!
DAKAR PRO Brackets Part
# 524765
2014 Chevrolet Silverado 1500 2/4WD
Do not attempt to install this product on any vehicle other than the one listed above!
Tool Required:
13mm, 15mm, 18mm, 7/16”, 9/16” & 3/4” Sockets
13mm, 15mm, 18mm, 7/16”, 9/16” & 3/4” Wrenches
Slotted Blade Screw Driver
5/32” Hex Key
Ratchet, Ratchet Extensions & Swivel Joint Adapter Approximate installation time: 90 min
1
7
5
9
4
3
6
8
12
ILLUSTRATION #1
2
6
6
6
6

2
Read the assembly and installation instructions completely and verify that all of the parts listed are accounted for. If you have
defective, missing or damaged parts or need assistance, please contact Go Rhino Products for fast, friendly customer service
at: 1-888-427-4466 or email: [email protected]
Front Bumper Removal
Step-1 Remove the plastic fasteners and rubber air deflector from the bumper and bottom of the vehicle, (Photo 1).
Note: If the vehicle has these options or equipment.
Fog Lights
Unplug the fog light wiring harness and remove the plastic fastener securing the wiring harness to the bumper, (Photo 2).
Engine Block Heater
Remove the plastic fastener securing the power cord to the bumper.
Step-2 Remove the bolts (2) per side securing the bumper support brackets to the bumper, and loosed the bolts (2) per side
securing the support bracket to the vehicle frame, (Photo 3).
Step-3 Remove the bolts (2) per side securing the front of the bumper to the bumper brackets, (Photo 4).
Remove the bumper from the vehicle and set it aside.
#1
#2
Driver
Side
#3
Driver
Side
#4
Driver
Side

3
Replacement Bumper Installation
Step-1 Remove the bolts (3) per side securing the tow hooks and bumper bracket assembly to the frame, (Photo 1). If
equipped remove the nuts and bolt plates securing the under rider guards to the frame, (Photo 2).
Step-2 Install the driver’s side frame bracket by positioning the bracket over the top and sides of the frame. Position the
driver side auxiliary bracket on top of the frame bracket align the holes and secure the auxiliary bracket and frame bracket to
the top of the frame using (3) 7/16” x 2” hex bolts (6) 7/16” flat washers, (3) 7/16” lock washers and (3) 7/16” hex nuts.
Secure the frame bracket and auxiliary bracket to the sides of the frame using (4) ½” x 1 ½” hex bolts, (8) ½” flat washers, (4)
½” lock washers and (4) ½” hex nuts, (Photo 3 & 4). Leave the nuts and bolts loose for final adjustment. Repeat this step to
install the passenger side brackets.
#1
Driver
Side
#2
Driver
Side
#3
Driver
Side
#4
Driver
Side
7/16” hex bolts, washers & hex nuts
1/2” hex bolts, washers & hex nuts

4
Step-3 Position the winch tray on top of the auxiliary brackets. Secure the winch tray to each frame bracket using
(3) ½” x 1 ½” hex bolts, (3) ½” flat washers, (3) ½” lock washers and (3) ½” hex nuts, and to the auxiliary bracket
using (3) ½” x 1 ½” carriage bolts, (3) ½” flat washers, (3) ½” lock washers and (3) ½” hex nuts, (Photo 5).
Adjust and position the winch tray mounting flanges approximately ¼” off center from the frame bracket flanges
toward the driver side of the vehicle and tighten all factory and supplied nuts and bolts.
Step-4 With assistance lift the replacement bumper shell up to the vehicle, align the holes in the bumper brackets
with the weld nuts on the winch tray and secure the replacement bumper shell to each side of the winch tray
using (3) ½” x 1 1/2” hex bolts, (3) ½” lock washers and (3) ½” flat washers, (Photo 6). Leave the bolts loose for
final adjustment.
Step-5 Align the holes and attach each of the factory bumper support brackets to the replacement bumper
support brackets using (2) 3/8” x 1 1/4” hex bolts, (2) 3/8” flat washers, (2)3/8” lock washers and (2) 3/8” hex nuts,
(Photo 7).
Step-6 With assistance, adjust and hold the replacement bumper shell visual alignment, then tighten the support
bracket factory and supplied nuts and bolts then all remaining nuts and bolts.
If installing a winch, install the roller fairlead to the bumper replacement at this time. Refer to the winch
manufacturer’s instructions for installation. If installing an optional light bar, install the light bar to the bumper
replacement at this time. Refer to the light bar instructions for installation.
#5
Driver
Side
#6
Driver
Side
#7
Driver
Side
#8
1/2” carriage bolts, washers & hex nuts

5
Step-8 Install the winch cover and driver and passenger side front vent covers to the bumper using the
supplied ¼” x ¾” button head bolts, (Photo 9).
Step-9 Install the flush mount light pods to the bumper using (4) ¼” x ¾” button head bolts and (4) ¼”
nylon lock nuts, (Photo 10).
If your state law requires a front license plate, attach the license plate bracket to the holes in the face of the
bumper, using the supplied 3/8” bolts, washers and nuts, and the license plate to the (2) obround holes in the
license plate bracket using the supplied ¼” bolts and nuts.
If installing a winch, attach the license plate directly to the (2) obround holes in the lower face of the bumper shell
using the supplied ¼” bolts and nuts. Remember to check and retighten all factory and supplied nuts and bolts
periodically.
#9
#10
Driver
Side
