GOAL ZERO RockOut Speakers User manual

Chain multiple speakers together
for even more boom.
1. Be sure to ACTIVATE YOUR WARRANTY at www.GOALZERO.com/warranty
2. Connect the ROCK OUT to your audio player with the audio input cord.
3. Turn it on to start playing.
4. Recharge through any USB power source, with included USB cable.
Get to Know Your Gear
How to Use Technical Specs
Comes With
Getting Started
HANG IT
PROTECT IT
RECHARGE IT
Use the elastic cord to attach the
speaker to your pack or ride.
Audio device and cable fit neatly
inside the internal pocket.
CONNECT IT
Input cord works with any
standard headphone jack.
Recharge directly from any USB power
source with the included cable.
Charging port Mini-USB jack, 5V
Audio input cord 3.5mm male plug, line-level
Inputs
Usage
Weight 14.4 oz (0.40 kg)
Dimensions 6x5x3 in (15 x 12.7 x 7.6 cm)
Warranty 12 months
Certifications CE and FCC
Optimal operating temp. 32-104ºF (0-40ºC)
Speakers 2x 40mm, 4 ohm, 2W drivers
Amplifier Stereo, 2W max, 70dB SNR, 70Hz-18KHz
Battery Lithium-ion, 3.7V, 0.6Ah (2.0 Wh)
Battery mgmt. Integrated and fully automatic
Mini-USB charging cable
Audio input cord (built-in, 3.5mm plug, 300mm cord)
General
Outputs
Audio output port 3.5mm female audio jack, line-level (chaining)
Run time Up to 20 hours
Recharge time 2 hours
Internal
USB-mini charging port and Charging LED
Charge directly from any USB power source, with included USB
cable. Red light indicates charging and turns off when full.
Audio output port
Chain an additional ROCK OUT speaker through this port.
Power switch and Power LED
Slide power switch to “ON.” Red indicates power is on.
Audio input cord
Plug your audio device into the built-in 3.5mm audio input.
CHAIN IT
The wooden sound box produces an
impressively full range of sound.
ROCK IT
Mini-USB,
Charging LED
Audio output
port (chaining)
Power switch,
Power LED

Output Ports
Frequently Asked Questions
How durable is it?
The ROCKOUT is impact and weather resistant. It can handle a hit, but take care to
protect your audio equipment if stored inside.
Does it need to be plugged in for power?
Nope. The ROCKOUT has a built in battery that will last up to 20 hours depending on how loud you
crank the volume. Recharge from any USB power source.
Can multiple speakers be chained together?
Yes. Chain any number in close proximity together with the built-in cording, or use a 3.5mm audio
extension cable for larger spaces. Each speaker in the chain must be recharged separately.
Is the internal battery replaceable?
No, but it will last for hundreds of cycles, or several years of use.
Output Ports
Compatible With
CONTACT US:
Toll Free: 888.794.6250
14864 Pony Express Road
Bluffdale, UT, 84065
WWW.GOALZERO.COM
We proudly support TIFIE Humanitarian
WWW.TIFIE.ORG
USER GUIDE
Audio devices, like:
Smartphone
MP3 player
Laptop
Anything with a phone jack
GOAL ZERO products:
NOMAD solar panels
GUIDE 10 PLUS
SHERPA power packs
• Fill out your warranty
• Watch demo video
• Download this manual
