Gocontrol GC-TBZ48 Original operating instructions

MODE
FAN 74
Off
Auto
F
Model GC-TBZ48
Battery Powered Z-Wave
Thermostat
Installation & Operation Guide

Table of Contents
Typical Wiring for Standard Gas/Electric HVAC System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Typical Wiring for Heat Pump HVAC System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Thermostat Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
The C Wire. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
24VAC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Baery Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Z-Wave Operaon when Baery Powered. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Remove Exisng Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Wiring Colors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Install the Back Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Standard HVAC System Connecons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Single and Dual Transformer Systems (Split Systems) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Single Transformer System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Dual Transformer Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Heat Pump HVAC System Connecons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Mount the Thermostat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Baery Installaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Thermostat Setup Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Preset HVAC System sengs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Wait Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Minimum Run Time (MRT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Entering Menu Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Menu Mode Navigaon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
System Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
System Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Fan Type (For Standard HVAC systems only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Changeover Type (For Heat Pump HVAC Systems Only) . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Z-Wave Installaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Inclusion and Exclusion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Clock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Seng the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
INFO Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Advanced System Sengs Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Thermostat Operaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Main Thermostat Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Backlight and Buon Operaon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Staging Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Seng the System Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
System Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Special Heat Pump Mode: Emergency Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Seng the Heang or Cooling Temperature Setpoint. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Automac Setpoint Push . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Seng the Fan Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Fan Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
User Customizaon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
User preference sengs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Clock Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Seng the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
INFO Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Specificaons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Regulatory Informaon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Industry Canada Noces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Copyright ©2015 Nortek Security & Control LLC 1
GC-TBZ48
BATTERY POWERED Z-WAVE THERMOSTAT
INSTALLATION INSTRUCTIONS
The Z-Wave Thermostat (GC-TBZ48) is a programmable, Z-Wave communicang thermostat.
It can be powered using 24VAC (if both “R”&”C”wires are available at the thermostat), or
using four (4) AA baeries. Using Z-Wave technology, end users have the ability to use the
2GIG Go!Control panel to control the thermostat, configure programming sengs, as well
as to display current condions in the home or office.
Figure 1. Z-Wave Thermostat Front View
MODE
FAN
Y
BATTERIES (4) PHILLIPS
SCREWS (2)
ANCHORS (2)
ADHESIVE WIRING LABELS SHEET
GC-TBZ48 THERMOSTAT
Features Include:
• A fixed format display with white backlight
• Heang and cooling setup display opons
• System mode (OFF, Heat, Cool, Auto,
E-Heat)
• Fan mode control and display (Auto, ON)
• Changeover type for Heat Pump (HP)
systems
• On-screen setup of HVAC type, Fan type
• F/C mode, and sensor calibraon
Compatible with 24 VAC gas, oil, or
electric heating and air conditioning
systems; or gas millivolt heating
systems
DO NOT USE ON 120VAC SYSTEMS!
Standard Systems
• 1 Stage Heang and Cooling
• 2 Stage Heang and Cooling
Heat Pump Systems
• 1 Stage Heang and Cooling
• 2 Stage Heang and Cooling
• 2nd or 3rd Stage Aux Heang (Electric Heat
Strips
Box Contents
• 1─Z-Wave Thermostat
• 1─Sheet Adhesive Wiring Labels
• 2─Plasc Wall Anchors
• 4─AA Baeries
Installation Outline
• Step 1 Remove Exisng Thermostat
• Step 2 Install GC-TBZ48 Thermostat
• Step 3 Setup Thermostat to match System
Type
• Step 4 Install into Z-Wave Network

2Copyright ©2015 Nortek Security & Control
Typical Wiring for Standard Gas/Electric HVAC System
THERMOSTAT CONNECTION
C 24VAC COMMON
R 24VAC RETURN
W1 HEAT STAGE 1
W2 HEAT STAGE 2
G FAN
Y1 COMPRESSOR STAGE 1
Y2 COMPRESSOR STAGE 2
TYPICAL THERMOSTAT WIRING COLORS.
CAUTION: VERIFY THAT ORIGINAL WIRING
MATCHES. COLORS MAY BE DIFFERENT
STANDARD HVAC SYSTEM
BLUE
RED
WHITE
ORANGE
GREEN
YELLOW
BLACK/BROWN
THERMOSTAT BACK PANEL
INTERNAL RC=RH JUMPER
CWIRE IS NOT REQUIRED
FOR BATTERY OPERATION
CWIRE IS REQUIRED FOR
24VAC OPERATION
DEFAULT THERMOSTAT SETUP:
TYPE: STANDARD HVAC
FAN: GAS HEAT
1 STAGE HEATING
1 STAGE COOLING
NO SETUP CHANGE REQUIRED
FOR THIS CONFIGURATION
Y2 Y1 G RC CRH W1 W2
FOR SINGLE
TRANSFORMER SYSTEMS
CONNECT RWIRE TO
EITHER RC OR RH
TERMINAL
FOR SYSTEMS WITH SEPARATE
HEATING AND COOLING
TRANSFORMERS, CONNECT
HEATING RTO RH AND COOLING
RTO RC. NOTE! THE RC-RH
JUMPER MUST BE CUT
ON THE THERMOSTAT BOARD.

Copyright ©2015 Nortek Security & Control LLC 3
Typical Wiring for Heat Pump HVAC System
THERMOSTAT CONNECTION
C 24VAC COMMON
R 24VAC RETURN
W1 HEAT STAGE 1
O CHANGEOVER VALVE
G FAN
Y1 COMPRESSOR STAGE 1
Y2 COMPRESSOR STAGE 2
TYPICAL THERMOSTAT WIRING COLORS.
CAUTION: VERIFY THAT ORIGINAL WIRING
MATCHES. COLORS MAY BE DIFFERENT
HEAT PUMP HVAC SYSTEM
BLUE
RED
WHITE
ORANGE
GREEN
YELLOW
BLACK/BROWN
THERMOSTAT BACK PANEL
Y2 Y1 G R C RW1
O
INTERNAL R=R JUMPER
CWIRE IS NOT REQUIRED
FOR BATTERY OPERATION
BATTERIES ARE NOT
REQUIRED FOR 24VAC
POWERED SYSTEMS
CONNECT THE R WIRE TO
EITHER R TERMINAL.
R = R ARE JUMPERED
TOGETHER INTERNALLY
NOTE: IF HEATING IS OCCURING
WHEN COOOLING IS EXPECTED,
OR VICE-VERSA, CHANGE THE
CHANGEOVER TYPE TO THE
OPPOSITE SETTING.
O or B WIRE
NOTE! MOST HEAT PUMP
SYSTEMS DO HAVE THE C
WIRE AND THE
THERMOSTAT CAN BE
POWERED BY THE 24VAC
FROM THE HVAC SYSTEM

4Copyright ©2015 Nortek Security & Control
Thermostat Power
The thermostat can be powered by either 24VAC from the HVAC system or from four (4) type AA
internal baeries. DO NOT use this thermostat for line voltage controls (120/240VAC).
The C Wire
If the 24VAC common wire (usually blue) is present and is connected to 24VAC common at the HVAC
system end, the thermostat can be powered from the HVAC system and baeries are not required. If
there is no common wire, baeries are required.
24VAC Power
Powering the thermostat with 24VAC power requires both the 24VAC “C” common wire (typically a
blue wire) and the 24VAC ”R” return wire (typically a red wire).
BaƩery Power
Powering the thermostat from baeries does not require a “C” wire connecon.
DO NOT install baeries if the thermostat is powered by 24VAC. They are not required for backup.
If the thermostat is powered by baeries, the thermostat will operate for approximately (2) two
years on four (4) AA Alkaline baeries depending on the frequency of user operaons and backlight
operaon. Always use Alkaline baeries and replace in complete sets of four (4) at a me.
Z-Wave OperaƟon when BaƩery Powered
IMPORTANT: If the thermostat is installed on a Z-Wave network, while it is baƩery powered, it will
NOT work as a Z-Wave repeater.
CAUTION: Do not install baeries and temporarily power the thermostat from 24VAC to include onto
a Z-Wave network. Shortened baery life may occur when 24VAC power is removed.

Copyright ©2015 Nortek Security & Control LLC 5
Remove Existing Thermostat
• Turn offthe power to the thermostat. This is usually done at the heang/cooling system or
circuit breaker panel.
• Remove the cover of old thermostat to expose the wiring terminals.
• Take a picture of the wiring terminals and the wires before disconnecting them!
• Mark the exisng thermostat wires with the wiring labels included according to the terminal
markings. Some installaons may have addional wires not shown in this example illustraon.
Y1, Y2, W1, W2, O,B.
• Use the thermostat terminal “names/marking” (not the wiring color) to mark the wires.
• Remove the old thermostat base.
CAUTION: When removing thermostat, don’t let the wires slip into the wall and don’t let the wires
touch each other.
• If the old thermostat was a mercury style thermostat, dispose of it properly as described below.
Figure 2. Label Wire Terminals
NOTE: Taking a picture is critical if problems are encountered. This will allow reinstallation
of the old thermostat and will help with troubleshooting later if needed.
Terminal Typical Wire Color Function
Y YELLOW Cool
W WHITE Heat
G GREEN Fan
R RED 24VAC Return
CBLUE 24V Common (typically BLUE). When the wire is
present, the thermostat can be powered without
baeries. When the wire is absent, the thermostat
must be powered by baeries if 24VAC is present
across the R&C wires
Wiring Colors
While the thermostat terminal markings are intended to match the wire color, (R=RED, G=GREEN,
W=WHITE, Y=YELLOW) be sure to follow the terminal marking when marking the wires, even if the
wire color doesn’t match.
WARNING: If the exisƟng thermostat is a mercury-containing device, it must be disposed
of in compliance with federal, state, and local regulaƟons. Many states and /or local
agencies have collecƟon/exchange programs or hazardous waste collecƟon programs for
mercurycontainingdevices. For more informaƟon, see the U.S. Environmental ProtecƟon
Agencywebsite at:hƩp://www.epa.gov/osw/hazard/wastetypes/universal/mce.htm For Canada:
Environment Canada and Disposing of Mercury Products at: hƩps://www.ec.gc.ca/mercure-
mercury/default.asp?lang=En&n=F111AAC6-1.
C
R
G
W
Y
C
RG
W
Y
LABEL THE WIRES TO MATCH
THE OLD THERMOSTAT TERMINAL
MARKINGS
EXISTING THERMOSTAT TERMINALS
TAKE A PICTURE!

6Copyright ©2015 Nortek Security & Control
Install the Back Panel
Remove the back panel of the thermostat by pushing down the thumb tab on the boom of the body.
Figure 3. Removing back panel of thermostat.
Mount the thermostat back panel on the wall (See Figure 4).
1. Use the two (2) wall anchors and two (2) Phillips screws (provided) to mount the back panel.
2. Level as needed.
Figure 4. Mounting the Back Panel
BACK PANEL
BODY (WITH PCB)
PUSH ON THUMB TAB TO RELEASE
BACK PANEL
Y2 Y1 G RC C RH W1 W2 Standard
Y2 Y1 G R C R WI 0 Heat Pump
ANCHORS (2) PROVIDED
PHILLIPS SCREWS (2) PROVIDED

Copyright ©2015 Nortek Security & Control LLC 7
Standard HVAC System Connections
NOTE: For typical connecons to a Standard HVAC system, refer to the diagram on Page 2.
The terminals on the back panel have two sets of labels. The upper label shows the STANDARD HVAC
terminal connecons. The lower label shows HEAT PUMP HVAC terminal connecons.
Figure 5. Standard HVAC System Terminal Block Labeling
Figure 6. Standard HVAC Systems Terminal Block Connections
Single and Dual Transformer Systems (Split Systems)
HVAC systems may have one or two transformers. The “R” wire connects differently depending on
the system.
Single Transformer System
Most HVAC systems have a single 24VAC transformer. For these systems, there is only one “R”
wire and it can be connected to either the thermostat’s RC or RH terminal as these are internally
jumpered together.
If installing a Standard HVAC system, connect the wires from the HVAC system to the corresponding
terminals on the thermostat back terminal block. Use the table below as a guideline for connecng
the wires.
Wire Terminal
Y Connect to the Y1 terminal
G Connect to the G terminal
R Connect to either RC or RH terminals (Except for Dual Transformer Systems, See Next
Page)
C Connect to the C terminal. C wire (24VAC common) may not be present. If not present,
baeries MUST be installed.
W Connect to the W1 terminal
NOTES: Ensure that the appropriate wires are screwed into the terminal blocks firmly.
Gently pull on the wires to confirm the connecon.
Push all excess wiring back into the wall opening.
Y2 Y1 GRC CRH W1 W2
W
C
R
G
Y
STANDARD
Y2 Y1 GRCRW1 OHEAT PUMP
(STICKER LABELED WIRES)
REFERENCE
STANDARD
TERMINALS
CONNECT IF 2 STAGE SYSTEM CONNECT IF 2 STAGE SYSTEM
Y2 Y1 GRC
C RH W1W2 Standard
Y2 Y1 GRCRW1 OHeat Pump
STANDARD HVAC
SYSTEM TERMINAL
WIRING

8Copyright ©2015 Nortek Security & Control
Dual Transformer Systems
For HVAC systems that have separate heang and cooling systems, each with their own 24VAC
transformers, there will be an “R” wire from the heang system and an “R” wire from the cooling
system.
For dual transformer systems, connect the “C” wire from the cooling system to the thermostat’s “C”
terminal. DO NOT CONNECT THE “C” WIRE FROM THE HEATING SYSTEM.
Figure 7. Dual Transformer HVAC System Thermostat Terminal Connections
Connect the wires from the HVAC system to the corresponding terminals on the thermostat back
terminal block. Use the table below as a guideline for connecng the wires.
Wire Terminal
Y2 Connect to the Y2 terminal (2-stage systems only)
Y or Y1 Connect to the Y1 terminal
G Connect to the G terminal
COOL Rc Connect to RC terminal
C Connect to C terminal (Cooling System C Wire, NOT Heang System C Wire)
HEAT Rh Connect to RH terminal
W or W1 Connect to W1 terminal
W2 Connect to W2 terminal (2-stage system only)
IMPORTANT! FOR SEPARATE RC/RH SYSTEMS, THE INTERNAL RC=RH JUMPER MUST BE
CUT ON THE BACK OF THE THERMOSTAT’S PRINTED CIRCUIT BOARD— (See Figure 8).
Figure 8. Internal RC=RH Jumper
RC=RH JUMPER
CUT JUMPER FOR
DUAL TRANSFORMER
SYSTEMS ONLY
Y2 Y1 GRC CRH W1 W2
W
C
G
STANDARD
Y2 Y1 GRCRW1 OHEAT PUMP
(STICKER LABELED WIRES)
REFERENCE
STANDARD
TERMINALS
Rc Rh
HEATING SYSTEM R WIRE
COOLING SYSTEM R WIRE
Y2 W2
Y
OR
Y1
RR
W1
